Frigidaire PRDA1922AF Professional Single-Door Refrigerator User Manual

Frigidaire.com USA 1-800-374-4432 Frigidaire.ca Canada 1-800-265-8352

Refrigerator

use & care

A16366506 (July 2024)

Introduction

.......................................................2

Important Safety information.....................3

Features .............................................................6

Installation .........................................................8

Door Reversal .................................................. 11

Door Removal ................................................. 12

Door Handle Installation ............................. 13

Water Supply Connection (some models) ... 14

Controls and Settings ..................................16

Automatic Water Dispenser .....................20

Storage Features ........................................... 21

Saving Energy ............................................... 25

Filter Replacement ...................................... 26

Care and Cleaning .......................................30

Troubleshooting .......................................... 32

Limited Warranty ......................................... 35

INTRODUCTION

Doors

 Handles are secure and tight

 Door seals completely to cabinet on

all sides

 Door is level from side to side across

the top

Leveling

 Appliance is level, side to side and

front to back

 Cabinet is setting solid on all corners

 Anti-tip bracket is set in front

(hinge side)

Electrical Power

 House power turned on

 Appliance is plugged in

Water Supply

 House water supply is connected

to appliance (Warning: Potable

water supply only.)

 No water leaks present at all

connections - recheck in 24 hours

Final Checks

 Shipping material is removed

 Registration card is sent in

 Appliance temperatures are set to

the recommended settings

 Provided accessories and

consumables are installed

Installation Checklist



Serial Number Location

jfk;fkda;jfda jfk;fkda;jfda jfk;fkda;jfda jfk;fkda;jfda

Welcome to our family

Thank you for bringing Frigidaire into

your home! We see your purchase as the

beginning of a long relationship together.

This manual is your resource for the use

and care of your product. Please read

it before using your appliance. Keep it

handy for quick reference. If something

doesn’t seem right, the troubleshooting

section will help you with common issues.

FAQs, helpful tips and videos, cleaning

products, and kitchen and home

accessories are available at Frigidaire.com.

We are here for you! Visit our website,

chat with an agent, or call us if you need

help. We may be able to help you avoid

a service visit. If you do need service, we

can get that started for you.

Let’s make it ocial! Be sure to register

your product.

Keep your product info here so it’s easy

to ﬁnd.

Model Number

Serial Number

Purchase Date

WARNING

WARNING indicates a potentially haz-

ardous situation which, if not avoided,

could result in death or serious injury.

IMPORTANT

IMPORTANT indicates installation, oper-

ation or maintenance information which

is important but not hazard-related.

DANGER

DANGER indicates an imminently haz-

ardous situation which, if not avoided,

will result in death or serious injury.

CAUTION

CAUTION indicates a potentially haz-

ardous situation which, if not avoided,

may result in minor or moderate injury.

Safety Deﬁnitions

This is the safety alert symbol. It is

used to alert of potential personal injury

hazards. Obey all safety messages that

follow this symbol to avoid possible injury

or death.

WARNING

Please read all instructions before using

this appliance.

IMPORTANT SAFETY INFORMATION

DANGER

DANGER Risk of ﬁre or explosion.

Flammable refrigerant used. Do not use

mechanical devices to defrost refrigera-

tor. Do not puncture refrigerant tubing.

DANGER Risk of ﬁre or explosion.

Flammable refrigerant used. To be re-

paired only by trained service person-

nel. Use only manufacturer-authorized

service parts. Any repair equipment

used must be designed for ﬂammable

refrigerants. Follow all manufacturer

repair instructions. Do not puncture

refrigerant tubing.

CAUTION

CAUTION Risk of ﬁre or explosion.

Dispose of refrigerator properly

in accordance with the applicable

federal or local regulations. Flammable

refrigerant used.

CAUTION Risk of ﬁre or explosion

due to puncture of refrigerant tubing.

Follow handling instructions carefully.

Flammable refrigerant used.

WARNING

CALIFORNIA RESIDENTS ONLY

Cancer and Reproductive Harm

www.P65Warnings.ca.gov

IMPORTANT SAFETY INFORMATION

Safety Instructions

• DO NOT store or use gasoline, or

other ﬂammable liquid within or in

the vicinity of this appliance. Read

Product Label for warnings regarding

ﬂammability and other hazards.

• DO NOT store explosive substances

such as aerosol cans with a ﬂamma-

ble propellant in this appliance.

• DO NOT operate the refrigerator in

the presence of explosive fumes.

• Avoid contact with any moving parts

of automatic ice maker.

• Remove all staples from the carton.

Staples can cause severe cuts, and

also destroy ﬁnishes if they come

in contact with other appliances or

furniture.

