Car Refrigerator
SKU：CFY-45/CFY-65
Instruction Manual
Congratulations
Dear Customer:
Welcome to the Euhomy family. Thank you for purchasing one of our products.
Our goal is to provide you with superior service. If there is anything missing from or wrong with
your order, or if you have any questions about using our fridge, PLEASE contact us.
Email: [email protected]
Facebook: @Euhomy.Official
The Euhomy team is available 24/7 to address your questions, comments, and concerns. Your
satisfaction is our ultimate goal. We want to make everything right so you'll share your positive
experience with other shoppers on Amazon.
If you experience any problems, please send an email to [email protected].
Our mission:
* To be the most trusted appliance brand.
* To create practical, compact appliances that better your life.
Be sure to register at
www.euhomy.com/register
for updates, warranty, and other relevant information.
Contents
GETTING STARTED 05-06
DESCRIPTION 04
SAFETY INFORMATION 02
DATA SHEET 03
08
OPERATION OF CFY-45
FAULTS
09-10
OPERATION OF CFY-65
11
VIP Service 12
APPLICATIONS
07
01
02
SAFETY INFORMATION
Please read this operating manual carefully before starting the appliance. Keep it in a safe place for
future reference. If the appliance is passed on to another person, this instruction manual must be handed
over to the user along with it.
The manufacturer cannot be held liable for damage resulting from improper usage or incorrect operation.
WARNING
● This appliance is not intended for use by persons (including children) with reduced physical, sensory
or mental capabilities, or lack of experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible for their safety.
● Children should be supervised that they do not play with the appliance.
● Cleaning and user maintenance shall not be carried out by children without supervision.
● Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
● Do not use this appliance near direct heat sources, for example, a cooker, radiator or exposing it to
direct sunlight.
● The appliance shall not be exposed to rain. Place the refrigerator on a dry, protected surface, away
from edges.
● Do not use an extension cord.
NOTICE
● No responsible for the damage by ignoring the safety instructions EUHOMY.
● The use of accessories that are not recommended by EUHOMY can cause injuries and will
invalidate any warranty that you may have.
● Place the products so that they do not collide against each other or break when the appliance is in
motion.
● If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
● Disconnect the power cable from the plug before carrying out any maintenance.
● Do not place carbonated drinks and gaseous drinks under 0°C(32°F) in this appliance.
INTENDED TO USE
This appliance is intended to be used in household and similar applications such as:
● Staff kitchen areas in shops, offices and other working environments;
● Farm houses and by clients in hotels, motels and other residential type environments;
● Bed and breakfast type environments;
● Catering and similar non-retail applications.
CAUTION
● Keep ventilation openings, clear of obstruction in the appliance enclosure or in the built-in structure.
● Do not use electrical appliances inside the food storage compartments of the appliance, unless they
are of the type recommended by EUHOMY.
● Do not place ice or liquids which are not sealed in containers within the refrigerator.
● Do not place hot products or hot food in this appliance.
CORRECT DISPOSAL OF THIS PRODUCT:
To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle
it responsibly to promote the sustainable reuse of material resources. To return your used device, please
use the recovery systems or contact the retailer that they can take this product for environmental safe
recycling.
● Risk of child entrapment.
Before you throw away your old refrigerator or freezer:
● Take off the doors.
● Leave the shelves in place so that children may not easily climb inside.
DANGER:
03
DATA SHEET
External dimensions
Net weight
Installed power
Supply voltage
R513A
R513A
C-pentane
Metal cabinet
Temperature setting
Refrigerant gas
Insulation
Shell material
-20℃ to +20℃(-4℉to+68℉)
-20℃ to +20℃(-4℉to+68℉)
SINGLE ZONE
CFY-45
DC 12V/24V , AC 100-240V
85W
External dimensions
Net weight
Installed power
Supply voltage
C-pentane
Metal cabinet
Temperature setting
Refrigerant gas
Insulation
Shell material
DC 12V/24V , AC 100-240V
85W
22 Kg
CFY-65
DUAL ZONE
29.5 Kg
845x495x495 mm
717x410x489 mm
04
DESCRIPTION
2
05
GETTING STARTED
Installation
Please check whether the parts of Fridge/Freezer are complete after unpacking.
