POP.C.P30., POP.C.P31.
E
B
D D
CA
1
Component
The grill -
Control panel -
Economy burner
1kW
Standard-output
burner
1,75kW
High-output
burner
3kW
1
The images shown in these instructions are for guidance only.
2
Table of contents en
You can find additional information and explanations online.
Scan the QR code on the title page.
Table of contentsTable of contents
1 Safety ........................................................................ 3
2 Preventing material damage .................................. 6
3 For your safety (only for ZA) .................................. 6
4 Environmental protection and saving energy ...... 7
5 Familiarising yourself with your appliance .......... 7
6 Accessories ............................................................. 8
7 Basic operation ....................................................... 8
8 Cookware ................................................................. 9
9 Recommended settings for cooking .................... 9
10 Cleaning and servicing ...................................... 10
11 Troubleshooting ................................................. 11
12 Customer Service ............................................... 12
13 Disposal ............................................................... 12
Safety 1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product
information safe for future reference or for
the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
The appliance can only be used safely if it is
correctly installed according to the safety in-
structions. The installer is responsible for en-
suring that the appliance works perfectly at its
installation location.
CAUTION‒Risk of injury!
This appliance is for cooking purposes only.
It shall not be used for other purposes, for
example room heating.
Only use this appliance:
¡ To prepare meals and drinks.
¡ Under supervision. Never leave the appli-
ance unattended when cooking for short
periods.
¡ In a private household and in a domestic en-
vironment.
¡ Up to an altitude of 2000m above sea level.
Do not use the appliance:
¡ On boats or in vehicles.
¡ as a room heater.
¡ with an external timer or a remote control.
¡ Outdoors.
Call the after-sales service if you want to con-
vert your appliance to a different type of gas.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
WARNING‒Risk of explosion!
Escaping gas may cause an explosion.
WHAT TO DO IF YOU SMELL GAS OR IF
THERE ARE FAULTS IN THE GAS INSTALLA-
TION
Immediately shut off the gas supply or close
the gas cylinder valve.
Immediately extinguish all naked flames and
cigarettes.
Do not operate any light switches or appli-
ance switches.
Do not pull any plugs out of any sockets.
Do not use any telephones or mobile
phones within the building.
3
en Safety
Open windows and ventilate the room.
Call the after sales service or the gas sup-
plier.
Escaping gas may cause an explosion.
Small amounts of gas can collect over a
longer period of time and ignite.
Close the safety valve for the gas supply
when the appliance is out of use for pro-
longed periods.
Escaping gas may cause an explosion.
If the liquefied gas bottle is not upright, lique-
fied propane/butane can enter the appliance.
Intense darting flames may therefore escape
from the burners. Components may become
damaged and start to leak over time so that
gas escapes uncontrollably.
Always use liquefied gas bottles in an up-
right position.
WARNING‒Risk of poisoning!
The use of a gas cooking appliance results in
the production of heat, moisture and products
of combustion in the room in which it is in-
stalled. Ensure that the kitchen is well ventil-
ated especially when the appliance is in use.
Prolonged intensive use of the appliance
may require additional ventilation, for ex-
ample the increasing of mechanical ventila-
tion where present, additional ventilation to
safely remove the products of combustion to
outside (external) air whilst also providing
room air changes with additional ventilation.
Consult a professional before installation of
the additional ventilation.
WARNING‒Risk of fire!
Leaving fat or oil cooking on an unattended
hob can be dangerous and may lead to fires.
Never leave hot oil or fat unattended.
Never attempt to extinguish a fire using wa-
ter; instead, switch off the appliance and
then cover with a lid or a fire blanket.
The appliance becomes very hot.
Never place flammable objects on the cook-
top or in its immediate vicinity.
Never store any objects on the cooktop.
The appliance will become hot.
Do not keep combustible objects or aerosol
cans in drawers directly underneath the hob.
Never store or use combustible materials
(e.g. spray cans or cleaning agents) under
the appliance or in its immediate vicinity.
Hob covers can cause accidents, for example
due to overheating, catching fire or materials
shattering.
Do not use hob covers.
When gas burners are in operation without any
cookware placed on them, they can build up a
lot of heat. The extractor hood above it may
become damaged or catch fire.
Only operate the gas burners with cookware
on them.
The appliance becomes very hot, fabrics and
other objects may ignite.
Keep fabrics (e.g. garments or curtains)
away from the flames.
