Replacement Parts List
• Buckle Assembly
• Harness Strap
• Chest Clip
• Lower Anchor Belt
• Tether
• Locking Clip
• Seat Pad Set
• Cup Holders
• Instructions
4358-8527
10.30.24
8575 9642 9643 9644
8594
entrada
convertible car seat
Your model may look different than the one shown.
KEEP INSTRUCTIONS FOR FUTURE USE.
Read all instructions before using this car seat.
Failure to follow the warnings on the labels and
in the instruction manual can result in serious injury
or death to your child. Serious injury may include
paralysis and/or permanent brain injury.
3
getting
started
To help you get started using your child’s new
car seat (also known as a child restraint), these
are the four main tasks you’ll need to complete.
1
Measure your child.
Adjust the car seat to
fit your child.
2
Install the car seat
into your vehicle.
3
Table of Contents
Vehicle Belt, LATCH Belt, &
Tether Strap Information ............67
Vehicle Belts .............................68
LATCH: Lower Anchor Belt .........72
Tether Strap ..............................75
Safety Information .....................76
Child Restraint Use ....................77
Vehicle Seating Position ............78
Installation in Vehicle .................79
Replacement and Expiration.......80
Registration and Safety Notices ..81
Aircraft Information ...................82
Warranty ..................................83
Getting Started ............................3
Parts of the Car Seat ...................4
Accessory Use ............................6
Choosing a Car Seat Mode ..........7
Rear-Facing Mode .....................10
Rear-Facing
Child Fit Requirements ..............11
Rear-Facing
Vehicle Installation ....................14
Forward-Facing Mode ...............22
Forward-Facing
Child Fit Requirements ..............23
Forward-Facing
Vehicle Installation ....................26
Securing Your Child
in the Car Seat ...........................35
Making Adjustments
to the Car Seat ...........................40
Adjusting the Headrest ..............41
Changing the Harness Height .....42
Changing the Buckle Position.....44
Adjusting the Harness System
for Smaller Infants .....................48
Wash and Care ...........................54
Removing the Harness System ...55
Removing the Seat Pad Set
for Cleaning ..............................58
Cleaning the Seat Pad Set
and Parts of the Car Seat ..........59
Installing the Harness System
and Seat Pad Set ......................60
Secure your child in
the car seat.
4
4
5
Parts of the Car Seat
Adjustable
Headrest
Removable
Cup Holders
LATCH: Lower Anchor
Belt (bag may be in the
Forward-Facing Belt Path)
Headrest
Adjustment
Handle
Harness Release
Lever (through
opening in pad)
Harness
Adjustment
Strap
Upper Shoulder
Harness Slots
Lower Shoulder
Harness Slots (for
smaller infants only)
Hip Slots
Harness Straps
Chest Clip
Buckle Tongues
Buckle
Buckle Strap
Buckle Slots
Harness System
Instruction Manual
Storage (underneath
the seat pad)
Your model may look different than the one shown.
Front
Rear-Facing
Belt Path
Rear-Facing
Level Lines
Forward-Facing
Belt Path
Tether Strap
Tether Strap
Adjuster
LATCH: Lower
Anchor Belt Adjuster
Tether Strap
Storage Attachment
LATCH: Lower Anchor
Belt Storage Attachments
Buckle Metal Retainer
(underneath the
harness straps)
Harness Strap
Splitter Plate
Back BottomSide
6
7
Removable Cup Holders
To remove the cup holders: Twist the cup holder
counterclockwise and pull it out of the slot in the
seat. Repeat on the other side.
To install the cup holders: Align the bottom of
the cup holder to the slot on the seat. Twist the
cup holder clockwise until it clicks into place.
Repeat on the other side.
The cup holders are top-rack dishwasher safe.
Failure to follow these instructions may result in serious injury or death to your child. Serious injury can include
paralysis and/or permanent brain injury.
Be certain to measure your child’s weight and height (do not guess) before choosing this car seat’s mode.
WARNING
Your child’s height, weight, and age determine how the car seat
should be placed in the vehicle.
Children vary widely in body size, shape, and temperament—
please consult your doctor before switching between any
modes within the limits and fit requirements of the car seat.
Infants and Toddlers
Children must ride rear-facing and remain rear-facing until
they reach the maximum weight or height limits for rear-facing
mode. Rear-facing child restraints installed behind another
vehicle seat must be installed touching the back of the vehicle
seat in front of it, or be as close as possible.
Toddlers and Preschoolers
Children can only use a forward-facing car seat once they outgrow
rear-facing weight or height limits. Once they are forward-facing,
children must use their child restraint in forward-facing mode with
a harness until they reach the maximum weight or height limits for
forward-facing harness mode.
continued on next page
Accessory Use
Choosing a Car Seat Mode
8
9
In this car seat, your child MUST ride Rear-Facing and remain in
Rear-Facing mode until they outgrow any one of the above.
Rear-Facing Child Fit Requirements PAGE 11
Rear-Facing Vehicle Installation PAGE 14
REAR-FACING MODE
5–40 lb (2.3−18 kg) and
19–40 in. (48–101.6 cm)
In this car seat, your child can use the harnessed Forward-Facing
mode until they outgrow any one of the above.
Forward-Facing Child Fit Requirements PAGE 23
Forward-Facing Vehicle Installation PAGE 26
FORWARD-FACING MODE
30–65 lb (13.7−29.5 kg) and
34.4–49 in. (87.1–125 cm)
10
11
Rear-Facing Mode
Rear-Facing Child Fit Requirements
1
2
1 in. (2.5 cm)
1
1
2
1 in. (2.5 cm)
2
1
2
1 in. (2.5 cm)
3
Fully loosen the
harness straps
Push down on the harness release
lever (through the opening in the
seat pad) while pulling the harness
straps away from the backrest.
Unfasten the chest clip
While holding both sides of the
chest clip, press the release
button with your thumb and
pull the chest clip apart.
Unbuckle the harness
Press the red button to
release the buckle tongues.
1
2
1 in. (2.5 cm)
4
Place your child in
the car seat
Your child’s bottom and
back should be flat against
the car seat.
continued on next page
5–40 lb (2.3−18 kg) and
19–40 in. (48–101.6 cm)
In this car seat, your child MUST ride
Rear-Facing and remain in Rear-Facing
mode until they outgrow any one of the following:
•Weight limit: 40 lb (18 kg); OR
•Height limit: 40 in. (101.6 cm); OR
•
Rear-Facing Child Fit Requirements
PAGE 11
Rear-Facing Vehicle Installation PAGE 14
NEVER install a rear-
facing child restraint
in the front seat of a
vehicle equipped with
an active frontal airbag.
