Panasonic SC-HC2020EBK Micro Hifi System Google Chromecast User Manual

TQBJ2081-2

Operating Instructions

Compact Stereo System

Model No. SC-HC2020

“EB” indicates the United Kingdom model.

Thank you for purchasing this product.

For optimum performance and safety, please read these instructions carefully.

Please keep this manual for future reference.

The installation instructions are on page 2, 3 and 26, 27, 28.

Please read these instructions carefully before installing.

HC2020EB.GN_TQBJ2081-2_En.fm Page 1 Friday, August 5, 2022 5:05 PM

TQBJ2081

Caution for AC mains lead

(For the AC mains plug of three pins)

For your safety, please read the following text carefully.

This appliance is supplied with a moulded three pin mains

plug for your safety and convenience.

A 5-ampere fuse is fitted in this plug.

Should the fuse need to be replaced please ensure that

the replacement fuse has a rating of 5-ampere and that it

is approved by ASTA or BSI to BS1362.

Check for the ASTA mark or the BSI mark on the

body of the fuse.

If the plug contains a removable fuse cover you must

ensure that it is refitted when the fuse is replaced.

If you lose the fuse cover the plug must not be used until a

replacement cover is obtained.

A replacement fuse cover can be purchased from your

local dealer.

Before use

Remove the connector cover.

How to replace the fuse

The location of the fuse differ according to the type of AC

mains plug (figures A and B). Confirm the AC mains plug

fitted and follow the instructions below.

Illustrations may differ from actual AC mains plug.

1. Open the fuse cover with a screwdriver.

2. Replace the fuse and close or attach the fuse cover.

Safety precautions

WARNING!

Unit

• To reduce the risk of fire, electric shock or product

damage,

– Do not expose this unit to rain, moisture, dripping or

splashing.

– Do not place objects filled with liquids, such as vases,

on this unit.

– Use the recommended accessories.

– Do not remove covers.

– Do not repair this unit by yourself. Refer servicing to

qualified service personnel.

– Do not let metal objects fall inside this unit.

– Do not place heavy items on this unit.

• To prevent injury, this apparatus must be securely

attached to the wall in accordance with the installation

instructions.

AC mains lead

• To reduce the risk of fire, electric shock or product

damage,

– Ensure that the power supply voltage corresponds to

the voltage printed on this unit.

– Insert the mains plug fully into the socket outlet.

– Do not pull, bend, or place heavy items on the lead.

– Do not handle the plug with wet hands.

– Hold onto the mains plug body when disconnecting

the plug.

– Do not use a damaged mains plug or socket outlet.

• The mains plug is the disconnecting device. Install this

unit so that the mains plug can be unplugged from the

socket outlet immediately.

CAUTION!

Unit

• This unit utilizes a laser. Use of controls or adjustments

or performance of procedures other than those

specified herein may result in hazardous radiation

exposure.

• Do not place sources of naked flames, such as lighted

candles, on this unit.

• This unit may receive radio interference caused by

mobile telephones during use. If such interference

occurs, please increase separation between this unit

and the mobile telephone.

• This unit is intended for use in moderate climates.

Placement

• Place this unit on an even surface.

• To reduce the risk of fire, electric shock or product

damage,

– Do not install or place this unit in a bookcase, built-in

cabinet or in another confined space. Ensure this unit

is well ventilated.

– Do not obstruct this unit’s ventilation openings with

newspapers, tablecloths, curtains, and similar items.

– Do not expose this unit to direct sunlight, high

temperatures, high humidity, and excessive vibration.

Figure A Figure B

Fuse cover

Fuse (5 ampere)

HC2020EB.GN_TQBJ2081-2_En.fm Page 2 Friday, August 5, 2022 5:05 PM

TQBJ2081

Battery

• Danger of explosion if battery is incorrectly replaced.

Replace only with the type recommended by the

manufacturer.

• When disposing of the batteries, please contact your

local authorities or dealer and ask for the correct

method of disposal.

• Do not heat or expose to flame.

• Do not leave the battery(ies) in a car exposed to direct

sunlight for a long period of time with doors and

windows closed.

• Do not break open or short-circuit the battery.

• Do not charge the alkaline or manganese battery.

• Do not use the battery if the cover has peeled off.

• Remove the battery if you do not use the remote control

for a long period of time. Keep in a cool, dark area.

Table of contents

Caution for AC mains lead. . . . . . . . . . . . . . . . . . . . . . . . 2

Safety precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Supplied accessories. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Making the connections. . . . . . . . . . . . . . . . . . . . . . . . . . 4

Preparing the remote control . . . . . . . . . . . . . . . . . . . . . . 4

Overview of controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Network settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Streaming music over the network. . . . . . . . . . . . . . . . . . 8

Preparing the media . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Media playback . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Radio . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

DAB/DAB+. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Clock and timers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Sound effects. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16

External music device . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Firmware updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

Others . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Sales and Support Information . . . . . . . . . . . . . . . . . . . 25

Attaching the unit to a wall (optional). . . . . . . . . . . . . . . 26

References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28

Supplied accessories

Check and identify the supplied accessories.

Product numbers correct as of March 2018. These may

be subject to change.

 1 AC mains lead

For the United Kingdom and Ireland

(K2CT2YY00127)

For Australia and New Zealand

(K2CJ2YY00116)

 1 DAB indoor antenna

(N1CYYYY00022)

 1 Remote control

(N2QAYB001204)

 1 Remote control battery

The symbols on this product (including the accessories)

represent the following:

(Back of product)

Wall mount kit

 1 Safety holder

(TPBDA004)

 2 Wall mount brackets

(RSC1262-1)

 1 Wall mounting sheet

• Use this sheet for wall

mounting. (~26)

Class II equipment (The construction of the

product is double-insulated.)

! ON

` Standby

HC2020EB.GN_TQBJ2081-2_En.fm Page 3 Friday, August 5, 2022 5:05 PM

TQBJ2081

Making the connections

Connect the AC mains lead only after all the other

connections have been made.

1 Connect the DAB indoor antenna.

This system can receive DAB/DAB+ and FM stations

with the DAB antenna.

Rotate the antenna at to improve reception.

Note:

• Do not use any other DAB antenna except the supplied one.

• Do not mount the DAB antenna on metal objects such as

water pipes or any metal parts of the building.

2 Connect the AC mains lead.

Do not use any other AC mains lead except the

supplied one.

Conserving power

The system consumes a small amount of power

(~24) even when it is in standby mode. Disconnect

the power supply if you do not use the system.

Some settings will be lost after you disconnect the

system. You have to set them again.

Note:

• These speakers do not have magnetic shielding. Do not put

them near TVs, PCs or other equipment easily influenced by

magnetism.

• Tape the antenna to a wall with the least amount of

interference.

• Use an outdoor antenna (not supplied) if reception is poor.

Preparing the remote control

Use alkaline or manganese battery.

Install the battery so that the poles (+ and –) align with

those in the remote control.

(For the AC mains plug of three pins)

READ THE “Caution for AC mains lead” BEFORE

CONNECTION.

Adhesive tape

(not supplied)

Be sure to

tighten the nut

fully.

To household

mains socket

HC2020EB.GN_TQBJ2081-2_En.fm Page 4 Friday, August 5, 2022 5:05 PM

TQBJ2081

Overview of controls

Do the procedures with the remote control. You can also use the buttons on the unit if they are the same.

A Standby/on switch [`], [1]

Press to switch the unit from on to standby mode or

vice versa. In standby mode, the unit is still consuming

a small amount of power.

B Store or select favourite radio stations

(~9, 13, 14)

C Numeric buttons

To select a 2-digit number

Example: 16: [ 10]=[1]=[6]

D Delete a programmed track

E Select the audio source

On the remote control:

Press the corresponding button to select the source.

[NET/ ]: NETWORK BLUETOOTH

[CD/USB, AUX]:

[RADIO]: DAB+ FM

On the unit:

Select “BLUETOOTH” as the audio source

To start Bluetooth

pairing or disconnect a Bluetooth

device, press and hold the corresponding button.

F Basic playback control

G Select the sound effects

H View the play menu

I View the content information

J Set the clock and timers

K Open or close the sliding door

L Set the programme play

M Adjust the volume level

N Mute the sound

To cancel, press the button again.

“MUTE” is also cancelled when you adjust the volume

or when you switch off the system.

O Enter setup menu

P Select the functions in the radio menu

Q Select or confirm the option

R Dim the display panel and indicator

Press again to cancel.

S USB port ( )

T AUX IN terminal (~17)

U Sliding door

V Display panel

W Remote control sensor

Distance: Within approximately 7 m

Angle: Approximately 20° up and down, 30° left

and right

X Network indicator

AUX

NET/

Top view

HC2020EB.GN_TQBJ2081-2_En.fm Page 5 Friday, August 5, 2022 5:05 PM

TQBJ2081

Network settings

You can stream online music service or music stored on

your devices to this system. To use these features, this

system must join the same internet-connected network as

the compatible device.

• Please update the system’s firmware after the network

settings are complete. (~18)

Choose a network setting method from the following.

Note:

The setting will be cancelled after the set time limit. Redo the

setup.

Wireless LAN connection

This system has a built-in Wi-Fi

and can be connected to

a wireless router.

Preparation

• Place this system as close to the wireless router as

possible.

• Do not connect a LAN cable. Doing so will disable the

Wi-Fi

function.

• Make sure your smartphone or tablet is connected to

the same network as this system.

Method 1:

Using the “Google Home” app

1 Press [NET/ ] repeatedly to select “NETWORK”.

2 Download the “Google Home” app (free of charge)

onto your smartphone or tablet.