Never reach over the flames.
Do not place combustible objects (e.g. tea
towels or newspapers) on, next to or behind
the appliance.
Escaping gas may ignite.
If the burner does not ignite after
15seconds, turn the control knob to the
"Off" position and open the door or window
in the room. Do not attempt to re-ignite the
burner for at least one minute.
In the event of the burner flames being acci-
dentally extinguished, turn off the burner
control. Do not attempt to re-ignite the
burner for at least one minute.
Food may catch fire.
The cooking process must be monitored. A
short process must be monitored continu-
ously.
WARNING‒Risk of burns!
The accessible parts can become hot during
operation.
Small children should be kept away from the
appliance.
Hob guards may cause accidents.
Never use hob guards.
Empty cookware becomes extremely hot when
set on gas burners that are operating.
Never heat up empty cookware.
The appliance becomes hot during operation.
Allow the appliance to cool down before
cleaning.
WARNING‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be car-
ried out by trained specialist staff.
Only use genuine spare parts when repairing
the appliance.
If the power cord of this appliance is dam-
aged, it must be replaced by the manufac-
4
Safety en
turer, the manufacturer's Customer Service
or a similarly qualified person in order to pre-
vent any risk.
If the appliance or the power cord is damaged,
this is dangerous.
Never operate a damaged appliance.
Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
If the appliance or the power cord is dam-
aged, immediately unplug the power cord or
switch off the fuse in the fuse box and turn
off the gas supply.
Call customer service.
Page12
An ingress of moisture can cause an electric
shock.
Do not use steam- or high-pressure cleaners
to clean the appliance.
The insulation on cables of electrical appli-
ances may melt if it touches hot parts of the
appliance.
Never bring electrical appliance cables into
contact with hot parts of the appliance.
WARNING‒Risk of injury!
Faults or damage to the appliance and repairs
that have not been carried out correctly are
dangerous.
Never switch on the appliance if there is a
fault with it.
If the appliance is faulty, unplug the mains
plug or switch off the fuse in the fuse box.
Shut off the gas supply and call the after
sales service.
Always have repairs carried out to the appli-
ance and damaged gas lines replaced by
trained, specialist personnel.
Cracks or fractures in the glass surface are
dangerous.
All of the burners and each electrical heating
element switch off immediately and discon-
nect the appliance from the power supply.
Shut off the gas supply.
Do not touch the surface of the appliance
Do not use the appliance.
Call the customer service.
Strong temperature fluctuations may cause the
glass to break.
When using the hob, avoid draughts and
spilling cold liquids.
Cookware that is not the right size, or that is
damaged or incorrectly positioned may cause
serious injuries.
See the notes on cookware.
When switching on the burner, sparks are gen-
erated in the ignition plugs.
Never touch the ignition plugs while the
burner is being lit.
If a control knob is too stiff to turn or it is
loose, it must no longer be used.
Contact our after-sales service immediately
to have the control knob repaired or re-
placed.
An appliance with a cracked or broken surface
can cause cuts.
Do not use the appliance if it has a cracked
or broken surface.
WARNING‒Danger: Magnetism!
Caution: Magnetic field
Attention for persons with pacemakers
Permanent magnets are integrated in the con-
trol element bases and the control elements.
Magnets may affect electronic implants, e.g.
heart pacemakers or insulin pumps.
Persons with electronic implants must stand
at least 10cm away from the magnetic con-
trol element bases and control elements.
Never carry the control element base and
the control elements on your body.
WARNING‒Risk of suffocation!
Children may put packaging material over their
heads or wrap themselves up in it and suffoc-
ate.
Keep packaging material away from chil-
dren.
Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
Keep small parts away from children.
Do not let children play with small parts.
5
en Preventing material damage
Preventing material damage2 Preventing material damage
ATTENTION
Heat can cause damage to adjacent appliances or kit-
chen units.
If the appliance is in operation for an extended period,
heat and moisture will be generated.
Open a window or switch on an extractor hood lead-
ing to the outside.
A build-up of heat may damage the appliance.
Do not use two burners or heat sources to heat one
single item of cookware.
Do not use griddle plates, clay pots, etc. for a long
time at full power.
A build-up of heat may damage the controls.
Do not use a large item of cookware on burners that
are close to the control knobs.
If a control knob is in the wrong position, this could lead
to malfunctions.
Always turn the control knob to the "Off" position
when the appliance is not being used.
