EN
Model SJI-OMS16-SPK Form No. ASP-SJI-OMS16-SPK-880E-M (A)
OPERATOR’S MANUAL
OSCILLATING SPRINKLER
WITH METAL GROUND SPIKE
1
Original instructions.
© 2026 All Season Power LLC.
Snow Joe
®
, Sun Joe
®
, Aqua Joe
®
, Auto Joe
®
, and Power Joe
®
are
registered trademarks used under license from Weather Brands LLC.
New Castle, DE 19720
SAVE THESE INSTRUCTIONS
THANK YOU FOR YOUR PURCHASE!
Failure to register your product purchase will not diminish
your warranty rights. For more information visit shopjoe.com
Place UPC sticker here
UPGRADE YOUR COVERAGE
AT SHOPJOE.COM
/
REGISTER
FOR UP TO 3, 4, OR 5 YEARS OF TOTAL TOOL COVERAGE
When we say we stand behind our product, we mean it! Now you can blow, mow, cut,
saw or tend to any other yard task with confidence, knowing that if there is a problem
with your tool within the warranty period, we will gladly solve it.
+EXTENDED
WARRANTY
ACTIVATE YOUR
2 YEAR WARRANTY
RECEIVE
90 DAYS BONUS COVERAGE
VISIT
SHOPJOE.COM/REGISTER
TELL YOUR FRIENDS
AND TAG US!
We love to hear your feedback! Share your experience by
writing comments and reviews on shopjoe.com, or
connect with us on social media!
HAS YOUR SNOW JOE
EXPERIENCE LEFT
YOU SMILING?
#GOWITHJOE
E Q
OR HAS SOMETHING
LEFT YOU LESS
THAN SATISFIED?
WE’RE SORRY
ABOUT THAT!
Our friendly customer service team is ready to
help you with any issues you may have.
@ SNOWJOECO
CALL US
1-866-225-9723
m
For fastest response
CHAT WITH US
SHOPJOE.COM/CHAT
2
5
2
3
4
1
7
6
1. Base
2. Spray nozzles
3. Oscillator tube
4. Hose-end
5. Sliding tabs
6. Inlet filter
7. Cleaning pin
8. Metal spike
Technical Data
Plastic Nozzle Heads ......................................................................... 16
Fit Standard Garden Hose ................................................................Yes
Adjustable Range Control ................................................................. Yes
Coverage Max ........................................................3400 sq ft (317 m
2
)
Spray Distance Max ..................................................... 67.2 ft (20.5 m)
Spray Width Max ..............................................................51 ft (16.5 m)
Max Pressure* .............................................................................120 PSI
Max Flow .................................................................................. 6.65 GPM
Product Dimensions .................................. 15.8 in. x 5.1 in. x 2.36 in.
(40.2 cm x 13 cm x 6 cm)
Net Weight ..................................................................0.83 lbs (0.38 kg)
Know Your Sprinkler
Operation
Setting Up the Sprinkler
1. To install, unfold the metal ground spikes on the underside
of the sprinkler and press them firmly into the soil until the
sprinkler is stable and level, then connect the hose and
adjust the spray settings as needed (Fig. 1).
2. Use sliding tabs to select desired position and take
advantage of the sprinkler’s adjustable range control
(Fig.2).
Fig. 1
* Peak pressure at initial discharge; working pressure under typical load is 60 PSI.
sliding tabs
Fig. 2
3. Refer to (Fig. 3) to see the different sprinkler options.
Fig. 3
Intended Use
1. The sprinkler is suitable for use in soft soil conditions
2. If used in hard soil, loosen soil before inserting
8
3
Watering Tips
Water only when necessary, preferably in the morning to
minimize water loss through evaporation. To promote deep root
growth, water deeply but as infrequently as possible. Watch
water application to avoid water run-off.
Maintenance + Care
Follow the steps below if the sprinkler stops working or exhibits
poor water flow/performance due to debris or dirt build-up.
1. Remove the inlet filter from the hose-end of the oscillator
and run under water (Fig. 4).
2. Remove the cleaning pin from the opposite end of the
oscillator (Fig. 5).
3. To flush, connect the oscillator to a spigot. Turn on the
faucet and while the water continues running, spin the tube
gently back and forth for a few minutes. Then screw the inlet
filter firmly back in place (Fig. 6)
4. Use the provided cleaning pin to clear any clogs from the
spray nozzles. Fit cleaning pin firmly back in place before
using the sprinkler (Fig. 7).
Storage
Drain the sprinkler after use. DO NOT allow water to freeze in the
sprinkler (Fig. 8).
Service + Support
If your Aqua Joe
®
SJI-OMS16-SPK oscillating sprinkler requires
service or maintenance, please call All Season Power customer
service at 1-866-225-9723 for assistance.
Model + Serial Numbers
When contacting the company or arranging service from an
authorized dealer, you will need to provide the model and serial
numbers, which can be found on the decal located on the
sprinkler. Copy these numbers into the space provided below.