DO NOT use the tether for rear-facing
mode. Secure the tether strap hook to
its storage attachment.
DO NOT use the lower anchor belt
along with the vehicle lap or lap/
shoulder belt.
DO NOT fasten multiple lower anchor
hooks on the same lower anchor bar
in the vehicle.
Check the vehicle belt or the lower
anchor belt before each use.
Use ONLY if the belt can be tightened
properly and locked securely in place.
Even when unoccupied, this child
restraint MUST be firmly secured to
the vehicle with the lower anchor belt
or with the vehicle seat belt.
This child restraint MUST ALWAYS
face the rear of the vehicle until the
child has reached the maximum
weight or height limit for the rear-
facing mode.
WARNING
12
13
1
2
1 in. (2.5 cm)
5
Buckle the harness and fasten the chest clip
Pull the harness adjustment strap straight out to snugly tighten the
harness. Position the chest clip mid-chest (even with the armpits)
and away from your child’s neck.
See Securing Your Child in the Car Seat on page 35 for details on
chest clip position and checking harness tightness.
1
2
1 in. (2.5 cm)
6
Check the head position
The top of your child’s head MUST
be at least 1 in. (2.5 cm) below
the top of the car seat’s headrest.
To change the headrest position,
see page 41.
1
2
1 in. (2.5 cm)
1
2
1 in. (2.5 cm)
1
2
1 in. (2.5 cm)
7
Check the harness strap position
The harness strap MUST be positioned
at or slightly below the shoulders,
never above.
To change the harness strap height,
see page 42.
Check the buckle position
• Use the buckle slot closest to your child.
• The buckle strap should not be
underneath or behind your child.
• DO NOT use the third buckle slot in
Rear-Facing mode.
To change the buckle position, see page 44.
If you cannot achieve a snug
harness fit for your child, see
Adjusting the Harness System for
Smaller Infants on pages 48–53.
1
2
1 in. (2.5 cm)
8
Buckle
Buckle
Strap
14
15
Rear-Facing Vehicle Installation
There are two methods for installing the car seat in
your vehicle. Use only one:
OR
Vehicle Belt
LATCH: Lower Anchor Belt
DO NOT use both the LATCH: lower anchor belt and
vehicle belt at the same time to install the car seat.
WARNING
Lap/Shoulder
Belt
Lap Belt
Before installing the car seat:
• Check the child fit requirements on pages 11–13 and make any
necessary adjustments to the harness height or buckle position.
You can’t make these adjustments while the seat is installed.
• Review your vehicle owner’s manual to determine the type of
vehicle belts in your car and how to use them to lock a car
seat in place OR to locate the LATCH: lower anchor seating
positions. See also Vehicle Belts on page 68 and LATCH:
Lower Anchor Belt on page 72.
• If you are using a vehicle belt to install the seat, make sure the
lower anchor belt is stored away.
• If you are using the lower anchor belt to install the seat, unpackage
it from the shipping bag or remove it from the storage location if
necessary (see LATCH: Lower Anchor Belt on page 72).
• Make sure the tether strap is properly stored away (see page 75).
1
Place the car seat Rear-Facing
in the back seat
When using the passenger or driver side
locations, the car seat MUST be touching
the back of the vehicle seat in front of it
or be as close as possible.
2
Check the Rear-Facing Level Lines
For children 5–30 lb (2.3–13.6 kg) and 19–34.3 in. (48–87 cm), the
bottom level line on the car seat MUST be parallel with the ground.
For children 30–40 lb (13.7–18 kg) and 34.4–40 in. (87.1–101.6 cm)
AND can sit up unassisted, the top level line on the car seat MUST be
parallel with the ground.
Rotate the car seat up or down as needed until the appropriate level line for
your child’s weight and height is parallel with the ground.
continued on next page
16
17
You may need to fully lengthen the lower anchor belt
before routing it through the belt path. Squeeze the
adjuster button and pull the belt out as shown.
For the vehicle belt: Insert the vehicle belt into the
Rear-Facing Belt Path opening.
For the lower anchor belt: Start with the entire lower
anchor belt on the side where the belt is connected to
the seat (the child’s right). Insert one end of the lower
anchor belt into the Rear-Facing Belt Path opening.
3
Locate the Rear-Facing Belt Path opening and
begin routing the belt through the path
OR
4
Finish routing the vehicle belt or lower anchor
belt through the Rear-Facing Belt Path
Reach through the Rear-Facing Belt Path
opening on the other side of the car seat to pull
the belt completely through the path. Make sure
the belt is positioned properly so that it goes:
• Under the car seat pad; AND
• Across the car seat; AND
• In front of the buckle; AND
• Out the other Rear-Facing Belt Path opening.
DO NOT twist the belt.
Finished Lower Anchor
Belt Routing
Make sure there is a hook
on both sides of the car
seat. The lower anchor belt
adjuster can be located on
either side of the car seat.
Adjuster
continued on next page
18
19
5
OR
Buckle the vehicle belt
If your vehicle belt has a switchable retractor,
make sure it is in locking mode. Refer to
page 70 or your vehicle owner’s manual.
Attach the lower anchor hooks
to the vehicle’s lower anchors
The lower anchors are located in the crease
(also known as the bight) of the vehicle seat.
Fasten one hook to the vehicle lower anchor
bar on one side of the seat. Repeat with the
second hook on the other side of the seat.
6
Tighten the belt
Place your hand in the car seat. Firmly push the car
seat down and back towards the vehicle seatback
while using your other hand to pull the belt towards
you in line with the belt path.
If you are using a lap only vehicle belt or a lower
anchor belt, it may be easier to tighten the belt by
reaching into the belt path opening under the seat
pad and pulling the free end of the belt towards you.
7
Check the belt tightness
Hold the car seat at the Rear-Facing Belt Path with your
non-dominant hand. Push and pull the car seat from side to side.
The car seat should not move more than 1 in. (2.5 cm).
If the car seat moves more than 1 in. (2.5 cm), you can try:
• Pulling the belt tighter; OR
• Reinstalling the car seat: OR
• Changing to a different seating location; OR
• Switching to a different install method (vehicle belt or lower anchor belt).
continued on next page
20
21
FINISHED!
When using the passenger or driver side locations, the car seat MUST be
touching the back of the vehicle seat in front of it, or be as close as possible.
