New Password:
Let’s Get Started
Conrm Password:
http://tplinkwi.net
Connect the Hardware
Note: If the 2.4GHz LED and 5GHz LED are off, press and hold the WPS/Wi-Fi button on the back for
more than 2 seconds, then release the button. Both the LEDs should turn solid on.
Power
On
Internet
On
2.4GHz
On
5GHz
On
If your internet comes from an Ethernet outlet instead of a DSL / Cable / Satellite modem, connect the
router’s WAN port to it, and then follow steps 3 and 4 to complete the hardware connection.
*Image may dier from actual product.
Unplug the power to turn o your modem, if any, and remove
the backup battery if it has one.
Place the router horizontally and orient the antennas vertically.
Modem
Unplug the power
Power on the modem, and then wait
about 2 minutes for it to restart.
2
Connect the power adapter to the
router.
3
Verify that the hardware connection is correct by checking the following LEDs.
4
Set up with videos:
Scan QR code or visit
https://www.tp-link.com/support/setup-video/#wi--routers
1
Internet
Connect the powered-off
modem to the router’s WAN
port with an Ethernet cable.
1
Set Up the Network
Method ONE: Via TP-Link Tether App
1. Download the Tether app.
Scan for Tether
Tether
or
Method TWO: Via a Web Browser
The default wireless network names (SSIDs) and password
are printed on the label at the bottom of the router.
1. Connect your device to the router wirelessly
or with an Ethernet cable.
2. Open the Tether app and log in with your
TP-Link ID.
3. Tap the button in the Tether app and
select Wireless Router > Standard
Routers. Follow the steps to complete the
setup and connect to the internet.
Note: If you don’t have an account, create one first.
2
Model: Archer AX3000
AX3000 Gigabit Wi-Fi Router
Wireless Password/PIN:XXXXXXXX
SSID:TP-Link_XXXX
SSID:TP-Link_XXXX_5G
2. Launch a web browser, and enter
http://tplinkwifi.net or http://192.168.0.1 in
the address bar. Create a password to log in.
Note: If the login window does not appear, please refer to
Q1 of Need Help? in this guide.
3. Follow the step-by-step instructions to
set up the internet connection and
register for the TP-Link Cloud service.
To enjoy a more complete service from
TP-Link, bind your TP-Link ID to the router.
Choose Your Device Type
Gaming Router
Range Extender
Wireless Router
Note: Due to Tether app
updates, your actual
user interface and
pathway may differ from
those depicted here.
Dual Band Wi-Fi 6 Router
Q1. What should I do if I can’t access the web
management page?
•
Reboot your router and try again.
•
If the computer is set to a static IP, change its settings to
obtain an IP address automatically.
•
Verify that http://tplinkwifi.net is correctly entered in the web
browser. Alternatively, enter http://192.168.0.1 or
http://192.168.1.1 in the web browser.
•
Use another web browser and try again.
•
Disable and enable the network adapter in use.
Q2. What should I do if I can’t access the internet?
•
Power off your modem for about 5 minutes, then power it on
and check the internet. If your modem has more than one
Ethernet port, keep other ports unconnected.
•
Check if the internet is working normally by connecting a
computer directly to the modem via an Ethernet cable. If it is
not, contact your internet service provider.
•
Log in to the web management page, and go to the Network
Map page to check whether the internet IP address is valid
or not. If it’s valid, go to Advanced > Network > Internet,
click Advanced Settings, select Use the Following DNS
Addresses, set the primary DNS to 8.8.8.8, and set the
secondary DNS to 8.8.4.4. If it is not, check the hardware
connection or contact your internet service provider.
•
For cable modem users, log in to the web management
page of the router and go to Advanced > Network > Internet
> MAC Clone. Select Clone Current Device MAC and click
SAV E. Then reboot both the modem and the router.
Q3. What should I do if I forget my wireless password?
•
If you have not changed the default wireless password, it can
be found on the label at the bottom of the router.
•
Connect a computer directly to the router using an Ethernet
cable. Log in to the router’s web management page at
http://tplinkwi.net, and go to the Wireless page to retrieve
or reset your wireless password.
Q4. What should I do if I forget my web management
page password?
•
If you are using a TP-Link ID to log in, click Forgot
Password? on the login page and then follow the
instructions to reset it.
•
Alternatively, press and hold the Reset button on the back
for about 6 seconds until the Power LED blinks. Then visit
http://tplinkwifi.net to create a new login password.
©2024 TP-Link 7106511442 REV3.1.0
Need Help?
Button Explanation
Reset Button
Press and hold the button for about 6 seconds until the Power
LED blinks to reset the router to its factory default settings.
Quick Installation Guide
WPS/Wi-Fi Button
Press the button for 1 second, and immediately press the
WPS button on your client to start the WPS process.
Press and hold the button for more than 2 seconds, then
release the button to turn on or o the wireless function of
your router.
· Keep the device away from water, re, humidity or hot environments.
· Do not attempt to disassemble, repair, or modify the device. If you need
service, please contact us.
· Do not use any other chargers than those recommended.
· Do not use damaged charger or USB cable to charge the device.
· Do not use the device where wireless devices are not allowed.
· Adapter shall be installed near the equipment and shall be easily accessible.
For technical support, replacement services, user guides
and more, please visit https://www.tp-link.com/support
TP-Link hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of directives 2014/53/EU,
2009/125/EC, 2011 /65/EU and (EU) 2015/863.
The original EU declaration of conformity may be found at
https://www.tp-link.com/en/support/ce
TP-Link hereby declares that the device is in compliance with the essential
requirements and other relevant provisions of the Radio Equipment
Regulations 2017.
The original UK declaration of conformity may be found at
https://www.tp-link.com/support/ukca
Flexible Scalability
Flexibly scale your home networking with dierent
vendors,* dierent topologies, dierent Protocols and
dierent product categories.
One-Click Settings
Press the WPS button on the main router and the satellite
device within 2 minutes of each other, then the EasyMesh
network will set up.
Seamless Roaming
Connects mobile devices to your routers or extenders
that provide the best coverage. Devices compatible with
EasyMesh also share a single Wi-Fi name so you stay
connected in every room.
For more information, visit https://www.tp-link.com/easymesh/
*Failure may be due to rmware conicts of dierent vendors. A
better network connection can be established between all APs
from TP-Link.
You can experience strong, stable, and seamless
wireless connections throughout your home with
EasyMesh.
EasyMesh-Compatible
Setup Video
