Liebherr MBSDDI 9024 Plus BioFresh NoFrost 4-Door French User Manual

User Guide

Quality, Design and Innovation

home.liebherr.com/fridge-manuals

Contents

1 Safety information and warnings......................... 3

1.1 Intended use................................................................. 3

1.2 Climate classes............................................................ 3

1.3 User group..................................................................... 3

1.4 Installation and commissioning................................ 3

1.5 Safe handling of the appliance.................................. 4

1.6 Cleaning......................................................................... 4

1.7 Faults, damage and repairs........................................ 4

1.8 Disposal......................................................................... 4

1.9 Conformity..................................................................... 4

1.10 SVHC substances in accordance with the REACH

Regulation..................................................................... 4

1.11 EPREL database........................................................... 4

1.12 Open source licences.................................................. 5

1.13 Spare parts.................................................................... 5

1.14 Symbols on the appliance.......................................... 5

1.15 Warning levels.............................................................. 5

2 Appliance at a glance............................................ 5

2.1 Scope of delivery.......................................................... 5

2.2 Overview of the appliance and equipment.............. 5

2.3 VarioTempZone............................................................. 6

2.4 SmartDevice.................................................................. 6

2.5 Appliance range of use............................................... 6

2.6 Conformity..................................................................... 6

2.7 SVHC substances according to REACH regulation. 6

2.8 EPREL database........................................................... 7

2.9 Spare parts.................................................................... 7

3 Functionality of the Touch&Swipe display......... 7

3.1 Navigation and symbol explanation......................... 7

3.2 Menus............................................................................. 7

3.3 Sleep mode................................................................... 8

4 Putting into operation........................................... 8

4.1 Switching on appliance (first use)............................ 8

4.2 Starting the IceMaker for the first time................... 8

5 Storage.................................................................. 8

5.1 Information regarding storage................................... 8

5.2 Fridge compartment.................................................... 9

5.3 BioFresh......................................................................... 9

5.4 Freezer compartment.................................................. 9

5.5 Storage times............................................................... 10

6 Saving energy........................................................ 11

7 Controls................................................................. 11

7.1 Controls and displays.................................................. 11

7.1.1 Status display............................................................ 11

7.1.2 Display symbols.........................................................11

7.2 Appliance functions..................................................... 11

7.2.1 Notes on the appliance functions.......................... 11

Switching the appliance off and on...................... 11

Switching temperature zone off and on.............. 12

WiFi.............................................................................12

Temperature..............................................................13

Temperature unit......................................................14

BioFresh B-Value......................................................14

SuperCool..................................................................14

SuperFrost.................................................................15

Start defrosting cycle..............................................15

PartyMode ................................................................ 16

HolidayMode............................................................. 16

SabbathMode............................................................17

EnergySaver ............................................................. 17

IceMaker / MaxIce ..................................................18

IceMaker water supply............................................ 19

TubeClean .................................................................19

CleaningMode.......................................................... 20

Display brightness.................................................. 20

H-Value...................................................................... 21

Door alarm.................................................................21

Child lock...................................................................21

Language.................................................................. 22

Appliance and software information....................22

Reminder...................................................................23

Demo mode...............................................................23

Resetting to factory settings.................................24

7.3 Messages...................................................................... 24

7.3.1 Overview of warnings.............................................. 24

7.3.2 Ending warnings....................................................... 24

7.3.3 Overview of reminders.............................................25

7.3.4 Ending reminders......................................................25

8 Features................................................................. 26

8.1 Door rack....................................................................... 26

8.2 Adjustable bottle shelf................................................ 27

8.3 Drawers.......................................................................... 28

8.4 Compartment lid for BioFresh Safe........................... 29

8.5 Glass shelves................................................................ 29

8.6 IceMaker........................................................................ 30

8.7 Egg rack......................................................................... 30

8.8 Bottle holder................................................................. 30

9 Maintenance.......................................................... 30

9.1 FreshAir carbon filter................................................... 30

9.2 Dismantling the door rack.......................................... 30

9.3 Assembling the door rack........................................... 31

9.4 Disassembling / assembling pull-out systems...... 32

9.5 Removing / inserting the variable bottle rack........ 32

9.6 Compartment lid for BioFresh Safe........................... 33

9.7 Defrosting the appliance............................................ 33

9.8 Cleaning the appliance............................................... 33

10 Customer help....................................................... 34

10.1 Technical specifications............................................. 34

10.2 Operating noises.......................................................... 35

2 * Depending on model and options

10.3 Technical fault.............................................................. 35

10.4 Customer Service......................................................... 36

10.5 Model plate................................................................... 37

11 Shutting down....................................................... 37

12 Disposal................................................................. 37

12.1 Preparing the appliance for disposal........................ 37

12.2 Disposing of the appliance in an environmentally

friendly manner............................................................ 37

The manufacturer is continually working on the further

development of all types and models. Please be aware that

we reserve the right to make changes to the shape, equip‐

ment and technology.

Symbol

Explanation

Read instructions

Please read the information in these instruc‐

tions carefully to understand all of the benefits

of your new appliance.

Additional information on the Internet

The digital manual with additional informa‐

tion and in other languages can be found

via the QR code on the front of the

manual or by entering the service number at

home.liebherr.com/fridge-manuals.

The service number can be found on the serial

tag:

Fig.Example illustration

Check appliance

Check all parts for transport damage. If you

have any complaints, please contact your

agent or customer service.

Differences

These instructions apply to a range of models,

so differences are possible. Sections that

apply to certain models only are marked with

an asterisk (*).

Instructions and results

Instructions are marked with a .

Results are marked with a .

Videos

Videos about the appliances are available on

the YouTube channels of Liebherr-Hausgeräte.

Open source licences:

The appliance contains software components that use

open source licences. Information on the open source

licences used can be found here: home.liebherr.com/

open-source-licences

These operating instructions apply to:

MB..i

90..

1 Safety information and warnings

Keep this user information in a safe place so that you can

refer to it at any time.

If you pass on the appliance, pass this user information on

to subsequent owners.

To use the appliance properly and safely, read this user

information carefully before installation and use. Always

follow the instructions, safety instructions and warnings

contained therein. They are important so that you can install

and operate the appliance safely and properly.

1.1 Intended use

This appliance is intended for household use and similar

applications such as:

in staff kitchen areas in shops, offices and other work

areas

in agricultural environments and by guests in hotels,

motels and other accommodation

in bed and breakfasts

in catering and similar wholesale operations

All other types of application are impermissible.

1.2 Climate classes

Depending on its climate class, the appliance is designed

for operation within certain ambient temperature limits. The

climate class for your appliance is printed on the type plate.

Note

► In order to guarantee fault-free operation comply with

the specified ambient temperatures.

Climate class for ambient temperatures from

SN 10°C to 32°C

N 16°C to 32°C

ST 16°C to 38°C

T 16°C to 43°C

SN-ST 10°C to 38°C

SN-T 10°C to 43°C

The appliance is designed for a maximum relative humidity

of 80%. If the appliance is operated at a relative humidity of

more than 80%, the appliance will work, but condensation

will form on the surface of the appliance.

1.3 User group

This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory

or mental capabilities or lack of experience and knowl‐

edge if they have been given supervision or instruction

concerning use of the appliance in a safe way and under‐

stand the hazards involved.

Children must not play with the appliance.

Children must not carry out cleaning and user mainte‐

nance without supervision.

Children aged from 3 to 8 years are allowed to load and

unload refrigerating appliances.

1.4 Installation and commissioning

Only set up and connect the appliance in accordance

with the instructions in the user information.

Do not close the ventilation openings in the appliance

housing or in the installation housing.

Safety information and warnings

* Depending on model and options 3

Do not damage the mains cable. The appliance must not

be operated with a defective mains cable.

Do not place portable multiple sockets or power supply

units at the rear of the appliance.

It must be easy to access the socket so that the appli‐

ance can be quickly disconnected from the power supply

in case of an emergency. It must not be behind the appli‐

ance.

Appliances with anti-tip protection:

Secure the appliance with an anti-tip device in accord‐

ance with the instructions in the user information to

prevent the appliance from tipping over.

Appliances with fixed water connection:

Only connect the fixed water connection to the drinking

water supply to avoid poisoning from contaminated

water.

Only connect the appliance to the drinking water supply

using the new hose set supplied with the appliance. Do

not reuse old hose sets, dispose of them instead.

1.5 Safe handling of the appliance

Do not store any explosive substances, such as aerosol

containers with flammable propellant gas, in the appli‐

ance. These types of aerosol can be identified by the

list of contents printed on it, or by a flame symbol. Any

leaking gas may ignite due to electrical parts.

Keep burning candles, lamps and other objects with

naked flames away from the appliance, so that these do

not set fire to the appliance.

Alcoholic beverages and other containers bearing alcohol

must be sealed tight for storage. Any leaking alcohol may

ignite due to electrical parts.

Avoid prolonged skin contact with cold surfaces or with

cold/frozen food. Use gloves for protection, for example.

The refrigerant contained (information on the type plate)

is environmentally friendly but flammable. Leaking refrig‐

erant may ignite.

•

Do not damage the refrigeration circuit.

•

Do not use any ignition sources inside the appliance.

•

Do not use electrical appliances inside the appliance

(e.g. steam cleaners, heaters).

•

If the refrigerant leaks: remove any naked flames or

ignition sources from the vicinity of the leakage point.

Properly air the room. Inform customer service.

Only open the door for a short time. This prevents the

temperature inside the appliance from rising.

Do not reach between the door and the appliance when

opening and closing. Fingers may become trapped.

The temperature in the warmest part of the appliance

may be higher than the set temperature.

1.6 Cleaning

Regularly clean surfaces that come into contact with

food.

Clean the defrost water drain regularly.

Do not use an electric heater or steam cleaner, naked

flames or defrost spray to speed up the defrosting

process.

Do not remove the ice with sharp objects.

1.7 Faults, damage and repairs

If the mains connection cable of the appliance is

damaged, replace the mains connection cable.

Repairs and interventions on the appliance may only be

carried out by the customer service or by other qualified

personnel trained for this purpose.

In the event of malfunctions and appliance faults, pull

out the mains plug or switch off the fuse. Always hold

the plug when pulling out the mains plug. Never tug on

the cable.

1.8 Disposal

The appliance contains valuable materials and is marked

with the appropriate symbol. (see 1.14 Symbols on the

appliance)

•

Do not dispose of the appliance in the household

waste.

•

Dispose of the appliance free of charge at your

local recycling centre using the Class 1 collection

containers.

•

When purchasing a new appliance, return the old

appliance to the retailer free of charge.

•

Provide information about return options.

Your appliance may contain personal data.

•

Delete personal data before disposal.

The appliance contains refrigerant (information on the

type plate) and oil. The refrigerant inside the appliance

is environmentally friendly, but flammable. The oil it

contains is also flammable. Escaping refrigerant and oil

can ignite in high concentrations and in contact with an

external heat source.

•

Do not damage the refrigeration circuit.

•

Only dispose of the appliance in accordance with the

instructions in the user information.