Child Safety

This appliance is not intended for use by

persons (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience and knowledge, unless

they have been given supervision or in-

struction concerning use of the appliance

by a person responsible for their safety.

Destroy or recycle the carton, plastic

bags, and any exterior wrapping mate-

rial immediately after you unpack the

refrigerator. Children should NEVER use

these items to play. Cartons covered with

rugs, bedspreads, plastic sheets or stretch

wrap may become airtight chambers, and

can quickly cause suocation.

Proper Disposal of your Appliance

Risk of child entrapment

Child entrapment and suocation are not

problems of the past. Junked or aban-

doned appliances are still dangerous –

even if they will sit for “just a few days”. If

you are getting rid of your old appliance,

please follow the instructions below to

help prevent accidents.

We strongly encourage responsible

appliance recycling/disposal methods.

Check with your utility company or visit

energystar.gov/products/recycle for more

information on recycling your

old appliance.

Before you throw away your old appliance:

• Remove door.

• Leave shelves in place

so children may not

easily climb inside.

• Have refrigerant

removed by a qualiﬁed

service technician.

IMPORTANT

CFC/HCFC Disposal

Your old appliance may have a cooling

system that used CFCs or HCFCs (chlo-

roﬂuorocarbons or hydrochloroﬂuoro-

carbons). CFCs and HCFCs are believed

to harm stratospheric ozone if released

to the atmosphere. Other refrigerants

may also cause harm to the environ-

ment if released to the atmosphere.

If you are throwing away your old

appliance, make sure the refrigerant

is removed for proper disposal by a

qualiﬁed technician. If you intentionally

release refrigerant, you may be subject

to ﬁnes and imprisonment under provi-

sions of environmental legislation.

WARNING

Do not use electrical appliances inside

the food storage compartments of the

appliance unless they are of the type

recommended by the manufacturer.

Grounding type duplex wall receptacle

Power cord with

3-prong grounded plug

Do not, under

any circumstances,

cut, remove,

or bypass the

grounding prong.

Electrical information

• Plug the appliance into its own

dedicated 115 Volt, 60 Hz., 15 Amp,

AC only duplex electrical outlet.

The power cord of the appliance is

equipped with a 3-prong grounding

plug for your protection against elec-

trical shock hazards. Plug it directly

into a properly grounded 3-prong

receptacle. Install the receptacle in

accordance with local codes and or-

dinances. Consult a qualiﬁed electri-

cian. Avoid connecting the appliance

to a Ground Fault Interrupter (GFI)

circuit. Do not use an extension cord

or adapter plug.

• If the power cord is damaged, an

authorized service technician should

replace it to prevent any risk.

• Never unplug the appliance by pull-

ing on the power cord. Always grip

the plug ﬁrmly, and pull straight out

from the receptacle to prevent dam-

aging the power cord.

• Unplug the appliance before cleaning

to avoid electric shock.

• Performance may be aected if the

voltage varies by 10% or more. Oper-

ating the appliance with insucient

power can damage the compressor.

Such damage is not covered under

your warranty.

• Do not plug the unit into an electrical

outlet controlled by a wall switch or

pull cord to prevent the appliance

from being turned o accidentally.

IMPORTANT SAFETY INFORMATION

WARNING

Follow these guidelines to ensure

safety mechanisms in this appliance

will operate properly.

IMPORTANT

To turn o power to your appliance you

must unplug the power cord from the

electrical outlet.

Appliance Setup

Use a dedicated grounding-type duplex

electrical outlet for each unit (i.e. two

duplex outlet receptacles, each on a

dedicated electrical circuit) for a paired

unit conﬁguration

FEATURES

Features may vary according to model

A Lower Drawer with

Removable Dividers

B Slide-out Shelf

C Water Filter

D Appliance Control Display

E CrispSeal Plus Drawer with Auto

Humidity and Produce Keeper™

F Internal Water Dispenser

G Adjustable Full Width

Glass Shelves

H Air Filter

I *Multi-Port Air Exhaust Ducts

J LED Lighting

K Adjustable Half Gallon Door Bins

with Removable Dividers

L Adjustable Gallon Door Bin with

Removable Divider

M Adjustable Tall Item Door Bins

with Removable Dividers

N Temperature Sensor/Thermistor

J J

IMPORTANT

*Do not place items in front of the

Multi-Port Air Exhaust Ducts or the

Temperature Sensor as this will impact

temperature performance.

IMPORTANT

Accessories are available for your appliance and may be purchased at

Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or 1-800-265-8352 in

Canada) or from an authorized seller.

FEATURES

IMPORTANT

Cleaning your Appliance

Remove tape and glue residue from surfaces before turning on the appliance.

Rub a small amount of liquid dish soap over any remaining adhesive with your

ﬁngers. Rinse with warm water and dry with a soft cloth.