• If you used a vehicle belt, is it buckled and the switchable retractor
locked? See step 5.
• If you used the lower anchor belt, are the hooks securely attached to the
vehicle’s lower anchors? See step 5.
• Is the belt tightened enough so that the car seat does not move more
than 1 in. (2.5 cm) from side to side? See steps 6 and 7.
• Is the appropriate level line for your child parallel with the ground? See
steps 2 and 9.
Check your child’s fit often and make any adjustments to the car seat as they grow.
Check the tightness of the installation often to make sure it has not loosened.
Lap/Shoulder Belt
Lap Belt
LATCH: Lower
Anchor Belt
9
Recheck the Rear-Facing Level Lines
Check that the appropriate level line for your
child’s weight and height (see step 2) is parallel
with the ground. Redo the installation if the car
seat is not reclined correctly.
8
Secure your child in the car seat.
For complete details on properly securing your
child in the car seat, including how to position
the chest clip and check for harness tightness,
see pages 35–38.
22
23
Forward-Facing Mode
Forward-Facing Child Fit Requirements
30–65 lb (13.7−29.5 kg) and
34.4–49 in. (87.1–125 cm)
In this car seat, your child can use the
harnessed Forward-Facing mode until they
outgrow any one of the following:
•Weight limit: 65 lb (29.5 kg); OR
•Height limit: 49 in. (125 cm); OR
•
Forward-Facing Child
Fit Requirements PAGE 23
Forward-Facing Vehicle Installation
PAGE 26
DO NOT use the lower anchors of the child
restraint anchorage system (LATCH system)
to attach this child restraint when restraining
a child weighing more than 55 lb (24.9 kg).
The vehicle belt MUST be used for
installation if your child weighs more than
55 lb (24.9 kg).
When anchors are available, you MUST
ALWAYS attach, adjust, and secure
the tether (top anchorage) strap when
installing the car seat in the Forward-
Facing Mode with internal harness.
DO NOT use the lower anchor belt along
with the vehicle lap or lap/shoulder belt.
Check the vehicle belt or the lower anchor
belt before each use.
Use ONLY if the belt can be tightened
properly and locked securely in place.
DO NOT fasten multiple lower anchor
hooks on the same lower anchor bar in
the vehicle.
Even when unoccupied, this child restraint
MUST be firmly secured to the vehicle
with the lower anchor belt or with the
vehicle seat belt.
Before using this seat in Forward-Facing
Mode, your child must have outgrown the
seat in Rear-Facing Mode.
WARNING
1
2
3
1
Fully loosen the
harness straps
Push down on the harness release
lever (through the opening in the
seat pad) while pulling the harness
straps away from the backrest.
Unfasten the chest clip
While holding both sides of the
chest clip, press the release
button with your thumb and pull
the chest clip apart.
Unbuckle the harness
Press the red button to release
the buckle tongues.
1
2
3
4
Place your child in
the car seat
Your child’s bottom and
back should be flat against
the car seat.
1
2
1 in. (2.5 cm)
2
1
2
1 in. (2.5 cm)
3
continued on next page
24
25
1
2
3
5
Buckle the harness and fasten the chest clip
Pull the harness adjustment strap straight out to snugly tighten the
harness. Position the chest clip mid-chest (even with the armpits)
and away from your child’s neck.
See Securing Your Child in the Car Seat on page 35 for details on
chest clip position and checking harness tightness.
1
2
3
1
2
3
1
2
3
6
Check the head position
The top of your child’s ears MUST be
below the top of the car seat’s headrest.
To adjust the headrest, see page 41.
1
2
3
7
1
2
3
8
Check the harness strap position
The harness strap MUST be positioned at or slightly
above the shoulders, never below.
To change the harness strap height, see page 42.
Check the buckle position
• Use the buckle slot closest to your child.
• The buckle strap should not be underneath or
behind your child.
• The buckle can be used in any buckle slot in
Forward-Facing mode.
To change the buckle position, see page 44.
Buckle
Buckle
Strap
26
27
Forward-Facing Vehicle Installation
There are two methods for installing the car seat in
your vehicle. Use only one:
Before installing the car seat:
• Check the child fit requirements on pages 23–25 and make any
necessary adjustments to the harness height or buckle position.
You can’t make these adjustments while the seat is installed.
• Review your vehicle owner’s manual to determine the type of
vehicle belts in your car and how to use them to lock a car
seat in place OR to locate the LATCH: lower anchor seating
positions. See also Vehicle Belts on page 68 and LATCH:
Lower Anchor Belt on page 72.
• If you are using a vehicle belt to install the seat, make sure
the lower anchor belt is stored away.
• If you are using the lower anchor belt to install the seat,
remove it from the storage location if necessary (see LATCH:
Lower Anchor Belt on page 72).
For children up to
65 lb (29.5 kg).
DO NOT install by this method for children
weighing more than 55 lb (24.9 kg).
OR
Vehicle Belt + Tether
LATCH: Lower Anchor Belt + Tether
Lap/Shoulder
Belt
Lap Belt
DO NOT use both the LATCH: lower
anchor belt and vehicle belt at the
same time to install the car seat.
When anchors are available, you
MUST ALWAYS attach, adjust, and
secure the tether (top anchorage)
strap when installing the car seat
in the Forward-Facing Mode with
internal harness.
WARNING
1
Locate the top tether
anchors in your vehicle
Review your vehicle owner’s manual for
the top tether anchor locations and how
to route the tether strap if there are
vehicle headrests.
2
Lift the tether adjuster to
loosen and lengthen
the tether strap
Remove the tether hook from its
storage location first if necessary
(see page 75).
continued on next page
28
29
3
Place the car seat Forward-Facing
in the back seat
Make sure the tether strap is accessible at
the top of the seat.
The vehicle seatback MUST be in the upright
position, but you can adjust the angle slightly
to better match the angle of the car seat.
Refer to the vehicle owner’s manual for how
to adjust the vehicle seatback.
If your vehicle has a headrest that
interferes with a flush car seat
fit, refer to your vehicle owner’s
manual to check whether it can
be removed or adjusted, or if
there are other seating locations
to install the car seat.
You may need to fully lengthen the lower
anchor belt before routing it through the belt
path. Squeeze the adjuster button and pull
the belt out as shown.
5
For the vehicle belt: Insert the vehicle belt
into the Forward-Facing Belt Path opening.
For the lower anchor belt: Start with the
entire lower anchor belt on the side where the
belt is connected to the seat (the child’s right).
Insert one end of the lower anchor belt into
the Forward-Facing Belt Path opening.