• To download the “Google Home” app, visit:

https://www.google.com/cast/setup/

3 Start the app and follow the on-screen

instructions.

4 Check that the connection has completed.

The network indicator lights up.

– If connection failed, the network indicator blinks. Do

the setup again.

Note:

• “Panasonic HC2020- ” is shown if the device name is

not set.

(“

” represents a character that is unique to each set.)

• You can check your network information (SSID, MAC

address and IP address) from the “Google Home” app or

“Panasonic Music Control” app. (

~8)

• Certain on-screen display items, etc. of the “Google Home”

app may not apply to this system.

• Availability and performance of certain features, services

and applications are device- and network-dependent and

may not be available in all countries/regions; subscription(s)

may be required, and additional terms, conditions and/or

changes may apply.

Wireless LAN connection

Method 1: Using the “Google Home” app

(Z right)

You can establish the wireless network settings with

the “Google Home” app (free of charge).

Wired LAN connection

Method 2: Using a LAN cable (Z 7)

You can establish a stable connection to the network

with a LAN cable.

HC2020EB.GN_TQBJ2081-2_En.fm Page 6 Friday, August 5, 2022 5:05 PM

TQBJ2081

Wired LAN connection

Method 2:

Using a LAN cable

1 Disconnect the AC mains lead.

2 Connect the unit to a broadband router, etc. using

a LAN cable.

3 Connect the AC mains lead to the unit and switch

on the system.

When the connection is established, the network

indicator lights up.

Note:

• Use category 5 or above straight LAN cables (STP) when

connecting to peripheral devices.

• The LAN cable must be connected or disconnected while

the AC mains lead is disconnected.

• Inserting any cable other than a LAN cable in the LAN port

can damage the system.

• If the LAN cable is disconnected, redo the network settings.

• When a LAN cable is connected, the Wi-Fi function will be

disabled.

LAN cable

(not supplied)

Broadband router, etc.

Example:

HC2020EB.GN_TQBJ2081-2_En.fm Page 7 Friday, August 5, 2022 5:05 PM

TQBJ2081

Streaming music over the

network

You can stream online music services or music files from

your smartphone/tablet to this system.

Streaming online music

This system is compatible with Chromecast-enabled

apps. For the list of Chromecast-enabled apps, visit

g.co/cast/apps

Preparation

• Complete the network settings. (~6)

• Make sure that the network is connected to the Internet.

1 Connect the device by Wi-Fi to the same network

as that of this system.

2 Install the Chromecast-enabled app to the mobile

device.

3 Start the Chromecast-enabled app, tap the cast

icon “ ”, and select this system or group which

this system is included.

Use the “Google Home” app to group speakers when

streaming online music to other compatible speakers.

4 Select and play the desired music on your

Chromecast-enabled app.

“CASTING” is shown.

Note:

• “Panasonic HC2020- ” is shown if the device name is

not set.

(“ ” represents a character that is unique to each set.)

• Not all music services are available in all countries/regions.

Registration/subscription required. Fees may apply.

Services subject to change. For details, visit the individual

music service’s website.

Streaming music on network devices

You can stream music files from the device on your

network to this system’s speakers by using the

“Panasonic Music Control” app (free of charge).

Preparation

• Complete the network settings.

(~6)

• Connect the following devices to the same network as

this system.

– Device with “Panasonic Music Control” app installed.

– Device containing music.

1 Download “Panasonic Music Control” app (free of

charge) on your smartphone/tablet.

•:

Google Play

• : App Store

2 Start the app.

Always use the latest version of the app.

3 Select this system as the output speaker.

4 Select a music source.

5 Select a music file.

• If playback music from your device or Deezer or

TIDAL, “NETWORK” is shown.

• If playback from Radio, “NET RADIO” is shown.

• If playback from Podcasts, “PODCAST” is shown.

█

Enhancing the sound

When using the “Panasonic Music Control” app, you can

change the sound functions as below from the app

settings.

• Equalizer

• D.Bass (powerful bass effect)

• Surround

• Clear Mode Dialog

• Wall Mount

Android

iOS

HC2020EB.GN_TQBJ2081-2_En.fm Page 8 Friday, August 5, 2022 5:05 PM

TQBJ2081

Note:

• “Panasonic HC2020- ” is shown if the device name is

not set.

(“ ” represents a character that is unique to each set.)

• When playing back music from the DLNA server (PC with

Windows 7 or later installed, smartphone, Network Attached

Storage (NAS) device, etc.), add the contents and folder to

the libraries of the Windows Media

Player, the smartphone,

or the NAS device, etc.

• Playlist of Windows Media

Player can play back only the

contents that are stored in the libraries.

• About supported format, refer to “Specifications”. (~24)

• Depending on the contents and the connected equipment,

playback may not be performed properly.

• Ensure to stop playback on your device before switching it

off.

Storing stations under [FAVOURITE]

[1] to [5]

(Select Radio and Podcasts from

“Panasonic Music Control” app menu)

You can store up to 5 stations under [FAVOURITE] [1] to

[5].

• A station previously stored is overwritten when another

station is stored under the same [FAVOURITE] [1] to

[5].

Preparation

• Make sure that the network is connected to the Internet.

• Connect a device with the “Panasonic Music Control”

app installed to the same network as this system.

1 Start the “Panasonic Music Control” app and

select Radio and Podcasts to playback.

Always use the latest version of the app.

2 Press and hold one of [1] to [5] until “P ” is

shown.

(“ ” represents a number.)

█

Listening to a stored station

Press one of [1] to [5].

Note:

• If the selected preset channel has not been preset, “NO

PRESET” is shown.

• This service may be discontinued without notice.

• Not all music services are available in all countries/regions.

Registration/subscription required. Fees may apply.

Services subject to change. For details, visit the individual

music service’s website.

The operations and on-screen display items, etc. of

the “Panasonic Music Control” app are subject to

change.

For the latest information, visit

http://panasonic.jp/support/global/cs/audio/app/

(This site is in English only.)

Important notice:

Before you dispose or transfer this system to a third

party, log out your TIDAL/Deezer account to prevent

unauthorized use of your account.

You can also select the preset station using the

“Panasonic Music Control” app. For details on the app,

refer to the site below.

http://panasonic.jp/support/global/cs/audio/app/

(This site is in English only.)

HC2020EB.GN_TQBJ2081-2_En.fm Page 9 Friday, August 5, 2022 5:05 PM

TQBJ2081

Preparing the media

Disc

1 Press [CD/USB, AUX] repeatedly to select “CD”.

2 Press [CD x] (unit: [x]) to open the sliding door.

Put in a disc with the label facing towards you.

3 Press [CD x] (unit: [x]) again to close the sliding

door.

Keep fingers away from the sliding door when it is

closing.

USB

Press [CD/USB, AUX] repeatedly to select “USB”.

Note:

Do not use a USB extension cable. The system cannot

recognise USB device connected through a cable.

Bluetooth

You can connect and play an audio device wirelessly

through Bluetooth

Preparation

• Switch on the unit.

• Switch on the Bluetooth

feature of the device and put

the device near the system.

• Read the operating instructions of the device for details.

█

Pairing a device

Preparation

If this system is connected to a Bluetooth

device,

disconnect it. (~11)

Press [NET/ ] repeatedly to select “BLUETOOTH”.

If “PAIRING” is shown, continue with step 3.

2 Press [PLAY MENU] to select “PAIRING”.

Or press and hold [SELECTOR/ – PAIRING] on the

unit until “PAIRING” is shown.

3 Select this system from the Bluetooth

menu of

the device.

If prompted for a passkey, input “0000”.

The device connects with this system automatically

after pairing is complete.

The MAC address (example: 6C:5A:B5:B3:1D:0F)

may be shown before this system is shown.

The name of the connected device is shown for a few

seconds.

Note:

You can pair up to 8 devices with this system. If a 9th device is

paired, the device that has not been used for the longest time

will be replaced.

█

Connecting a device

Preparation

If this system is connected to a Bluetooth

device,

disconnect it. (~11)

Press [NET/ ] repeatedly to select “BLUETOOTH”.

“BLUETOOTH READY” is shown.

2 Select this system from the Bluetooth

menu of

the device.

The name of the connected device is shown for a few

seconds.

3 Start playback on the device.

Note:

• “Panasonic HC2020- ” is shown if the device name is

not set.

(“ ” represents a character that is unique to each set.)

• If the speaker name is changed by using the “Panasonic

Music Control” app or during the network setup, the speaker

name for Bluetooth

will be also changed.

• A device must be paired to connect.

• This system can only connect to one device at a time.

•

When “BLUETOOTH” is selected as the source, this system

will automatically try to connect to the last connected device.

(“LINKING” is shown during this process.)

USB device

(Not supplied)

HC2020EB.GN_TQBJ2081-2_En.fm Page 10 Friday, August 5, 2022 5:05 PM

TQBJ2081

█

Disconnecting a device

While a Bluetooth

device is connected

1 Press [PLAY MENU] repeatedly to select

“DISCONNECT?”.

2 Press [Y, U] to select “OK? YES” and then press

[OK].

Note:

A device is disconnected when you:

• Select a different source.

• Move the device out of the maximum range.

• Disable the Bluetooth

transmission of the device.

• Switch off the system or the device.

• Press and hold [SELECTOR/ – PAIRING] on the unit.

█

Link mode

You can change the link mode to suit the connection type.

Preparation

If this system is connected to a Bluetooth

device,

disconnect it. (~above)

1 Press [PLAY MENU] repeatedly to select

“LINK MODE”.

