SCP 5010SS
EN
SINGLE SUPERCONDUCTOR
COOKTOP
Translation of the original manual
SCP 5010SS
A
1
2
3
4
5
B
1
2
3
4
5
7
6
– 1 –
03/2024
2024, .
EN
Single SuperConductor Cooktop
Important Safety Instructions
READ CAREFULLY AND STORE FOR FUTURE USE.
• This appliance may be used by children 8 years of age
and older and by persons with physical, sensory or mental
impairments or by inexperienced persons, if they are
properly supervised or have been informed about how to
use of the product in asafe manner and understand the
potential dangers.
• Children must not play with the appliance.
• Cleaning and user maintenance shall not be done
by children unless they are older than 8 years and
supervised.
• Children under 8 years of age must be kept away from the
appliance and its power cord.
• If the power cable is damaged, have it replaced in
aprofessional service centre in order to prevent
adangerous situation. It is forbidden to use the appliance
with the power cable damaged.
ATTENTION: Hot surface
The temperature of accessible surfaces may be
higher if the appliance is in operation.
WARNING: If the surface of the appliance is cracked, switch
it off to prevent possible electric shock.
– 2 –
03/2024
2024, .
CAUTION: This appliance is not designed to be controlled
using an external timer switch or aremote control.
• When cleaning, follow the instructions in the chapter
“Cleaning and Maintenance”.
• This appliance is intended for household use only. It is also suitable for personal non-commercial use in spaces such as:
– staff kitchens in stores, offices and other workplaces;
– recreational objects, chalets, cottages;
– hotel or motel rooms andother living areas;
– Bed & Breakfast facilities.
• Do not use the appliance in outdoor or industry environment.
• The appliance is designed for heating and preparing food. Do not use it for any other purposes than those for which it was designed.
• Before connecting the appliance to apower socket, check that the nameplate rated voltage matches the voltage of the power socket the appliance
is to be connected to. Connect the appliance only to aproperly earthed socket. Do not use an extension cord. Unwind the power cable in full before
use.
• Only use the appliance on flat, dry, clean, stable and fire-resistant surface. Do not use the appliance on metal surfaces, such as on the kitchen sink
drainage board.
• Do not place the appliance on or near table edge, electric or gas stove or other sources of heat.
• Do not use the appliance on asurface which is heat-sensitive or covered with table cloth, paper or other flammable material, in the vicinity of
curtains or other flammable or heat-sensitive materials.
• During operation there needs to be sufficient area for air circulation above the appliance and around it. Asafety distance of at least 50cm and 10cm
must be observed over the hotplate in the main heat radiation direction and in other directions around the appliance respectively.
• During operation, the appliance must be placed on the kitchen unit countertop with no cabinet or overhanging shelf over itself.
• Do not place any objects on the appliance.
• Do not cover or block the ventilation openings of the appliance.
• Not not use the appliance without any pot or pan put on the hotplate. During operation, regularly check the food status.
• Always make sure that the pot or pan are placed correctly on the hotplate.
• The dish handles should be in asafe position to prevent getting caught on and overturning the dishes.
• Liquids or meals may not be heated in closed containers, such as cans, as an explosion could result.
• Take special care if oil or fat is used for cooking. If fat or oil is heated to ahigh temperature, it may catch fire.
• When handling hot dishes containing hot food or liquids, take special care to prevent burning or scalding.
• Use oven mitts when handling hot dishes.
• The appliance must not be left unattended while in operation or connected to apower socket.
• Keep in mind that the hotplate will still radiate some residual heat for awhile after use. Take care not to touch the hot surface of the appliance.
• After use, always switch the appliance off using the on/off button and disconnect the appliance'spower cord from the power socket. Take this action
also if the appliance is to be left unattended, unused or before cleaning, maintenance, moving or storage.
• When disconnecting the appliance from the power socket, always pull the plug, not the power cord. Otherwise, damage to the power cable or the
socket may occur.
• Allow the appliance to fully cool down before moving, cleaning, maintenance or storage. Never move the appliance during operation, while there is
apot or apan on it or if it’snot cooled down completely.
• To prevent the risk of electric shock, do not immerse the appliance, power cable, or plug into water or any other liquid.
• Do not place heavy objects on the power cable. Make sure that the power cable does not hang over the edge of the table or touch hot surfaces or
sharp objects.
• Clean the appliance regularly after each use according to the instructions in the Cleaning and Maintenance section. Do not perform any
maintenance on the appliance other than the cleaning described in this user’smanual.