Note:
Place the unit in a dry place which is protected against splashing water. Do not place directly adjacent to
sources of heat (heating, gas ovens, hot water, pipes or under the blazing sun).
The normal operation of the appliance requires heat to be radiated away from the condenser located at the
end of the cabinet. Adequate airflow is required around the compressor at all times. (Fig. 1).
The cooling system has been designed to operate correctly when the appliance is positioned on angles up
to 30 degrees. It is recommended that the time the of unit is exposed to angles over 30 degrees is limited
to a maximum of four (4) hours continuous operation.
Application and Operative Cooling Range
The cooling compartment has varying temperature zones. The values indicated on the digital display are
related to the middle of the cabinet. The Single Zone Fridge/Freezer is designed to either refrigerate or
freeze food. The Flexi Zone Fridge/Freezer can be used as either a fridge or a freezer or both
Fig. 1
simultaneously. The Fridge/Freezer may be used for outdoor, use such as for camping purposes.If you
wish to refrigerate medicines, first ensure the Fridge/Freezer’s cooling capacity meets the demands of
the respective medicines.The Fridge/Freezer is designed to operate in ambient temperatures from -20℃
to +20℃(-4℉ to +68℉) in a maximum air humidity of 90%.
The Fridge/Freezer is designed to operate on AC or DC voltage.
●
AC input 100-240V AC at 50/60Hz (e.g. electrical power point)
●
DC input 12V or 24V DC (e.g. car cigarette lighter or car battery)
●
The power supply automatically switches the Fridge/Freezer to mains operation when connected
to 100-240V mains power, even if the 12V/24V DC power cable is connected.
●
If the Fridge/Freeze is operating when the vehicle ignition switched OFF, the Fridge/Freezer
will switch OFF automatically when the power source voltage falls below the Battery Monitor
cut-out setting.
●
The Fridge/Freezer will automatically switch back ON when the vehicle is re-started and the
power source voltage reaches the Battery Monitor cut-in setting.
Power Requirements
06
GETTING STARTED
IMPORTANT:
●
If a DC extension cable is required we recommended use of a 6mm dia. (AWG11) 4.58mm Twin
Sheath Two Core cable with direct connection to the positive and negative battery terminals with
15A inline fuse protection.
●
The Fridge/Freezer is equipped with an electronic control system that will prevent polarity reversal.
In the event that the battery connection is reversed the unit will not start or operate. The power
input socket is fitted with a 15A blade fuse for protection.
2
●
Plug the 12V/24V DC power cable into the DC POWER socket (as circled) on the end of the Fridge/
Freezer and then connect to the vehicle cigarette lighter socket or suitable 12V or 24V DC power source.
●
The Fridge/Freezer will automatically turn on, there is no requirement to switch the appliance on.
●
The display will automatically show the current internal cabinet temperature.
●
For optimum performance and efficiency, it is important that the Fridge/Freezer has a reliable DC power
source. It is recommended that connect the battery in directly and reduce the risk of voltage dropping to
the appliance.
●
Use only the 3.5m DC power cable supplied with the Fridge/Freezer.
Operating your Fridge/Freezer with 12/24V DC
12/24V DC Power Requirements
If your Fridge/Freezer is cutting out prematurely, it could be due to:
1.The low voltage protection being set too high on the Battery Monitor.
2.DC power cable and/or connections are not suitable to carry the required current. Check the
power cable and all connections and adjust the Battery Monitor on the control panel.
● The Fridge/Freezer is equipped with a multi-level Battery Monitor that protects your vehicle
batteryagainst excessive discharging when the Fridge/Freezer is connected to 12V or 24V DC power
source.