2 Press [Y, U] to select the mode and then press

[OK].

Note:

• Depending on the device, the playback image and sound

may not be synchronised. In this case, select “MODE 1”.

• Select “MODE 1” if the sound is interrupted.

• You can change the setting by “Panasonic Music Control”

app. (~8)

Media playback

The following marks indicate the availability of the feature.

Basic playback

CD USB BLUETOOTH

Note:

• To use this unit’s remote control with a Bluetooth

device,

the Bluetooth

device must support AVRCP (Audio Video

Remote Control Profile). Depending on the Bluetooth

device, some operations may not work.

• CD , USB : Track can be selected by pressing the numeric

buttons.

Viewing available information

-CD USB BLUETOOTH NETWORK

You can view the available information on the display

panel.

Press [DISPLAY] repeatedly.

Note:

• Maximum characters that can be shown: Approximately 32

• This system supports ver. 1.0, 1.1 and 2.3 ID3 tags.

• Text data that the system does not support can show

differently.

• Example: MP3 album and track number display.

MODE 1 Emphasis on connectivity.

MODE 2 (default) Emphasis on sound quality.

CD :

USB :

BLUETOOTH :

NETWORK :

CD-R/RW in CD-DA format or with MP3 files.

(~12)

USB device with MP3 files. (~12)

Bluetooth

device. (~10)

When connected to Wi-Fi/DLNA compatible

device. (~8)

Play Press [4/9].

Stop Press [8].

USB

The position is memorised.

“RESUME” is shown.

Press again to stop fully.

Pause Press [4/9].

Press again to continue playback.

Skip Press [2] or [6] (unit: [2/3] or

[5/6]) to skip track.

CD USB

Press [R, T] to skip MP3 album.

Search Press and hold [3] or [5]

(unit: [2/3] or [5/6]).

(Except

-BLUETOOTH )

Album

number

Track

number

HC2020EB.GN_TQBJ2081-2_En.fm Page 11 Friday, August 5, 2022 5:05 PM

TQBJ2081

Play menu

CD USB

1 Press [PLAY MENU] repeatedly to select

“PLAYMODE” or “REPEAT”.

2 Press [Y, U] to select the setting and then press

[OK].

Note:

• During random playback, you cannot skip to tracks which

have been played or press the numeric buttons.

• “PLAYMODE” function does not work with “Programme

play”.

• The setting is cancelled when you open the sliding door or

disconnect the USB device.

Programme play

CD USB

This function allows you to programme up to 24

tracks.

CD (CD-DA)

1 Press [PROGRAM] in the stop mode.

“PROGRAM” is shown.

2 Press the numeric buttons to select the desired

track.

Do this step again to programme other tracks.

3 Press [4/9] to start playback.

CD (MP3), USB

1 Press [PROGRAM] in the stop mode.

“PROGRAM” is shown.

2 Press [R, T] to select the desired album.

3 Press [6] and then press the numeric buttons to

select the desired track.

4 Press [OK].

Do steps 2 through 4 again to programme other

tracks.

5 Press [4/9] to start playback.

Note:

The programme memory is cleared when you open the sliding

door or disconnect the USB device.

█

Note on disc

• This system can play CD-R/RW with CD-DA or MP3

format content.

• This system can access up to:

– CD-DA: 99 tracks

• Before playback, finalise the disc on the device it was

recorded on.

• Some CD-R/RW cannot be played because of the

condition of the recording.

█

Note on USB device

• This system does not guarantee connection with all

USB devices.

• This system supports USB 2.0 full speed.

• This system can support USB devices of up to 32 GB.

• Only FAT 12/16/32 file system is supported.

█

Note on MP3 file

• Files are defined as tracks and folders are defined as

albums.

• Tracks must have the extension “.mp3” or “.MP3”.

• Tracks will not necessarily be played in the order you

recorded them.

• Some files can fail to work because of the sector size.

MP3 file on disc

• This system can access up to:

– 255 albums (including root folder)

– 999 tracks

– 20 sessions

• Disc must conform to ISO9660 level 1 or 2 (except for

extended formats).

MP3 file on USB device

• This system can access up to:

– 800 albums (including root folder)

– 8000 tracks

– 999 tracks in one album

PLAYMODE

OFF

PLAYMODE

Cancel the setting.

1-TRACK

Play one selected track.

Press [2] or [6] to select the

track.

1-ALBUM

Play one selected MP3 album.

Press [R, T] to select the MP3 album.

RANDOM

RND

Play all tracks randomly.

1-ALBUM

RANDOM

1 RND

Play all tracks in one selected MP3

album randomly.

Press [R, T] to select the MP3 album.

REPEAT

OFF REPEAT Cancel the setting.

ON REPEAT Repeat playback.

Check

programme

contents

Press [2] or [6] in the stop mode.

Clear the last

track

Press [DEL] in the stop mode.

Cancel

programme

mode

Press [PROGRAM] in the stop mode.

“PGM OFF” is shown.

Clear all

programmed

tracks

Press [8] in the stop mode.

“CLEAR ALL” is shown.

Within 5 seconds, press [8] again.

HC2020EB.GN_TQBJ2081-2_En.fm Page 12 Friday, August 5, 2022 5:05 PM

TQBJ2081

Radio

Preparation

Press [RADIO] repeatedly to select “FM”.

Manual tuning

1 Press [RADIO MENU] repeatedly to select

“TUNE MODE”.

2 Press [Y, U] to select “MANUAL” and then press

[OK].

3 Press [3] or [5] (unit: [2/3] or

[5/6]) to tune in to the station.

To tune automatically, press and hold the button until

the frequency starts changing quickly.

“STEREO” is shown when a stereo broadcast is being

received.

Memory presetting

You can preset up to 30 FM stations.

Channel 1 to 5 will be set as the favourite stations under

“Changing the stations stored under [FAVOURITE] [1] to

[5]”. (~right)

█

Automatic presetting

1 Press [RADIO MENU] to select “A.PRESET”.

2 Press [Y, U] to select “LOWEST” or “CURRENT”

and then press [OK].

The tuner presets all the stations it can receive into the

channels in ascending order.

To cancel, press [8].

█

Manual presetting

While listening to the radio broadcast

1 Press [PROGRAM].

2 Press the numeric buttons to select a preset

number.

Do steps 1 through 2 again to preset more stations.

The new station replaces any station that occupies the

same preset number.

█

Selecting a preset station

1 Press [RADIO MENU] repeatedly to select

“TUNE MODE”.

2 Press [Y, U] to select “PRESET” and then press

[OK].

3 Press the numeric button, [2] or [6]

(unit: [2/3] or [5/6]) to select the preset

station.

You can select channel 1 to 5 by pressing one of

[FAVOURITE] [1] to [5].

Changing the stations stored under

[FAVOURITE] [1] to [5]

You can easily change the stations stored under

[FAVOURITE] [1] to [5].

While listening to the radio broadcast

Press and hold one of [1] to [5] until “P ” is shown.

(“ ” represents a number.)

Note:

When you change the station stored under [FAVOURITE] [1] to

[5], channel 1 to 5 are also changed to the same

corresponding stations.

Improving the sound quality

1 Press [RADIO MENU] repeatedly to select

“FM MODE”.

2 Press [Y, U] to select “MONO” and then press

[OK].

To cancel, select “STEREO”.

“MONO” is also cancelled when you change the

frequency.

Checking the signal status

Press [DISPLAY].

LOWEST Tuning begins from the lowest frequency.

CURRENT Tuning begins from the current frequency.

FM - - - - The FM signal is weak.

The system is not tuned in to a station.

FM ST The FM signal is in stereo.

FM MONO “MONO” is selected as the “FM MODE”.

The FM signal is in monaural.

HC2020EB.GN_TQBJ2081-2_En.fm Page 13 Friday, August 5, 2022 5:05 PM

TQBJ2081

DAB/DAB+

Preparation

Press [RADIO] repeatedly to select “DAB+”.

Note:

If you select “DAB+” for the first time, the system will tune

automatically.

Manual tuning

1 Press [RADIO MENU] repeatedly to select

“MANUAL SCAN”.

2 Press [Y, U] to select the frequency block and

then press [OK].

If no station is detected, “SCAN FAILED” is shown.

Adjust the antenna and try again.

To tune automatically

1 Press [RADIO MENU] to select “AUTO SCAN” and

then press [OK].

“START?” is shown.

2 Press [OK] to start tuning.

“DAB AUTO SCAN” is shown.

If no station is detected, “SCAN FAILED” is shown.

Do manual tuning.

█

Selecting a station

Press [3] or [5] to select a station.

•

Or press [2/3] or [5 /6] on the unit when

“STATION” is selected as the tune mode*

Note:

Preset frequencies are erased after you do automatic tuning.

Memory presetting

You can preset up to 20 stations.

Channel 1 to 5 will be set as the favourite stations under

“Changing the stations stored under [FAVOURITE] [1] to

[5]”. (~right)

While listening to a DAB/DAB+ broadcast

1 Press [PROGRAM].

2 Press the numeric buttons to select a preset

number.

Do steps 1 through 2 again to preset more stations.

The new station replaces any station that occupies the

same preset number.

Note:

You cannot preset a station when the station is not

broadcasting or when you have selected a secondary service.

█

Selecting a preset station

Press the numeric buttons, [2] or [6] to select the

preset station.

•

Or press [2/3] or [5 /6] on the unit when

“PRESET” is selected as the tune mode*

• You can select channel 1 to 5 by pressing one of

[FAVOURITE] [1] to [5] on the unit.

