INTRODUCTION
WARNING
1. Please make sure to turn o the power before starting the installation.
2. Installation should only be done by a certified electrician.
3. Proper grounding should be ensured throughout the installation.
4. Waterproof Box not included.
TECHNICAL DATA
GARDEN SPIKE LAMP OUTDOOR SERIES
MODEL VT-44005
RATED LOAD (MAX)
SKU
35W
24227, 24228
HOLDER GU10 (Bulb not included)
DIMENSION
Φ56x90x285mm
MATERIAL Aluminium
IK RATING IK06
INPUT VOLTAGE
AC 220-240V, 50Hz
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions care-
fully before starting the installation and keep this manual handy for future reference. If you have any another query,
please contact our dealer or local vendor from whom you have purchased the product. They are trained and ready
to serve you at the best. The warranty is valid for 3 years from the date of purchase. The warranty does not apply to
damage caused by incorrect installation or abnormal wear and tear. The company gives no warranty against damage
to any surface due to incorrect removal and installation of the product. The products are suitable for 10-12 Hours Daily
operation. Usage of product for 24 Hours a day would void the warranty. This product is warranted for manufacturing
defects only.
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTRUCTION MANUAL
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
INSTALLATION DIAGRAM
• Install the floor socket and GU10 light source according to the provided diagram.
• Switch o the power supply before starting the installation.
• Connect the lamp to the mains power supply, ensuring appropriate waterproofing measures are applied.
• Securely position the lamp in its designated location.
• Turn on the power and test the lamp.
INSTALLATION INSTRUCTIONS
GU10 HOLDER
INCLUDED
2
1
5
L
N
L
N
4
OFF OFF
ON
ON
3
X1
