LED GLASS POOL LIGHT
INSTRUCTION MANUAL
INTRODUCTION & WARRANTY
TECHNICAL DATA
Thank you for selecting and buying V-TAC LED product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installing and keep this manual handy for future reference. If you have any other query,
please contact our dealer or local vendor from whom you have purchased the product. They are trained and ready to
serve you at the best.
The warranty is valid for 2 years from the date of purchase. The warranty does not apply to damage caused by incor-
rect installation or abnormal wear and tear. The company gives no warranty against damage to any surface due to
incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily operation. Usage of
product for 24 Hours a day would void the warranty. This product is warranted for manufacturing defects only.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
VT-1258 217555, 217556 8W 800LM AC/DC 12V, 50/60Hz 178x110mm
VT-1268 217558 8W 800LM AC/DC 12V, 50/60Hz 178x110mm
VT-1262 217559, 217560 12W 1260LM AC/DC 12V, 50/60Hz 178x110mm
VT-1263 217562 12W 1260LM AC/DC 12V, 50/60Hz 178x110mm
VT-12118 8024 18W 2000LM AC/DC 12V, 50/60Hz 178x110mm
VT-12125 8025 25W 2850LM AC/DC 12V, 50/60Hz 178x110mm
VT-12135 8026 35W 4100LM AC/DC 12V, 50/60Hz 178x110mm
MODEL WATTS LUMENS INPUT VOLTAGE DIMENSIONSKU
WARNING
INSTALLATION INSTRUCTIONS
1. Install only by certified electrician.
2. Please make sure to turn o the power before starting the installation.
3. The light source of this luminaire is not replaceable, when the light source reaches
its end of life the whole luminaire should be replaced.
4. Proper grounding should be ensured throughout the installation.
1
2
3
STEP 1
Switch o the power. Take out the pool embed-
ded parts, twist o the screws from the lid, and
then take o the lid.
STEP 2
Connect the power output cable of
the embedded parts with the terminals of
the lamp, and then tighten the screws.
STEP 3
Put the lamp into the embedded parts and cover
the lid and tighten the screws. Swtich on the light
and test.