: To change the tune mode

1 Press [RADIO MENU] repeatedly to select

“TUNE MODE”.

2 Press [Y, U] to select “STATION” or “PRESET”

and then press [OK].

Changing the stations stored under

[FAVOURITE] [1] to [5]

You can easily change the stations stored under

[FAVOURITE] [1] to [5].

While listening to the radio broadcast

Press and hold one of [1] to [5] until “P ” is shown.

(“ ” represents a number.)

Note:

When you change the station stored under [FAVOURITE] [1] to

[5], channel 1 to 5 are also changed to the same

corresponding stations.

Secondary service

You can listen to secondary services when “ ” is shown.

1 Press [RADIO MENU] repeatedly to select

“DAB SECONDARY”.

2 Press [Y, U] to select the secondary service and

then press [OK].

To cancel, select “PRIMARY”.

Note:

The setting is cancelled when you select other stations.

Viewing available information

You can view the following information on the display

panel:

Press [DISPLAY].

Automatic clock adjustment

You can set the clock to update automatically.

1 Press [RADIO MENU] repeatedly to select

“AUTO CLOCK ADJ”.

2 Press [Y, U] to select “ON ADJUST” and then

press [OK].

To cancel, select “OFF ADJUST”.

Dynamic label Information about the DAB

broadcast

PTY display Programme type

Ensemble label The name of the ensemble

Frequency display The frequency block and

frequency

Time display Current time

HC2020EB.GN_TQBJ2081-2_En.fm Page 14 Friday, August 5, 2022 5:05 PM

TQBJ2081

To verify or improve the signal

reception quality

To check the signal reception quality, at least 1 frequency

block needs to be successfully memorised.

• If “SCAN FAILED” is displayed after “DAB+” is selected

or after an auto scan, proceed to “Manual tuning”.

(~14)

• If stations have already been memorised to this unit,

proceed to “Checking the signal quality”. (~below)

█

Checking the signal quality

You can check the signal quality when adjusting the

antenna.

1 Press [RADIO MENU] repeatedly to select

“SIGNAL QUALITY”.

2 Press [OK].

The frequency block followed by the reception quality

is shown.

To select other frequency blocks, press [Y, U].

3 Press [OK] again to exit.

Clock and timers

Setting the clock

This is a 24-hour clock.

█

Using network device

This system can receive the clock information from the

device by using the “Panasonic Music Control” app. (~8)

Preparation

• Complete the network settings. (~6)

• Install the “Panasonic Music Control” app on your

device.

• Connect your device to the same network as this

system.

1 Switch on this system.

Check that the network indicator (~5) lights up.

If it does not light up, check the network settings.

(~6)

2 Start the app.

Always use the latest version of the app.

The clock information will be sent to this system.

█

Manual setting

1 Press [CLOCK/TIMER] repeatedly to select

“CLOCK”.

2 Press [R, T] to set the time and then press [OK].

To check the time

Press [CLOCK/TIMER].

In standby mode, press [CLOCK/TIMER].

Note:

• Reset the clock regularly to maintain accuracy.

• The clock is reset when there is a power failure or when the

AC mains lead is disconnected.

Sleep timer

The sleep timer switches off the system after the set time.

Press [SLEEP] to select the setting (in minutes).

To cancel, select “OFF”.

Note:

• The remaining time is shown at every minute except when

other operations are being performed. “SLEEP 1” will

always be shown when only 1 minute remains.

• The sleep timer always comes first. Be sure not to set an

overlap of timers.

Frequency

block

Frequency Reception quality

0 (poor) to 8 (excellent)

HC2020EB.GN_TQBJ2081-2_En.fm Page 15 Friday, August 5, 2022 5:05 PM

TQBJ2081

Play timer

You can set the timer to switch on this system at a certain

time to wake you up.

Preparation

Set the clock.

1 Press [CLOCK/TIMER] repeatedly to select

“TIMER ADJ”.

2 Press [R, T] to set the start time and then press

[OK].

3 Do step 2 again to set the end time.

4 Press [R, T] to select the music source you want

to play and then press [OK].

To start the timer

1 Press [CLOCK/TIMER] repeatedly to select

“TIMER SET”.

2 Press [R, T] to select “SET” and then press [OK].

“#” is shown.

To cancel, select “OFF”.

The system must be switched off for the timer to

operate.

To check the setting

Press [CLOCK/TIMER] repeatedly to select

“TIMER ADJ”.

In standby mode, press [CLOCK/TIMER] two times.

Note:

• The timer starts at a low volume and increases gradually to

the preset level.

• The timer comes on at the set time every day if the timer is

on.

• If you switch off the system and then switch on again while a

timer is in operation, the timer will not stop at the end time.

•“CD”, “USB”, “DAB+” and “FM” can be set as the music

source.

Sound effects

1 Press [SOUND] repeatedly to select the sound

effect.

2 Press [Y, U] to select the setting and then press

[OK].

• Sound quality may reduced when these effects are

used with some sources. If this occurs, switch off the

sound effects.

• When “AUX” is selected as the source, you can select

“INPUT LEVEL” to adjust the sound input level of the

external device. (~17)

Saving the sound settings

You can save the current sound effects (up to

3 combinations).

Preparation

Select the sound effects.

1 Press [SETUP] to select “SAVE MY SOUND”.

2 Press [Y, U] to select a sound setting number and

then press [OK].

“SAVED” is shown.

The new setting replaces the one existing in the same

sound setting number.

To recall the setting

1 Press [SOUND] to select “MY SOUND”.

2 Press [Y, U] to select the sound setting number

and then press [OK].

MY SOUND “SOUND 1”, “SOUND 2” or

“SOUND 3” (~below)

BASS –4 to +4

TREBLE –4 to +4

SURROUND “ON SURROUND” or

“OFF SURROUND”

Or press [SURROUND] on the unit.

CLEAR-MODE

DIALOG

“ON CLEAR-MODE DIALOG” or

“OFF CLEAR-MODE DIALOG”

WALL MOUNT “MODE 1 WALL MOUNT”,

“MODE 2 WALL MOUNT” or

“OFF WALL MOUNT”

Or press [WALL MOUNT] on the unit.

HC2020EB.GN_TQBJ2081-2_En.fm Page 16 Friday, August 5, 2022 5:05 PM

TQBJ2081

D.Bass

Press [D.BASS] repeatedly to select “ON D.BASS” or

“OFF D.BASS”.

Note:

The default setting is “ON D.BASS”.

Preset EQ

Press [PRESET EQ] repeatedly to select “HEAVY”,

“SOFT”, “CLEAR”, “VOCAL” or “FLAT”.

Note:

• When “PRESET EQ” is selected, Bass and Treble settings

will be changed to the settings as in the Preset EQ.

• The default setting is “HEAVY”.

External music device

You can play music from an external music device.

Preparation

• Switch off the equaliser (if any) of the external music

device to prevent sound distortion.

• Decrease the volume of the system and the external

music device before you connect or disconnect the

external music device.

1 Connect the external music device.

Plug type: Ø 3.5 mm stereo (not supplied)

2 Press [CD/USB, AUX] repeatedly to select “AUX”.

3 Play the external music device.

To adjust the input level

1 Press

[SOUND]

repeatedly to select

“INPUT LEVEL”

2 Press [Y, U] to select “LOW” or “HIGH” and then

press [OK].

Note:

• The default setting is “HIGH”.

• Select “LOW” if the sound is distorted during “HIGH” input

level.

• Read the operating instructions of the external music device

for details.

• Components and cables are sold separately.

Audio cable

(not supplied)

HC2020EB.GN_TQBJ2081-2_En.fm Page 17 Friday, August 5, 2022 5:05 PM

TQBJ2081

Firmware updates

Occasionally, Panasonic may release updated firmware

for this system that may add or improve the way a feature

operates. These updates are available free of charge.

Automatic updates

When a new update is available, this system will update

the firmware automatically after midnight if it is not in use.

• Connect this system to the network. (~6)

– Make sure that the network is connected to the

Internet.

Note:

• If an update is detected during the network settings,

updating will be performed as a part of the network settings.

• If a critical update is detected while the system is in use,

updating will be prioritised.

• Updating may take longer or may not work properly

depending on the connection environment.

Manual updates

Preparation

• Connect this system to the home network. (~6)

– Make sure that the network is connected to the

Internet.

1 Press [NET/ ] repeatedly to select “NETWORK”.

2 Press [SETUP] repeatedly to select “FW UPDATE”.

3 Press [Y, U] to select “OK? YES” and then press

[OK] to start the update.

To cancel, select “OK? NO”.

While updating, “UPDATING” or “UPD %” is shown.

(“ ” represents a number.)

4 After the update has finished, “SUCCESS” is

shown for a few seconds and the system may

automatically switch off.

Note:

• If there are no updates, “NO NEED” is shown.

• Downloading may take longer or may not work properly

depending on the connection environment.

Checking the firmware version

Press [SETUP] repeatedly to select “FW VER.” and

then press [OK].

The version of the installed firmware is shown.

Press [OK] again to exit.

DO NOT DISCONNECT the AC mains lead

while one of the following messages is

shown.

“UPDATING” or “UPD %”

(“ ” represents a number.)

• During the update process, no other operations can

be performed.

HC2020EB.GN_TQBJ2081-2_En.fm Page 18 Friday, August 5, 2022 5:05 PM

TQBJ2081

Others

Auto off

This system automatically switches off when you do not

use it for approximately 20 minutes.

1 Press [SETUP] repeatedly to select “AUTO OFF”.

2 Press [Y, U] to select “ON” and then press [OK].

To cancel, select “OFF”.

