DEMO HAMMER TROLLEY QUICK ASSEMBLY
GUIDE - MAKITA HAMMER & OTHERS
SKU: TDHT55
Remove the bolts and washers from
the trolley base. Slide each wheel
onto the peg and secure them with
bolts and washers. Tighten
everything using a 13mm socket.
Remove the top portion of the
mount and slide the demo
hammer handle into position.
Align the top halves of the
hammer mounts with the
corresponding lower halves.
Attach the top block and secure
the upper mount with bolts and
washers using a 13mm socket.
Align the housing plate with the
hammer mounts. Once aligned,
secure it in place with 4 long
bolts and a 17mm socket.
Your Demo Hammer Trolley
is now assembled.
Flip the trolley onto the handles
and align the lower halves of
the hammer mounts with the
mounting holes on the
hammer and trolley.
Remove the bolts and washers
from the top of the trolley. Align
the handles with the bolt holes
and secure them in place using
a 19mm socket.
Attach the upper mount to the top
of the frame and secure it in place
using a 13mm socket and
an adjustable wrench.
1
4 5
6
8 97
2
3
Tomahawk Power | San Diego, California
(866) 577 4476 | www.tomahawk-power.com
STEP-BY-STEP
ASSEMBLY
VIDEO
DEMO HAMMER TROLLEY QUICK
ASSEMBLY GUIDE - HILTI HAMMER
SKU: TDHT55
Remove the bolts and washers from
the trolley base. Slide each wheel
onto the peg and secure them with
bolts and washers. Tighten
everything using a 13mm socket.
Flip the trolley onto the handles
and remove the bottom portion
of the mount and place the demo
hammer handle into position.
Align the top halves of the
hammer mounts with the
corresponding lower halves.
Attach the bottom block and
secure the upper mount with bolts
and washers using a 13mm socket.
Align the housing plate with the
hammer mounts. Once aligned,
secure it in place with 4 long
bolts and a 17mm socket.
Align the lower halves of
the hammer mounts with the
mounting holes on the
hammer and trolley.
Remove the bolts and washers
from the top of the trolley. Align
the handles with the bolt holes
and secure them in place using
a 19mm socket.
Attach the upper mount facing
downward in the second mount
hole at the top of the frame.
Secure it in place using a 13mm
socket and an adjustable wrench.
1
4 5
6
87
Your Demo Hammer Trolley
is now assembled.
87
2
3
Tomahawk Power | San Diego, California | (866) 577 4476 | www.tomahawk-power.com
