7084 159-00
WKEgb 582, WKEgw 582
Operating instructions Page 10
Wine storage cabinet
Read the operating instructions before switching on for the rst time
EN
10
Description of the appliance
Disposal notes
The appliance contains reusable materials and should
be disposed of properly - not simply with unsorted
household refuse. Appliances which are no longer
needed must be disposed of in a professional and
appropriate way, in accordance with the current local
regulations and laws.
When disposing of the appliance, ensure that the refrigerant circuit
is not damaged to prevent uncontrolled escape of the refrigerant
it contains (data on type plate) and oil.
• Disable the appliance.
• Pull out the mains plug.
• Cut through the connection cable.
WARNING
Danger of suocation due to packing material
and plastic lm!
Do not allow children to play with packaging
material.
Take the packaging material to an ocial collec-
tion point.
Content
Description of the appliance ...................................................10
Disposal notes ........................................................................10
Safety instructions and warnings ........................................... 11
Range of appliance use .......................................................... 11
EPREL database .................................................................... 11
Climate rating .........................................................................12
Setting up ...............................................................................12
Electrical connection ..............................................................12
Door opening mechanism (TipOpen) .....................................12
Operating and control elements ............................................. 13
Switching the appliance on and o ........................................13
Setting the temperature .......................................................... 13
Storing wine ............................................................................ 14
Door open alarm ..................................................................... 14
Temperature alarm ................................................................. 14
Fan .........................................................................................14
Child lock ................................................................................14
Interior light .............................................................................15
Storage diagram .....................................................................15
Air exchange with activated charcoal lter ............................. 16
Cleaning .................................................................................16
Malfunctions ...........................................................................17
Shutting your appliance down ................................................ 17
Activated charcoal lter
Operating and control elements
Bottle shelf
The bottle shelf is removable. The
type plate is located below the
bottle shelf.
Interior light
(LED light strip)
Pull-out shelves
CAUTION
Danger of damage or injury.
Do not weigh down the door when it is open.
11
EN
Safety instructions and warnings
• To prevent injury or damage to the unit, the ap-
pliance should be unpacked and set up by two
people.
• In the event that the appliance is damaged on
delivery, contact the supplier immediately before
connecting to the mains.
• To guarantee safe operation, ensure that the ap-
pliance is set up and connected as described in
these operating instructions.
• Disconnect the appliance from the mains if any
fault occurs. Pull out the plug, switch off or remove
the fuse.
• When disconnecting the appliance, pull on the
plug, not on the cable.
• Any repairs and work on the appliance should
only be carried out by the customer service
department, as unauthorised work could prove
highly dangerous for the user. The same applies
to changing the mains power cable.
• Do not allow naked flames or ignition sources
to enter the appliance. When transporting and
cleaning the appliance, ensure that the refrigerant
circuit is not damaged. In the event of damage,
make sure that there are no ignition sources
nearby and keep the room well ventilated.
• Do not stand on the plinth, drawers or doors or
use them to support anything else.
• This appliance can be used by children of 8 years
old and over, and also by persons with restricted
physical, sensory or mental capacity or lack of
experience and knowledge, if they are supervised
or have been instructed on safe use of the appli-
ance and understand the resulting risks. Children
must not be allowed to play with the appliance.
Cleaning and user maintenance must not be
carried out by children without supervision.
• Avoid prolonged skin contact with cold surfaces or
chilled/frozen food. This could cause pain, numb-
ness and frostbite. In the case of prolonged skin
contact, protective measures should be taken,
e.g. gloves should be worn.
• Do not consume food which has been stored for
too long, as it could cause food poisoning.
• Do not store explosives or sprays using com-
bustible propellants such as butane, propane,
pentane, etc. in the appliance. Electrical com-
ponents might cause leaking gas to ignite. You
may identify such sprays by the printed contents
or a flame symbol.
• Do not use electrical appliances inside the ap-
pliance.
• The appliance is designed for use in enclosed
areas. Do not operate the appliance outdoors or
in areas where it is exposed to splash water or
damp conditions.