Record the following numbers from the housing or handle of your
new product:
Model #:
Serial #:
SJI-OMS16-SPK
Fig. 4
inlet filter
hose-end
inlet
filter
Fig. 5
cleaning
pin
Fig. 6
hose-end
tube
cleaning pin
Fig. 7
Fig. 8
4
Problem
Troubleshooting
No water flow /
very low flow
Poor spray performance /
uneven spray
Spray nozzles not spraying /
clogged
Sprinkler stops working
Water leaks /
reduced performance
Sprinkler tips over /
unstable
Reduced range /
watering coverage
Sprinkler damaged after
winter storage
Possible Cause
Inlet filter clogged with debris
Dirt/debris build-up in
oscillator tube
Nozzles clogged
Debris/dirt build-up
Inlet filter not seated properly
after cleaning
Spike not fully inserted
or soil too hard
Sliding tabs not
positioned correctly
Water froze inside sprinkler
Recommended Solution
Remove inlet filter from hose-end
and rinse under water,
then reinstall
Flush the oscillator: connect to spigot,
turn on faucet, and spin tube gently
back and forth for a few minutes
Use the provided cleaning pin to clear
clogs from spray nozzles; reinstall
cleaning pin firmly before use
Follow Maintenance + Care steps
(filter rinse, remove pin, flush tube,
clear nozzles)
Screw inlet filter firmly
back in place after flushing
Press spikes firmly into soil until stable
+ level; if soil is hard, loosen soil
before inserting
Adjust sliding tabs to select
desired watering range
Drain after use and do not allow
water to freeze inside
5
R7_06022025
OUR CUSTOMER PROMISE + LIMITED WARRANTY
OUR WARRANTY:
All Season Power warrants new, genuine, powered and non-powered Products to be free from defects in material or workmanship when
used for ordinary household use for a period of two years from the date of purchase or delivery by the original, end-user purchaser when
purchased from All Season Power or from one of All Season Power’s authorized sellers with proof of purchase. Because All Season Power
is unable to control the quality of its Products sold by unauthorized sellers, unless otherwise prohibited by law, this Warranty does not
cover Products purchased from unauthorized sellers. If you have any questions about how to buy from an authorized seller, chat with us at
shopjoe.com/support or call us at 1-866-225-9723. If your Product does not work or there’s an issue with a specific part that is covered
by the terms of this Warranty, All Season Power will elect to either (1) send you a free replacement part, (2) replace the Product with a new
or comparable product (which may include a refurbished, like-new product) at no charge, or (3) repair the Product. How cool is that!
PRODUCT REGISTRATION:
All Season Power strongly encourages you to register your Product. You can register online at shopjoe.com/register, by chatting with us at
shopjoe.com/support
or calling our Customer Service Department at 1-866-225-9723. Failure to register your Product will not diminish your
warranty rights. However, registering your Product will allow All Season Power to better serve you with any of your customer service needs.
WHO CAN SEEK LIMITED WARRANTY COVERAGE:
This Warranty is extended by All Season Power to the original purchaser and original owner of the Product.
WHAT IS NOT COVERED?
This Warranty does not apply if the Product has been used commercially or for non-household or rental applications. This Warranty also
does not apply if the Product was purchased from an unauthorized seller. This Warranty also does not cover cosmetic changes that do
not affect performance. Wearing parts like belts, augers, chains and tines are not covered under this Warranty, and can be purchased at
shopjoe.com or by calling 1-866-225-9723.
We encourage you to use CERTIFIED AUTHENTIC Snow Joe
®
, Sun Joe
®
, Aqua Joe
®
+ Auto Joe
®
replacement parts + accessories. Damage
caused by the use of any other parts + accessories on your Product will not be covered under the warranty. Genuine parts + accessories
can be found and purchased here by entering the model number of your product.
ABOVE ALL ELSE, All Season Power, LLC (“All Season Power”) is dedicated to you, our customer. We strive to make your experience as
pleasant as possible. Unfortunately, there are times when a Snow Joe
®
, Sun Joe
®
, Aqua Joe
®
or Auto Joe
®
product (“Product”) does not
work or breaks under normal operating conditions. We think it’s important that you know what you can expect from us. That’s why we have
a Limited Warranty (“Warranty”) for our Products.
When you register your powered or non-powered Product with All Season Power at shopjoe.com/register, you will receive an additional
90 days of warranty coverage. In addition, you will have the option of purchasing extended warranty coverage beyond the standard 2-year
manufacturer’s warranty. Choose from one, two, or three years of extended coverage through Extend, Inc. Additional charges apply. When
you Go With Joe
®
, you’re not just buying an extended warranty; you’re buying total peace of mind to know that you can rely on our top-notch
tools, top-tier customer support, complete product coverage + no hassle return policy. Chat with us at shopjoe.com/support or call us at
1-866-225-9723 7 days a week 10AM-6PM EST. We’ve got you covered!
There are no warranties which extend beyond those stated herein. ANY IMPLIED WARRANTIES THAT MAY BE APPLICABLE TO
PRODUCTS, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED
IN DURATION TO THE DURATION OF THIS WARRANTY. Some States do not allow limitations on how long an implied warranty lasts, so
the above limitation may not apply to you.
UNDER NO CIRCUMSTANCES SHALL WE BE LIABLE FOR ANY SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES BASED UPON
BREACH OF THIS LIMITED WARRANTY, BREACH OF CONTRACT OR STRICT LIABILITY. Some States do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific
legal rights, and you may also have other rights which vary from State to State. This warranty supersedes those printed in product manuals.