1.9 Conformity

The coolant circuit has been tested for leak-tightness. The

appliance complies with the relevant safety regulations and

directives.

For the EU

market:

The appliance complies with Directive

2014/53/EU.

For GB market: The appliance complies with the Radio

Equipment Regulations 2017 SI 2017 No.

1206.

The full text of the EU Declaration of Conformity is available

at the following web address: www.liebherr.com

The BioFresh compartment fulfils the requirements of a

chiller compartment in accordance with DIN EN 62552:2020.

1.10 SVHC substances in accordance

with the REACH Regulation

You can use the following link to check whether your appli‐

ance contains SVHC substances in accordance with the

REACH Regulation:

home.liebherr.com/en/en/liebherr-experience/sustaina‐

bility/environment/scip/scip.html

1.11 EPREL database

From 1 March 2021, the information on energy labelling and

eco-design requirements will be available in the European

product database (EPREL). The product database can be

accessed via the following link https://eprel.ec.europa.eu/.

Here, you are asked to enter the model identifier. You will

find the model identifier on the type plate.

Safety information and warnings

4 * Depending on model and options

1.12 Open source licences

The appliance contains software components that use open

source licences. Information on the open source licences

used can be found here:

home.liebherr.com/open-source-licences

1.13 Spare parts

The spare parts availability for functional parts and stock‐

able parts of the equipment is 15 years.

1.14 Symbols on the appliance

This symbol may be found on the

compressor. It pertains to the oil in the

compressor and indicates the following

danger: Can be fatal if swallowed or with

penetration of the respiratory tract. This

information is only significant for recycling.

No risk exists with normal use. Do not

remove this symbol.

Warning: Fire hazard due to flammable

substances. This symbol is located on the

compressor and can also be found in other

places on the appliance. This symbol warns

of flammable substances. Do not remove

this symbol.

This or a similar symbol may be on the rear

of the appliance. It indicates that there are

vacuum insulation panels (VIP) or perlite

panels in the door and/or housing. This

information is only significant for recycling.

Do not remove this symbol.

This symbol is located on the type plate.

It indicates that the appliance contains

valuable materials and that you must not

dispose of it with household waste.

(see1.8Disposal)

1.15 Warning levels

DANGER

Identifies an immediately

dangerous situation that will

result in death or serious bodily

injuries if it is not prevented.

WARNING

Identifies a dangerous situation

that could result in death or

serious bodily injury if it is not

prevented.

CAUTION

Identifies an immediately

dangerous situation that could

result in slight or moderate injuries

if it is not prevented.

ATTENTION Identifies a hazardous situation

that could result in property

damage if it is not prevented.

Note Identifies useful information and

tips.

2 Appliance at a glance

2.1 Scope of delivery

Check all parts for transport damage. Contact your

dealer or customer service in the event of complaints.

(see 10.4 Customer Service)

Your new appliance comes with the following parts:

Standalone appliance

Features (depending on the model)

Installation materials (depending on the model)

“Quick Start Guide”

“Installation Guide”*

Service Brochure

2.2 Overview of the appliance and

equipment

Fig. 1 Example illustration

Temperature range

(A)

Coldest area

Equipment

(1)

Controls (7) Door rack

(2) Fan with FreshAir acti‐

vated charcoal filter

(8) Type plate

(3) Shelf (9) Freezer drawer

(4) Variable bottle rack (10) IceMaker

(5) BioFresh Safe (11) Adjustable foot

(6) Compartment lid for

BioFresh Safe

Appliance at a glance

* Depending on model and options 5

2.3 VarioTempZone

Your appliance is equipped with a VarioTempZone (-18 °C to

+5 °C). This allows you to use an area of the freezer section

as an additional cooling zone.

Fig. 2 Example illustration

(1)

VarioTempZone

If you use the VarioTempZone as an additional cooling zone,

louder appliance noises may occur. However, the appliance

is fully functional.

More information:

Set the temperature in the VarioTempZone. (see Setting

the temperature in the VarioTempZone)

Observe the notes on storing food. (see 5.1 Information

regarding storage)

2.4 SmartDevice

SmartDevice is the networking solution for your fridge-

freezer.

If your appliance SmartDevice-enabled or compatible, you

can quickly and easily connect your appliance to your

WiFi. With the SmartDevice app, you can operate your appli‐

ance from a mobile device. Additional functions and setting

options are available in the SmartDevice SmartDevice app.

SmartDevice-

enabled appliance:

Your appliance is capable of being a

SmartDevice. To be able to connect

your device to WiFi, you need to

download the SmartDevice app.

More information

about SmartDe‐

vice:

smartdevice.liebherr.com

Downloading the

SmartDevice app:

After installing and configuring

the SmartDevice app, you can

connect your appliance to your Wi-Fi

(see WiFi) using the SmartDevice app

and the appliance's Wi-Fi function.

Note

The SmartDevice function is not available in the following

countries: Russia, Belarus, Kazakhstan.

2.5 Appliance range of use

Intended use

The appliance is only suitable for cooling food products in

a domestic or household-like environment. This includes, for

example, use:

in staff kitchens, bed and breakfast establishments,

by guests in country houses, hotels, motels and other

accommodation,

for catering and similar services in the wholesale trade.

The appliance is not suitable as a built-in unit.

All other types of use are not permitted.

Foreseeable misuse

The following applications are expressly forbidden:

Storing and refrigerating medicines, blood plasma, labo‐

ratory preparations or similar substances and products

based on the Medical Device Directive 2007/47/EC

Use in areas at risk of explosions

Misusing the appliance may lead to damage to the goods

stored or they may spoil.

Climate classifications

Depending on the climate classification the appliance is

designed to operate in restricted ambient temperatures. The

climate classification applying to your appliance is printed

on the rating plate.

Note

► Keep to the specified ambient temperatures in order to

guarantee that the appliance works properly.

Climate clas‐

sification

for ambient temperatures of

SN 10°C to 32°C

N 16°C to 32°C

ST 16°C to 38°C

T 16°C to 43°C

SN-ST 10°C to 38°C

SN-T 10°C to 43°C

The appliance is designed for a maximum relative humidity

of 80%. If the appliance is operated at a relative humidity of

more than 80%, the appliance will work, but condensation

will form on the surface of the appliance.

2.6 Conformity

The refrigerant circuit has been tested for leaks. The appli‐

ance complies with the applicable safety regulations and

with the corresponding directives.

For the EU

market:

The appliance complies with directive

2014/53/EU.

For the GB

market:

The appliance complies with Radio

Equipment Regulations 2017 SI 2017 No.

1206.

The full text of the EU Declaration of Conformity is available

on the following website: www.Liebherr.com

The BioFresh compartment meets the requirements of a

cold storage compartment as set out in DIN EN 62552:2020.

2.7 SVHC substances according to

REACH regulation

You can check whether your appliance contains SVHC

substances according to REACH regulation at the following

link: home.liebherr.com/de/deu/de/liebherr-erleben/nach‐

haltigkeit/umwelt/scip/scip.html

Appliance at a glance

6 * Depending on model and options

2.8 EPREL database

Details about energy labelling and ecodesign requirements

will be available on the European product database (EPREL)

from 1st March 2021. You can access the product database

at the following link: https://eprel.ec.europa.eu/ You will be

asked to enter the model ID. You can find the model ID on

the nameplate.

2.9 Spare parts

The spare parts availability for functional parts and stock‐

able parts of the equipment is 15 years.

3 Functionality of the

Touch&Swipe display

You operate your appliance using the Touch & Swipe display.

You select appliance functions in the Touch & Swipe display

(hereafter referred to as display) by tapping them. If you

do not perform any action on the display for 10 seconds,

the display either jumps back to the higher-level menu or

directly to the status display.

3.1 Navigation and symbol explanation

In the illustrations, different symbols are used to navigate

the display. The following table describes these symbols.

Symbol

Description

Briefly touch the display:

Activates/deactivates function.

Confirms selection.

Opens submenu.

Touch the display for a specified time

(e.g. 3seconds):

Activates/deactivates function or

value.

Swipe left or right:

Navigate in the menu.

Briefly touch the Back symbol:

Jumps back one menu level.

Press and hold the Back symbol for

3seconds:

Jumps back to the status display.

Briefly touch the Back symbol at the

top left:

Jumps back one menu level.

Arrow with clock:

It takes more than 10 seconds for the

following message to appear in the

display.

Symbol Description

Arrow with a time indication:

It takes the specified amount of time

until the following message appears in

the display.

“Open Settings menu” symbol:

Navigates to the Settings menu and

opens the settings menu.

If necessary: Navigate to the desired

function in the Settings menu.

(see 3.2.1 Opening the Settings menu)

“Open Advanced menu” symbol:

Navigates to the Advanced menu and

opens the advanced menu.

If necessary: Navigate to the desired

function in the Advanced menu.

(see 3.2.2 Opening the expanded

menu)

No action for

10seconds

If you do not perform any action on

the display for 10 seconds, the display

either jumps back to the higher-level

menu or directly to the status display.

Close the door and

open it again.

If you close the door and immedi‐

ately open it again, the display jumps

directly back to the status display.

Note: Illustrations of the display are shown in the English

version.

3.2 Menus

The appliance functions are distributed over various menus:

Description

Main menu When you switch the appliance on, you

are automatically in the main menu.

From here you can navigate to the most

important appliance functions, to the

Settings menu and to the Advanced

menu.

Settings menu

The Settings menu contains additional

appliance functions for setting up your

appliance.

Advanced menu

The advanced menu contains special

appliance functions for setting up your

appliance. Access to the Advanced menu

is protected by the numerical code 151.

3.2.1 Opening the Settings menu

Functionality of the Touch&Swipe display

* Depending on model and options 7

Fig. 3 Example illustration

► Carry out action steps according to the illustration.

▷ Settings menu is open.

► If necessary: Navigate to the desired function.

3.2.2 Opening the expanded menu

Fig.4

Fig. 5 Example illustration, access with numerical code 151

► Carry out action steps according to the illustration.

▷ The expanded menu is open.

► If necessary: Navigate to the desired function.

3.3 Sleep mode

If you do not touch the display for 1 minute, the display

switches to sleep mode. In sleep mode, the display bright‐

ness is dimmed.

3.3.1 Ending sleep mode

► Touch the display briefly with your finger.

▷ Sleep mode is ended.

4 Putting into operation

4.1 Switching on appliance (first use)

Make sure that the following requirements are fulfilled:

❑

The appliance has been installed and connected in

accordance with the installation instructions.

❑

All adhesive strips, adhesive and protective films and

transport locks are removed from inside and on the appli‐

ance.

❑

All marketing leaflets are removed from the drawers.

❑

You are familiar with the functionality of the

Touch & Swipe display. (see 3 Functionality of the

Touch&Swipe display)

Switch on the appliance using the Touch&Swipe display:

► If the display is in sleep mode: Briefly touch the display.

► Carry out action steps according to the illustration.

Fig. 6 Example illustration

▷ Status display appears.

▷ The appliance cools to the temperature set at the factory.