Locate the Forward-Facing Belt Path opening
and begin routing the belt through the path
OR
continued on next page
4
Loosely attach the tether
hook to the vehicle’s
top tether anchor
See step 2 if you need to lengthen
the strap to reach the anchor.
30
31
Finished Lower Anchor
Belt Routing
Make sure there is a hook
on both sides of the car
seat. The lower anchor belt
adjuster can be located on
either side of the car seat.
Adjuster
6
Finish routing the vehicle belt or lower anchor
belt through the Forward-Facing Belt Path
Reach through the Forward-Facing Belt Path
opening on the other side of the car seat to pull the
belt completely through the path. Make sure the belt is
positioned properly so that it goes:
• Under the car seat pad; AND
• Across the car seat; AND
• Out the other Forward-Facing Belt Path opening.
DO NOT twist the belt.
7
Buckle the vehicle belt
If your vehicle belt has a switchable retractor,
make sure it is in locking mode. Refer to
page 70 or your vehicle owner’s manual.
Attach the lower anchor hooks
to the vehicle’s lower anchors
The lower anchors are located in the crease
(also known as the bight) of the vehicle seat.
Fasten one hook to the vehicle lower anchor
bar on one side of the seat. Repeat with the
second hook on the other side of the seat.
OR
continued on next page
32
33
8
Tighten the belt
Place your hand in the car seat. Firmly push the car
seat down and back towards the vehicle seatback
while using your other hand to pull the belt towards
you in line with the belt path.
a. If you are using a lap only vehicle belt or a lower
anchor belt, pull the free end of the belt parallel with
the belt path. It may be easier to reach into the belt
path opening to access the free end of the belt.
9
Check the belt tightness
Hold the car seat at the Forward-Facing Belt Path with your
non-dominant hand. Push and pull the car seat from side to side.
The car seat should not move more than 1 in. (2.5 cm).
If the car seat moves more than 1 in. (2.5 cm), you can try:
• Pulling the belt tighter; OR
• Reinstalling the car seat: OR
• Changing to a different seating location; OR
• Switching to a different install method(vehicle belt or lower anchor belt).
a
11
Secure your child in the car seat
For complete details on properly securing your
child in the car seat, including how to position
the chest clip and check for harness tightness,
see pages 35–38.
10
Tighten the tether
Push firmly on the back of the car seat and pull the
free end of the tether strap to remove all the slack.
continued on next page
35
34
FINISHED!
• If you used a vehicle belt, is it buckled and the switchable
retractor locked? See step 7.
• If you used the lower anchor belt, are the hooks securely
attached to the vehicle’s lower anchors? See step 7.
• Is the belt tightened enough so that the car seat does not
move more than 1 in. (2.5 cm) from side to side? See
steps 8 and 9.
• Has the tether been installed and tightened? See steps 4
and 10.
Check your child’s fit often and make any adjustments to the
car seat as they grow. Check the tightness of the installation
often to make sure it has not loosened.
Lap/Shoulder Belt + Tether
For children up to 65 lb (29.5 kg).
Lap Belt + Tether
For children up to 65 lb (29.5 kg).
LATCH: Lower Anchor Belt + Tether
DO NOT install by this method
for children weighing more than
55 lb (24.9 kg).
Securing Your Child in the Car Seat
1
2
1 in. (2.5 cm)
2
1
2
1 in. (2.5 cm)
3
Place your child in the car seat
Your child’s bottom and back should
be flat against the car seat.
Buckle the harness
Push the buckle tongues into the buckle
until they click. Pull the harness straps
up to make sure the buckle is locked.
Fasten the chest clip
Insert the right half of the
chest clip into the left half
and snap together.
1
2
1 in. (2.5 cm)
1
1
2
3
Follow the steps in this section to secure your child in both Rear-Facing and Forward-Facing modes, remove your child from
the car seat, and troubleshoot any issues.
Refer to Rear-Facing Child Fit Requirements on page 11 and Forward-Facing Child Fit Requirements on page 23 to make
sure your child fits the seat properly.
continued on next page
36
37
1
2
1 in. (2.5 cm)
4
Tighten the harness
Pull the harness adjustment strap straight
out to snugly tighten the harness.
Position the chest clip
Slide the chest clip up the harness straps
and position it at mid-chest (even with the
armpits) and away from your child’s neck.
5
Check the harness tightness
Try to pinch the harness at the shoulders vertically
between your index finger and thumb as shown.
If your fingers slip off, the harness is tight enough.
If you can pinch the harness strap, tighten it more
(see step 4).
6
A snug strap should not allow any slack. It lies in a
relatively straight line without sagging. It does not
press on the child’s flesh or push the child’s body
into an unnatural position.
If one side of the harness is tighter than the other,
lengthen the tighter side by pulling up the harness
near the hip slot.
continued on next page
38
39
FINISHED!
Your child is now secured in the
car seat.
Check your child’s fit often and
make any needed adjustments
to the car seat as they grow.
To remove your child from the car seat:
1. Loosen the harness straps. Push down on the
harness release lever (through the opening in
the seat pad) while pulling the harness straps
away from your child.
2. Unfasten the chest clip. While holding both sides
of the chest clip, press the release button with
your thumb and pull the chest clip apart.
3. Unbuckle the harness. Press the red button to
release the buckle tongues.
4. Remove your child.
Failure to fasten and tighten the harness system
correctly may allow the child to be ejected from the
child restraint in a crash or sudden stop causing serious
injury or death. Serious injury can include paralysis and/
or permanent brain injury.
DO NOT mistake comfort for safety. The harness system
must be snugly adjusted.
DO NOT put snowsuits or bulky garments
on your child when placing them in the
child restraint.
Bulky clothing can prevent the harness
straps from being tightened properly.
WARNING
Troubleshooting
• If the buckle or harness release lever sticks: DO
NOT LUBRICATE THEM. Check for dropped food, sticky
spilled drinks, dirt, leaves, etc. Clean the buckle or
harness release lever with warm water and remove any
objects with tweezers. If you cannot adjust the harness
to remain tight with the buckle securely locked, DO NOT
use this car seat.
• If the harness twists: Straighten the harness each time
you put your child in the car seat. When you remove your
child, lock the buckle and tighten the harness so it will
be ready for the next use.
40
41
making
adjustments to
the car seat
Follow the steps in these sections
when you need to adjust the car seat
to better fit your child.