Handling the cookware roughly may damage the sur-
face of the appliance.
Handle the cookware on the hob carefully.
Do not place any heavy objects on the hob.
Moving the cookware may scratch the glass.
Lift the cookware when moving it.
Damage may occur if hard or pointed objects fall on the
hob.
Do not let hard or pointed objects fall onto the hob.
Do not bump into any of the edges of the hob.
Salt, sugar or sand that may fall from the vegetables will
scratch the glass.
Do not use the hob as a work surface or storage
space.
Melted sugar or food with a high sugar content may
damage the glass.
Remove boiled-over food immediately with a glass
scraper.
For your safety (only for ZA)3 For your safety (only for ZA)
This appliance is adjusted to operate on LPG only.
Do not tamper or modify the appliance.
Burn back
Fire in burner tube or chamber.
In the event of a burn-back, where the flame burns
back to the jet, immediately turn the gas supply off at
the control valve on the panel.
After ensuring the flame is extinguished, wait for 1
minute and re-light the appliance in the normal man-
ner.
Should the appliance again burn back, close the con-
trol valve and call a service technician. Do not use
the appliance again until the service technician has
declared that it is safe to do so.
Gas-pressure regulator
This appliance requires an operating pressure of
2,8kPa at the appliance.
A suitable LPG regulator that complies with the re-
quirements of SANS1237 must be installed.
Note: This appliance may only be installed by a re-
gistered SAQCC Gas installer.
Important information for the user:
All registered installers are issued with a card carry-
ing their registration number. Ask to be shown the
card before allowing the installation work to com-
mence and make a note of the installer registration
number.
Upon completion of the installation, the installer is re-
quired to explain the operational details of the appli-
ance together with the safety instructions.
You will be asked to sign acceptance of the installa-
tion and be provided with a completion certificate.
You should only sign for acceptance of the installa-
tion when the installation is completed to your satis-
faction.
Note that your invoice is required in the event that
you wish make a guarantee claim.
Important information for the installer:
This appliance may only be installed by a gas installer
registered with the South African qualification and cer-
tification committee (SAQCC).
The appliance must be installed in accordance with
the requirements of SANS10087-1 for use with LPG,
SANS827 for use with NG and any fire department
regulations and/or local bylaws applicable to the
area. If in doubt, check with the relevant authority be-
fore undertaking the installation.
Upon completion of the installation you are required
to fully explain and demonstrate to the user the oper-
ational details and safety practices applicable to the
appliance and the installation.
Caution
The primary air intake adjuster is set at the factory for
the set gas and must not be reset or tampered with, this
must only be set by an authorized BSH technician. No
modifications to the primary air is allowed to be done.
Please check the rating label for the type of gas to be
used.
6
Environmental protection and saving energy en
Environmental protection and saving energy4 Environmental protection and saving energy
4.1 Saving energy
If you follow these instructions, your appliance will use
less energy.
Choose a burner roughly the same size as your pan.
Centre the cookware on the hob.
Tip: Cookware manufacturers often give the upper dia-
meter of the saucepan. It is often larger than the base
diameter.
Unsuitable cookware or incompletely covered cook-
ing zones consume a lot of energy.
Cover saucepans with suitable lids.
Cooking without a lid consumes considerably more
energy.
Lift lids as infrequently as possible.
When you lift the lid, a lot of energy escapes.
Using a glass lid
You can see into the pan through a glass lid without
having to lift it.
Use cookware that is suitable for the quantity of food.
Large items of cookware containing little food need
more energy to heat up.
Cook with only a little water.
The more water there is in the cookware, the more
energy that is required to heat it up.
Turn down to a lower power level early on.
If you use an ongoing power level that is too high,
you will waste energy.
4.2 Disposing of packaging
The packaging materials are environmentally compatible
and can be recycled.
Sort the individual components by type and dispose
of them separately.
Familiarising yourself with your appliance5 Familiarising yourself with your appliance
5.1 Control knob
Use the control knobs to set the flame size increment-
ally.
Burner assigned to the control knob.
Burner off.
Highest power setting and electric ignition of
the burner.
Lowest power setting.
Removable control knob
You can remove the appliance's control knob.
The control knob is magnetic and connected to the
control knob base .
Remove the control knob upward.
Note: Never remove the control knob base and its
holder . Only Customer Service can reinsert the con-
trol knob base and its holder.