▷ The appliance starts in demo mode (status display with

DEMO appears): If the appliance starts in demo mode,

you can deactivate demo mode within the next 5 minutes.

(seeDemo mode)

More information:

Start the IceMaker for the first time. (see 4.2 Starting the

IceMaker for the first time)

Start the SmartDevice for the first time. (see 2.4 Smart‐

Device) and (seeWiFi)

Note

The manufacturer recommends:

► Stock with food: Wait for around 6 hours until the set

temperature is reached.

► Store frozen foods at -18°C or colder.

► Observe the notes on storing food. (see 5.1 Information

regarding storage)

Note

Accessories can be purchased from the Liebherr-

Hausgeräte store at home.liebherr.com/shop/de/deu/

zubehor.html.

4.2 Starting the IceMaker for the first

time

If your appliance is equipped with IceMaker, you must clean

the IceMaker before using it for the first time.

Make sure that the following requirements are fulfilled:

❑

The water supply has been connected. See Installation

Guide or mounting instructions.

❑

The appliance is properly connected.

► Clean the IceMaker. (see 9.8.5 Cleaning the IceMaker)

5 Storage

5.1 Information regarding storage

WARNING

Fire hazard from electrical appliances!

If you use electrical appliances in the food area of your

appliance, they can cause a fire.

► Do not use electrical appliances in the food area of the

appliance unless recommended by the manufacturer.

Note

The energy consumption increases and the cooling power

goes down if ventilation is not sufficient.

► Always keep air slots clear.

Putting into operation

8 * Depending on model and options

Observe the following specifications for storage:

Keep the air vents on the fan free.

In the freezer compartment: Package food properly.

Package or cover foods that readily take on or give off

odours or taste in closed containers.

Package raw meat or fish in clean, closed containers.

This will prevent meat or fish from touching or dripping

onto other food.

Keep liquids in closed containers.

Leave space between goods to ensure good air circula‐

tion.

Store food according to the instructions on the pack‐

aging.

Always observe the best-before date indicated on the

packaging.

Note

Failure to follow these guidelines can lead to foodstuffs

spoiling.

Temperature zone Food

VarioTempZone

Store food according to the set temper‐

ature. Liebherr recommends storing

food in the VarioTempZone:

Temperature

range

Food

4°C to 5°C ready prepared food,

cheese, tinned food

0°C packaged fruit and

vegetables

-2°C fresh fish and

seafood

-18°C siehe Gefrierteil

VarioTempZone overview

5.2 Fridge compartment

The air circulation in the appliance creates different temper‐

ature zones. You will find the different temperature zones in

the appliance and equipment overview. (see 2.2 Overview of

the appliance and equipment)

5.2.1 Arranging your food properly

► Upper area and door: Store butter, cheese, tinned food

and tubes.

► Coldest temperature zone: Store perishable foods such

as pre-cooked meals.

5.3 BioFresh

BioFresh will extend the storage time for some fresh foods

compared to traditional refrigeration.

In your appliance, you have the option of using the BioFresh

Safe as a Fruit & Vegetable Safe or as a Meat & Dairy Safe.

(see8.4 Compartment lid for BioFresh Safe)

Note

If the temperature drops below 0°C foods may freeze.

► Store cold-sensitive produce such as cucumbers, auber‐

gines, courgettes and tropical fruit in the fridge compart‐

ment.

5.3.1 Fruit & Vegetable safe

This safe creates a storage climate of close to 0 °C. The

compartment lid ensures constant levels of humidity. This

storage climate is suitable for storing unpackaged food with

high intrinsic moisture (for example, lettuce, vegetables,

fruit).

The humidity in the compartment depends on the moisture

content of the chilled goods placed in it, and also depends

on how often the compartment is opened. You can regulate

the humidity level.

Arranging your food properly

► Store unpackaged fruit and vegetables.

If the humidity is too high:

► Regulate the humidity.

5.3.2 Meat & Dairy safe

This safe creates a storage climate of close to 0 °C. This

storage climate is suitable for more sensitive foods (e.g.

dairy products, meat, fish, sausage).

Arranging your food properly

► Store dry or packaged food.

5.4 Freezer compartment

Here, a dry, frosty storage climate is created at -18 °C. A

frosty storage climate is suitable for storing frozen food for

several months, for making ice cubes or freezing fresh food.

5.4.1 Freezing food

Freezing quantity

The maximum amount of fresh food that you can

freeze within 24 hours is specified on the type plate

(see 10.5 Model plate) under “Freezing capacity ... kg/24h”.

To ensure that food quickly freezes through, adhere to the

following quantities per package:

Fruit and vegetables up to 1 kg

Meat up to 2.5 kg

Freezing food using SuperFrost

Depending on the quantity to be frozen, you can activate

SuperFrost before freezing in order to achieve lower freezing

temperatures. (see SuperFrost)

► Activate SuperFrost if the amount of food you have to

freeze is more than approx. 2 kg.

The time at which you activate SuperFrost depends on the

amount of food you have to freeze:

Freezing quan‐

tity

Time at which you should activate

SuperFrost

Small amount of

food to freeze

Activate SuperFrost about 6 hours

before freezing.

As soon as the appliance automatically

deactivates SuperFrost, you can rear‐

range the food.

Maximum

amount of food

to freeze

Activate SuperFrost about 24 hours

before freezing.

As soon as the appliance automatically

deactivates SuperFrost, you can rear‐

range the food.

Storage

* Depending on model and options 9

Arranging your food properly

CAUTION

Risk of injury from broken glass!

Bottles and cans with beverages can burst during freezing.

This applies in particular to carbonated beverages.

► Only freeze bottles and cans with beverages if you have

activated the BottleTimer function in the SmartDevice

app.

Freezing quan‐

tity

Arranging your food properly

Small amount of

food to freeze

Place packaged food in the top drawer.

If possible, place groceries at the back

of the drawer near the rear wall.

Maximum

amount of food

to freeze

Distribute packaged groceries

throughout all drawers, but only place

frozen food in the bottom drawer.

If possible, place groceries at the back

of the drawer near the rear wall.

5.4.2 Defrosting food

WARNING

Risk of food poisoning!

► Do not re-freeze thawed food.

► Use defrosted foodstuff as soon as possible.

You can defrost food in several ways:

In the fridge compartment

In the microwave

In the oven/fan-assisted oven

At room temperature

► Take out only as much food as necessary.

5.5 Storage times

Refer to the specified storage times as a guide.

In the case of foods with a minimum shelf life, the date

indicated on the packaging still applies.

5.5.1 Fridge section

Always follow the best-before date stated on the packaging.

5.5.2 BioFresh

Recommended storage periods in the Meat & Dairy-Safe

Butter at 1°C up to 90 days

Hard cheese at 1°C up to 110 days

Milk at 1°C up to 12 days

Sausage, cold meats at 1°C up to 8 days

Poultry at 1°C up to 6 days

Pork at 1°C up to 6 days

Beef at 1°C up to 6 days

Game at 1°C up to 6 days

Note

► Remember that high-protein foods perish quicker; shell‐

fish and crustaceans do not last as long as fish, and fish

does not last as long as meat.

Recommended storage periods in the Fruit & Vegetable-

Safe

Vegetables, salads

Artichokes at 1°C up to 14 days

Celery at 1°C up to 28 days

Cauliflower at 1°C up to 21 days

Broccoli at 1°C up to 13 days

Chicory at 1°C up to 27 days

Lettuce at 1°C up to 19 days

Peas at 1°C up to 14 days

Kale at 1°C up to 14 days

Carrots at 1°C up to 80 days

Garlic at 1°C up to 160 days

Turnip at 1°C up to 14 days

Lettuce at 1°C up to 13 days

Herbs at 1°C up to 13 days

Leeks at 1°C up to 29 days

Mushrooms at 1°C up to 7 days

Radishes at 1°C up to 10 days

Brussels sprouts at 1°C up to 20 days

Asparagus at 1°C up to 18 days

Spinach at 1°C up to 13 days

Savoy at 1°C up to 20 days

Fruit

Apricots at 1°C up to 13 days

Apples at 1°C up to 80 days

Pears at 1°C up to 55 days

Blackberries at 1°C up to 3 days

Dates at 1°C up to 180 days

Strawberries at 1°C up to 7 days

Figs at 1°C up to 7 days

Blueberries at 1°C up to 9 days

Raspberries at 1°C up to 3 days

Currants at 1°C up to 7 days

Sweet cherries at 1°C up to 14 days

Kiwis at 1°C up to 80 days

Peaches at 1°C up to 13 days

Plums at 1°C up to 20 days

Cranberries at 1°C up to 60 days

Rhubarb at 1°C up to 13 days

Gooseberries at 1°C up to 13 days

Grapes at 1°C up to 29 days

5.5.3 Freezer compartment

Recommended storage period for various types of food

Ice cream at -18°C 2 to 6 months

Storage

10 * Depending on model and options

Recommended storage period for various types of food

Sausages, ham at -18°C 2 to 3 months

Bread, baked goods at -18°C 2 to 6 months

Game, pork at -18°C 6 to 9 months

Fatty fish at -18°C 2 to 6 months

Lean fish at -18°C 6 to 8 months

Cheese at -18°C 2 to 6 months

Poultry, beef at -18°C 6 to 12 months

Vegetables, fruit at -18°C 6 to 12 months

6 Saving energy

Pay attention to good ventilation. Do not cover ventilation

holes or grids.

Always keep the fan air slits clear.

Do not place the appliance in direct sunlight or near radi‐

ators or similar sources of heat.

If the appliance is placed directly next to an oven,

the energy consumption may increase slightly. This is

dependent on the service life and usage intensity of the

oven.

Energy consumption depends on the installation condi‐

tions, e.g. the ambient temperature (see 2.5 Appliance

range of use) . A warmer ambient temperature can

increase the energy consumption.

Open the appliance for as short a time as possible.

The lower the temperature is set the higher the energy

consumption.

Sort your food: home.liebherr.com/food.

Keep all food properly packed and covered. This prevents

frost from forming.

Only take food out for as long as necessary so that it

doesn’t warm up too much.

Inserting warm food: allow to cool down to room temper‐

ature first.

Thaw frozen food in the refrigerator.

For longer periods of absence, use HolidayMode

(seeHolidayMode) .

7 Controls

7.1 Controls and displays

7.1.1 Status display

Fig. 7 The status display shows the actual temperature.

(1)

Fridge section temper‐

ature display

(3) Freezer section tempera‐

ture display

(2) VarioTempZone

temperature display

The status display shows the actual temperature and is the

initial display. Navigation to the functions takes place from

there.

7.1.2 Display symbols

Display symbols provide information on the current appli‐

ance status:

Symbol Appliance status

Standby

The appliance or temperature zone

is switched off.

Flashing number

Appliance is working. Temperature

flashes until the set temperature is

reached.

Flashing symbol

Appliance is working. Setting is

made.

"D" on the status display

Demo mode is active.

IceMaker symbol on the status

display

The IceMaker is active.

WLAN symbol on the status display

WLAN is active.