1
Adjusting the Headrest
Changing the Harness Height
2
Changing the Buckle Position
3
Adjusting the Harness
System for Smaller Infants
4
1
2
1 in. (2.5 cm)
1
sewn
end
2
3
Fully loosen the
harness straps
Push down on the harness
release lever (through the
opening in the seat pad) while
pulling the harness straps
away from the backrest.
Squeeze the headrest
adjustment handle
Move the headrest up or down
to the proper height for your
child. You may also need to
adjust the harness straps to
achieve the desired headrest
height (see page 42).
Release the handle to
lock the headrest at the
chosen height
Turn the seat around to check
that the horizontal bar is
securely locked into position.
The headrest MUST be at the
lowest position if you have
adjusted the car seat for a
smaller infant.
For Rear-Facing Child Fit
Requirements, see page 11.
For Forward-Facing Child Fit
Requirements, see page 23.
Adjusting the Headrest
42
43
Changing the Harness Height
sewn
end
The harness system MUST be installed
correctly. DO NOT use a child restraint
with damaged harness straps.
WARNING
sewn
end
1
Fully loosen the harness straps
Push down on the harness release
lever (through the opening in the seat
pad) while pulling the harness straps
away from the backrest.
2
Adjust the harness height
Move the headrest up or down
to adjust the harness to the
proper height for your child. See
page 41 for additional details on
adjusting the headrest.
sewn
end
3
Tighten the harness adjustment strap
Turn the car seat over and pull the harness
adjustment strap straight out to tighten the
harness. Slide the chest clip up or down
as needed.
For Rear-Facing Child Fit Requirements,
see page 11.
For Forward-Facing Child Fit Requirements,
see page 23.
To check harness tightness, see pages 35–38.
If you cannot achieve a snug harness fit for your child,
see Adjusting the Harness System for Smaller Infants
on pages 48–53.
Check the harness straps often for any wear
or damage.
44
45
Changing the Buckle Position
Failure to place buckle’s metal retainer
completely through pad and child restraint
can result in serious injury or death.
Serious injury can include paralysis and/or
permanent brain injury.
WARNING
1
2
1 in. (2.5 cm)
1
1
2
3
2
Unbuckle the harness
Press the red button to release
the buckle tongues.
Turn the car seat over
Locate the buckle’s metal retainer
on the bottom of the car seat.
If the buckle had been adjusted for a
smaller infant, the metal retainer will
not be visible from the bottom of the
seat. From the top of the seat, push the
metal retainer down through the middle
slot (pull the front of the car seat pad
up for easier access). You’ll then be
able to access the metal retainer from
the bottom of the seat. Be sure to tuck
the seat pad back in when finished.
1
2
3
3
Rotate the metal retainer and
push it through the slot
Push the metal retainer through
the slot in both the car seat and
the seat pad.
1
2
3
4
Pull the buckle out
From the top of the car seat,
pull the buckle out
continued on next page
46
47
1
2
3
5
Insert the metal retainer into
the slot closest to the child
The buckle MUST face out. The buckle strap
should not be underneath or behind your child.
For Rear-Facing Mode: You MUST use the first or
second buckle slots closest to the back of the seat.
For Forward-Facing Mode: You can use any of
the three slots.
1
2
3
6
Pull the metal retainer through the slot
Turn the car seat over and pull the metal retainer
completely through the slot in both the seat pad and
the car seat. Rotate the metal retainer into position.
1
2
3
1
2
3
7
Check the buckle
Pull up on the buckle to make sure it is
secured. The buckle MUST NOT pull out.
For Rear-Facing Child Fit Requirements,
see page 11.
For Forward-Facing Child Fit Requirements,
see page 23.
To check harness tightness, see pages 35–38.
If you cannot achieve a snug harness fit for your child,
see Adjusting the Harness System for Smaller Infants
on pages 48–53.
48
49
Adjusting the Harness System
for Smaller Infants
If you cannot achieve a snug
harness fit for your infant, you
may need to adjust the buckle
strap position and/or the harness
strap length and location as
shown in this section.
1
2
3
1
1
2
3
2
Make sure the buckle
is in the first slot
To move the buckle to the
first slot, see page 44.
Pull the front of the
car seat pad up
Pull the seat pad over the cup
holders for easier access to the
buckle slots.
The harness system MUST be installed
correctly. DO NOT use a child restraint
with damaged harness straps.
WARNING
Adjusting the Buckle for Smaller Infants
1
2
3
3
Reach under the car seat to
move the metal retainer
While keeping the buckle in the first
slot, reach under the car seat and pull
the buckle’s metal retainer down and
away from the first slot. Push the metal
retainer up into the middle slot from
below the car seat as shown.
1
2
3
4
From the top of the car seat,
lay the metal retainer flat
against the car seat
The buckle strap should still be
in the first slot while the metal
retainer is flat against the car
seat in the second slot as shown.
1
2
3
5
Tuck the car seat pad around
the front of the car seat and
check the buckle
Pull up on the buckle to make sure
it is secured. The buckle MUST NOT
pull out.
50
51
When using the lower shoulder
harness slots for smaller
children, the headrest MUST
be in the lowest position as
shown in this section.
sewn
end
1
sewn
end
2
Fully loosen the harness straps
Push down on the harness release
lever (through the opening in the
seat pad) while pulling the harness
straps away from the backrest.
Remove both harness strap
loops from the splitter plate
Turn the car seat over to access
the splitter plate.
sewn
end
3
Pull the harness straps out of
the shoulder harness slots
Turn the car seat over and back around
to the front to remove the harness
straps from the shoulder slots.
sewn
end
4
Adjust the headrest to
the lowest position
Squeeze the handle to move the
headrest to the lowest position.
continued on next page
Adjusting the Harness Straps for Smaller Infants
52
53
6
Pull the harness straps through
the seat pad and car seat
Reach into the Forward-Facing Belt Path
with one hand to pull the strap through the
seat pad and then use the other hand to
pull the strap from the lower shoulder slot
in the rear of the car seat.
Repeat with the other strap.
5
Rethread the harness straps into
the lower shoulder slots
DO NOT twist the harness straps as you
insert them into the lower shoulder slots.
7
The sewn ends of the harness strap
loops MUST face towards you.
DO NOT twist the harness straps or
the harness adjustment strap.
sewn
end
Make sure the same upper harness
strap loops (labeled “2” above) are
fitted completely on both sides of
the splitter plate. DO NOT use the
lower loops (labeled “1” above) for
smaller infants.
8
Check the finished harness system
On the bottom of the car seat, the
harness system straps MUST lie under
the horizontal portion of the harness
strap as shown.