Do not use sharp instruments, rubbing alcohol, ﬂammable ﬂuids, or abrasive

cleaners to remove tape or glue. These products can damage the surface of

your appliance.

After you remove all of the package materials, clean the inside of your appliance

before using it. See the CARE AND CLEANING section in this manual.

See important information about cleaning glass shelves and covers in the STORAGE

FEATURES section of this manual.

IMPORTANT

Moving your Appliance

Your appliance is heavy. When moving the appliance for cleaning or service, raise

the anti-tip bracket (see Setting the anti-tip bracket). Be sure to cover the ﬂoor

with cardboard or hardboard to avoid ﬂoor damage. Always pull the appliance

straight out when moving it. Do not wiggle or “walk” the appliance when trying to

move it as ﬂoor damage could occur.



NOTE

If you place your appliance with the

door hinge side against a wall, you may

have to allow additional space for the

handle so you can open the door wider.

This Use & Care Manual provides general

operating instructions for your model. Use

the appliance only as instructed in this Use

& Care Manual. Before starting the appli-

ance, follow these important ﬁrst steps.

Installation

Location

• Choose a place near a grounded

electrical outlet. Do Not use an

extension cord or an adapter plug.

• If possible, place the appliance

out of direct sunlight and away

from the range, dishwasher or

other heat sources.

• Install the appliance on a ﬂoor level

and strong enough to support a fully

loaded appliance.

Refrigerator

3/16˝

(5 mm)

3/16˝

(5 mm)

1˝

(25 mm)

1˝ (25 mm)

INSTALLATION

WARNING

DO NOT install the appliance where

the temperature will drop below 55°F

(13°C) or rise above 110°F (43°C). The

compressor will not be able to maintain

proper temperatures inside the unit.

CAUTION

Do not block the lower front of your ap-

pliance. Sucient air circulation is essen-

tial to operate your appliance properly.

WARNING

This appliance is intended for use

in residential household and similar

interior applications such as:

• Kitchen / Kitchenette

• Pantry Room

• Basement

• Enclosed Garage

• Other interior residential

type environments

WARNING

Installation clearances

Allow the following clearances for

ease of installation, proper air

circulation, and plumbing and

electrical connections:

Sides 3/16"

Top & Back 1"

33"

73.5"

25.625"

min

Minimum Cabinet dimensions for Single

Unit WITHOUT Trim Kit

Recommended Tools

• Level

• Appliance Slider

INSTALLATION

CAUTION

The cabinet is heavy. We recommend

two people to level the cabinet.

CAUTION

This unit does not have rollers. Use an

appliance slider or protective ﬂoor

covering while moving the unit into

place. Do not slide the unit with leveling

legs fully extended.

Leveling

Rest all bottom feet ﬁrmly on a

solid ﬂoor.

It is VERY IMPORTANT for your unit to

be level in order to function properly. If

you do not level the appliance during

installation, the door may be misaligned

and not close or seal properly, causing

cooling, frost or moisture problems.

To Level the Appliance:

Insert the appliance slider under the unit.

Place the unit into its location. Use the

carpenter’s level to make sure the unit is

level from front to back and side to side.

First adjust the front leveling legs, and

then the rear if necessary. If you cannot

access the rear leveling legs, slide the unit

back out and adjust it. Slide the unit back

into place and recheck with the level.

Repeat if necessary.

WARNING

Install the anti-tip device

according to the instruc-

tions in your Use & Care

Manual. Failure to do so

may result in injury.

Setting the anti-tip bracket:

Units are equipped with an anti-tip brack-

et. The anti-tip bracket is located on the

lower front corner of the cabinet, on the

lower hinge bracket. After fully leveling

the unit, lower the anti-tip foot by turning

it clockwise until is securely contacts the

ﬂoor. Do not raise the cabinet.

Lower

Anti-tip Bracket

Guidelines for ﬁnal positioning of

your appliance:

• Rest all bottom leveling feet ﬁrmly

on a solid ﬂoor.

• Level the cabinet on all sides.

• Level the door.

Pairing Installation

Pairing kit (TWINSPAIRKIT) is REQUIRED

if you are installing the following

appliances next to each other:

• Freezer and Refrigerator

• Freezer and Freezer

• Refrigerator and Refrigerator

To obtain this kit, please contact the

retailer where you purchased your

appliances, or contact Frigidaire customer

service at 1-800-374-4432 in the US,

1-800-265-8352 in Canada.

INSTALLATION

Filtered Ice Kit

In order for the freezer ice maker to have

ﬁltered water for ice, we recommend

ﬁltered ice kit (TTICEKITSVC) when you

are installing the following appliances

next to each other:

• Freezer and Refrigerator

To obtain this kit, please contact the

retailer where you purchased your

appliances, or contact Frigidaire customer

service at 1-800-374-4432 in the US,

1-800-265-8352 in Canada.