To put the control knob back on, press it on at its ori-
ginal position.
Tip: The magnets can interfere with magnetic data carri-
ers, TV sets and displays. Keep magnetic data carriers,
e.g., credit cards or other cards with magnetic strips, TV
sets and monitors away from the device's control knob.
5.2 Burner
You can find an overview of the parts of the burner here.
7
en Accessories
1
2
3
4
Burner cover
Burner cup
Thermocouple for the flame monitoring
Ignition plug
5.3 Pan supports
Insert the pan supports correctly.
→Page2
Place the cookware correctly on the pan supports.
Never place the cookware directly on the burner.
Always carefully remove the pan supports. When mov-
ing a pan support, the pan supports next to it may also
move.
Tip: You can remove the metal residue that remains
when some items of cookware are moved on the pan
support by cleaning it properly.
"Cleaning and servicing", Page10
Accessories6 Accessories
You can buy accessories from the after-sales service, from specialist retailers or online. Only use original accessor-
ies, as these have been specifically designed for your appliance.
Accessories vary from one appliance to another. When purchasing accessories, always quote the exact product
number (E no.) of your appliance.
Page12
You can find out which accessories are available for your appliance in our catalogue, in the online shop or from our
after-sales service.
www.bosch-home.com
Accessories Use
Additional espresso maker
grid
Only use on the burner with the lowest
power setting.
Use with cookware with a diameter smaller
than 12.
Basic operation7 Basic operation
7.1 Igniting a gas burner
The hob has automatic ignition of the burners.
WARNING‒‒Risk of fire!
Escaping gas may ignite.
If the burner does not ignite after 15seconds, turn
the control knob to the "Off" position and open the
door or window in the room. Do not attempt to re-ig-
nite the burner for at least one minute.
In the event of the burner flames being accidentally
extinguished, turn off the burner control. Do not at-
tempt to re-ignite the burner for at least one minute.
1.
Press the control knob for the selected burner and
turn it anti-clockwise to the highest level.
Keep the control knob pressed in.
For all of the burners, sparks are generated and the
flame ignites in the selected burner.
2.
Wait a few seconds and release the control knob.
"Safety system", Page8
3.
Turn the control knob to the required position.
4.
If the burner does not ignite, turn the control knob to
the off position and repeat the steps described
above. This time, hold the control knob down for
longer (up to 10 seconds).
Note
Take the following information into account to ensure
that the appliance works correctly:
The burner parts
Page7
and the pan supports
Page8
must be inserted correctly.
Do not swap the burner caps around.
The burner holes and grooves must be clean to en-
sure a correct flame.
"Cleaning recommendations", Page10
7.2 Safety system
The safety system (thermocouple) prevents the flow of
gas if the flames accidentally go out. To ignite the
burner, you must activate the system that enables the
gas flow.
8
Cookware en
1.
Ignite the burner without releasing the control knob.
The flame ignites.
2.
Press and hold the control knob for a further four
seconds.
7.3 Igniting a gas burner manually
In the event of a power cut, you can light the burners
manually.
1.
Press the control knob for the selected burner and
turn it anti-clockwise to the highest level.
2.
Hold a lighter or a flame (lighter, match, etc.) against
the burner.
7.4 Switching off a burner
Turn the control knob clockwise to .
7.5 Normal behaviour during operation
This behaviour is normal for the appliance:
Slight hissing noise from the ignited burner.
Release of odours when using the appliance for the
first time. These odours disappear after a short time.
An orange flame is normal. This is due to dust in the
environment, spilled liquids, etc.
Popping noise a few seconds after the burner is
switched off. This is caused by switching on the
safety system.
"Safety system", Page8
Cookware8 Cookware
This information has been provided to help you save en-
ergy and avoid damaging your cookware.
8.1 Suitable cookware
Only use cookware with a suitable diameter. The cook-
ware must not protrude over the edge of the hob.
Never use small cookware on large burners. The flames
must not touch the sides of the cookware.
Burner Minimum dia-
meter of the
cookware base
(cm)
Maximum dia-
meter of the
cookware base
(cm)
High output
burner
20 26
Standard output
burner
14 22
Economy burner 12 20
Only use cookware with a concave base on the multi-
crown burner.
The hob must have a multi-crown burner and addi-
tional wok grid.
The additional wok grid must be correctly inserted.