• The LED light strips illuminate the interior of the
appliance. They are not suitable for lighting a
room.
• When transporting or operating the appliance at
an altitude of more than 1500 m above sea level,
the glass pane in the door can break due to the
reduction in air pressure. Broken fragments are
sharp-edged and can cause serious injury.
Range of appliance use
The appliance is suitable solely for storing wine in
a domestic environment or similar. This includes,
for example, use
- in staff kitchenettes, bed and breakfast establish-
ments,
- by guests in cottages, hotels, motels and other
forms of accommodation,
- in catering and similar services in the wholesale
trade.
Use the appliance solely as is customary within a domestic en-
vironment. All other types of use are inadmissible.
The appliance is not suitable for storing and cooling medicines,
blood plasma, laboratory preparations or similar substances and
products covered by the 2007/47/EC Medical Devices Directive.
Any misuse of the appliance may result in damage to or spoilage
of stored goods.
Furthermore, the appliance is not suitable for operation in poten-
tially explosive atmospheres.
EPREL database
As from 1 March 2021, information about energy labelling and
ecodesign requirements will be available in the European product
database (EPREL). You can access the product database using
the following link: https://eprel.ec.europa.eu/. You will be asked
to enter the model identier. You will nd the model identier on
the type plate.
12
Setting up
• Avoid positioning the appliance in direct sunlight or near cookers,
radiators and similar sources of heat.
• Do not cover ventilation openings
or grille.
• Standard EN 378 specifies that the room in
which you install your appliance must have
a volume of 1 m
3
per 8 g of R 600a refriger-
ant used in the appliance, so as to avoid the
formation of inflammable gas/air mixtures in
the room where the appliance is located in the
event of a leak in the refrigerant circuit. The
quantity of refrigerant used in your appliance
is indicated on the type plate on the inside of
the appliance.
Electrical connection
Only operate the appliance with alternating current (AC).
The permissible voltage and frequency are indicated on the type
plate. The position of the type plate is shown in the section entitled
Description of the appliance.
The socket must be properly earthed and protected by a fuse.
The tripping current of the fuse must be between 10 A and 16 A.
The socket must not be situated behind the appli-
ance and must be easily accessible.
Do not connect the appliance using an exten-
sion cable or extension socket.
Do not use stand-alone inverters (conversion
of direct current to alternating/three-phase
current) or energy-saving plugs. Risk of dam-
age to the electronic control system!
Climate rating
The climate rating indicates the room
temperature at which the appliance may
be operated in order to achieve full refrig-
eration performance.
The climate rating is indicated on the
type plate.
The position of the type plate is shown in the section entitled
Description of the appliance.
Climate rating Room temperature
SN +10°C to +32°C
N +16°C to +32°C
ST +16°C to +38°C
T +16°C to +43°C
SN-ST +10°C to +38°C
SN-T +10°C to +43°C
Do not operate the appliance outside the
specied room temperature range.
Door opening mechanism (TipOpen)
The TipOpen function is disabled when the appliance is deliv-
ered.
The TipOpen function must be enabled after installation in the
recess by pressing the On/O button, see Installation instruc-
tions.
Opening the door
Push the door slightly inwards on the top left-hand side and
release again.
The door is opened approx. 5 cm by the push rod.
The door can then be fully opened.
Note
The door will close again automatically after approx. 3 seconds
if it has not been fully opened.
Note on door opening cycles
I f t h e d o o r i s c l o s e d , i t c a n o n l y b e o p e n e d a g a i n u s i n g t h e T i p O p e n
function after 3 seconds.
13
EN
Switching the appliance on and o
Switching the appliance on
Press the On/O button until the temperature display
lights up.
Switching the appliance o
Keep the On/O button pressed for approx. 3 seconds so that
the temperature display goes out.
Setting the temperature
Increasing the temperature
Press the Up button.
Reducing the temperature
Press the Down button.
- When pressing one of the buttons for the first time, the display
will start to flash.
- Pressing this button again enables you to change the temperature
setting.
- The electronic control system will switch over automatically about
5 seconds after the last time you pressed the button, and the
actual temperature will be displayed.