Attach the second harness strap
loops to the splitter plate
54
55
wash
and
care
Use the following sections to help
you clean and care for your car seat.
1
Removing the Harness System
Removing the Seat Pad Set for Cleaning
2
Cleaning the Seat Pad Set
and Parts of the Car Seat
3
Installing the Harness
System and Seat Pad Set
4
DO NOT use the child restraint without the
seat pad or with damaged harness straps.
WARNING
You MUST remove the harness system
before you can remove the seat pad set for
cleaning. Only remove the harness system
to clean the seat pad.
sewn
end
1
sewn
end
2
Fully loosen the harness straps.
Push down on the harness release
lever (through the opening in the
seat pad) while pulling the harness
straps away from the backrest.
From the back of the car seat,
remove both harness strap
loops from the splitter plate.
Removing the Harness System
continued on next page
56
57
sewn
end
3
Pull the harness straps out of
the shoulder harness slots
4
Unthread the harness
straps from both sides of
the chest clip.
5
Unthread the harness straps
from both buckle tongues.
DO NOT unbuckle them.
6
Pull the harness strap
out of the car seat.
7
Turn the car seat over. Rotate
the metal retainer and push
it through the slot in both the
car seat and the seat pad.
If the buckle had been adjusted for
a smaller infant, the metal retainer
will not be visible from the bottom
of the seat. From the top of the
seat, push the metal retainer down
through the middle slot (pull the
front of the seat pad up for easier
access). You’ll then be able to
access the metal retainer from the
bottom of the seat.
8
From the top of the car
seat, pull the buckle out.
9
Push the harness adjustment
strap through the slot in seat
pad, but DO NOT remove it
from the seat. See the next
section for how to remove
the seat pad.
58
59
Removing the Seat Pad
Set for Cleaning
Cleaning the Seat Pad Set and
Parts of the Car Seat
You MUST remove the harness system
before you can remove the seat pad set
for cleaning. See page 55.
sewn
end
1 2
Move the headrest to the middle
of the car seat (see Adjusting
the Headrest on page 41).
Gently pull the headrest
pad off from one side of
the headrest and then lift
it off the other.
3
Lift the seat pad off from the
sides by the cup holders.
4
Pull the seat pad off from
the top of the car seat and
gently remove it.
To clean the seat pad set:
Machine wash separately with cold water on gentle
cycle. DO NOT use bleach. Tumble dry separately for
10–12 minutes on low heat. Remove immediately.
To clean the harness straps:
Check the harness straps often for wear or damage.
Spot clean using warm sudsy water and a damp cloth.
Spilled food and liquids on the car seat may result in
mold or bacterial growth over time. These spills could
also attract insects or rodents.
To clean the buckle and the car seat:
Spot clean using warm sudsy water and a damp cloth.
DO NOT submerge into water.
60
61
Installing the Harness System
and Seat Pad Set
The harness system MUST be
installed correctly. DO NOT use the
child restraint without the seat pad
or with damaged harness straps.
WARNING
1
2
3
1
a. Turn the car seat over. Hold the harness strap with the sewn end
facing down. Insert the harness strap through the side slot at the
bottom of the car seat.
b. From the front of the car seat, pull the harness strap through the hip
slot. Leave enough of the harness strap beneath the seat to use with
the other hip slot. Make sure the sewn end is facing in as shown.
c. Repeat these steps with the other hip slot.
a
1
2
3
b
1
2
3
2
Pull the seat pad over the
top and sides of the car
seat, but not over the cup
holders yet.
1
2
3
3
Pull the harness strap that is
extending from one of the hip
slots in the car seat through the
corresponding hip slot in the seat
pad. Repeat with the harness
strap in the other hip slot.
1
2
3
4
Pull the seat pad around the
cup holders, making sure it is
tucked around the bottom of
both sides of the car seat.
1
2
3
5
Pull the headrest pad
over the headrest.
continued on next page
62
63
1
2
3
6
Pull the harness adjustment
strap through the slot in the
bottom of the seat pad.
1
2
3
7
Insert the metal retainer into the slot closest
to the child. The buckle MUST face out.
For Rear-Facing Mode: You MUST use the
first or second buckle slots closest to the
back of the seat.
For Forward-Facing Mode: You can use
any of the three slots.
1
2
3
8
Turn the car seat over and pull the
metal retainer completely through the
slot in both the seat pad and car seat.
Rotate the metal retainer into position.
1
2
3
9
Turn the car seat back over. Pull up on
the buckle to make sure it is secured.
The buckle MUST NOT pull out.
1
2
3
10
Make sure the straps are even in
length. The sewn ends of the harness
strap loops MUST face each other
when you hold them up. Pull the shorter
side of the strap up if needed until both
harness straps are the same length.
1
2
3
11
Rethread the harness straps through
the buckle and chest clip. The harness
strap ends go through the back of the
buckle tongues and then through the
chest clip from front to back.
continued on next page
64
65
sewn
end
12
Thread the harness straps into the
correct shoulder slots for your child.
DO NOT twist the harness straps as
you insert them into the shoulder slots.
sewn
end
13
From the back of the car seat, pull the harness
straps through the seat pad and car seat.
DO NOT twist the harness straps. Make sure
the straps are positioned over the horizontal bar.
sewn
end
14
Attach the first harness strap loops to the
splitter plate. The sewn ends of the harness
strap loops MUST face towards you.
DO NOT twist the harness straps or the
harness adjustment strap.
Make sure the same lower harness
strap loops (labeled “1” above) are fitted
sewn
end
sewn
end
completely on both sides of the splitter
plate. The loops labeled “2” are for
smaller infants only (see page 48).
On the bottom of the car seat, the
harness system straps MUST lie under
the horizontal portion of the harness
strap as shown.
sewn
end
15
Turn the seat over and pull the
harness adjustment strap straight out
to tighten the harness system.
continued on next page
66
67
For Rear-Facing Child Fit
Requirements, see page 11.
For Forward-Facing Child Fit
Requirements, see page 23.
To check harness tightness, see
pages 35–38.
If you cannot achieve a snug harness
fit for your child, see Adjusting the
Harness System for Smaller Infants
on pages 48–53.
Failure to place harness adjustment strap behind the
harness strap as shown can result in serious injury or death.
Serious injury can include paralysis and/or permanent
brain injury.
DO NOT use a child restraint with damaged harness straps.
sewn
end
WARNING
Vehicle Belt,
LATCH Belt, &
Tether Strap
Information
Refer to the following sections for
information about the belts and
straps used to install your car seat.