7.2 Appliance functions

7.2.1 Notes on the appliance functions

The appliance functions are set at the factory so that your

appliance is fully functional.

Before you alter, activate or deactivate the device functions,

make sure that the following requirements are met:

❑

You have read and understood the descriptions of

how the display works. (see 3 Functionality of the

Touch&Swipe display)

❑

You have familiarised yourself with the operating and

display elements of your appliance.

Switching the appliance off and on

Use this function to switch the entire appliance off and on.

Switching off the appliance

When you switch the appliance off, then the previously

saved settings are saved.

Make sure that the following requirements are fulfilled:

❑

Handling instructions (see 11 Shutting down) are carried

out.

Fig.8

Saving energy

* Depending on model and options 11

Fig.9

► Carry out action steps according to the illustration.

▷ Appliance is switched off.

▷ The standby symbol appears in the display.

▷ Display turns black.

Switching on the appliance

If the display is in sleep mode:

► Briefly touch the display.

Fig. 10 Example illustration

► Carry out action steps according to the illustration.

When the appliance starts in demo mode:

► Deactivating demo mode. (see Deactivating demo mode)

▷ The appliance is switched on.

▷ Previous settings are restored.

▷ The appliance cools to the target temperature set.

Switching temperature zone off and on

You can switch temperature zones of the appliance off inde‐

pendently.

Switching the fridge compartment off

Make sure that the following requirements are fulfilled:

❑

Refrigerator compartment has been emptied.

Fig. 11 Example illustration

► Carry out action steps according to the illustration.

▷ Refrigerator compartment is switched off.

Switching the fridge compartment on

Fig. 12 Example illustration

► Carry out action steps according to the illustration.

▷ Refrigerator compartment is switched on.

▷ The appliance cools to the last set temperature.

WiFi

Use this function to connect your appliance to WiFi. You can

then operate it via the SmartDevice app on a mobile device.

You can also use this function to disconnect or reset the

WiFi connection.

More information on the SmartDevice: (see2.4 SmartDevice)

Note

The SmartDevice function is not available in the following

countries: Russia, Belarus, Kazakhstan.

Establishing the WiFi connection for the first time

Make sure that the following requirements are fulfilled:

❑

You have installed the SmartDevice app (see

apps.home.liebherr.com).

❑

Registration in the SmartDevice app is completed.

Fig.13

Fig. 14

► Carry out action steps according to the illustration.

▷ Connection is established.

Disconnecting from the WiFi

Fig. 15

Controls

12 * Depending on model and options

Fig. 16

► Carry out action steps according to the illustration.

▷ There is no connection.

Resetting the WiFi connection

Fig.17

Fig. 18

► Carry out action steps according to the illustration.

▷ WiFi connection and other WiFi settings are reset to

factory settings.

Showing information about the WiFi connection

Fig. 19

Fig.20

► Carry out action steps according to the illustration.

Temperature

Use this function to set the temperature.

The temperature depends on the following factors:

Frequency of door opening

Duration of door opening

Room temperature of the installation site

Type, temperature and quantity of food

Temperature zone Factory-set

temperature

Recommended

setting

Fridge section

4°C 4°C

Freezer section

-18°C -18°C

BioFresh

0°C B-Value

(see BioFresh B-

Value)

VarioTempZone

-18°C Depending on

the use of

the VarioTempZone

(see 2.3 Vario‐

TempZone)

Setting the temperature in the fridge section

Fig. 21 Example illustration

► Carry out action steps according to the illustration.

▷ Temperature is set.

Setting the temperature in the freezer section

Fig. 22 Example illustration

Controls

* Depending on model and options 13

► Carry out action steps according to the illustration.

▷ Temperature is set.

Setting the temperature in BioFresh

Set the temperature using the BioFresh B-Value.

(see BioFresh B-Value)

Setting the temperature in the VarioTempZone

Fig. 23 Example illustration

► Carry out action steps according to the illustration.

▷ Temperature is set.

Temperature unit

Use this function to set the temperature unit. You can set

degrees Celsius or degrees Fahrenheit as the temperature

unit.

Setting the temperature unit

Fig. 24

Fig. 26 Example illustration: Switch from degreesCelsius

to degrees Fahrenheit.

► Carry out action steps according to the illustration.

▷ The temperature unit is set.

BioFresh B-Value

Use this function to set the BioFresh B-Value. With the

BioFresh B-Value, you can set BioFresh slightly warmer or

colder if necessary due to higher or lower ambient temper‐

atures. The BioFresh B-Value is pre-set to value B5 as deliv‐

ered. If you change the B-Value, refer to the following table:

Value

Description

B1 Lowest temperature

Value Description

B1-B4 The temperature can drop below 0 °C which means

foods can easily freeze.

B5 Pre-set temperature

B9 Highest temperature

Setting the BioFresh B-Value

Fig.27

Fig. 29 Example illustration: Switch from B5 to B6.

► Carry out action steps according to the illustration.

▷ The BioFresh B-Value is set.

▷ Status display shows target temperature.

SuperCool

You can use this function to activate or deactivate Super‐

Cool. If SuperCool is activated, then the appliance increases

the cooling capacity. It allows you to achieve lower cooling

temperatures. You can activate SuperCool when you would

like to cool a large quantity of food quickly.

The temperature in the VarioTempZone remains as preset.

The active SuperCool function has no effect on the Vario‐

TempZone.

If the function is active, the appliance operates at higher

power. As a result, the appliance's operating noise may be

temporarily louder and energy consumption will increase.

Activating SuperCool

Time for activation of the function:

When you would like to store fresh food in the fridge

section: Activate the function when inserting food.

Fig.30

Fig.31

► Carry out action steps according to the illustration.

-or-

► Activate with the SmartDevice app.

▷ SuperCool is activated.

Controls

14 * Depending on model and options

▷ The temperature display turns blue.

Deactivating SuperCool

SuperCool is deactivated automatically after 18 hours.

However, you can also deactivate SuperCool manually at

any time:

Fig. 32 Example illustration

► Carry out action steps according to the illustration.

-or-

► Deactivate with the SmartDevice app.

▷ SuperCool is deactivated.

▷ The appliance continues to run in normal mode.

▷ The appliance cools to the temperature set previously.

SuperFrost

You can use this function to activate or deactivate

SuperFrost. If SuperFrost is activated, then the appliance

increases the freezing capacity. It allows you to achieve

lower freezing temperatures.

Application:

Quickly freeze fresh food through to the core.

This ensures that the nutrition, appearance and taste of

frozen food is maintained.

Increase the cold reserve in stored frozen food before

defrosting the appliance.

The temperature in the VarioTempZone is influenced by the

activation of the SuperFrost function as long as the Vario‐

TempZone is set between -12 °C and -18 °C. If the tempera‐

ture of the VarioTempZone is within this temperature range,

the SuperFrost function is activated for the VarioTempZone.

If the temperature is set higher than -12 °C, the VarioTemp‐

Zone is not affected by SuperFrost.

If the function is active, the appliance operates at higher

power. As a result, the appliance's operating noise may be

temporarily louder and energy consumption will increase.

If the door is open for too long, e.g. because you are

putting food in, the appliance automatically checks whether

the actual temperature in the appliance matches the set

temperature. If the difference exceeds a certain value, the

appliance automatically cools more vigorously. As a result,

the temperature shown on the display may be higher than

the actual temperature in the appliance. This is normal and

your appliance is working correctly.

Activating SuperFrost

Make sure that the following requirements are fulfilled:

❑

Freezing quantity and time for activation of SuperFrost

are taken into account. (see Freezing food using

SuperFrost)

Fig.33

Fig.34

► Carry out action steps according to the illustration.

-or-

► Activate with the SmartDevice app.

▷ SuperFrost is activated.

▷ The temperature display turns blue.

Deactivating SuperFrost

SuperFrost is automatically deactivated after 56 to 72 hours

depending on the quantity of the food inserted. However,

you can also deactivate SuperFrost manually at any time:

Fig. 35 Example illustration

► Carry out action steps according to the illustration.

-or-

► Deactivate with the SmartDevice app.

▷ SuperFrost is deactivated.

▷ The appliance continues to run in normal mode.

▷ The appliance cools to the temperature set previously.

Start defrosting cycle

Use this function to start the automatic defrosting cycle

manually if it does not start automatically in the event of a

fault.

Starting defrosting cycle

Fig.36

Fig.37

► Carry out action steps according to the illustration.

▷ Defrosting cycle has started: Icon flashes until defrosting

cycle is automatically completed.

▷ When defrosting cycle is finished: The device continues

to run in normal mode.

Controls

* Depending on model and options 15

Cancelling defrosting cycle

The defrosting cycle will be stopped automatically. However,

you can also cancel the defrosting cycle at any time during

the defrosting process:

Fig.38

► Carry out action steps according to the illustration.

▷ Defrosting cycle is cancelled.

▷ The device continues to run in normal mode.

PartyMode

You can use this function to activate or deactivate Party‐

Mode. PartyMode activates various functions that are useful

for a party.

PartyMode activates the following functions:

SuperCool (seeSuperCool)

SuperFrost (see SuperFrost)

IceMaker with MaxIce (see IceMaker / MaxIce )

You can adjust all listed functions individually and flexibly.

When you deactivate PartyMode, all changes are discarded.

If the function is active, the device operates at higher

power. As a result, the device's operating noise may be

temporarily louder and energy consumption will increase.

Activating PartyMode

Make sure that the following requirements are fulfilled:

❑

The IceMaker has been started. (see 4.2 Starting the

IceMaker for the first time)

Fig. 39

Fig.40

► Carry out action steps according to the illustration.

▷ PartyMode and the associated functions are activated.

▷ The temperature display turns blue.

▷ The current temperature flashes until the target tempera‐

ture is reached.

Deactivating PartyMode

The PartyMode is automatically deactivated after

24 seconds. However, you can also deactivate PartyMode

manually at any time:

Fig. 41 Example illustration

► Carry out action steps according to the illustration.

▷ PartyMode is deactivated.

▷ The appliance cools to the temperature set previously:

The current temperature flashes until the target tempera‐

ture is reached.

HolidayMode

You can use this function to activate or deactivate Holiday‐

Mode. If you activate HolidayMode, the fridge section is set

to 15 °C. This saves you energy during longer periods of

absence and prevents bad odours and growth of mould.

Appliance status when HolidayMode is active

Fridge section cools to 15°C.

BioFresh cools to 15°C.

The set temperature is maintained in the freezer section.

PartyMode is deactivated.

SuperCool is deactivated.

Activating HolidayMode

► Empty the fridge section completely.

► Empty BioFresh completely.

Fig. 42

Fig.43

► Carry out action steps according to the illustration.

▷ HolidayMode is activated.

▷ Temperature display turns blue and shows HolidayMode

symbol.

Controls

16 * Depending on model and options

Deactivating HolidayMode

Fig.44

► Carry out action steps according to the illustration.

▷ HolidayMode is deactivated.

▷ The appliance cools to the temperature set previously.

SabbathMode

You can use this function to activate or deactivate

SabbathMode. If you activate this function, some electronic

functions are switched off. As a result, your device meets

the religious requirements for Jewish holidays such as

Sabbath and complies with STAR-K Kosher certification.