The temperature can be set at between +5°C and +20°C.
Operating and control elements
The electronic control panel has the new "touch capacitance
technology". Any function can be activated by touching the
corresponding icon.
The exact contact point is
between the symbol and its label
(1)
Temperature display
(2)
Temperature setting buttons
(3)
On/Off button
(4)
Audible warning On/Off button
(5)
Fan button
(6)
Interior light On/Off button
Symbols in the display
Alarm (symbol flashes if the temperature inside the appli-
ance is too high or too low)
Demo mode is activated
Setup mode is activated (activating the child lock)
The interior fan runs constantly
Child lock is activated
The interior light is switched on constantly
Important notes
Do not operate the appliance near magnetic elds or
place magnetic objects near the appliance.
The door may otherwise open when you do not want
it to.
Do not block the door or hold on to it while it is
opening.
If the door is blocked or held open during opening, the internal
safety coupling will be activated.
Loud, repeated cracking noises will be heard.
Do not push the push rod
in or hold on to it during
closing.
If the push rod is blocked during
closing, it will no longer be able to
reach its initial position.
In the initial position, the push rod is ush with the front of the
appliance.
Setting the push rod back in its initial position
Disconnect the appliance from the mains, wait for approx.
5 seconds and plug it back in again.
The push rod returns to its initial position.
Do not weigh down the door
when it is open.
14
Fan
The interior fan ensures a constant and even interior temperature
and a suitable climate for wine storage.
When activating the Ventilation button, the humid-
ity in the appliance is further increased, which has
a particularly positive eect for long-term storage.
The increased level of humidity prevents the corks from drying out.
Note
If the appliance is operated in a low ambient temperature, the fan
may also run when the fan function is deactivated.
Child lock
The child lock is designed to protect the appliance from being
switched o and the temperature setting from being changed
accidentally.
Activating the child lock
Press for 5 seconds. Display =
Display =
Display =
Display =
Deactivating the child lock
Press for 5 seconds. Display =
Display =
Display =
Display =
Door open alarm
If the door is left open for more than 60 seconds, the audible
warning signal will sound.
If the door must be opened for a lengthy period to place
items into the appliance, cancel the audible warning
signal by pressing the Alarm button.
The alarm switches back to standby when the door is shut.
Temperature alarm
If the temperatures in the interior are out of the permitted range,
the audible warning signal will sound and the temperature display
will ash.
• Cancel the audible warning signal by pressing the Alarm button.
The temperature display will stop ashing as soon as the tem-
perature in the interior has reached the set value.
Temperature alarm after a fault in the appliance
If the appliance develops a fault, the temperature in the interior
may rise too high or fall too low. The audible warning signal will
sound and the temperature display will ash.
• Cancel the audible warning signal by pressing the Alarm button.
If the temperature display continues to show a value that is too high
or too low after one hour, contact the customer service department.
If F1 appears in the display, the appliance has suered a fault. In
this case, contact the customer service department.
Storing wine
If you are storing wine for long periods of time, it should be stored
at a temperature of between 10°C and 14°C.
This is the temperature wine cellars are kept at, and it is just right
to allow wine to mature properly.
The following drinking temperatures are recommended for the
various types of wine.
Red wines: +14°C to +18°C
Rosé wines: +10°C to +12°C
White wines: +8°C to +12°C
Sparkling wines, Prosecco: +7°C to +9°C
Champagne: +5°C to +7°C
15
EN
Storage diagram
for 0.75 l Bordeaux bottles to standard NF H 35-124
Important
The maximum load per wooden shelf is 25 kg.
The storage pattern shown above is only possible
with the specied bottle size.
Taller bottles must be stored crossways since
otherwise the bottles will collide with the
appliance door.
Interior light
The interior light will always switch on when the appliance door
is opened.
The interior light will go out approx. 5 seconds after the door is
closed.
Press the Light button if you want the interior light to be
on even when the door is closed.
Furthermore, the brightness of the lighting can be adjusted.
• Press the Light button.
• Press and hold the Light but-
ton and at the same time press
the temperature setting but-
tons to increase or decrease
the brightness.