Note:

• This function does not work when you are in radio source or

when a Bluetooth

device is connected or when “STANDBY

MODE” is “ON”.

• If “STANDBY MODE” is set to “ON”, this function will also be

set to “ON”. To change the setting, set “STANDBY MODE”

to “OFF”. (~below)

Standby mode

This function automatically switches on the system when

you establish a Bluetooth

connection from a paired

device or when this system is selected as the network

device’s output speakers.

Select “NETWORK” or “BLUETOOTH” before switch off

this system to use this feature.

When you connect it to the home network for the first time,

this function will automatically switch to on.

You can also switch on the network standby using the

following steps:

1 Press [SETUP] repeatedly to select “STANDBY

MODE” and then press [OK].

2 Press [Y, U] to select “ON” and then press [OK].

When “STANDBY MODE” is “ON”

– The network (wired LAN/Wi-Fi) and Bluetooth

will

be active even in standby mode.

– The power consumption in standby mode will

increase. To reduce the power consumption in

standby mode, switch off the “STANDBY MODE”.

To switch off the standby mode

Select “OFF” in step 2.

When you have switched “STANDBY MODE” to “OFF”,

– Network and Bluetooth

standby will be active if the

system is switched to standby mode at “NETWORK”

and “BLUETOOTH” selector mode and this system is

connected to the network.

– To keep the “STANDBY MODE” switched off, select a

source other than “NETWORK” and “BLUETOOTH”

before switching the system to standby mode.

Note:

• This function will return to default setting if you have

performed the operation for reset. (

~20)

• When the system is switched on by this feature, the

beginning part of the music may not be played back.

• Depending on the app, the conditions for activating this

function may differ.

• The system may not be switched on even when selected as

the output speakers. Start playback.

Charging a device

This system can supply power to a device, such as

Android™ smartphone, connected to the USB port.

Note:

• Use a cable compatible with the device.

• Use the charger supplied with the device if power is not

supplied to the device.

• Do not use a cable or connect a device that exceeds the

rated value of 5 V, 1.5 A.

• Examine the screen of the device to check if charging is

complete. Disconnect the device after charging.

• Depending on the device, power may not be supplied to it.

• Read the operating instructions of the device for details.

Wi-Fi signal strength

To check the Wi-Fi signal strength where this system is

located.

Preparation

Connect this system to the wireless network. (~6)

1 Press [NET/ ] repeatedly to select “NETWORK”.

2 Press [SETUP] repeatedly to select “SIGNAL

LEVEL” and then press [OK].

Press [OK] again to exit.

Note:

• It is recommended to have a signal strength of “3”. Change

the position or angle of your wireless router or this system if

the indication is “2” or “1” and see if the connection

improves.

• If “LEVEL 0” is shown, this system cannot establish a link

with the wireless router. (

~21)

Wireless network name (SSID)

Show the name for the connected wireless network

(SSID).

1 Press [NET/ ] repeatedly to select “NETWORK”.

2 Press [SETUP] repeatedly to select “NET INFO”.

3 Press [Y, U] repeatedly to select “SSID” and then

press [OK].

Press [OK] again to exit.

Note:

• If “NO CONNECT” is shown on this system, it is not

connected to a wireless network.

• Characters that cannot be shown are replaced with “ ”.

HC2020EB.GN_TQBJ2081-2_En.fm Page 19 Friday, August 5, 2022 5:05 PM

TQBJ2081

IP/MAC Address

To check this system’s IP address or the Wi-Fi MAC

address.

1 Press [NET/ ] repeatedly to select “NETWORK”.

2 Press [SETUP] repeatedly to select “NET INFO”.

3 Press [Y, U] repeatedly to select “IP ADDR.” or

“MAC ADDR.”.

The IP address or the MAC address is partially shown.

4 Press [Y, U] to show the rest of the IP address or

the MAC address.

Press [OK] to exit.

The “ – ” shown on the top or bottom left of the display

indicates the first and last units respectively.

Reset

To return all settings to the factory defaults.This function

will reset all memory contents and network settings.

1 Press [NET/ ] repeatedly to select “NETWORK”.

2 Press [SETUP] repeatedly to select “RESET”.

3 Press [Y, U] to select “OK? YES” and then

press

[OK].

“RESET” blinks. When the display returns to “CD”, the

settings are reset.

Troubleshooting

Before requesting service, make the following checks. If

you are in doubt about some of the check points, or if the

solutions indicated do not solve the problem, consult your

dealer for instructions.

For further dedicated help, support and advice about

your product please visit:

http://panasonic.jp/support/global/cs/audio/

(This site is in English only.)

█

Common problems

The unit cannot be switched on.

• Connect the AC mains lead and wait for a minimum of

10 seconds before switching on the unit.

The unit does not work.

• The safety device has been activated. Do the following:

1. Press [1] on the unit to switch the unit to standby mode.

If the unit does not switch to standby mode, disconnect

the AC mains lead and connect it again.

2. Press [1] again to switch on the unit. If the problem

persists, consult your dealer.

No operations can be done with the remote control.

• Examine that the battery is installed correctly.

Sound is distorted or no sound.

• Adjust the volume of the system.

• Switch off the system, determine and correct the cause, and

then switch on again. It can be caused by straining of the

speakers through excessive volume or power, and when

using the system in a hot environment.

A humming sound can be heard during playback.

• An AC mains lead or fluorescent light is near the cables.

Keep other appliances and cords away from the cables of

this system.

Noise is heard.

• Depending on the device, noise may be heard if the device

is connected to the AUX IN terminal and USB port at the

same time. Disconnect the cable from the USB port.

█

Disc

Display not shown correctly.

Playback does not start.

• You have not put in the disc correctly. Put it in correctly.

• Disc is dirty. Clean the disc.

• Replace the disc if it is scratched, warped, or non-standard.

• There is condensation. Let the system dry for 1 to 2 hours.

The total number of tracks shown is incorrect.

The disc cannot be read.

Distorted sound is heard.

• You put in a disc that the system cannot play. Change to a

playable disc.

• You put in a disc that has not been finalised.

Do you have the latest firmware installed?

Panasonic is constantly improving the system’s firmware

to ensure that our customers are enjoying the latest

technology.

(~18)

HC2020EB.GN_TQBJ2081-2_En.fm Page 20 Friday, August 5, 2022 5:05 PM

TQBJ2081

█

USB

No response when you press [4/9].

• Disconnect the USB device and then connect it again.

Alternatively, switch the unit off and on again.

The USB device or the contents in it cannot be read.

• The format of the USB device or the contents in it are not

compatible with the system.

• USB devices with storage capacity of more than 32 GB

cannot work in some conditions.

Slow operation of the USB device.

• Large content size or large memory USB device takes

longer time to read.

The elapsed time shown is different from the actual play

time.

• Transfer the data to another USB device or backup the data

and reformat the USB device.

█

Bluetooth

Pairing cannot be done.

• Check the Bluetooth

device condition.

• The device is out of the 10 m communication range.

Move the device nearer to the system.

The device cannot be connected.

• The pairing of the device was unsuccessful. Do pairing

again.

• The pairing of the device has been replaced. Do pairing

again.

• This system might be connected to a different device.

Disconnect the other device and try connecting the device

again.

• The system may have a problem. Switch off the system and

then switch on again.

• If “MODE 2” is selected in “LINK MODE”, select “MODE 1”.

(

~11)

The device is connected but audio cannot be heard

through the system.

• For some built-in Bluetooth

devices, you have to set the

audio output to this system manually. Read the operating

instructions of the device for details.

Sound from the device is interrupted.

• The device is out of the 10 m communication range.

Move the device nearer to the system.

• Remove any obstacle between the system and the device.

• Other devices that use the 2.4 GHz frequency band

(wireless router, microwaves, cordless phones, etc.) are

interfering. Move the device nearer to the system and

distance it from the other devices.

• Select “MODE 1” for stable communication. (~11)

█

Network

Cannot connect to the network.

• Confirm the network connection and settings. (~6)

• If the network is set to be invisible, make the network visible

while you set up the network for this unit or make a wired

LAN connection. (

~7)

• This unit’s Wi-Fi security does not support

WPA2-Enterprise. For details on the security supported by

your router and how to change the settings, please refer to

the operating instructions for the router or contact your

Internet service provider.

• Make sure that the multicast function on the wireless router

is enabled.

Cannot select this system as the output speakers.

• Make sure that the devices are connected to the same

network as this system.

• Reconnect the devices to the network.

• Switch the wireless router off and then on.

• Switch this system off and on, and then select this system

as the output speakers again.

Playback does not start.

The sound is interrupted.

• If using the 2.4 GHz band on the wireless router,

simultaneous use with other 2.4 GHz devices, such as

microwaves, cordless telephones, etc., may result in

connection interruptions. Increase the distance between this

unit and these devices.

– If your wireless router supports 5 GHz band, try using the

5 GHz band.

To change to the 5 GHz band, redo the network settings

(

~6). Make sure to select your network name (SSID) for

the 5 GHz band during the setup.

• Do not place this system inside a metal cabinet, for it might

block the Wi-Fi signal.

• Place this system closer to the wireless router.

• If several wireless devices are simultaneously using the

same wireless network as this system, try switching off the

other devices or reducing their wireless network usage.

• If the playback stops, check the playback status on the

device.

• Reconnect the devices to the network.

• Switch the wireless router off and then on.

• Try a wired LAN connection. (~7)

The network indicator (

~5) blinks.

• This may occur when, for instance, the network connection

is interrupted.

█

Radio, DAB/DAB+

Sound is distorted or static is heard.