1
Vehicle Belts
LATCH: Lower Anchor Belt
2
Tether Strap
3
68
69
Vehicle Belts
Your vehicle’s features may be considerably
different than those pictured here.
If LATCH: lower anchors are not an option or if your
child weighs more than 55 lb (24.9 kg), you MUST use
the vehicle seat belt system to install the car seat.
Not all vehicle belts and seating positions will work
with car seats. Follow the steps in this section to
learn how to lock a car seat in Rear-Facing Mode
or Forward-Facing Mode with a vehicle belt.
DO NOT use both the lower anchor belt
and vehicle belt at the same time.
WARNING
You MUST review your vehicle owner’s manual
Review your vehicle owner’s manual to determine
the type of vehicle belts in your car and the
seating positions available for installing a car seat.
1 2
Check how this car seat can be locked into
place with the vehicle belt
The vehicle belt MUST NOT loosen after tightening
it. This requires locking it by using either:
• The vehicle belt’s retractor (see step 3) OR
• The vehicle belt’s latch plate (see step 4)
continued on next page
70
71
3
Check the retractor on your vehicle belts
Retractors pull vehicle belts into stored positions and lock
the belt to hold passengers in place. The following retractors
will work with this car seat:
• Switchable retractor (most vehicles have this type).
This retractor can be manually switched to a locking
mode. Your retractor MUST be in this locking mode to use
the vehicle belt with this car seat.
To switch to locking mode:
1. Slowly pull the shoulder belt all the way out and then let it go
back into the retractor 1–2 in. (2.5–5 cm).
2. As it retracts, you will likely hear a ratcheting sound.
3. Gently pull the belt to see if it has locked. You will not
be able to pull any more of the belt out once the lock
has engaged.
• Automatic locking retractor. This retractor always locks. It
will automatically lock after slowly pulling the shoulder belt out
at least halfway and letting it go back into the retractor 1–2 in.
(2.5–5 cm).
Emergency locking retractor
If the retractor does not lock, it is likely an emergency locking
retractor. This retractor only locks during a sudden stop or collision.
Continue to step 4 to determine if your vehicle belt’s latch plate
can lock the belt.
4
Check the latch plates on your vehicle belts
Latch plates are the part of the vehicle belt that goes into the buckle.
To check if the latch plate locks:
1. Buckle the vehicle belt.
2. Slowly pull up on the lap portion of the vehicle belt.
a. If the vehicle belt does not slide through the latch plate, it’s
locked. You can use the locking latch plate with this car seat.
b. If the vehicle belt slides through the latch plate, it is
a sliding latch plate. Sliding latch plates easily slip
between the lap and shoulder portions of the belt.
If you have an emergency locking retractor with
a sliding latch plate, you MUST use a locking clip.
Please contact us for a locking clip; see the
back cover.
NEVER use the following with this car seat:
• Emergency locking retractor lap-only belt
• Inflatable seat belts
Locking Latch Plate Sliding Latch Plate
a
b
72
73
LATCH: Lower Anchor Belt
Your vehicle’s features may be considerably
different than those pictured here.
The lower anchors of LATCH (Lower Anchors and Tethers
for CHildren) is a universal system for installing car seats
without using vehicle seat belts. The LATCH: lower anchor
belt can ONLY be used in vehicles that have the lower
anchor bars installed in designated seating positions. Most
vehicles manufactured after September 2022 are equipped
with LATCH: lower anchor bars. Check your vehicle
owner’s manual to see which seating positions may be
equipped with LATCH: lower anchor bars.
DO NOT use both the lower anchor belt
and vehicle belt at the same time.
WARNING
Squeeze the spring lever on the hook and remove it from
the storage attachment next to the Forward-Facing Belt
Path. Repeat with the hook on the other side of the car seat.
Reach into the Forward-Facing Belt Path to pull the lower
anchor belt out for use.
Hooks
Adjuster
Remove the tension from the belt by pushing down on the
side of the car seat with the adjuster. Press the adjuster’s
button to loosen the belt.
Squeeze the spring lever on the hooks, push the hooks
back into the vehicle seat, and rotate the hooks to the
side. Pull the hooks out of the vehicle seat.
Removing the Lower Anchor Belt
from the Storage Location
Removing the Lower Anchor Belt from
the Vehicle’s Lower Anchor Bars
continued on next page
74
75
The lower anchor belt MUST be properly stored in its location when:
• Using the vehicle belts to install the car seat OR
• The car seat is not installed in a vehicle.
To store the lower anchor belt, route the belt through the Forward-Facing
Belt Path. Secure the hooks to the storage attachments on both sides of
the car seat as shown. Gently tighten the belt to remove slack.
Storing the Lower Anchor Belt
Tether Strap
Your vehicle’s features may be considerably
different than those pictured here.
When anchors are available, you MUST ALWAYS attach,
adjust, and secure the tether (top anchorage) strap when
installing the car seat in Forward-Facing Mode with the
internal harness. Tethers improve the installation and stability of
car seats and reduce the risk of injury. Attach the tether hook
to the tether anchor designated by your vehicle manufacturer
for that seating position. Check your vehicle owner’s manual for
more information. If the seating position does not have a tether
anchor, use a different seating position or see your dealer or a
qualified mechanic to have one installed.
Using this child restraint without the tether strap anchored
as required by the manufacturer would be a misuse of
the child restraint and, in a sudden stop or crash, could
result in serious injury or death. Serious injury can include
paralysis and/or permanent brain injury.
DO NOT fasten multiple tether hooks on the same tether
anchor in the vehicle.
Storing the Tether Strap
The tether strap MUST be properly stored in its
storage location when:
• Installing the car seat in Rear-Facing Mode OR
• The car seat is not installed in a vehicle.
Attach the tether hook to its storage location as
shown. Use the tether strap adjuster to gently
tighten the tether strap and remove any slack.
WARNING
77
76
Safety
Information
Review the following sections to learn about car
seat safety and other important information.
1
Child Restraint Use
Vehicle Seating Position
2
Installation in Vehicle
3
Replacement and Expiration
4
5
6
7
Registration and Safety Notices
Aircraft Information
Warranty
NEVER take your child out of the child restraint
while the vehicle is moving.
NEVER leave your child unattended.
Placing your child in a hot child restraint may
result in burns.
DO NOT use a child restraint with damaged or
missing parts.
DO NOT use a child restraint with cut, frayed, or
damaged harnesses.
