Important
(In the UK Only)
The wires in this mains lead are coloured in accordance
with the following code:
As the colours of the wires in the mains lead of this
apparatus may not correspond with the coloured
markings identifying the terminals in your plug, proceed
as follows:
The wire which is coloured Green and Yellow must be
connected to the terminal in the plug which is marked
with the letter E or by the earth symbol( ) or coloured
Green or Green and Yellow.
The wire which is coloured Blue must be connected to
the terminal which is marked with the letter N or
coloured Black.
The wire which is coloured Brown must be connected to
the terminal which is marked with the letter L or
coloured Red.
If a 13 amp(BS 1363) plug is used, fit a 13 amp BS 1362
fuse.
GREEN AND YELLOW:EARTH
BLUE:NEUTRAL
BROWN:LIVE
This appliance must be earthed
2