Device status when SabbathMode is active

The status display shows SabbathMode permanently.

All functions on the display are locked except for the

Deactivate SabbathMode function.

Active functions remain active.

The display remains bright when you close the door.

The interior lighting is deactivated.

Reminders are not implemented. The set time interval

stops.

Reminders and warnings are not displayed.

There is no door alarm.

There is no temperature alarm.

The IceMaker is switched off.

The defrosting cycle operates only for the specified time,

without considering the appliance consumption.

After a power failure, the appliance returns to

SabbathMode.

Device status

Note

This appliance has certification from the “Institute for

Science and Halacha”. (www.machonhalacha.co.il)

You can find a list of STAR-K-certified appliances at

www.star-k.org/appliances.

Activating SabbathMode

WARNING

Danger of food poisoning from spoiled food!

If you have SabbathMode activated and a power failure

occurs, no message appears in the status display about the

power failure. Once the power is restored, the appliance

continues to operate in SabbathMode. The power failure

may mean that food spoils and the consumption of this food

could lead to food poisoning.

After a power failure:

► Do not consume food that was frozen and has thawed

out.

Fig.45

Fig.46

► Carry out action steps according to the illustration.

▷ SabbathMode is activated.

▷ The status display shows SabbathMode permanently.

Deactivating SabbathMode

The SabbathMode is automatically deactivated after

80 hours. However, you can also deactivate SabbathMode

manually at any time:

Fig. 47

► Carry out action steps according to the illustration.

▷ SabbathMode is deactivated.

EnergySaver

You can use this function to activate or deactivate Energy

saving mode. If energy saving mode is activated, the energy

consumption decreases and the temperature in the device

increases. The food remains fresh, but the shelf life is short‐

ened.

The temperature in the VarioTempZone remains as preset.

The active EnergySaver function has no effect on the Vario‐

TempZone.

Temperature zone

Recommended

setting (see Setting

the temperature in

the fridge section)

Temperature

with active

EnergySaver

Fridge section

4°C 7°C

Controls

* Depending on model and options 17

Temperature zone Recommended

setting (see Setting

the temperature in

the fridge section)

Temperature

with active

EnergySaver

Freezer section

-18°C -16°C

Temperatures

Activating EnergySaver

Fig.48

Fig. 49

► Carry out action steps according to the illustration.

▷ Energy saving mode is activated.

Deactivating EnergySaver

Fig. 50 Example illustration

► Carry out action steps according to the illustration.

▷ Energy saving mode is deactivated.

IceMaker / MaxIce

Use the IceMaker function to activate or deactivate the

production of ice cubes. Use the MaxIce function to

increase the amount of ice cubes produced by the IceMaker.

MaxIce is automatically deactivated after 48 hours.

However, you can also deactivate MaxIce manually at any

time: (see Deactivating MaxIce)

More information on the number of

ice cubes:

(see 10.1 Technical

specifications)

Further information on the

IceMaker water supply:

More information on cleaning the

lines of the IceMaker:

(see TubeClean )

If the function is active, the device operates at higher

power. As a result, the device's operating noise may be

temporarily louder and energy consumption will increase.

Activating IceMaker

Make sure that the following requirements are fulfilled:

❑

The water supply is established at the fixed water

connection. See installation instructions.

❑

IceMaker is put into operation. (see8.6 IceMaker)

Fig.51

Fig.52

► Carry out action steps according to the illustration.

-or-

► Activate with the SmartDevice app.

▷ IceMaker is activated. It can take up to 24 hours for the

IceMaker to produce the first ice cubes.

▷ The IceMaker symbol appears on the status indicator.

Activating the IceMaker with MaxIce

If you have not activated the IceMaker function before,

make sure that the following requirements are met:

❑

The water supply is established at the fixed water

connection. See installation instructions.

❑

IceMaker is put into operation. (see8.6 IceMaker)

Fig.53

Fig.54

► Carry out action steps according to the illustration.

-or-

► Activate with the SmartDevice app.

▷ The IceMaker is activated with MaxIce.

▷ The IceMaker symbol appears on the status indicator.

Changing between the IceMaker and MaxIce

If you have activated the IceMaker and would like to change

to MaxIce:

Controls

18 * Depending on model and options

Fig.55

Fig.56

► Carry out action steps according to the illustration.

▷ The IceMaker is activated with MaxIce.

If you have activated MaxIce and would like to change to the

IceMaker:

Fig.57

Fig.58

► Carry out action steps according to the illustration.

▷ IceMaker is activated.

▷ MaxIce is deactivated.

Deactivating the IceMaker and MaxIce

Fig. 59

Fig. 60 Example illustration of the active IceMaker function

► Carry out action steps according to the illustration.

-or-

► Deactivate with the SmartDevice app.

▷ IceMaker and MaxIce are deactivated.

▷ If ice cubes are currently being made, the system

completes the process.

▷ The IceMaker goes off automatically.

Deactivating MaxIce

► Activate the IceMaker. (see Activating IceMaker )

▷ MaxIce is deactivated.

▷ IceMaker is activated.

▷ To deactivate the IceMaker and MaxIce: (see Deactivating

the IceMaker and MaxIce)

IceMaker water supply

Use this function to set the water supply. The water supply

regulates the amount of water supplied. The water supply

can be changed if it does not match the water pressure and

the ice cube size dispensed.

The water supply is pre-set to value 4 as delivered. A value

from 1 (smallest inflow volume) to 8 (largest inflow volume)

can be selected.

Setting water supply

Make sure that the following requirements are fulfilled:

❑

The IceMaker has been started. (see 4.2 Starting the

IceMaker for the first time)

❑

IceMaker is activated. (see IceMaker / MaxIce )

Fig.61

Fig. 62 Example illustration: Switch from value 5 to

value6.

► Carry out action steps according to the illustration.

▷ The water supply is set.

TubeClean

You can use this function to activate or deactivate Tube‐

Clean. If TubeClean is activated, it cleans the IceMaker lines.

Activating TubeClean

Make sure that the following requirements are fulfilled:

❑

IceMaker cleaning is prepared. (see 9.8.5 Cleaning the

IceMaker)

❑

Empty container with a capacity of 1.5 l and with a

maximum height of 10cm is ready.

► Place the container in the drawer under the IceMaker.

Controls

* Depending on model and options 19

Fig.63

Fig.64

► Carry out action steps according to the illustration.

▷ TubeClean is activated.

▷ The cleaning process has started: Icon flashes until

the cleaning process is automatically completed after

60 minutes.

▷ When the cleaning process is complete: The device

continues to run in normal mode.

Deactivating TubeClean

TubeClean is automatically ended after 60 minutes.

However, TubeClean can also be deactivated at any time

during the cleaning process:

Fig.65

► Carry out action steps according to the illustration.

▷ TubeClean is deactivated: Cleaning process is aborted.

▷ The device continues to run in normal mode.

CleaningMode

You can use this function to activate or deactivate Cleaning‐

Mode. CleaningMode enables the appliance to be cleaned

conveniently.

This setting applies to the fridge section.

Application:

Clean the fridge section. (see 9.8Cleaning the appliance)

Device status when CleaningMode is active

The status display shows CleaningMode permanently.

The fridge section is switched off.

Interior lighting is activated.

The reminders and warnings are not displayed. No signal

tone sounds.

Device status

Activating CleaningMode

Fig.66

Fig. 67

► Carry out action steps according to the illustration.

▷ CleaningMode is activated.

▷ The status display shows CleaningMode permanently.

Deactivating CleaningMode

CleaningMode is deactivated automatically after

30 minutes. However, you can also deactivate Cleaning‐

Mode manually at any time:

Fig.68

► Carry out action steps according to the illustration.

▷ CleaningMode is deactivated.

▷ The appliance cools to the temperature set previously.

Display brightness

Use this function to set the display brightness in stages.

You can select the following brightness levels:

40%

60%

80%

100 % (pre-setting)

Setting the brightness

Fig. 69

Fig. 70 Example illustration: Switch from 80 % to 60%.

► Carry out action steps according to the illustration.

▷ The brightness is set.

Controls

20 * Depending on model and options

H-Value

You can use this function to switch on the appliance's

anti-condensation heating if condensation forms around the

fridge section or freezer section. Condensation can form in

high humidity and low ambient temperatures.

The H-Value is set to HA on delivery. If you change the

H-Value, refer to the following table:

Value Description

HA Automatic control depending on

humidity and ambient temperature

H0 Anti-condensation heating is switched

off.

Setting the H-Value

Fig.71

Fig. 72 Example illustration: Switch from HA to H0.

► Carry out action steps according to the illustration.

▷ The H-Value is set.

Door alarm

Use this function to activate or deactivate the door alarm.

The door alarm sounds if the door is open for too long. The

door alarm is activated on delivery. You can set how long

the door may be open before the door alarm sounds.

The following values can be set:

1 minute

2 minutes

3 minutes

Off

Setting the door alarm

Fig.73

Fig. 74 Example illustration: Change door alarm from

1 minute to 3 minutes.

► Carry out action steps according to the illustration.

▷ The door alarm is set.

Deactivating the door alarm

Fig.75

Fig. 76

► Carry out action steps according to the illustration.

▷ The door alarm is deactivated.

Child lock

You can use this function to activate or deactivate the child

lock. The child lock prevents the appliance being operated

accidentally, e. g. by children.

Application:

Avoid unintentional modification of functions.

Avoid unintentional switching off of the device.

Avoid unintentional temperature setting.

Activating the child lock

If you activate the child lock, you can continue to navigate

in the menus but you cannot select or change other func‐

tions.

Fig.77

Controls

* Depending on model and options 21

Fig.78

► Carry out action steps according to the illustration.

▷ Child lock is activated.

Deactivating the child lock

Fig.79

Fig.80

► Carry out action steps according to the illustration.

▷ Child lock is deactivated.

Language

Use this function to set the display language.

You can select the following languages:

Deutsch

English

Français

Español

Italiano

Nederlands

Čeština

Polski

Português

Bulgarian

Русский

温度单位

Setting the language

Fig.81

Fig. 82 Example illustration depending on the language

and temperature

► Carry out action steps according to the illustration.

▷ The language is set.

▷ The display returns to the status display.

Appliance and software information

Use this function to indicate the model name, index, serial

number and service number of your device. You will need

the device information when you contact customer service.

(see 10.4 Customer Service)

This function also opens the Advanced menu. (see 3 Func‐

tionality of the Touch&Swipe display)

Indicating the device information

Fig.83

Fig.84

► Carry out action steps according to the illustration.

▷ Display indicates device information.

Displaying software information

Fig.85

Fig.86

► Carry out action steps according to the illustration.

▷ Display shows software information.

Controls

22 * Depending on model and options

Reminder

Use this function to activate or deactivate the reminders.

The function is activated on delivery.

If the function is activated, the following reminders will

appear:

Replace the FreshAir activated carbon filter (see Replace

the FreshAir activated carbon filter)

Activating the reminder

Fig. 87

Fig.88

► Carry out action steps according to the illustration.