Door

Raise

Door

Raise

Door

Freezer Hinge

Adjustment

Freezer

Refrigerator

Door

Lower Hinge Adjustment for Leveling

the Doors of the Matching Refrigerator /

Freezer Pair

To level the doors using the adjustable

lower hinge (some models):

If the refrigerator door is lower than the

freezer door, raise the refrigerator door

by turning the adjustment screw counter-

clockwise using a 19 mm socket wrench.

(See illustration below.)

If the freezer door is lower than the

refrigerator door, raise the freezer door

by turning the adjustment screw counter-

clockwise using a 19 mm socket wrench.

(See illustration below.)

DOOR REVERSAL

Single Unit Door Swing Reversal:

• Refrigerator: Right-hand to Left-hand Swing order TTDRRVFRKIT

• Freezer: Left-hand to Right-hand Swing order TTDRRVFFKIT

Order the kit on Frigidaire.com or by calling 1-800-374-4432 (Frigidaire.ca or

1-800-265-8352 in Canada).

Right-hand Swing Left-hand Swing

CAUTION

Doors are heavy. Two people are recommended to remove or replace the door

assembly from the cabinet.

Dual Unit Door Reversal:

• Moving the Refrigerator door to the Freezer also changes the left-hand swing to

a right-hand swing.

• Moving the Freezer door to the Refrigerator also changes the right-hand swing to

a left-hand swing.



NOTE

You need to also transfer the hinges and associated hardware in order to the

switch doors.

DOOR REMOVAL

Tools Necessary:

Socket

Wrench Set

Adjustable

Wrench

5/16"

(8mm)

Fixed

Wrench

Flathead

Screwdriver

and

Phillips

Head or

#2 Square

Drive Head

8mm

(M5x16mm)

Hex head screw x3

Door removal:

• Unplug the unit or switch the breaker

that supplies power to the unit to the

o position.

• Hold the door in place while remov-

ing the top hinge from the cabinet.

• Remove the M5x16 mm hex head

screws from the top hinge with a

wrench or socket.

• Lift the door upward and pull up and

away from the cabinet until free of

the bottom hinge pin mounted on

the front of the cabinet.

• To replace the door, reverse the above

procedures and securely tighten all

screws to prevent hinge slippage.

IMPORTANT

Before you begin, remove the electrical power cord from the wall outlet. Remove

any food from door bins.

CAUTION

Doors are heavy. Two people are

recommended to remove or replace

the door assembly from the cabinet.

CAUTION

Close the door prior to removing

or installing.

If you need to remove the door to

transport your unit, you must have a

consistent 9 mm door gap around the

perimeter of the cabinet to ensure proper

gasket sealing to prevent frost in freezer.

Measure the 9 mm gap from the metal of

the cabinet to the metal on the door.

9mm

Set hinge

parallel to

cabinet

Door Handle Mounting Instructions

1. Remove the handle and any

protective packaging from inside

the appliance.

2. Position the handle end caps over the

upper and lower pre-installed shoul-

der bolts (A) fastened into the door,

ensuring the holes for the set screws

are facing away from the hinge.

3. While holding the handle ﬁrmly

against the door, fasten the upper

and lower Allen set screws (B) with

the supplied Allen wrench.

CAUTION

Wear gloves and use extreme

CAUTION when installing these

handles. The rounded end of the

handles may be sharp.



NOTE

Tighten and sub ﬂush all set screws

(Allen set screw should be seated just

below the surface of the end cap) of

the handle end cap. Tightly draw the

end caps to the door with no gaps.

DOOR HANDLE INSTALLATION

WATER SUPPLY CONNECTION (SOME MODELS)

Before Installing The Water Supply Line,

You Will Need:

• Basic Tools: adjustable wrench,

ﬂat-blade screwdriver, and

Phillips

screwdriver

• Access to a household cold water

line with water pressure between

30 and 100 psi.

• A braided stainless steel water supply

line with integral ﬁttings such as Smart

Choice® 5304437642 or ¼" copper

line with compression ﬁttings. The line

must be 6' or longer to allow appliance

to be moved out for cleaning.

• A shuto valve to connect the water

supply line to your household water

system. DO NOT use a self-piercing

type shuto valve.

• Do not reuse compression ﬁtting or

use thread seal tape.

CAUTION

To Avoid Property Damage:

• Use Copper or Stainless Steel braid-

ed tubing for the water supply line.

We do not recommend water supply

tubing made of ¼” plastic. Plastic

tubing greatly increases the potential

for water leaks, and the manufac-

turer will not be responsible for any

damage if plastic tubing is used for

the supply line.