• Check that the antenna is properly connected. (~4)

• Adjust the position of the antenna.

• Keep a certain amount of distance between the antenna

and the AC mains lead.

• Use an outdoor antenna if there are buildings or mountains

nearby.

• Switch off the TV or other audio players or separate it from

the system.

• Keep the system away from mobile phones if there is

interference.

If there is excessive noise during FM reception.

• Change the audio output to monaural. (~13)

DAB/DAB+ reception is poor.

• Keep the antenna away from computers, TV, other cables

and cords.

█

Unit displays

“--:--”

• You connected the AC mains lead for the first time or there

was a power failure recently. Set the clock.

“ADJUST CLOCK”

• The clock is not set. Adjust the clock.

“ADJUST TIMER”

• The play timer is not set. Adjust the play timer.

“AUTO OFF”

• The system has not been used for 20 minutes and will

switch off within a minute. To cancel, press any button.

HC2020EB.GN_TQBJ2081-2_En.fm Page 21 Friday, August 5, 2022 5:05 PM

TQBJ2081

“BLUETOOTH INITIALIZING”

“NETWORK INITIALIZING”

• The system is carrying out an internal process.

– Wait for approximately 3 minutes.

– Do not disconnect the AC mains lead. Doing so may

cause malfunction.

“ERROR”

• An incorrect operation was done. Read the instructions and

try again.

“F ” / “F ” (“ ” represents a number.)

• There is a problem with this unit.

Disconnect the AC mains lead from the AC outlet, reconnect

it to the outlet after about 30 seconds. Wait for about 10

seconds, then switch on the unit. If the problem still persists,

disconnect the AC mains lead and consult your dealer.

“FAIL”

• Updating or setting has failed. After switching off the unit,

disconnect the AC mains lead from the AC outlet, reconnect

it to the outlet after about 30 seconds. Wait for about

10 seconds, then switch on the unit and redo the update.

• The firmware download has failed. Press any button to exit.

Try again later.

• The server cannot be found. Press any button to exit. Make

sure that the wireless network is connected to the Internet.

“ILLEGAL OPEN”

• The sliding door is not in a correct position. Switch off the

system and then switch on again.

“INVALID TO PRESET”

• You cannot preset an online music service.

“LEVEL 0”

• There is no link between this system and the wireless

router. Try the following operations:

– Check that the wireless router is switched on.

– Switch this system off and on again.

– Reset the wireless network settings. (~6)

– If the problem persists, consult your dealer.

“LINKING”

• This system is trying to connect to the last connected

Bluetooth

device when “BLUETOOTH” is selected.

“NO CONNECT”

• This system cannot connect to the network.

Check the network connection. (

~6)

“NO DEVICE”

• The USB device is not connected. Examine the connection.

“NO DISC”

• You have not put in a disc.

“NO PLAY”

• Examine the content. You can only play supported format.

• The files in the USB device may be corrupted. Format the

USB device and try again.

• The system may have a problem. Switch off the system and

then switch on again.

“NO PRESET”

• DAB memory presetting has not been done.

“NO SIGNAL”

• The station cannot be received. Adjust the antenna.

“NOT SUPPORTED”

• You have connected an unsupported USB device.

“PGM FULL”

• The number of programmed tracks is more than 24.

“PLAYERROR”

• An unsupported MP3 file has been played. The system will

skip that track and play the next one.

“READING”

• The unit is checking the “CD/USB” information.

After this display has disappeared, start operating.

“REMOTE 1”

“REMOTE 2”

• The remote control and this unit are using different codes.

Change the code of the remote control.

– When “REMOTE 1” is shown, press and hold [OK] and

[1] for a minimum of 4 seconds.

– When “REMOTE 2” is shown, press and hold [OK] and [2]

for a minimum of 4 seconds.

“SCAN FAILED”

• Stations cannot be received. Adjust the antenna or perform

the “AUTO SCAN” tuning function. (

~14)

If “SCAN FAILED” is still shown, find the best signal

reception with the “MANUAL SCAN” tuning function.

(

~14)

“SOUND 1 NOT SET”

“SOUND 2 NOT SET”

“SOUND 3 NOT SET”

• You have not saved the sound effects into the sound setting

number.

“USB OVER CURRENT ERROR”

• The USB device is drawing too much power. Disconnect the

USB device, switch off the system and then switch on again.

• Check the connection, it may be caused by a faulty USB

cable.

“VBR”

• The system cannot show the remaining play time for

variable bit rate (VBR) tracks.

“WAIT”

• This is shown, for example, when this unit is switching off.

• This is flashing when the system is trying to enter a network

setting mode.

HC2020EB.GN_TQBJ2081-2_En.fm Page 22 Friday, August 5, 2022 5:05 PM

TQBJ2081

Remote control code

When other Panasonic equipment responds to the remote

control of this system, change the remote control code for

this system.

Preparation

Press [CD/USB, AUX] repeatedly to select “CD”.

█

To set the code to “REMOTE 2”

1 Press and hold [8] on the unit and [2] on the

remote control.

“REMOTE 2” is shown.

2 Press and hold [OK] and [2] for a minimum of

4 seconds.

█

To set the code to “REMOTE 1”

1 Press and hold [8] on the unit and [1] on the

remote control.

“REMOTE 1” is shown.

2 Press and hold [OK] and [1] for a minimum of

4 seconds.

Maintenance

Disconnect the AC mains lead before maintenance.

█

Clean this system with a soft, dry cloth.

• When dirt is heavy, wring a cloth moistened in water

tightly to wipe the dirt, and then wipe it with a dry cloth.

• Never use alcohol, paint thinner or benzine to clean this

system.

• Before using chemically treated cloth, read the

instructions that came with the cloth carefully.

█

Maintenance of the lens

• Clean the lens regularly to prevent malfunctions. Use a

dust blower to remove dust and a cotton swab if it is

extremely dirty.

• You cannot use a CD type lens cleaner.

• Do not leave the sliding door open for prolonged

periods of time. This will cause the lens to get dirty.

• Be careful not to touch the lens with your fingers.

█

Clean discs

Wipe with a damp cloth and then wipe dry.

█

Disc handling precautions

• Handle discs by the edges to avoid inadvertent

scratches or fingerprints on the disc.

• Do not attach labels or stickers to discs.

• Do not use record cleaning sprays, benzine, thinner,

static electricity prevention liquids or any other solvent.

• Do not use the following discs:

– Discs with exposed adhesive from removed stickers

or labels (rented discs etc.).

– Discs that are badly warped or cracked.

– Irregularly shaped discs, such as heart shapes.

█

To dispose of or transfer this system.

• This system may keep the user settings information in

the unit. If you discard this unit either by disposal or

transfer, then follow the procedure to return all the

settings to the factory presets to delete the user

settings. (~20)

• The operation history may be recorded in the memory

of this unit.

DO DO NOT

Lens

HC2020EB.GN_TQBJ2081-2_En.fm Page 23 Friday, August 5, 2022 5:05 PM

TQBJ2081

Specifications

█

General

Dimensions (W x H x D) 420 mm x 225 mm x 102 mm

Mass (approximate) 2.5 kg

Operating temperature range 0°C to +40°C

Operating humidity range

35% to 80% RH (no condensation)

█

Amplifier section

RMS output power

Front Ch (both ch driven)

20 W per channel (8 Ω), 1 kHz, 10% THD

Total RMS power 40 W

█

Speaker section

Speaker unit(s)

Full range 8 cm cone type x 2 pieces

█

Tuner, terminals section

Preset memory FM 30 stations

Frequency modulation (FM)

Frequency range

87.50 MHz to 108.00 MHz (50 kHz step)

Antenna terminal 75 Ω (unbalanced)

Ethernet interface LAN (10BASE-T/100BASE-TX)

AUX input

Terminal Stereo, 3.5 mm jack

█

DAB section

DAB memories 20 channels

Frequency band (wavelength)

Band III 5A to 13F

(174.928 MHz to 239.200 MHz)

Sensitivity *BER 4x10

-4

Min requirement –98 dBm

DAB external antenna

Terminal F - Connector (75 Ω)

█

Disc section

Disc played (8 cm or 12 cm)

CD, CD-R/RW (CD-DA, MP3

)

Pick up

Wavelength 790 nm (CD)

█

USB section

USB port power DC OUT 5 V, 1.5 A

USB standard USB 2.0 full speed

Media file format support MP3 (*.mp3)

Audio support format MP3

Sampling frequency 32 kHz, 44.1 kHz, 48 kHz

Audio word size 16 bits

Channel count 2 ch

USB device file system FAT12, FAT16, FAT32

█

Bluetooth

section

Version Bluetooth

Ver. 4.2

Class Class 2

Supported profiles A2DP, AVRCP

Frequency band 2.4 GHz band FH-SS

Operation distance 10 m line of sight

Supported codec AAC, SBC

For the United Kingdom and Ireland

Operating frequency 2402 MHz to 2480 MHz

Maximum power (EIRP) 4 dBm

█

Wi-Fi section

Wi-Fi

WLAN Standard IEEE802.11ac/a/b/g/n

Security WPA

/ WPA2

Frequency range 2.4 GHz band / 5 GHz band

For the United Kingdom and Ireland

Operating frequency, Maximum power (EIRP)

2412 MHz to 2472 MHz, 19 dBm

5180 MHz to 5320 MHz, 19 dBm

5500 MHz to 5700 MHz, 19 dBm

Audio support format (Panasonic Music Control)

MP3

Sampling frequency 32 kHz, 44.1 kHz, 48 kHz

Audio word size 16 bits

Channel count 2 ch

Bit-rate 32-320 kbps

AAC

Sampling frequency

32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz

Audio word size 16 bits

Channel count 2 ch

Bit-rate 8-320 kbps

Power supply

Power consumption

AC 220 V to 240 V, 50 Hz

27 W

Power consumption in standby mode

When “STANDBY MODE”

is “OFF”

Approx. 0.2 W

When “STANDBY MODE”

is “ON”

Approx. 2 W

HC2020EB.GN_TQBJ2081-2_En.fm Page 24 Friday, August 5, 2022 5:05 PM

TQBJ2081

FLAC

/WAV/AIFF/ALAC

Sampling frequency

32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz,

96 kHz, 176.4 kHz, 192 kHz

Audio word size 16 bits, 24 bits

Channel count 2 ch

Note:

• Specifications are subject to change without notice.