"Accessories", Page8
8.2 Using cookware
The selection and positioning of the cookware affects
the safety and energy efficiency of your appliance.
"Saving energy", Page7
WARNING‒‒Risk of fire!
Flammable objects may ignite.
Maintain a distance of at least 50mm between the
cookware and flammable objects.
Do not use deformed
cookware. Only use cook-
ware with a thick, flat
base.
Deformed cookware is not
stable on the hob and may
tip over.
Place the cookware right
in the centre of the burner.
The cookware may tip over
if it is not placed in the
centre of the burner.
Place the cookware cor-
rectly on the pan supports.
The cookware may tip over
if you place it directly on
the burner.
Recommended settings for cooking9 Recommended settings for cooking
The cooking times and power levels may vary depending on the type of food, its weight and quality, on the type of
gas used, and on the material from which the cookware is made.
Burner Highest/high heat setting Medium power level Lowest power level
High-output burner Escalope, steaks, tortilla,
deep-fried
Rice, bechamel sauce, rag-
out
Steaming: Fish, vegetables
Standard-output burner Steamed potatoes, fresh ve-
getables, stews, pasta
Warming up ready-to-eat
meals and keeping them
warm, and cooking fine
stews
Warming up ready-to-eat
meals and keeping them
warm, and cooking fine
stews
Economy burner Cooking: Stews, rice pud-
ding, caramel
Defrosting and slow cook-
ing: Pulses, fruit, frozen
products
Preparing/melting: Butter,
chocolate, gelatine
9
en Cleaning and servicing
Cleaning and servicing10 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
10.1 Cleaning product
You can obtain suitable cleaning products from after-
sales service or the online shop
www.bosch-home.com
.
ATTENTION
Unsuitable cleaning products may damage the surfaces
of the appliance.
Do not use harsh or abrasive detergents.
Do not use any industrial soap or cleaning agents.
Do not use steel wool or scouring sponges.
Do not use a knife or sharp objects to remove dried-
on food remnants from the hob.
Do not use a knife or sharp objects to clean the con-
nection between the glass and the burner panels, the
metal frames or the glass/aluminium plates for clean-
ing.
Do not use steam-cleaning appliances.
10.2 Cleaning recommendations
Clean all parts of the appliance after each use.
Note: Read the information on the cleaning agents.
"Cleaning product", Page10
General information:
Allow the appliance to cool down before cleaning.
After cleaning, dry all parts of the appliance completely using a soft cloth. Surface damage may occur if there are
still drops of water or residual moisture at the beginning of the cooking process.
Reattach the parts of the appliance properly, making sure that the surfaces are not damaged.
"Familiarising yourself with your appliance", Page7
Part Recommended cleaning method Notes
Appliance surface Clean using a sponge and soapy
water.
Wipe up spilled liquids immediately. This prevents food
residues from burning.
The control elements can be removed for easier clean-
ing. Never remove the control element base or its
holder.
"Removable control knob", Page7
After cleaning, check the correct position of the control
element bases and holders.
Control elements Clean using a damp sponge cloth
and hot soapy water.
The control elements can be removed for easier clean-
ing. Never remove the plinth for the control elements or
its holder.
"Removable control knob", Page7
Do not clean it in the dishwasher or immerse it in water,
as this may damage it.
Do not use abrasive or corrosive products, such as cit-
ric acid, vinegar, aggressive cleaning agents or glass
ceramic cleaners.
Pan supports Scrub with a non-metallic brush
or a non-scratching scouring
sponge and soapy water.
Do not clean in the dishwasher.
Carefully remove the pan supports.
Carefully clean the area around the rubber pads. If the
rubber pads come loose, the pan support may scratch
the hob.
After cleaning, dry the pan supports completely using a
soft cloth. Damage to enamel may occur if there are
still drops of water or residual moisture at the beginning
of the cooking process.
Burner
Page7
Scrub with a non-metallic brush
or a non-scratching scouring
sponge and soapy water.
Do not clean in the dishwasher.
Do not mix up the burner lids.
Gently move the burner lid back and forth until it locks
into the projections on the burner.
Thermocouples/igni-
tion plugs
Clean using a small non-metallic
brush.
Clean carefully. Thermocouples and ignition plugs are
sensitive.
Do not moisten the thermocouple and the ignition plug.
If there is excessive moisture, the burner may not light.
10
Troubleshooting en
Troubleshooting11 Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshooting information before contacting after-
sales service. This will avoid unnecessary costs.