▷ Reminder is activated.

Deactivating the reminder

Fig.89

Fig.90

► Carry out action steps according to the illustration.

▷ Reminder is deactivated.

Demo mode

Demo mode is a special feature for dealers who want to

demonstrate appliance features. If you activate demo mode,

all refrigeration functions are deactivated.

If you switch on your appliance and a “D” appears on the

status display, demo mode is already activated.

If you activate and then deactivate demo mode, the appli‐

ance will be reset to factory defaults. (see Resetting to

factory settings)

Activating demo mode

Fig. 91

Fig.92

► Carry out action steps according to the illustration.

▷ Demo mode is activated.

▷ Appliance is switched off.

► Switch on the appliance. (see 4.1 Switching on appliance

(first use))

▷ “D” appears in the status display.

Deactivating demo mode

Fig. 93

Fig. 94

► Carry out action steps according to the illustration.

▷ Demo mode is deactivated.

▷ Appliance is switched off.

► Switch on the appliance. (see 4.1 Switching on appliance

(first use))

▷ Appliance is reset to factory settings.

Controls

* Depending on model and options 23

Resetting to factory settings

Use this function to reset all settings to factory defaults.

All settings you have made so far are reset to their original

settings.

Performing a reset

Fig.95

Fig.96

► Carry out action steps according to the illustration.

▷ Device is reset.

▷ Device is switched off.

► Restart the device. (see 4.1 Switching on appliance (first

use))

7.3 Messages

There are two categories of messages:

Category

Importance

Warning Warnings appear in the event of malfunctions.

Simple warnings can be cancelled by yourself.

In the event of serious malfunctions, you must

contact customer service. (see 10.4 Customer

Service)

Reminder Reminders remind you of general processes.

You can carry out these operations to end the

message.

7.3.1 Overview of warnings

Behaviour of the appliance in the event of warnings:

Warning appears in red on the display.

The alarm tone sounds at an ever-increasing volume.

The interior lighting pulsates for some warnings.

Message

Cause Exit the

message

Power outage

alarm

The message appears

if the temperature has

risen due to a power

failure.

Carry out

action steps.

Temperature

alarm

The message appears

if the temperature in

the appliance does not

correspond to the set

temperature.

Carry out

action steps.

Message Cause Exit the

message

Error

The message appears

if there is an appliance

error. A component of

the appliance has a

fault.

Carry out

action steps.

(see Error)

WLAN error

The message appears

if the appliance could

not be connected to

the WLAN. (see Estab‐

lishing the WiFi

connection for the first

time) The message

only appears during

the initial setup.

Carry out

action steps.

(see WLAN

error)

Connection error

The message appears

if the connection to

the home network

is interrupted. The

message only appears

during the initial setup.

Carry out

action steps.

Defrosting cycle

error

The message appears

if the appliance has

tried to defrost five

times in a row

and problems have

occurred.

Carry out

action steps.

(see Defrostin

g cycle error)

7.3.2 Ending warnings

Power outage alarm

This message is displayed for each temperature zone of

your appliance. When the power failure has ended, the

appliance will automatically cool down to the previously

set target temperature without you having to confirm the

message. You must confirm the message for it to disappear

from the display.

Fig. 97 Example illustration

► Briefly touch the display.

▷ Display shows information about the warning.

► Briefly touch the display.

▷ Warmest freezing temperature is displayed.

▷ If the freezing temperature was below -9 °C: Food can

still be consumed.

If the freezing temperature has risen above -9°C:

► Check the food.

► Briefly touch the display.

▷ The display returns to the status indicator: Current

temperature and target temperature are displayed.

Temperature alarm

This message is displayed for each temperature zone of

your appliance. You must confirm the message for it to

disappear from the display.

Controls

24 * Depending on model and options

Temperature differences can be caused by:

You have put in warm, fresh food.

Too much warm air has got in while you were sorting out

the freezer or removing items.

There has been a longer power failure.

The appliance is faulty.

► Eliminate causes.

▷ The appliance cools to the target temperature set previ‐

ously.

Fig. 98 Example illustration

► Briefly touch the display.

▷ Display shows information about the warning.

► Briefly touch the display.

▷ Warmest freezing temperature is displayed.

▷ If the freezing temperature was below -9 °C: Food can

still be consumed.

If the freezing temperature has risen above -9°C:

► Check the food.

► Briefly touch the display.

▷ The display returns to the status indicator: Current

temperature and target temperature are displayed.

Error

Fig. 99 Example illustration

► Briefly touch the display.

▷ Error code is displayed.

► Note the error code.

► Briefly touch the display.

▷ The display returns to the status indicator.

► Contact Customer Service. (see 10.4 Customer Service)

WLAN error

► Check WLAN connection.

► Reconnect the appliance to the WLAN. (seeWiFi)

Defrosting cycle error

► Starting automatic defrosting cycle manually: (see Start

defrosting cycle)

7.3.3 Overview of reminders

Behaviour of the appliance during reminders:

Reminder appears yellow on the display.

Alarm tone sounds.

The interior lighting pulsates for some reminders.

The following reminders can be deactivated

(see Deacti‐

vating the reminder) :

Replace the FreshAir activated carbon filter

Message Cause Exit the

message

Check the water

connection

The message

appears if the

IceMaker is acti‐

vated but the

IceMaker is not

being supplied with

water via the fixed

water connection.

Carry out action

steps.

(see Check the

water connec‐

tion)

Insert the IceMaker

drawer

The message

appears if the

IceMaker is acti‐

vated but the

IceMaker drawer is

open.

Carry out action

steps.

(see Insert the

IceMaker

drawer)

Replace the Fres‐

hAir activated

carbon filter

The message

appears when the

FreshAir activated

carbon filter needs

to be replaced.

Carry out action

steps.

(see Replace

the FreshAir

activated

carbon filter)

The message

appears if the door

is open for too long.

Carry out action

steps.

(see Door

alarm)

7.3.4 Ending reminders

Check the water connection

Fig. 100 Example illustration

► Briefly touch the display

▷ Display shows reminder information.

► Briefly touch the display

► Check the water connection.

-or-

► Deactivate IceMaker. (see Deactivating the IceMaker and

MaxIce)

If water connection is checked and IceMaker is activated:

► Clean the IceMaker. (see 9.8.5 Cleaning the IceMaker)

▷ IceMaker produces ice cubes.

Insert the IceMaker drawer

► Insert the IceMaker drawer.

-or-

► Deactivate IceMaker. (see IceMaker / MaxIce )

▷ If IceMaker drawer is inserted and IceMaker is activated:

IceMaker produces ice cubes.

Controls

* Depending on model and options 25

Replace the FreshAir activated carbon filter

Liebherr recommends: Replace the FreshAir activated

carbon filter every 6 months.

Note

FreshAir activated charcoal filters can be purchased

from the Liebherr-Hausgeräte store at home.liebherr.com/

shop/de/deu/zubehor.html.

Fig. 102 Example illustration

► Briefly touch the display.

▷ Display shows reminder information.

► Briefly touch the display.

► Replace the activated carbon filter. (see 9.1 FreshAir

carbon filter)

▷ Activated carbon filter ensures optimum air quality in the

cooling unit.

▷ Reminder appears again after 6 months.

If you no longer wish to receive this reminder, you can deac‐

tivate it. (see Deactivating the reminder)

Door alarm

Fig. 103

► Carry out action steps according to the illustration.

-or-

► Close the door.

▷ The display returns to the status indicator.

You can set how long the door may be open before the door

alarm sounds. (see Setting the door alarm)

8 Features

8.1 Door rack

Door racks are suitable for storing drinks and food. You can

move door racks for your own individual use and take them

apart for cleaning. However, Liebherr recommends using the

door racks in the position in the door as delivered from the

factory.

Fig. 104 Example illustration, Door rack

(1) Shelf

Fig. 105 Example illustration, Door rack with organiser and

bottle holder

(1)

Organiser (2) Bottle holder

Fig. 106 Example illustration, Door rack

Fig. 107 Example illustration, fold-down door racks

The following table shows examples of what can be stored

in each door rack. Do not exceed the maximum loading

weight of the door.

Door rack

Food

Door rack (see

Fig. 104)

Butter, cheese, tinned food, large

containers

Door rack with organ‐

iser and bottle holder

(see Fig. 105)

Bottles, tubes

The sliding bottle holder secures

the bottles in the door rack.

The divider for small food items

can be used in any door rack.

Door rack (see

Fig. 106)

small food items and packages,

tubes, cosmetics

Fold-down door rack

(see Fig. 107)

small food items and packages,

tubes, cosmetics

Features

26 * Depending on model and options

8.1.1 Removing the door rack

Fig. 108 Example illustration

Fig. 109 Example illustration

► Push the door rack upwards.

► Pull the door rack forward.

8.1.2 Inserting the door rack

Fig. 110 Example illustration

Fig. 111 Example illustration

► Slide in the door rack.

► Press the door rack down.

8.2 Adjustable bottle shelf

Either one glass shelf, both glass shelves or the variable

bottle rack can be used in the bottom section of the refrig‐

erator. Both glass shelves are inserted at delivery.

Fig. 112 Example illustration

(1)

Variable bottle rack (2) Glass shelf

8.2.1 Using the variable bottle rack

Fig.113

► Lift one or both glass shelves Fig. 113 (1) at the front and

remove.

► Store the glass shelf(shelves) Fig.113(1) in a secure place

outside the appliance.

Fig. 114

► Place bottles in the back row with their bases against the

back wall. (see Fig. 114)

Note

When the bottles protrude over the variable bottle rack at

the front:

► Set the lower door rack one position higher.

8.2.2 Using the glass shelves

Ensure that the following requirements are met:

❑

Bottles have been removed.

❑

Variable bottle rack has been cleaned.

(see 9.5 Removing / inserting the variable bottle rack)

(see 9.8.4 Clean the components)

Features

* Depending on model and options 27

Fig. 115

► Place the glass shelf Fig. 115 (1) at an angle, sloping it

downwards and backwards.

► Lower the glass shelf Fig. 115(1) at the front.

► Insert the second glass shelf in the same way.

8.3 Drawers

You can remove the drawers for cleaning.

The way to remove/insert the drawers varies depending

on the pull-out system. Your appliance can contain various

pull-out systems.

Note

The energy consumption increases and the cooling power

goes down if ventilation is not sufficient.

► Leave the bottom drawer inside the appliance.

► Always keep the inside vents at the rear wall clear.

8.3.1 Drawer on appliance base or glass shelf

The drawer runs directly on the appliance base or on a glass

shelf. There are no rails.

When you remove the drawers, you can use the glass

shelves below them as storage shelves.

Removing drawer

Fig. 116

► Remove drawer as shown in the illustration.

Inserting drawer

Fig.117

► Insert drawer as shown in the illustration.

8.3.2 Drawer on telescopic rails

The drawer runs on extendible rails (telescopic rails). There

are fully extendible telescopic rails and telescopic rails with

partial pull-out. Drawers which are fully extendible can be

pulled out fully from the appliance. Drawers with partial

pull-out cannot be removed fully from the appliance. The

system in your appliance depends on the type of appliance.