• DO NOT install water supply tubing

in areas where temperatures fall

below freezing.

WARNING

To avoid electric shock, which can

cause death or severe personal injury,

disconnect the unit from electrical

power source before connecting a

water supply line to the appliance.



NOTE

Ensure your water supply line

connections comply with all local

plumbing codes.

To Connect Water Supply Line To Water

Inlet Valve

1. Disconnect the refrigerator from the

electrical power source.

2. Place the end of the water supply

line into a sink or bucket. Turn ON

the water supply and ﬂush the supply

line until the water is clear. Turn OFF

the water supply at the shuto valve.

3. Remove the plastic cap from the wa-

ter valve inlet and discard the cap.

4. If you use copper tubing - Slide the

brass compression nut and then

the ferrule (sleeve) onto the water

supply line. Push the water supply

line into the water valve inlet as far

as it will go (¼"/6.4 mm). Slide the

ferrule (sleeve) into the valve inlet

and ﬁnger tighten the compression

nut onto the valve. Tighten another

half turn with a wrench; DO NOT

overtighten. See Figure 1.

If you use braided ﬂexible stainless

steel tubing - The nut is already

assembled on the tubing. Slide the

nut onto the valve inlet and ﬁnger

tighten the nut onto valve. Tighten

another half turn with a wrench; DO

NOT overtighten. See Figure 2.

5. With the steel clamp and screw,

secure the water supply line (copper

tubing only) to the rear panel of

refrigerator as shown.

6. Coil the excess water supply line

(copper tubing only), about 2½ turns,

behind refrigerator as shown and

arrange coils so they do not vibrate or

wear against any other surface.

7. Turn ON the water supply at shuto

valve and tighten any connections

that leak.

8. Reconnect the appliance to the

electrical power source.

• A compression nut and ferrule

(sleeve) for connecting a copper

water supply line to the water valve.

WATER SUPPLY CONNECTION (SOME MODELS)

A Plastic Water Tubing to

Water Dispenser (foamed within

the cabinet)

B Steel Clamp (Fig. 1: ¼"; Fig. 2: ½")

C Brass Compression Nut

D Ferrule (Sleeve)

E Copper Water Line

F Water Valve Bracket

G Valve Inlet

H Water Valve

I Copper Water Line from

Household Water Supply*

J Braided Flexible Stainless Steel

Water Line

*Include enough tubing in the loop to allow

moving the refrigerator out for cleaning

Figure 1

Figure 2



NOTE

Check with your local building authori-

ty for recommendations on water lines

and associated materials prior to in-

stalling your new refrigerator. Depend-

ing on your local/state building codes,

We recommend for homes with existing

valves its Smart Choice® water line kit

5305513409 (with a 6�Stainless Steel

Water Line) and for homes without an

existing valve, we recommend Smart

Choice® water line kit 5305510264

(with a 20�copper water line with

self-tapping saddle valve). Please refer

to Frigidaire.com for more information.

CONTROLS AND SETTINGS

Cool Down Period

To ensure safe food storage, allow the appliance to operate with the door closed for at

least 8 hours before loading it with food.

Power On

Upon opening the door, the settings icon illuminates on the appliance control display.

Appliance Control Display

5 6 7 8 9

1110

By pressing the settings icon, you illuminate all of the icons on the appliance control.

After 10 seconds of no user interaction with the icons or door closure, all the icons

fade, except for the settings icon.

The appliance control display is located in the cabinet below the upper drawer.

Features may vary by model.

CONTROLS AND SETTINGS

Alarms

Controls

DOOR OPEN

This alert indicates the door has been open for 5 minutes or more. The DOOR

OPEN LED illuminates and the audible alert sounds until the door is closed.

You can turn o the audible alert by pressing DOOR OPEN or by closing the

door. If the door is ajar for 5 minutes, the interior light turns o.

POWER OUTAGE

The POWER OUTAGE indicator light informs you of a power interruption. Reset

the alarm by pressing POWER OUTAGE.

HIGH TEMP

If the temperature increases above a safe temperature range, the red HIGH

TEMP LED light illuminates and the alarm sounds. Reset the alarm by pressing

HIGH TEMP.

You can use the lock button to lock the control display. Press and hold for 3 sec-

onds to enable. While in the locked state, you cannot make changes until unlocked.

Press and hold for 3 seconds to disable.

The settings icon illuminates upon opening the appliance door. Press the set-

tings icon to reveal other function icons. After 10 seconds of non use of icons or

door closure, all icons fade except the settings icon.

Adjusting Temp

To adjust the temperature setting, press + to raise the temperature and — to

lower the temperature on the appliance control display. Allow several hours for

the temperature to stabilize between adjustments.

TEMP °F/°C

Short press to toggle between Fahrenheit (°F) and Celsius (°C).