DO NOT substitute parts or try to modify the
child restraint in any way. DO NOT lubricate
buckles and fasteners.
DO NOT use any child restraint accessory except
those approved by Dorel Juvenile Group.
NEVER allow any child to play with this child
restraint; it is not a toy.
DO NOT remove or cover up any of the warning
labels or other labels on the child restraint.
This child restraint has been certified for use in
passenger vehicles. DO NOT use in a boat, on a
motorcycle, or in a cargo van or bus where there
are no seat belts or tether anchors.
Read all instructions for additional warnings.
WARNING
Child Restraint Use
78
79
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front seating positions.
Rear seating positions are statistically safer, whether you
have air bags, advanced air bags, or no air bags at all.
If you are not sure where to place the car seat in your vehicle:
• Consult your vehicle owner’s manual; OR
• Contact Dorel Juvenile Group Consumer Care Department; OR
• Visit your local Child Passenger Inspection Station. Go to https://
www.nhtsa.gov/vehicle-safety/car-seats-and-booster-seats to
find your closest station.
NEVER place a child rear-facing
in a seating position with an
active frontal air bag.
Check the vehicle owner’s manual for more
information about air bag/child restraint use.
Use the child restraint only on
vehicle seats that face forward.
DO NOT use on seats that face
the sides or rear of the vehicle.
For vehicles without a back seat, refer to your
vehicle owner’s manual.
WARNING
Vehicle Seating Position
Installation in Vehicle
To avoid your child being seriously burned, take the
following precautions:
• Park in the shade or where the sun does not directly hit
the car seat.
• Cover the car seat with a sheet or blanket when not in use.
• Check for hot seat and buckles before placing child in
car seat.
To help protect your vehicle seat’s upholstery from
damage: You may use an accessory approved by Dorel
Juvenile Group or a single layer towel underneath and
behind car seat.
Check the vehicle belt or lower anchor belt before each
use. Use only if the belt can be tightened properly and
locked securely in place.
Even when unoccupied, this child restraint MUST be firmly
secured to the vehicle with the lower anchor belt or with
the vehicle seat belt.
In a crash or sudden stop, an unsecured child restraint
could injure occupants.
WARNING
80
81
Replacement and Expiration
Registration and Safety Notices
DO NOT risk your child’s safety.
To keep your child as safe as possible, Dorel Juvenile Group
strongly recommends replacing the car seat even after a minor
crash, even if it was not occupied at the time.
Replacement After a Minor Crash
The National Highway Traffic Safety Administration states
that for a crash to be considered minor ALL of the following
MUST be true:
• Vehicle able to drive away from the crash site; AND
• Vehicle door nearest the car seat was not damaged; AND
• No passengers were injured; AND
• Airbags did not deploy; AND
• There is no visible damage to the car seat.
If the crash your car seat was involved in meets ALL the criteria,
you may not need to replace the car seat.
If one or more of these criteria are not true or if you are uncertain
of any of your answers, replace the car seat immediately.
Replacement After a Moderate to Severe Crash
You MUST replace this car seat if it has been in a moderate
to severe car crash.
This car seat is intended to protect a child in a single crash.
During a crash, the car seat and all of its parts absorb crash
energy which can deform or weaken it. Damage is not always
visible. A damaged car seat MUST be replaced immediately.
Expiration
On the side of the car seat there is a date
of manufacture label as shown. DO NOT
use this car seat more than 10 years
after the date of manufacture.
Please complete the postage-paid registration card that
came with your child restraint, and send it to us.
Child restraints could be recalled for safety reasons.
You must register this restraint to be reached in a recall.
Send your name, address, email address if available, and
the restraint’s model number and manufacturing date to:
Dorel Juvenile Group
P.O. Box 2609
Columbus, IN 47202
or call 1-800-544-1108 or register online at
www.djgusa.com/registration/carseat/us.
For recall information, call the U.S. Government’s Vehicle
Safety Hotline at 1-888-327-4236 (TTY: 1-800-424-9153),
or go to www.NHTSA.gov.
Brand Car Seat
2024/05/16
Example of model number, manufacture date, and line code.
If you don’t have the card or if your address
changes, you will nd the model number,
manufacture date, and line code on the label
located on the side of the car seat.
82
83
Aircraft Information
Warranty
Forward-Facing Aircraft Installation
Follow the vehicle belt install steps on pages
26–33, skipping the tether strap steps.
Rear-Facing Aircraft Installation
Follow the vehicle belt install steps on
pages 14–20.
This restraint is certified for aircraft use when used with the
internal harness.
Install the car seat in a window seat to avoid blocking
the aisle. If the aircraft lap belt is too short, ask the flight
attendant for a belt extender.
Use only on forward-facing aircraft seats. Contact the
airline for their specific policies.
Some airlines may ask to see a label
stating that this car seat is certified
for aircraft use. There is an airplane
certification label located on the side
of this car seat as shown.
You MUST store the lower anchor belt and tether strap
when installing with aircraft belts.
WARNING
Dorel Juvenile Group, Inc. (DJG) warrants this product to the original retail purchaser as follows:
This product is warranted against defective materials or workmanship for one year from the date of original purchase. An original
receipt is required to validate your warranty. DJG will, at its option, provide replacement parts or replace this product. DJG
reserves the right to substitute if the part or model has been discontinued.
To make a claim under this warranty, please contact our Consumer Care Department by phone: 1-800-544-1108 or text:
1-812-652-2525. Our hours of operation are from 8:00 a.m. to 6:00 p.m. EST Monday through Thursday and from 8:00 a.m. to
4:30 p.m. on Friday.
Proof of purchase is required and shipping charges are the responsibility of the consumer.
Warranty Limitations: This warranty does not include damages which arise from misuse or abuse of this product.
Limitation of Damages: The warranty and remedies as set forth are exclusive and in lieu of all others, oral or written, expressed or
implied. In no event will DJG or the dealer selling this product be liable to you for any damages, including incidental or consequential
damages, arising out of the use or inability to use this product.
Limitation of warranties and other warranty terms and state law rights: Any implied warranties, including implied warranties
of the merchantability and fitness for a particular purpose, shall be limited to the duration and terms of the express written
warranty. Some states do not allow limitations as to how long an implied warranty lasts or the exclusion or limitation of incidental or
consequential damages, so the above limitations may not apply to you.
This warranty gives you specific legal rights, and you may have other rights, which vary from state to state. Neither DJG nor the dealer
selling this product authorized any person to create for it any other warranty, obligation, or liability in connection with this product.