• Do not use the appliance if it malfunctions, has been dropped on the floor, immersed in water or damaged in any way. Take it to an authorised
service centre for inspection or repair.
• To prevent dangerous situations, do not repair or modify the appliance yourself. All repairs should be carried out by an authorised service centre.
Tampering with the appliance may result in the loss of your legal rights regarding faulty performance or warranty for quality.
– 3 –
03/2024
2024, .
• Thank you for purchasing our SENCOR product; we hope it will serve
to your satisfaction.
• Before using this appliance, please familiarise yourself with the user
manual, even if you are already familiar with using similar types of
appliances. Use the appliance only as described in this user manual.
Keep the manual for future reference.
• It is recommended to keep the original packaging, packing material,
receipt and confirmation of the extent of the seller'sliability or warranty
certificate at least for the duration of the legal right of defective
performance or quality guarantee. When transporting the appliance,
we recommend packaging it again in the original box provided by the
manufacturer.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE APPLIANCE
A1 Cooker base
A2 Hotplate
A3 Control panel
A4 Hotplate colour sensor
A5 Display
Without illustration: power cord
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DESCRIPTION OF THE CONTROL PANEL
B1 Icons of preset programmes
B2
button to reduce hotplate
power
B3
button to shorten
preparation time
B4
button to select one of the
preset modes
B5
button to increase the
hotplate power
B6
button to extend
preparation time
B7
button to switch the
cooker on/off
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BEFORE FIRST USE
• Before first use, remove the appliance and its accessories form the
packaging and discard all promotional labels and tags. Check that
neither the appliance nor any of its components is damaged.
• Wipe the surface of the appliance with aclean, slightly damp cloth.
Then wipe it dry.
Note:
When first turned on there may be light smoke emitted.
This is acompletely normal phenomenon that disappears
in afew minutes.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
OPERATING THE APPLIANCE
1. Place the appliance on akitchen worktop or table withineasy
reach of apower socket. When doing so, make sure that all safety
instructions are followed.
Warning:
The appliance must not be placed on ahob, cooker,
gas cooker, etc.
2. Check that there are no foreign objects on the hotplate andthat the
surface is clean.
3. Unwind the power cord completely and connect it to the power
socket. The power indicator will come on.
Note:
The power cord must be positioned so that it does not touch
the surface of the appliance, as the appliance heats up
during operation.
4. Place the pot or pan on the hotplate. Toachieve optimal energy
consumption and cooking time, use cookware with aflat base, the
diameter of which corresponds to the size of the hotplate. Place food
into the pot or pan.
5. Press the
button, an audible alert will sound and all buttons will
come on.
6. The default mode is “Stir-fry”. “F-01” will appear on the display. After
3 seconds, if you do not press any button, the hotplate will start to
heat up andthe display will show the power and the preparation
time of the given mode.
7. Press the button
repeatedly to select one of thepreset modes –
see table below. Each of the preset programmes has apreset power
and preparation time.
8. Setting the power: press the
or buttons repeatedly to adjust
the power of the hotplate. Each time the button is pressed, the
power is reduced by 100 W. Each time the button is pressed, the
power is increased by 100 W.
9. Setting the preparation time: Press the
or buttons
repeatedly to adjust the preparation time. Each press of the
button reduces the preparation time by 10 minutes. Each press of
the
button increases the preparation time by 10 minutes. Press
and hold the button to speed up the time setting process.
10. Wait 3 seconds and the hotplate will start to heat up. During the
preparation, the values of the set power and the preparation time will
be alternately displayed on the display atan interval of 10 seconds.
11. During operation, regularly check the food status. Do not leave the
appliance unattended while operating.
12. When the preparation time has elapsed, the cooker will switch
off and the hotplate will stop heating. If you need to switch off the
cooker earlier, press the
button.
Warning:
During the heating of the hotplate, the colour of the
sensor around the hotplate will also change. When
the colour turns red, do not touch the hotplate. This
colour indicates that the hotplate is very hot and
dangerous to touch. There is arisk of serious burns.
13. Allow the appliance to cool down completely. Wait until the colour of
the hotplate sensor changes to the original colour. Regularly clean
the cooker according to the instructions in the chapter Cleaning
and Maintenance. Never move the appliance until it'scooled down
completely.
Note:
After the appliance is switched off, the fan will be
inoperation to speed up the cooling. This is anormal
phenomenon. However, do not touch the hotplate while the
colour of the sensor is red.
EN
Single SuperConductor Cooktop
User Manual
– 4 –
03/2024
2024, .