CHILL BOOST

Turning on CHILL BOOST cools the appliance down to a target temperature and

remains active for up to 24 hours before automatically deactivating or being

manually exited. To turn the function on/o, press CHILL BOOST. When you

turn o CHILL BOOST, it automatically resets the refrigerator back to the previ-

ous temperature setting.

AIR FILTERS

The AIR FILTERS replacement alert illuminates when it is time to replace the

air ﬁlters. See the FILTER REPLACEMENT section for instructions on how to

replace the air ﬁlters. After changing the air ﬁlters, reset the AIR FILTERS alert

by pressing and holding AIR FILTERS.

WATER FILTER

The WATER FILTER replacement alert illuminates when it is time to replace the

water ﬁlter. See the FILTER REPLACEMENT section for instructions on how to

replace the water ﬁlter. After changing the water ﬁlter, reset the WATER FILTER

alert by pressing and holding WATER FILTER. After replacing the water ﬁlter,

see the AUTOMATIC WATER DISPENSER section for instructions on how to

prime the water system.

WATER DISP

The illuminated WATER DISP LED means the internal water dispenser is ON.

Open the internal water dispenser by pushing the push-push nozzle. Press the

water dispenser paddle inside the cabinet to dispense water. Turn the dispens-

er o by pressing and holding WATER DISP for 3 seconds. When the water

dispenser is o, you cannot dispense water. You will hear a beep if you try to

press the paddle without turning on WATER DISP. Press and hold WATER DISP

to turn it on.

Sabbath Mode

The Sabbath Mode feature disables portions of the appliance and its controls in

accordance with observance of the weekly Sabbath and religious holidays within the

Orthodox Jewish community.

To enter Sabbath Mode

Simultaneously press and hold — and TEMP F/C for 5 seconds.

For further assistance, guidelines of proper usage and a complete list of models

with the Sabbath feature, please visit the web at star-k.org.

The unit stays in Sabbath mode after a power failure recovery. You must deactivate it

with the buttons on the appliance control display.

Sb appears on the appliance control display indicating the unit is in Sabbath mode.



NOTE

While in the Sabbath Mode, neither the lights nor the appliance control display will

work (except to exit Sabbath Mode) until you deactivate Sabbath Mode.

The appliance stays in Sabbath Mode after power failure recovery. You must deacti-

vate it with the buttons on the appliance control display.

CONTROLS AND SETTINGS

To exit Sabbath Mode

Simultaneously press and hold — and TEMP F/C for 5 seconds.

The appliance control display shows all of the icons depending on your model.

In the Sabbath mode, the HIGH TEMP alarm is active for health reasons. For example,

if you leave the door ajar, the HIGH TEMP alarm is activated. The refrigerator functions

normally once you close the door, without any violation of the Sabbath/holidays. The

HIGH TEMP alarm comes on when the cabinet temperature is outside the safe zone

for 20 minutes. The alarm silences itself after 10 minutes while the HIGH TEMP icon

stays lit until you exit the Sabbath mode.

All buttons are disabled, and all sounds (except the HIGH TEMP alert*) are muted.

Only the HIGH TEMP alert illuminates until you deactivate the Sabbath Mode.

AUTOMATIC WATER DISPENSER

Your refrigerator might be equipped with

an internal water dispenser mounted inside

the cabinet, along the left-hand cabinet

wall (varies by model).

Before using the water dispenser for the

ﬁrst time or after changing the water ﬁlter,

you must prime your water supply system.

The water nozzle inside the cabinet allows

the water nozzle (A) to be recessed

against cabinet when not in use and to

be extended outward when in use. To

use the water dispenser, push the water

nozzle (A) so it is fully extended. Place a

cup against the paddle (B) and press to

dispense water.

Water Dispenser

O

Priming the water supply system

Using the dispenser after installation:

If you do not ﬂush the system, the ﬁrst

glass of water may have discolored water

or have an odd ﬂavor.

1. Begin ﬁlling the system by pressing

a drinking glass against the water

dispenser paddle.

2. Keep the glass in this position until

the water comes out of

the dispenser. It may take about

1½ minutes.

3. Continue dispensing water for

about 4 minutes to ﬂush the system

and plumbing connections of any

impurities (stopping to empty the

glass as necessary).

If the water dispenser function becomes

disabled, enable the water dispenser by

pressing and holding WATER DISP on the

appliance control display. When you turn

on the water dispenser, the LEDs above

WATER DISP illuminate.



NOTE

Optional: Lock the water dispenser

back in place by pushing the water

nozzle back in when you have ﬁnished

dispensing water.



NOTE

If you prefer to keep the internal water

dispenser disabled, use the appliance

control display to disable it. The LEDs

will not illuminate above WATER DISP.

