DESIGNER PENDANT LAMP
DESIGNER PENDANT LAMP
INSTRUCTION MANUAL
This marking indicates that this
product should not be disposed
of with other household wastes.
Caution, risk of electric shock.
INTRODUCTION & WARRANTY
Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions
carefully before starting the installation and keep this manual handy for future reference. If you have any another
query, please contact our dealer or local vendor from whom you have purchased the product. They are trained
and ready to serve you at the best. The warranty is valid for 2 years from the date of purchase. The warranty does
not apply to damage caused by incorrect installation or abnormal wear and tear. The company gives no warranty
against damage to any surface due to incorrect removal and installation of the product. The products are suitable
for 10-12 Hours Daily operation. Usage of product for 24 Hours a day would void the warranty. This product is
warranted for manufacturing defects only.
1. Please make sure to turn o the power before starting the installation.
2. Installation must be performed by a qualified electrician.
3. The light source of this luminaire is not replaceable; when the light
source reaches its end of life the whole luminaire shall be replaced.
4. Proper grounding should be ensured throughout the installation.
5. For Indoor Use only
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
MODEL
SKU
MAX WATTS
HOLDER
INPUT POWER
DIMENSION
BODY TYPE
FABRIC COLOR
IP RATING
ADJUSTABLE HEIGHT
VT-89010
24114, 24115
60W
E27 (Bulb not included)
AC 220-240V, 50Hz
Ø420x500mm
Fabric+Metal
Matte Black, Beige
IP20
1.5M (Max)
IN CASE OF ANY QUERY/ISSUE WITH THE PRODUCT, PLEASE REACH OUT TO US AT: SUPPORT@V-TAC.EU
FOR MORE PRODUCTS RANGE, INQUIRY PLEASE CONTACT OUR DISTRIBUTOR OR NEAREST DEALERS.
V-TAC EUROPE LTD. BULGARIA, PLOVDIV 4000, BUL.L.KARAVELOW 9B
INSTALLATION INSTRUCTIONS
WIRING DIAGRAM
L
N
2. Use screws to fix mounting bar to the junction box.
1. Switch o the power before starting the installation.
3. Make the wire connections with connectors.
• Connect the live wire (L) from fitting to the live wire from main power supply.
• Connect the neutral wire (N) from fitting to the neutral wire from main power supply.
• Connect the earth wire from fitting to the earth wire from main power supply.
• Please pay close attention and make sure the wires are not exposed outside when wiring connections.
4. Use screws to fix canopy to mounting bar.
5. Check if the installation is completed and turn on the power.
1
2
3
4
5
Neutral Supply can be Blue or Black
Ground Supply Can be Green-yellow
Live Supply Can be Red or Brown
E27 Holder Included
D420
500
Ø120
25