WARNING‒‒Risk of injury!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
If the appliance is defective, call Customer Service.
"Customer Service", Page12
WARNING‒‒Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord of this appliance is damaged, it must be replaced by the manufacturer, the manufacturer's Cus-
tomer Service or a similarly qualified person in order to prevent any risk.
11.1 Malfunctions
Fault Cause and troubleshooting
The general electrical operation is
impaired.
The circuit breaker is faulty.
Check the circuit breaker in the fuse box.
The circuit breaker or one of the residual-current circuit breakers has been
triggered.
In the fuse box, check whether the circuit breaker or one of the residual-current
circuit breakers has been triggered.
The mains plug of the power cord is not plugged in.
Connect the appliance to the power supply.
There has been a power cut.
Check whether the lighting in your room or other appliances are working.
Automatic ignition is not working. Food remnants or dirt are located between the ignition plug and the burner.
Clean the space between the ignition plugs and burners.
Burner parts are wet.
Carefully dry the burner parts.
The burner parts are positioned incorrectly.
Correctly position the burner parts.
The appliance is not earthed or has not been connected correctly, or the earth
cable is damaged.
Contact an electrician.
The burner flame is not uniform. The burner parts are positioned incorrectly.
Correctly position the burner parts.
Openings on the burner are soiled.
Clean and dry the openings on the burner.
Burner flames are large or un-
stable.
The gas reaches the appliance at excessive pressure.
1.
Switch off the appliance.
2.
Contact an approved installer and have them check the regulator of the gas
cylinder or liquid gas tank.
Tip: To prevent damage due to excessive pressure, you can install an overpres-
sure safety device that limits or cuts off the gas supply if the regulator of the gas
cylinder or liquid gas tank fails.
The gas does not appear to be
flowing normally or there is no
gas being produced at all.
The gas supply has been shut off by the intermediate valves.
Open the intermediate valves.
There is a smell of gas in the kit-
chen.
The control knob is open.
Close the control knob.
The gas pipe to the appliance is leaking.
1.
Close the main gas tap.
2.
Ventilate the room.
11
en Customer Service
Fault Cause and troubleshooting
There is a smell of gas in the kit-
chen.
3.
Immediately call an authorised installer, who can inspect the gas system and
issue an installation certificate.
4.
Do not use the appliance until you are sure that gas is not leaking from the in-
stallation or the appliance.
The burner switches off as soon
as you release the control knob.
Control knob not pressed down long enough.
1.
Keep the control knob pressed down for a few seconds after ignition.
2.
Press the control knob down firmly.
Openings on the burner are soiled.
Clean and dry the openings on the burner.
Customer Service12 Customer Service
Detailed information about the warranty period and the
warranty conditions in your country is available via the
QR code on the enclosed document on service con-
tacts and warranty conditions, from our customer ser-
vice or on our website.
You can find the contact details for our customer ser-
vice via the QR code on the enclosed document on ser-
vice contacts and warranty conditions or on our website.
12.1 Product number (E-Nr.) and production
number (FD)
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number
(FD), which you can find on the appliance's rating plate.
Make a note of your appliance's details and the Cus-
tomer Service telephone number to find them again
quickly.
Disposal13 Disposal
13.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
1.
Unplug the appliance from the mains.
2.
Cut through the power cord.
3.
Close the main gas tap.
4.
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are avail-
able from your specialist dealer or local authority.
This appliance is labelled in accordance
with European Directive 2012/19/EU
concerning used electrical and elec-
tronic appliances (waste electrical and
electronic equipment - WEEE).
The guideline determines the framework
for the return and recycling of used ap-
pliances as applicable throughout the
EU.
12
Many thanks for choosing a Bosch home
appliance!
Register your new appliance now on MyBosch and benefit directly from:
• Expert advice and tips to make the most of your appliance
• Options for warranty extension
• Discounts on spare parts and accessories
• Digital information for use and all appliance data to hand
• Easy access to Bosch Home Appliance Service
Simple to register, free of charge – including on mobile devices:
www.bosch-home.com/welcome
Need some help?
You can find it here.
Expert advice on your Bosch home appliances, help with problems or repairs by professionals from
Bosch.
Discover all the different ways Bosch can assist you:
www.bosch-home.com/service
The contact details of all countries are listed in the attached service directory.
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
*9001918380*
9001918380 (050919)
en