CAUTION

For proper dispenser operation, the

recommended water supply pressure

should fall between 30 psi and 100

psi. Excessive pressure may cause the

system to malfunction.

STORAGE FEATURES

Full Width Cantilever Shelves

You can move multi-position adjustable

glass shelves to any position for larger

or smaller packages. You may also

remove and discard the shipping spacers

stabilizing the shelves for shipping.

To Adjust The Shelves

• Remove all food from the shelf.

• Shelves are heavy. We recommend

using both hands to install and

remove the shelf. Place one hand

centered on the front trim and the

other hand centered under the rear

of the shelf.

• Lift the front edge up at a slight

angle to release the tabs from the

slots in the rear. Continue lifting the

shelf vertically until the shelf clears

the built-in shelf supports located on

the sides of the cabinet. Then pull the

shelf out.

• Replace the shelf by inserting the

mounting bracket hooks into the

desired support slots at the rear.

• Carefully lower the shelf and lock it

into position.

IMPORTANT

Carefully handle the shelves when

removing and installing them to prevent

making contact with the cabinet liners

and the stainless steel rear air tower.

Do not block the air-ﬂow vents located

on the back wall of the air tower with

the shelves.

Slide-Out Shelf

The slide-out shelf can hold many

dierent containers and food types for

your convenience.

We recommend opening and closing the

slide-out shelf by grabbing the shelf with

a single hand in the middle of the shelf

handle.

To remove the slide-out shelf:

1. Remove all items from the shelf.

2. We recommend using both hands

to remove and install the shelf from

the slide rail supports. Remove the

shelf by pulling it out until it is fully

extended. Lift up on the front of the

handle area and lift it out.

3. Carefully handle the shelf to prevent

making contact with the cabinet

liner during removal and installation.

CrispSeal® Crisper with

Auto Humidity and PureAir

Produce Keeper™

The CrispSeal Crisper with Auto Humid-

ity keeps produce fresher longer, so you

waste less food and save money. It blocks

dry air by maintaining the perfect amount

of moisture while removing excess mois-

ture. The crisper contains the PureAir

Produce Keeper to ensure your produce

stays fresher longer. For more information

about your PureAir Produce Keeper, see

FILTER REPLACEMENT.

STORAGE FEATURES

We recommend opening and closing the

drawer by grabbing the center of the

crisper handle.

To remove the Crisper:

1. Remove all items from the crisper.

2. We recommend using both hands

to install the crisper into the slide

rail supports. Remove the crisper

by pulling it out until it is fully

extended. Lift up on the front of the

handle area and lift it out.

3. Carefully handle the crisper to

prevent making contact with the

cabinet liner during removal and

installation.

Lower Drawer with Dividers

The lower drawer with dividers works

great for food needing to be separated.

Use the drawer with the dividers or

without by removing or adding the inserts.

STORAGE FEATURES

We recommend opening and closing the

lower drawer by grabbing the center of

the handle.

To remove the lower drawer:

1. Remove all items from the

lower drawer.

2. We recommend using both hands to

remove and install the lower drawer

from slide rail supports. Remove the

drawer by pulling it out until it is

fully extended. Lift up on the front

of the handle trim and lift it out.

3. Carefully handle the drawer to

prevent making contact with the

cabinet liner during removal and

installation.

Adjustable Door Bins

with Dividers

The adjustable door bins are specially de-

signed to hold large containers or storage

bags. You can use each bin type only in

the zone indicated below so the door can

close correctly. Your unit has two 2-Liter

Door Bins (A), a Gallon Door Bin (B), and

two Tall Item Door Bins (C).

To remove a door bin:

• Grasp the ends of the door bin.

• Lift the door bin up until it clears the

locking lugs.

• Pull the door bin straight out

toward you.

To install a door bin:

• Make sure the locking feature on the

bin aligns with the mounting lugs on

the door.

• Lower the door bin into the mounting

lugs until it locks in place.

Use the bins with or without the dividers.

Customize your unit to ﬁt dierent sized

items as your needs change with door

bin dividers.

To remove, grasp the divider and pull

it upward until it disengages with the

door bin.

To install, slide the divider downward into

the corresponding door bin alignment

features until it is fully placed.

STORAGE FEATURES

SAVING ENERGY

• Locate the appliance in the coolest part of the room, out of direct sunlight,

and away from heating ducts or registers. Do not place the unit next to heat-

producing appliances such as a range, oven, or dishwasher. If this is not possible,

a section of cabinetry or an added layer of insulation between the two appliances

will help the unit operate more eciently.

• Level the appliance so the door closes tightly.

• Refer to CONTROLS AND SETTINGS for the suggested temperature control settings.

• Do not overcrowd the unit or block cold air vents. Doing so causes the appliance

to run longer and use more energy.