NOTE: It is important that the correct cable size and gauge is used for the installation of the DC supply
as over distance the voltage can decrease if the incorrect cable size and gauge cable is being
used.
●
Always consult a qualified automotive electrician when using a DC extension cable.
IMPORTANT:
When using the Fridge/Freezer with DC power supply, we recommended setting the Battery Monitor to
LOW (L).
NOTE: A battery charger may only be connected to the battery when the Fridge/Freezer has been
disconnected from the DC power source.
● Over-voltage may cause damage to the electronics of the Fridge/Freezer.
● Your Fridge/Freezer is equipped with reverse polarity protection. It protects your Fridge/Freezer against
reverse battery connection and short circuit.
● As a protection for your battery, the Fridge/Freezer switches OFF automatically if the power source
voltage is insufficient.
07
GETTING STARTED
FAULTS
● Plug the 100-240VAC power cable into the AC POWER socket (as circled below) on the end of the
Fridge/Freezer and then connect to a suitable 100-240V AC power source.
● Keep pressing the ON/OFF button for 3 seconds to switch the appliance on.
● The display will automatically show the current internal cabinet temperature.
● The Fridge/Freezer is equipped with a multi-voltage internal power supply with priority circuit for connecting
to an AC voltage power source of 100-240V.
● The power input socket is fitted with a 15A blade fuse for protection.
Operating your Fridge/Freezer with 100-240V AC
CAUTION: Do not touch cables, plugs or switches with wet hands or when your feet are in contact
with water! If you operate your Fridge/Freezer on board a boat by means of a shore
connection to a 100-240V AC power source, the power connection must include an earth
leakage RCD residual current device.
DC Power Cable
AC Power Cable
When there is error for the fridge, there will be code on the display. The possible error for each code would
be as follows
ERROR
CODE
ERROR TYPE
E1
E2
Fan error/Short circuit/ Frequently start and stop.
E3
E4
The motor speed of the compressor is too low (the refrigeration system is overloaded, the motor
cannot maintain the minimum speed of 1850r/min)
E5
LL
HH
NTC open circuit .
NTC short circuit.
The low battery protection mode take effect (the input voltage is lower than set value)
Compressor motor start error (Motor block or refrigeration system pressure difference is too large.)
Temperature too high or too low to protect the compressor control module (when the environment
temperature is too high or too low, or system load is too large, causing module/ECU internal
temperature 100 °C > or < - 10 °C)
08
OPERATION OF CFY-45
ECO/MAX Function
Power-off and on
Cabinet Temperature-Setting
Battery Monitor- Setting
22.7V
23.7V
25.7V
21.3V
22.3V
24.3V
9.6V
10.1V
11.1V
11.4V
12.4V
10.9V
Temperature Conversion
1. When the fridge is switched off: keep press on ‘ ’ button for 3 s to turn on.
2. When the fridge is switched on: keep press on ‘ ’ button for 3s to switch off the appliance.
1. Press the ‘ ’ button once, the temperature display will be flash.
2. Press the up ‘ ’ button or down ‘ ’ button to set the temperature accordingly.
Press the ‘ ’ button twice times, ‘ECO or MAX’ will be flash (The selected mode flashes, Default -
Max), press the up ‘ ’ button or down ‘ ’ button choose MAX or ECO accordingly.
The selected function will continue to flash for 3 to 5 seconds
Press the ‘ ’ button three times, ‘BATTERY PROTECTION’ (L or M or H) will be flash (The selected
mode flashes, Default - H), press the up ‘ ’ button or down ‘ ’ button until the desired setting is
shown.
In the standby state, press and hold ‘ ’ 3s to enter the menu function setting. After entering the menu,
press ‘ ’ 3 to enter the cycle of compensation temperature setting F1/F2/F3/C-F, and then press ‘ ’
or ‘ ’ to enter the parameter setting and temperature conversion（°C or F）accordingly.