Preset Programme Table
Preset Mode
Default
Temperature
Preparation Time
(hotplate power)
Note
F01 Stir-fry
600°C 0–120 minutes (1,500W)
The mode is suitable for frying on asmall amount of oil while stirring
constantly.
The heating of the hotplate takes place by changing the power until the
temperature stabilises around 600°C.
F02 Deep-fry
480°C
0–1 minutes (1,500W)
1–7 minutes (900W)
7–120 minutes (750W)
The mode suitable for frying food inoil.
The heating of the hotplate takes place by changing the power until the
temperature stabilises around 480°C.
F03 Fry
380°C
0–1 minutes (1,500W)
1–7 minutes (800W)
7–120 minutes (600W)
The mode suitable forroasting meat, vegetables, goulash base, sauces, etc.
The heating of the hotplate takes place by changing the power until the
temperature stabilises around 380°C.
F04 Simmer
570°C
0–15 minutes (1,500W)
15–120 minutes (750W)
The mode is suitable forstewing food, preparing on amild flame, etc.
The heating of the hotplate takes place by changing the power until the
temperature stabilises around 570°C.
F05 Boil
690°C 0–30 minutes (1,500W)
The mode suitable for heating water to the boiling point, e.g. forcooking pasta.
The heating of the hotplate takes place by changing the power until the
temperature stabilises around 690°C.
F06 Keep warm
150°C
0–1 minutes (300W)
1–120 minutes (150W)
The mode suitable for warming food.
The heating of the hotplate takes place by changing the power until the
temperature stabilises around 150°C.
TECHNICAL SPECIFICATIONS
Rated voltage range ...............................................................................220−240V~
Rated frequency ...........................................................................................50–60Hz
Rated input ......................................................................................................... 1,500W
Hotplate diameter ..................................................................................................19cm
Maximum cooking vessel diameter ............................................................... 28cm
Dimensions ...................................360 × 250 × 25mm (30mm including feet)
Power cord length ...............................................................................................120cm
Weight ......................................................................................................................2.7kg
We reserve the right to change the text and technical specifications.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
INSTRUCTIONS AND INFORMATION ON DISPOSAL OF USED
PACKAGING MATERIAL
Dispose of used packaging material in the designated waste disposal area
determined by the municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on the products or accompanying documents
indicates that used electrical and electronic products
should not be disposed of with regular municipal waste.
For proper disposal and recycling of these products, deliver
them to designated collection points. Alternatively, in some
European Union states or other European countries the
products can be returned to the local retailer when buying
an equivalent new product. By properly disposing of this
product, you help preserve valuable natural resources and contribute to
preventing potential negative impacts on the environment and human
health resulting from improper waste disposal. For further details, contact
your local authorities or the nearest collection point. Fines may be
imposed for improper disposal of this type of waste in accordance with
national regulations.
For Business Entities in European Union States
If you want to dispose of electric or electronic devices, ask your retailer or
supplier for the necessary information.
Disposal in Other Countries Outside the European Union
This symbol is valid in the European Union. To dispose of this product
elsewhere, request necessary information on the correct disposal method
from local authorities or your retailer.
This product complies with all the essential requirements of
the applicable EU directives.
Warning during water detection:
If, after switching on, the hotplate detects water on the
cooling fan port, awarning will sound and EC02 will
appear on the display. Atthis time, the hotplate will
not be functional. Disconnect it from the power supply
andwait for the water to dry.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CLEANING AND MAINTENANCE
• Clean the appliance after every use. Make sure that dried food
residues or other impurities do not accumulate on it.
• Switch off the cooker with the button
. Wait for the hotplate sensor
to change to its original colour, then disconnect the power cord from
the power socket.
• Toclean the hotplate, use asoft, slightly dampened sponge andthen
wipe dry.
• In case of heavy soiling, use aspecial cleaner for ceramic plates and
asoft sponge. Then wipe the cleaned surface thoroughly dry.
• Do not use wire wool, thinners, abrasive cleaners, etc. to clean the
appliance. Otherwise, the appliance'sfinish may be damaged.
Warning:
To prevent the risk of electric shock, do not immerse
the appliance, power cable, or plug into water or any
other liquid.
STORAGE
If the appliance will not be used for an extended period, unplug it from
the power socket, let it cool down, and clean it following the instructions
provided above. Before storing, make sure that the appliance is clean and
dry. Store the appliance in adry, clean, and well-ventilated place away
from extreme temperatures and out of the reach of children or pets.
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
