TECHNICAL DATA
MODEL
SKU
WATTS
LUMENS
BEAM ANGLE
CCT
MATERIAL
IP RATING
CANOPY SIZE
DIMENSION
INPUT POWER
VT-89023
24129
3x10W
3600Lm
280°
3000K
Ceramic+Metal+Acrylic
IP20
Ø250xH30mm
Ø120xH150mm
AC: 220-240V, 50Hz
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
Replaceable control gear
by a professional
WARNING
LED PENDANT LAMP
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
[email protected] FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR
OR NEAREST DEALERS. V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instruc-
tions carefully before starting the installing and keep this manual handy for future reference. If you have any
another query, please contact our dealer or local vendor from whom you have purchased the product. They
are trained and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase.
The warranty does not apply to damage caused by incorrect installation or abnormal wear and tear. The
company gives no warranty against damage to any surface due to incorrect removal and installation of the
product. The products are suitable for 10-12 Hours Daily operation. Usage of product for 24 Hours a day
would void the warranty. This product is warranted for manufacturing defects only.
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. The light source of this luminaire is not replaceable; when the light
source reaches its end of life the whole luminaire shall be replaced.
4. Proper grounding should be ensured throughout the installation.
5. For Indoor Use only
2. Use screws to fix mounting bar to the junction box.
3. Make the wire connections with connectors.
• Connect the live wire (L) from fitting to the live wire from main power supply.
• Connect the neutral wire (N) from fitting to the neutral wire from main power supply.
• Connect the earth wire from fitting to the earth wire from main power supply.
• Please pay close attention and make sure the wires are not exposed outside when wiring connections.
4. Use screws to fix canopy to mounting bar.
5. Check if the installation is completed and turn on the power.
1
2
3
4
5
INSTALLATION INSTRUCTIONS
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
V-TAC WEST EUROPE LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT:
SUPPORT@V-TAC.EU FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC WEST EUROPE LTD. GROUND FLOOR, 71 LOWER BAGGOT STREET, DUBLIN 02, IRELAND DO2 P593
V-TAC UK LTD. IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT PLEASE REACH OUT TO US AT
[email protected] V-TAC, 5A TUNGSTEN PARK, DOWNS ROAD, WITNEY, OXFORDSHIRE, OX29 0AX
WIRING DIAGRAM
Ground Supply Can be Green-yellow
Live Supply Can be Red or Brown
Neutral Supply can be Blue or Black