The light intensity of the LED light corresponds to laser
class 1/1M.
Important
The light cover may only be
removed by customer service
sta.
If the cover is removed, do not
l o o k d i r e c t l y a t t h e l i g h t t h r o u g h
optical lenses from close dis-
tance. This can damage your
eyes.
Lighting
Class
1
Light source
This product contains a light source that
meets energy eciency rating G
LED
1
The appliance may contain light sources with dierent
energy eciency classes. The lowest energy eciency class
is indicated.
16
Cleaning
B e f o r e c l e a n i n g , a l w a y s s w i t c h o t h e a p p l i a n c e . D i s c o n n e c t
from the mains or switch o or unscrew the fuse.
The wooden shelves can be removed for easier cleaning of the
inside of the appliance.
• Raise the appropriate shelf and
remove it towards you.
• Take the bottle shelf off the interior
floor.
• Clean the inside with lukewarm
water and a little detergent.
Do not use abrasive or acid cleaners or chemical solvents.
• Clean the glass front in the appliance door with a glass cleaner.
CAUTION
Risk of damage to the appliance components
and risk of injury due to hot steam.
Do not use steam cleaning equipment to clean
the appliance.
• Ensure that no cleaning water penetrates into the elec trical
components.
• Clean the pull-out rails with a
slightly dampened cloth only.
No cleaning water must be
allowed to get into the pull-out
rail guides.
• Do not damage or remove the
type plate on the inside of the
appliance. It is very important for
servicing purposes.
The position of the type plate is shown in the section entitled
Description of the appliance.
Inserting the wooden shelves
• Fully slide in the pull-out
rails.
Place the wooden shelf
on the pull-out rails from
above.
Air exchange with activated charcoal lter
The way in which wines continue
to mature depends on the ambient
conditions.
The quality of the air is therefore
decisive for preserving the wine.
We recommend that you replace
the illustrated lter once a year.
Filters can be obtained from your
dealer.
Changing the lter
• Push the filter in and release it
again.
• Pull out the filter.
• Remove the back part of the
filter.
• Fit the new filter to the cover.
• Insert the filter, push it in as far
as it will go and then release it
again.
The filter is automatically locked
into place.
You will hear a click.
17
EN
Malfunctions
• F1 appears in the display.
– The appliance has suffered a fault. Contact the customer service
department.
• The fans inside the appliance are running although the
fan function has been deactivated and the compressor
(refrigeration unit) is idle.
– This is a normal operating state depending on the set interior
temperature and ambient temperature at the place of installation.
• When inserting the mains plug, the refrigeration unit does
not switch on, but a value is shown in the temperature
display.
– Demo mode is activated.
Contact the customer service department.
You may be able to rectify the following faults by checking
the possible causes yourself.
• Appliance does not function:
– Is the appliance switched on?
– Is the plug correctly fitted in the mains socket?
– Is the fuse intact?
• Loud running noise:
– Is the appliance set up firmly on the floor?
– Does the appliance cause nearby items of furniture or objects to
vibrate? Please note that noises caused by the refrigerant circuit
cannot be avoided.
• The temperature is not low enough:
– Is the temperature setting correct (see "Setting the temperature")?
– Does the separately installed thermometer show the correct
reading?
– Is the ventilation system working properly?
– Is the appliance set up too close to a heat source?
If none of the above causes
apply and you cannot rectify
the fault yourself, contact the
nearest customer service de-
partment stating the type des-
ignation
(1)
, service number
(2)
and appliance number
(3)
as
indicated on the type plate.
The position of the type plate is shown in the section entitled
Description of the appliance.
Shutting your appliance down
If your appliance is to be shut down for any length of time, switch
it o and disconnect the plug or switch o or unscrew the fuse.
Clean the appliance and leave the door open in order to prevent
unpleasant smells.
The appliance complies with the relevant safety regulations and
EU Directives 2014/30/EU and 2014/35/EU.
Liebherr Hausgeräte Lienz GmbH
Dr.-Hans-Liebherr-Strasse 1
A-9900 Lienz
Österreich
www.liebherr.com