Mass and dimensions are approximate.

• Total harmonic distortion is measured by the digital

spectrum analyser.

No device is connected to the USB port before switching to

standby mode.

“STANDBY MODE” is standby settings for both network and

Bluetooth

. (~19)

MPEG-1 Layer 3, MPEG-2 Layer 3

Uncompressed FLAC files may not operate correctly.

For the United Kingdom and Ireland

EU Declaration of Conformity (DoC)

Hereby, “Panasonic Entertainment & Communication Co.,

Ltd.” declares that this product is in compliance with the

essential requirements and other relevant provisions of

Directive 2014/53/EU.

Customers can download a copy of the original DoC to

our RE products from our DoC server:

https://www.ptc.panasonic.eu/compliance-documents

Contact to Authorised Representative:

Panasonic Marketing Europe GmbH, Panasonic Testing

Centre, Winsbergring 15, 22525 Hamburg, Germany

5.15 – 5.35 GHz band is restricted to indoor operations

only in the following countries.

UK Declaration of Conformity (DoC)

Hereby, “Panasonic Entertainment & Communication Co.,

Ltd.” declares that this product is in compliance with the

essential requirements and other relevant provisions of

the Radio Equipment Regulations 2017 No.1206.

Customers can download a copy of the original DoC to

our RE products from our DoC server:

https://www.ptc.panasonic.eu/compliance-documents

Contact in the UK: Panasonic Testing Centre on behalf of

Panasonic UK, a branch of Panasonic Marketing Europe

GmbH (Importer)

Maxis 2, Western Road, Bracknell, Berkshire, RG12 1RT

5.15 – 5.35 GHz band is restricted to indoor operations

only in the United Kingdom.

The WLAN feature of this product shall exclusively be

used inside buildings.

This product on purpose to connect to access point of

2.4 GHz or 5 GHz WLAN.

Sales and Support Information

For the United Kingdom and Ireland

Customer Communications Centre

• For customers within the UK: 0344 844 3899

• For customers within Ireland: 01 289 8333

• Monday – Friday 9:00am – 5:00pm

(Excluding public holidays).

• For further support on your product, please visit our

website: www.panasonic.co.uk

Direct Sales at Panasonic UK

• Order accessory and consumable items for your

product with ease and confidence by phoning our

Customer Communications Centre

Monday – Friday 9:00am – 5:00pm

(Excluding public holidays).

• Or go on line through our Internet Accessory ordering

application at www.pas-europe.com

• Most major credit and debit cards accepted.

• All enquiries transactions and distribution facilities are

provided directly by Panasonic UK.

• It couldn’t be simpler!

• Also available through our Internet is direct shopping for

a wide range of finished products. Take a browse on our

website for further details.

Type of wireless

Frequency band

Maximum power

(dBm EIRP)

WLAN

2412 – 2472 MHz

5180 – 5320 MHz

5500 – 5700 MHz

19 dBm

Bluetooth

2402 – 2480 MHz 4 dBm

HC2020EB.GN_TQBJ2081-2_En.fm Page 25 Friday, August 5, 2022 5:05 PM

TQBJ2081

Attaching the unit to a wall (optional)

This unit can be wall mounted using the supplied wall

mount brackets, safety holder, etc. Make sure that the wall

and the screws used for securing to the wall are capable

of supporting at least 36 kg. The screws and other items

are not supplied as the type and size will vary with each

installation.

• Refer to step 6 and step 7 of “Installation instructions”

for details about the required screws.

• As an additional protective measure, attach the unit to

the wall with the fall prevention cord.

Installation accessories

█

Supplied accessories

 2 Wall mount brackets

 1 Safety holder

 1 Wall mounting sheet

█

Additional accessories

(commercially available)

 4 Wall mount bracket fixing screws

 2 Safety holder fixing screws

 1 Screw eye

 1 Fall prevention cord

Use a cord that is capable of supporting over 36 kg

(with a diameter of about 1.5 mm)

Safety precautions

Installation instructions

Preparation

• Disconnect the antenna and the AC mains lead.

• Put a protection layer below the unit to prevent

scratches.

1 Remove the fixing screw at the rear of the unit.

2 Detach the pedestal from the unit while pressing

the catches upward.

While lifting the catches upwards, gently pull the

pedestal forward.

3 Attach the fall prevention cord to the unit to

prevent the unit from falling.

Fall prevention cord (not supplied)

• Bend the cord twice from the tip, each at 45° and

5 mm apart for it to go through the holes.

5 mm

• Keep the screws out of reach of children to prevent

swallowing.

• Keep the wall mount brackets out of reach of children

to prevent swallowing.

• Keep the screws eye out of reach of children to

prevent swallowing.

Professional installation is required.

The installation should never be done by any other

than a qualified installation specialist.

PANASONIC DISCLAIMS ANY PROPERTY

DAMAGE AND/OR SERIOUS INJURY, INCLUDING

DEATH RESULTING FROM IMPROPER

INSTALLATION OR INCORRECT HANDLING.

WARNING:

To prevent injury, this apparatus must be securely

attached to the wall in accordance with the installation

instructions.

Keep the removed screw and pedestal for future use.

• When using the unit in a non-wall-mounted position

again, be sure to reattach the pedestal to the unit and

secure it with its screw.

Pedestal

Fixing screw

Protection layer

HC2020EB.GN_TQBJ2081-2_En.fm Page 26 Friday, August 5, 2022 5:05 PM

TQBJ2081

4 Put up the wall mounting sheet on the wall where

the unit is to be mounted.

• Before deciding the location to place the unit, be

sure to check that the Wi-Fi signal strength is

sufficient. (~19)

• Spread out the wall mounting sheet when tapping it

to the wall.

5 Make holes on the wall at the center of each cross

mark on the sheet.

Take the sheet away from the wall after its use.

6 Attach each wall mount bracket to the wall with

two screws (not supplied).

Use a level to align the wall mount brackets.

7 Attach the safety holder with two screws (not

supplied) to the wall.

8 Attach the unit.

Connect the antenna and the AC mains lead. (~4)

1. Hook the unit securely onto the wall mount

brackets with both hands.

2. Slightly lift up the unit vertically until the slot

reaches the hook of the safety holder.

3. Push down until the unit is hooked and locked onto

the safety holder with a click sound.

• After hanging the unit, slightly pull the unit

carefully to confirm that the unit sits securely on

the wall mount brackets and the safety holder.

Wall mounting sheet

Adhesive tape (not supplied)

Wall

420 mm

102.5 mm

130.5 mm

141 mm

100 mm

118.5 mm

300 mm

100 mm

39 mm

73 mm

Space required

At least 30 mm

Ø 7.5 mm to

Ø 9.4 mm

Ø 4.0 mm

Wall mount bracket

At least 30 mm

Ø 7.5 mm to

Ø 9.4 mm

Ø 4.0 mm

Safety holder

Wall

AC mains lead

Hook

Slot

Pull

HC2020EB.GN_TQBJ2081-2_En.fm Page 27 Friday, August 5, 2022 5:05 PM

TQBJ2081

9 Attach the fall prevention cord to the wall.

█

To release the unit from the safety holder

1. Hold the unit firmly with one hand.

2. Insert two fingers and press the two catches of the

safety holder with the other hand.

3. While pressing the two catches, slightly lift up the

unit vertically until the slot released from the hook

of the safety holder.

References

About Bluetooth

Frequency band

• This system uses the 2.4 GHz frequency band.

Certification

• This system conforms to the frequency restrictions and

has received certification based on frequency laws.

Thus, a wireless permit is not necessary.

• The actions below are punishable by law in some

countries:

– Taking apart or modifying the unit.

– Removing specification indications.

Restrictions of use

• Wireless transmission and/or usage with all Bluetooth

equipped devices is not guaranteed.

• All devices must conform to standards set by the

Bluetooth SIG, Inc.

• Depending on the specifications and settings of a

device, it can fail to connect or some operations can be

different.

• This system supports Bluetooth

security features. But

depending on the operating environment and/or

settings, this security is possibly not sufficient. Transmit

data wirelessly to this system with caution.

• This system cannot transmit data to a Bluetooth

device.

Range of use

• Use this device at a maximum range of 10 m.

• The range can decrease depending on the

environment, obstacles or interference.

Interference from other devices

• This system may not function properly and troubles

such as noise and sound jumps may arise due to radio

wave interference if this system is located too close to

other Bluetooth

devices or the devices that use the

2.4 GHz band.

• This system may not function properly if radio waves

from a nearby broadcasting station, etc. is too strong.

Intended usage

• This system is for normal, general use only.

• Do not use this system near an equipment or in an

environment that is sensitive to radio frequency

interference (example: airports, hospitals, laboratories,

etc.).