Full extension

You can recognise the full extension by a clamp located at

the front left and right of the rail.

Removing the drawer

Ensure that the following requirements are met:

❑

Fridge section: Door is open more than 90°.

Fig. 118

► Pull the drawer Fig. 118(1) out as far as it will go.

► Press the left and right clamp Fig. 118 (2) inwards at the

same time.

▷ Drawer Fig. 118(1) detaches from the rails.

► Lift up the drawer Fig. 118(1) forwards.

► Remove the drawer Fig. 118(1) forwards.

► Push in the rails Fig. 118(3).

Inserting the drawer

Fig. 119

► Pull out the rails Fig. 119(1).

► Hold the rails Fig. 119 (1) firmly and place the drawer

Fig. 119(2) diagonally on the rails Fig. 119(1) from above.

► Slide the drawer Fig. 119 (2) backwards on the rails

Fig. 119(1) as far as it will go.

Fig.120

Features

28 * Depending on model and options

► Lower the drawer Fig. 120 (1) at the front so that the

drawer slides into the clamp Fig. 120 (2) on the left and

right.

▷ The drawer Fig.120(1) locks in audibly.

► Push in the drawer Fig.120(1).

8.4 Compartment lid for BioFresh Safe

The compartment lid ensures constant levels of humidity.

The compartment lid is directly on the drawer and can be

covered by shelves or additional drawers.

Fig. 121 Example illustration, compartment lid for BioFresh

Safe

(1)

BioFresh Safe

(2) Compartment lid for

BioFresh Safe

(3) Variable bottle rack

8.4.1 Reducing the air humidity in the drawer

Fig.122

► Pull out the drawer Fig.122(1).

► Grasp the recessed grip Fig. 122 (2) on the compartment

lid and pull the compartment lid forwards at the same

time.

► Carry out the same action steps for the second compart‐

ment lid.

▷ When the drawer is closed, there is a small gap between

the compartment lid and the drawer.

8.4.2 Increasing the air humidity in the drawer

Fig.123

► Pull out the drawer Fig.123(1).

► Grasp the recessed grip Fig. 123 (2) on the compartment

lid and push the compartment lid backwards at the same

time.

► Carry out the same action steps for the second compart‐

ment lid.

▷ When the drawer is closed, the compartment lid seals

with the drawer.

8.5 Glass shelves

You can remove the glass shelves under the drawers for

cleaning.

8.5.1 Removing / inserting the glass shelf

Make sure that the following requirements are fulfilled:

❑

Glass shelf under the drawer: The drawer has been

removed. (see 8.3 Drawers)

Removing glass shelf

Fig. 124 Example illustration, glass shelf

► Lift the glass shelf forwards.

► Remove the glass shelf forwards.

Inserting glass shelf

Fig. 125 Example illustration, glass shelf

► Place the glass shelf at an angle behind the stoppers.

► Lower glass shelf.

► Slide in glass shelf to the back.

Features

* Depending on model and options 29

8.6 IceMaker

The IceMaker will produce ice cubes for household use only.

Ensure that the following conditions are met:

The IceMaker is clean. (see9 Maintenance)

IceMaker drawer is cleaned.

IceMaker drawer is fully inserted.

8.6.1 Producing ice cubes

The volume depends on the freezing temperature. The

colder the temperature, the more ice cubes the system can

produce in a certain time period.

After the IceMaker is turned on for the first time, it can take

up to 24 hours for the first ice cubes to be made.

► Activate the IceMaker function.

► Producing many ice cubes: Activate the MaxIce function.

► Distribute the ice cubes evenly in the drawer to increase

the capacity.

► Closing the drawer: IceMaker starts making ice cubes

again automatically.

Note

When a certain level is reached in the IceMaker drawer, it

stops producing ice cubes. The IceMaker does not fill the

drawer all the way to the top.

8.7 Egg rack

You can pull out and turn the egg rack. You can use both

sides of the egg rack so you can label specifics like the

purchase date.

8.7.1 Using the egg rack

Fig. 126

► Top layer: for storing hen eggs.

► Bottom layer: for storing quail eggs.

8.8 Bottle holder

8.8.1 Using the bottle holder

Fig.127

►

Push the bottle holder onto the bottles.

▷ The bottles are prevented from falling over.

9 Maintenance

9.1 FreshAir carbon filter

The FreshAir carbon filter is in the compartment above the

fan.

It guarantees the best air quality.

❑

Replace the carbon filter every 6 months.

When the reminder is set, a message on the display

prompts you to change it.

❑

The carbon filter can be disposed of with the regular

household waste.

Note

FreshAir activated charcoal filters can be purchased

from the Liebherr-Hausgeräte store at home.liebherr.com/

shop/de/deu/zubehor.html.

9.1.1 Removing the FreshAir carbon filter

Fig.128

► Pull out the compartment Fig.128(1).

► Remove the carbon filter Fig.128(2).

9.1.2 Inserting the FreshAir carbon filter

Fig.129

► Insert the carbon filter as shown in the diagram

Fig.129(1).

▷ The carbon filter clicks into place.

If the carbon filter is pointing downwards:

► Push the compartment in Fig.129(2).

▷ The carbon filter is now ready for use.

9.2 Dismantling the door rack

It is possible to dismantle some of the door racks if you

want to clean them or install or remove spare parts.

Maintenance

30 * Depending on model and options

9.2.1 Dismantling the door rack

Fig.130

► Remove the shelf Fig.130(1).

9.2.2 Dismantling the door rack with organiser

and bottle holder

Fig.131

► Slide the bottle holder Fig.131(1) to the side as far as the

recess.

► Remove the bottle holder Fig.131(1).

Fig.132

► Remove the organiser Fig.132(2) upwards.

► Remove the shelf Fig.132(3).

9.2.3 Dismantling the fold-down door rack

Fig.133

► Turn the turning unit Fig. 133 (1) in the specified direction

to the end stop.

► Press the tab Fig. 133 (2) up and remove the turning unit

Fig.133(1).

9.3 Assembling the door rack

9.3.1 Assembling the door rack

Fig.134

► Push the shelf Fig.134(1) into the side recesses.

9.3.2 Assembling the door rack with organiser

and bottle holder

Fig.135

► Push the shelf Fig.135(1) into the side recesses.

► Insert the organiser Fig.135(2).

Maintenance

* Depending on model and options 31

Fig.136

► Insert the bottle holder Fig.136(3) in the recess.

► Push the bottle holder Fig. 136 (3) to the desired position

to the side.

9.3.3 Assembling the fold-down door rack

Fig.137

► Position the turning unit Fig. 137 (1) so that the recesses

are exactly opposite the guide channels Fig.137(2) of the

door rack.

► Turn the turning unit Fig. 137 (1) towards the specified

direction.

Fig.138

▷ The elastic element Fig.138(3) of the turning unit audibly

engages in the round shape of the rib Fig.138(4).

9.4 Disassembling / assembling pull-

out systems

9.4.1 Notes on disassembly

You can disassemble some of the pull-out systems for

cleaning. Your appliance can contain a variety of pull-out

systems.

The following pull-out systems can be disassembled or

cannot be disassembled:

Pull-out system can be disassembled/

cannot be disassembled

Drawer on appliance base or

glass shelf

cannot be disassembled

Fully extendible cannot be disassembled

9.5 Removing / inserting the variable

bottle rack

The variable bottle rack can be removed for cleaning.

9.5.1 Removing the variable bottle rack

Ensure that the following requirements are met:

❑

Bottles have been removed.

❑

Glass shelves have been removed. (see 8.2.1 Using the

variable bottle rack)

Fig. 139

► Lift the variable bottle rack at the front and pull it out.

▷ The compartment lids are visible.

Note

Liebherr recommends:

Do not place any items on the compartment lids below.

9.5.2 Inserting the variable bottle rack

Fig. 140

► Push the variable bottle rack in to the end stop and press

it down.

Maintenance

32 * Depending on model and options

▷ The connectors at the back of the variable bottle rack are

connected via automated processes.

▷ LED lights up.

► Insert the glass shelves. (see 8.2.2 Using the glass

shelves)

-or-

► Use the variable bottle rack for bottles.

9.6 Compartment lid for BioFresh Safe

You can remove one or both compartment lids for cleaning.

9.6.1 Removing the compartment lid

Ensure that the following requirements are met:

❑

The glass shelves directly above the variable bottle rack

have been removed.

❑

The variable bottle rack has been removed.

❑

The drawer directly below the compartment lid has been

removed. (see 8.3 Drawers)

Fig. 141

► Push the compartment lid backwards.

► Lift the compartment lid forwards.

► Remove the compartment lid forwards and upwards at an

angle.

9.6.2 Inserting the compartment lid

Fig. 142

If the THIS SIDE UP lettering is at the top:

► Insert the rear retaining parts into the relevant rear open‐

ings.

► Push the compartment lid backwards.

► Lower the compartment lid forwards and engage the

front retaining parts into the openings.

► Move the compartment lid into the required position.

9.7 Defrosting the appliance

9.7.1 Defrosting the fridge compartment

Defrosting is performed automatically. The water from the

thawing process drains through the outlet and evaporates.

►

Clean the drain opening at regular intervals.

(see 9.8Cleaning the appliance)

9.7.2 Defrosting the freezer compartment with

NoFrost

Defrosting is performed automatically with the NoFrost

system. The moisture is deposited on the evaporator, is peri‐

odically defrosted and evaporates.

The appliance does not have to be defrosted.

9.8 Cleaning the appliance

9.8.1 Ready

WARNING

Danger of electric shock!

► Remove the refrigerator connector or interrupt the power

supply.

WARNING

Risk of fire

► Do not damage the refrigeration circuit.

► Empty the appliance.

► Remove mains connector.

-or-

► Activate CleaningMode. (seeCleaningMode)

9.8.2 Clean the housing

NOTICE

Improper cleaning!

Damage to the appliance.

► Only use soft cleaning cloths and ph-neutral all-purpose

cleaners.

► Do not uses abrasive sponges or steel wool which may

cause scratches.

► Do not use any sharp or abrasive cleaning agents, nor

any that contain sand, chloride or acid.

WARNING

Risk of injury and damage as a result of hot steam!

Hot steam can lead to burns and can damage the surfaces.

► Do not use any steam cleaners!

► Wipe the housing down with soft, clean cloth. If very

dirty, use lukewarm water with a neutral cleaner. Glass

surfaces can also be cleaned with glass cleaner.

9.8.3 Cleaning the interior

NOTICE

Improper cleaning!

Damage to the appliance.

► Only use soft cleaning cloths and ph-neutral all-purpose

cleaners.

► Do not uses abrasive sponges or steel wool which may

cause scratches.

► Do not use any sharp or abrasive cleaning agents, nor

any that contain sand, chloride or acid.

► Plastic surfaces: clean by hand with a soft clean cloth,

lukewarm water and a little detergent.

► Metal surfaces: clean by hand with a soft clean cloth,

lukewarm water and a little detergent.