09
OPERATION OF CFY-65
10.1V
11.1V
11.4V
12.4V
Power-off and on
ECO/MAX Function
Battery Monitor- Setting
22.7V
23.7V
25.7V
21.3V
22.3V
24.3V
9.6V 10.9V
Temperature Conversion
1. When the fridge is switched off: keep press on ‘ ’ button for 3 s to turn on.
2. When the fridge is switched on: keep press on ‘ ’ button for 3s to switch off the appliance.
Press the ‘ ’ button three times, ‘ECO or MAX’ will be flash (The selected mode flashes, Default
- Max), press the up ‘ ’ button or down‘ ’ button choose MAX or ECO accordingly.
The selected function will continue to flash for 3 to 5 seconds.
Press the ‘ ’ button four times, ‘BATTERY PROTECTION’ (L or M or H) will be flash (The selected
mode flashes, Default - H), press the up button or down button until the desired setting is shown.
In the standby state, press and hold ‘ ’ 3s to enter the menu function setting. After entering the
menu, press ‘ ’ 3 to enter the cycle of compensation temperature setting F1/F2/F3/C-F, and then
press ‘ ’ or ‘ ’ to enter the parameter setting and temperature conversion（°C or F）accordingly.
10
OPERATION OF CFY-65
.
.
Cabinet Temperature-Setting
Setting the left zone
Setting the right zone
Shutting Down a Selected Zone
1.Press the mode button once (1) and
the temperature display will flash with the
current setting.
2.Adjust the temperature by pressing up
to increase and down to decrease until
the selected temperature is reached.
3.The selected temperature will flash on the
display for 3 to 5 seconds before displaying
the current temperature .
1.Press the mode button twice (2) and
the temperature display for the right zone will
flash with the current setting.
2.Adjust the temperature by pressing up
to increase and down to decrease until
the selected temperature is reached.
3.The selected temperature will flash on the
display for 3 to 5 seconds before displaying
the current temperature .
The Flexi Zone + cooling system will allow either
zone to be shut down independently to the other.
This is perfect for when the total cabinet space
is not required and provides improved power
efficiencies.
The temperature may be set independently for each zone in the range -20℃ to 20℃(-4℉ to +68℉) .
1.Press and hold the up button 5s and the left
zone will shut down.
2.Repeat the same step and the left zone will
recommence operation.
3.Press and hold the down button 5s and the
right zone will shut down.
4.Repeat the same step and right zone will
recommence operation.
11
APPLICATIONS
By keeping a battery on hand, you can ensure that the refrigerator maintains its
set temperature in any situation.
When storing ice cream, please set the refrigerator to the lowest tempera-
ture and keep the power on constantly.
Prevent health problems from bottled water deterioration caused by high
temperatures.
Keep fresh or frozen foods—even luxurious seafood—safe during long trips.
Your car refrigerator effectively preserves the freshness of tea leaves. You can
enjoy fresh and delicious tea anytime during your road trip.
The ideal storage temperature for red wine is 50 -64 .
The precise temperature control of your Euhomy car refrigerator guarantees
the proper storage temperature.
Fruits will not keep in a hot car for more than 2 hours, even with the air condi-
tioning running. But your car refrigerator can keep fruit fresh for a long time.
Did you know? The coating on some sunglasses will peel off at high tempera-
tures! Your car refrigerator is the best place to store your sunglasses.
Cosmetics easily melt and go bad at high temperatures. Keep makeup and other
beauty products fresh and safe in your car refrigerator.
VIP Service
13
1. Search for "QR Code" on Facebook.
2. Scan the attached QR Code.
3. Become a member of the group.
4. Activate your warranty in the pinned post.
1. Go to Settings in mobile WhatsApp and tap on the QR icon next to your name.
2. Scan the attached QR Code.
3. Become a member of the group.
4. Your warranty is now active.
Email：support@euhomy.com
Facebook：@Euhomy.Official