Cord (not supplied)

Screw eye (not supplied)

Wall

Catches

Panasonic bears no responsibility for data and/or

information that is compromised during a wireless

transmission.

HC2020EB.GN_TQBJ2081-2_En.fm Page 28 Friday, August 5, 2022 5:05 PM

TQBJ2081

Licenses

The Wi-Fi CERTIFIED

Logo is a certification mark of Wi-Fi

Alliance

“Wi-Fi

” is a registered trademark of Wi-Fi Alliance

“WPA

” and “WPA2

” are trademarks of Wi-Fi Alliance

DLNA, the DLNA Logo and DLNA CERTIFIED are

trademarks, service marks, or certification marks of the

Digital Living Network Alliance.

Windows is a trademark or a registered trademark of

Microsoft Corporation in the United States and other

countries.

iPad, iPhone, iPod, and iPod touch are trademarks of Apple

Inc., registered in the U.S. and other countries.

App Store is a service mark of Apple Inc., registered in the

U.S. and other countries.

The Bluetooth

word mark and logos are registered

trademarks owned by Bluetooth SIG, Inc. and any use of

such marks by Panasonic Holdings Corporation is under

license. Other trademarks and trade names are those of their

respective owners.

Google, Google Home, Android, Google Play, Chromecast,

Chromecast built-in and other related marks and logos are

trademarks of Google LLC.

FLAC Decoder

Redistribution and use in source and binary forms, with or

without modification, are permitted provided that the following

conditions are met:

– Redistributions of source code must retain the above

disclaimer.

– Redistributions in binary form must reproduce the above

disclaimer in the documentation and/or other materials

provided with the distribution.

– Neither the name of the Xiph.org Foundation nor the

names of its contributors may be used to endorse or

promote products derived from this software without

specific prior written permission.

THIS SOFTWARE IS PROVIDED BY THE COPYRIGHT

HOLDERS AND CONTRIBUTORS “AS IS” AND ANY

EXPRESS OR IMPLIED WARRANTIES, INCLUDING, BUT

NOT LIMITED TO, THE IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR

PURPOSE ARE DISCLAIMED. IN NO EVENT SHALL THE

FOUNDATION OR CONTRIBUTORS BE LIABLE FOR ANY

DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEMPLARY,

OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT

LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS

OR SERVICES; LOSS OF USE, DATA, OR PROFITS; OR

BUSINESS INTERRUPTION) HOWEVER CAUSED AND

ON ANY THEORY OF LIABILITY, WHETHER IN

CONTRACT, STRICT LIABILITY, OR TORT (INCLUDING

NEGLIGENCE OR OTHERWISE) ARISING IN ANY WAY

OUT OF THE USE OF THIS SOFTWARE, EVEN IF

ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.

HC2020EB.GN_TQBJ2081-2_En.fm Page 29 Friday, August 5, 2022 5:05 PM

TQBJ2081

HC2020EB.GN_TQBJ2081-2_En.fm Page 30 Friday, August 5, 2022 5:05 PM

TQBJ2081

For Australia

Panasonic Australia Pty. Limited

ACN 001 592 187 ABN 83 001 592 187

1 Innovation Road, Macquarie Park NSW 2113

www.panasonic.com.au

PRO-031-F11 Issue: 5.0 23-01-2018

If you require assistance regarding warranty conditions or any other enquiries, please visit the

Panasonic Australia website

www.panasonic.com.au or contact by phone on 132 600

If phoning in, please ensure you have your operating instructions available.

THIS WARRANTY CARD AND THE PURCHASE DOCKET (OR SIMILAR PROOF OF PURCHASE)

SHOULD BE RETAINED BY THE CUSTOMER AT ALL TIMES

Panasonic Authorised Service Centres are located in major metropolitan areas and most regional centres of Australia, however,

coverage will vary dependant on product. For advice on exact Authorised Service Centre locations for your product, please telephone

our Customer Care Centre on 132 600 or visit our website and use the Service Centre Locator.

In addition to your rights under this warranty, Panasonic products come with consumer guarantees that cannot be excluded under

the Australian Consumer Law. If there is a major failure with the product, you can reject the product and elect to have a refund or to

have the product replaced or if you wish you may elect to keep the goods and be compensated for the drop in value of the goods.

You are also entitled to have the product repaired or replaced if the product fails to be of acceptable quality and the failure does not

amount to a major failure.

If there is a major failure in regard to the product which cannot be remedied then you must notify us within a reasonable period by

contacting the Panasonic Customer Care Centre. If the failure in the product is not a major failure then Panasonic may choose to

repair or replace the product and will do so in a reasonable period of time from receiving notice from you.

Subject to the conditions of this warranty Panasonic or its Authorised Service Centre will perform necessary service on the product,

without charge for parts or labour, if in the opinion of Panasonic the product is found to have a manufacturing defect within

one (1) year or (12 months) (the “warranty period”) from the date of purchase appearing on your purchase receipt.

This warranty only applies to Panasonic products purchased in Australia and sold by Panasonic Australia, it’s Authorised

Distributors, or Dealers, and only where the products are used and serviced within Australia or its territories. Warranty cover only

applies to the services that are carried out by a Panasonic Authorised Service Centre and only if valid proof of purchase is presented

when the warranty service is requested.

This warranty only applies if the product has been installed and/or used in accordance with the manufacturer’s recommendations

(as noted in the operating instructions) under normal use and reasonable care (in the opinion of Panasonic). The warranty does not

cover damage, malfunction or failure resulting from use of incorrect voltages, incorrect installation, accident, misuse, neglect,

build-up of dirt or dust, abuse, maladjustment of customer controls, mains supply problems, thunderstorm activity, infestation by

insects or vermin, tampering or repair by unauthorised persons (including unauthorised alterations), exposure to abnormally

corrosive conditions, or any foreign object or matter having entered the product.

This warranty does not cover the following items unless the fault or defect existed at the time of purchase:

(a) Consumable parts

(b) Cosmetic parts

(d) Information stored on Hard Disk Drives, Optical Discs, USB Devices, SD Cards, Tapes

(e) DTV reception issues caused by TV Aerial / Cabling / Wall socket(s)

Some products may be supplied with Ethernet connection hardware. The warranty is limited on such products and will not cover:

(a) Internet and or DLNA connection / setup related problems

(b) Access fees and or charges incurred for internet connection

(d) Any indirect or consequential costs associated with the incorrect use or misuse of the hardware, its connection to

the internet or any other device.

To claim warranty service, when required, you should:

&RQWDFW3DQDVRQLF¶V&XVWRPHU&DUH&HQWUHRQIRU6HUYLFH&HQWUHLQIRUPDWLRQ

&RQILUPWKHRSHQLQJDQGDFFHSWDQFHWLPHVZLWKWKH$XWKRULVHG6HUYLFH&HQWUHWKDW\RXFKRRVH

7KHQVHQGRUWDNHWKHSURGXFWWRD3DQDVRQLF$XWKRULVHG6HUYLFH&HQWUHWRJHWKHUZLWK\RXUSURRIRISXUFKDVH

receipt.

$Q\IUHLJKWDQGLQVXUDQFHFRVWVDVVRFLDWHGZLWKWKHWUDQVSRUWRIWKHSURGXFWWRDQGRUIURP\RXUQHDUHVW$XWKRULVHG6HUYLFH

Centre must be arranged and paid for by you.

The warranties hereby conferred do not extend to, and exclude, any costs associated with the installation, de-installation or

re-installation of a product, including costs related to the mounting, de-mounting or remounting of any screen, (and any other

ancillary activities), delivery, handling, freighting, transportation or insurance of the product or any part thereof or replacement of

and do not extend to, and exclude, any damage or loss occurring by reason of, during, associated with, or related to such

installation, de-installation, re-installation or transit.

Panasonic Warranty

HC2020EB.GN_TQBJ2081-2_En.fm Page 31 Friday, August 5, 2022 5:05 PM

Panasonic Entertainment & Communication Co., Ltd.

Web Site: https://www.panasonic.com

Disposal of Old Equipment and Batteries

Only for European Union and countries with

recycling systems

These symbols on the products, packaging,

and/or accompanying documents mean that

used electrical and electronic products and

batteries must not be mixed with general

household waste.

For proper treatment, recovery and recycling

of old products and used batteries, please

take them to applicable collection points in

accordance with your national legislation.

By disposing of them correctly, you will help

to save valuable resources and prevent any

potential negative effects on human health

and the environment.

For more information about collection and

recycling, please contact your local

municipality.

Penalties may be applicable for incorrect

disposal of this waste, in accordance with

national legislation.

Note for the battery symbol (bottom symbol):

This symbol might be used in combination

with a chemical symbol. In this case it

complies with the requirement set by the

Directive for the chemical involved.

TQBJ2081-2

L0318CH3082

Manufactured by:

Importer for UK:

Authorized Representative in

Europe:

Panasonic Entertainment & Communication Co., Ltd.

1-10-12 Yagumo-higashi-machi, Moriguchi City,

Osaka 570-0021, Japan

Panasonic UK, a branch of

Panasonic Marketing Europe GmbH

Maxis 2, Western Road, Bracknell,

Berkshire, RG12 1RT

Panasonic Marketing Europe GmbH

Panasonic Testing Centre

Winsbergring 15, 22525 Hamburg, Germany

HC2020EB.GN_TQBJ2081-2_En.fm Page 32 Friday, August 5, 2022 5:05 PM

Panasonic SC-HC2020EBK Micro Hifi System Google Chromecast Built-in

Product's Documents

SC-HC2020EBK Operating Instructions

Specifications

Panasonic SC-HC2020EBK Questions and Answers