Maintenance

* Depending on model and options 33

► Drain hole: remove deposits using a thin item (for

example a cotton bud).

9.8.4 Clean the components

NOTICE

Improper cleaning!

Damage to the appliance.

► Only use soft cleaning cloths and ph-neutral all-purpose

cleaners.

► Do not uses abrasive sponges or steel wool which may

cause scratches.

► Do not use any sharp or abrasive cleaning agents, nor

any that contain sand, chloride or acid.

Clean with a soft, clean cloth, lukewarm water and some

detergent:

- Shelf

- Compartment lid for Fruit & Vegetable Safe

- Drawer

Please note: Do not remove the magnet on the drawer.

The magnet ensures the functionality of the IceMaker.

- Adjustable bottle shelf

Clean with a damp cloth:

- Retractable rails

Please note: The grease in the tracks is used for lubrica‐

tion and must not be removed!

Wash in the dishwasher up to 60°C:

- Door rack

- Bottle rack

- Holder of the dividing shelf

- Egg rack

- Ice cube scoop

► To disassemble components: see the relevant section.

► Clean the components.

9.8.5 Cleaning the IceMaker

There are various options for cleaning the IceMaker.

Cleaning is required in the following cases:

❑

Initial operation

❑

With mains connection:

If out of use for more than 5 days.

Ensure that the following conditions are met:

❑

IceMaker drawer is emptied.

❑

IceMaker drawer is in place.

❑

The IceMaker is activated.

First use or after a long period of non-use

Clean the IceMaker with the TubeClean function.

► Put an empty 1.5 l vessel (max. height 10 cm) in the

drawer under the IceMaker.

► Activate the TubeClean function.

▷ The rinse process is prepared (max. 60 min.): Symbol

flashes.

▷ Water pipes are rinsed: Symbol flashes.

▷ Rinsing process is complete: Function turns off automati‐

cally.

► Remove the IceMaker drawer and remove the container.

► Clean the IceMaker drawer with warm water and a little

detergent.

► Push the IceMaker drawer in.

▷ The system starts making ice cubes automatically.

Without a water filter

► Dispose of any ice cubes that were made 24 hours after

the first ice cubes.

If cleaning is required

Clean the IceMaker by hand.

►

Remove the IceMaker drawer and clean with warm water

and a little detergent.

► Push the IceMaker drawer in.

▷ The system starts making ice cubes automatically.

9.8.6 After cleaning

► Wipe the appliance and the components dry.

► Connect and switch on the appliance.

► Activate SuperFrost (see 7.2Appliance functions) .

► Repeat cleaning regularly.

10 Customer help

10.1 Technical specifications

Temperature range

Cooling 3°C to 9°C

BioFresh 0°C to 3°C

Freeze -24°C to -15°C

VarioTemp‐

Zone

-18°C to +5°C

Maximum ice cube quantity / 24 hours

Freezer compart‐

ment

see type plate under “Freezing

capacity …/ 24 h”

Maximum loading weight for the equipment

Left refrigerator door 12 kg

Right refrigerator door 12 kg

Left freezer compartment door 1 kg

Right freezer compartment door 1 kg

Freezer compartment top drawer 15 kg

Freezer compartment middle drawer 15 kg

Freezer compartment bottom drawer 10 kg

Ice cube production with IceMaker

Ice cube produc‐

tion / 24 hours

At temperature -18 °C: 1.2 kg ice

cubes

maximum ice

cube produc‐

tion / 24 hours

With MaxIce function activated:

1.4 kg ice cubes

Lighting

Class

Light source

This product contains one or more energy

efficiency class G light sources.

LED

The appliance may contain light sources with different

energy efficiency classes. The lowest energy efficiency class

is indicated.

For appliances with a WiFi connection:

Frequency specification

Frequency band 2.4GHz

Maximum radiated

power

< 100 mW

Purpose of the

wireless equipment

Integration in the local WiFi network

for data communication

Customer help

34 * Depending on model and options

10.2 Operating noises

The appliance makes different noises when it is on.

At higher temperatures the appliance uses less energy

but works for longer. It is quieter.

At lower temperatures the food is cooled faster. It is

louder.

Examples:

•

Functions on (see 7.2Appliance functions)

•

Fan running

•

Food recently added

•

High ambient temperature

•

Door open for a while

Noise

Possible cause Type of noise

Bubbling and

splashing

Coolant flowing

into the cooling

circuit.

Normal operating

noise

Hissing Coolant sprays

into the cooling

circuit.

Normal operating

noise

Humming The appliance

is cooling. The

volume depends

on the cooling

output.

Normal operating

noise

Humming and

rustling

The fan is running. Normal operating

noise

Clicking Components are

switched on and

off.

Normal switching

noise

Noise Possible cause Type of noise

Rattling or

humming

Valves or flaps are

working.

Normal switching

noise

Noise Possible

cause

Type of noise Lifting

Vibration Improper

setup

Defective

noise

Level the

appliance

using the

adjustable

feet.

Rattling Components,

items inside

the appliance

Defective

noise

Secure

components.

Leave

enough

space

between the

items.

10.3 Technical fault

Your appliance is designed and built to ensure it works reli‐

ably and has a long service life. In the unlikely event that

a fault occurs during operation, please check whether it is

due to an operating error. If so, you will be charged for the

callout and repair costs even if it falls within the warranty

period.

You can fix the following faults yourself.

10.3.1 Appliance function

Defect

Cause Remedy

The appliance is

not working.

→ The appliance is not switched on. ► Switch the appliance on.

→ The power plug is not properly

plugged into the socket.

► Check the power plug.

→ There is something wrong with the

power outlet fuse.

► Check the fuse.

→ Power cut ► Keep the appliance closed.

► Safeguarding food: Place cold packs on top of food or

use another freezer if the power cut lasts longer.

► Do not re-freeze defrosted food,

→ The IEC socket is not plugged into

the appliance correctly.

► Check the IEC socket.

Temperature is not

cold enough.

→ The appliance door is not closed

properly.

► Close the appliance door.

→ The ambient temperature is too

high.

► Problem solution: (see 2.5 Appliance range of use)

→ The appliance was opened too

many times or for too long.

► Wait to see if the required temperature corrects itself.

If not, contact Customer Service. (see 10.4 Customer

Service)

→ Too much fresh food was placed

inside without SuperFrost.

► Solution: (see SuperFrost)

→ The appliance is too close to a heat

source (oven, radiator, etc).

► Move the appliance or the heat source.

The temperature

shown on the

→ Appliance door was open for a long

time and the door alarm was trig‐

► Close appliance door.

Customer help

* Depending on model and options 35

Defect Cause Remedy

display is higher

than the actual

temperature in the

appliance.

gered automatically. This causes

the appliance to cool more vigo‐

rously.

The door seal is

defective or needs

to be replaced for

another reason.

→ The door seal can be replaced. It

can be replaced without the need

for special tools.

► Contact Customer Service. (see 10.4 Customer Service)

The closing

damper is defec‐

tive or requires

replacement for

another reason.*

→ The closing damper is replaceable.

It can be changed without the need

for any additional tools.

► Contact Customer Service. (see 10.4 Customer Service)

The appliance

builds up too much

ice or condensa‐

tion.

→ The door seal may have slipped out

of its groove.

► Check that the door seal is well fitted in the groove.

The exterior

surfaces of the

appliance are

warm.*

→ The heat of the refrigeration circuit

is used to avoid condensation.

► This is normal.

10.3.2 Features

Defect Cause Remedy

You cannot acti‐

vate the IceMaker.

→ The appliance and therefore the

IceMaker are not connected.

► Connect the appliance (see the Installation Guide).

The IceMaker is

not producing ice

cubes.

→ The IceMaker is not on. ► Activate the IceMaker.

→ The drawer of the IceMakers is not

connected properly.

► Push the drawer in correctly.

→ The water connection is not open. ► Open the water connection.

The internal light

does not come on.

→ The appliance is not switched on. ► Switch the appliance on.

→ The door was open for longer than

15 minutes.

► Interior lighting switches off automatically after

about 15 minutes when the door is open.

→ The LED interior light is faulty or

the lid is damaged.

► Contact Customer Service. (see 10.4 Customer Service)

10.4 Customer Service

First check whether you can rectify the fault yourself

(see 10 Customer help) . If you cannot rectify the problem,

contact Customer Service.

You can find the address in the enclosed brochure “Liebherr-

Service” or at home.liebherr.com/service.

WARNING

Unprofessional repair!

Injuries.

► Have any repairs and action - not expressly specified -

on the appliance and mains cable carried out by service

personnel only. (see9 Maintenance)

► A damaged mains cable may only be replaced by the

manufacturer, the manufacturer’s Customer Service or a

similarly qualified person.

► In the case of appliances with an IEC connector, the

change may be made by the customer.

10.4.1 Contacting Customer Service

Make sure that the following appliance information is avail‐

able:

❑

Appliance name (model and index)

Customer help

36 * Depending on model and options

❑

Service no. (Service)

❑

Serial no. (S no.)

► Note down the appliance information.

► Notify customer service: Report errors and the appliance

information.

▷ This will help us to provide you with a faster, more accu‐

rate service.

► Follow further instructions from Customer Service.

10.5 Model plate

Fig. 143

(1)

Appliance description (3) Serial no.

(2) Service no.

► Note the data on the model plate.

11 Shutting down

► Empty the appliance.

► Switch off appliance. (see Switching the appliance off

and on)

► Pull the mains plug out of the socket.

► Remove the IEC socket if required: Pull the IEC socket out

of the appliance plug and move it to the left and right at

the same time.

► Clean appliance. (see 9.8Cleaning the appliance)

► Leave the door open, so that no unpleasant odours arise.

12 Disposal

Ensure that the following requirements are met:

❑

Meaning of the symbols on the appliance: are familiar.

(see 1.14Symbols on the appliance)

❑

Notes on disposal are familiar. (see1.8Disposal)

12.1 Preparing the appliance for

disposal

► Shutting your appliance down. (see11Shutting down)

12.2 Disposing of the appliance in an

environmentally friendly manner

WARNING

Leaking coolant and oil!

Fire. The coolant contained in the appliance is eco-friendly,

but also flammable. The oil contained in the appliance

is flammable. Escaping coolant and oil can ignite if the

concentration is high enough and in contact with an

external heat source.

► Do not damage the pipelines of the coolant circuit and

the compressor.

► Observe the notes on transporting the appliance.

► Remove the appliance without damaging it.

► Dispose of appliance according to specifications.

Shutting down

* Depending on model and options 37

home.liebherr.com/fridge-manuals

fridge/freezer with BioFresh

Issue date:20251208

Part number index:7086688-00

Liebherr-Hausgeräte Marica EOOD

Bezirk Plovdiv

4202 Radinovo

Bulgarien

Liebherr MBSDDI 9024 Plus BioFresh NoFrost 4-Door French Door Fridge-Freezer

Product's Documents

Operating instructions

Specifications

Liebherr MBSDDI 9024 PLUS BIOFRESH NOFROST Questions and Answers