• Cover foods and wipe containers dry before placing them in the appliance. This

cuts down on moisture build-up inside the unit.

• Organize the appliance to reduce door openings. Remove as many items as

needed at one time and close the door as soon as possible.

FILTER REPLACEMENT

PurePour™ and PureAdvantage™

Ultra Water & Ice Filters

Keep safe, great-tasting water ﬂowing

with a Genuine Water Filter. Using a

Genuine Water Filter:

• Makes Safe Water Second Nature

Genuine Water Filters are certiﬁed

to reduce contaminants* and keep

great-tasting water ﬂowing for you

and your family.

• Produces Purity You Can Trust

Know for certain your water ﬁlter is a

protector. Counterfeits and knockos

put your refrigerator and health at

risk. Genuine Water Filters are the

smarter, safer choice.

• Every Drop Gives Back

Partnered on sustainability eorts,

the use of a Genuine Water Filter

helps cut back on the cost and use of

plastic used to produce and package

bottled water.

Ordering your replacement water ﬁlter

If you have not used your refrigerator for

a period of time (during moving for exam-

ple), change the ﬁlter before reinstalling

the refrigerator. Order PurePour replace-

ment ﬁlters online at Frigidaire.com, by

calling 1 (800) 374-4432 or through the

dealer from which the refrigerator was

purchased. Order PureAdvantage replace-

ment ﬁlters

at Electrolux.com, by calling

toll-free at 1-877-435-3287, or by visiting

the dealer where you purchased your unit.

We recommend replacing ﬁlters at least

once every 6 months.

Here are the product numbers to request

when ordering:

PurePour™ Water & Ice Refrigerator Filter

PWF-1™ FPPWFUO1 (White interior)

Do not use with water that is microbio-

logically unsafe or of unknown quality

without adequate disinfection before or

after the system. Use systems certiﬁed for

cyst reduction on disinfected waters that

may contain ﬁlterable cysts.

Test & certiﬁcation results:

• Rated Capacity - 125 gal/453 L for

PurePour and PureAdvantage ice

and water ﬁlters

• Rated service ﬂow - .50 gal/min.

• Operating Temp.: Min. 33°F, Max. 100°F

• Maximum Rated Pressure - 100 lbs/in.²

• Recommended Minimum Operating

Pressure: 30 lbs/in²



NOTE

When you order your replacement ﬁlter,

please reorder the same ﬁlter type

currently in your refrigerator.

More about your advanced water ﬁlter

Certiﬁed by IAPMO R&T against NSF/ANSI

Standards 42, 53, 401, CSA B483.1 and

NSF/ANSI/CAN 372 in PurePour PWF-1

and PureAdvantage PWF-1 systems for

reduction of the claims on the Performance

Data Sheet*.

*Find the Performance Data Sheet

located in the Guides and Manuals

section for your speciﬁc water ﬁlter

on Frigidaire.com.

PureAdvantage™ Water & Ice Refrigerator

PWF-1™ Filter EPPWFU01 (Gray Interior)

*Find the Performance Data Sheet

located in the For Owners section for your

speciﬁc water ﬁlter on Electrolux.com.

FILTER REPLACEMENT

Replacing your

water ﬁlter

The water ﬁlter is located at the middle

left side of the refrigerator compartment.

In general, you should change the water

ﬁlter every 6 months to ensure the highest

possible water quality. Water Filter Status

on the appliance control display prompts

you to replace the ﬁlter after a standard

amount of water (125 gal/453 L)

has

ﬂowed through the system.

PureAir Ultra II™ Air Filter

WIth more power to clear the air, Frigid-

aire air ﬁlters banish pungent smells and

work better than baking soda. PureAir

Ultra II Air Filters:

• More powerful than baking soda

Keep your unit fresh for up to 6 months.

• Captures & Keeps Odors Away

Absorbs undesirable smells with

carbon technology.

Your appliance control display is

equipped with a REPLACE AIR FILTER

indicator to remind you to change your

ﬁlter every 6 months to ensure optimal

ﬁltering of appliance odors. Your PureAir

Ultra II Air Filter is included in your

Literature Pack. To order replacement

ﬁlters, please visit our online store at

Frigidaire.com, by calling toll-free at 1

(800) 372-4432, or by visiting the dealer

where you purchased your unit.

Here are the product numbers to request

when ordering:

PureAir Ultra II™ Air Filter PAULTRA2

It is not necessary to turn the water

supply o to change the ﬁlter. Be ready

to wipe up any small amounts of water re-

leased during the ﬁlter replacement.

1. Remove the ﬁlter by ﬁrmly press-

ing the water ﬁlter cartridge until it

releases. You will hear a click.

2. Slide the old water ﬁlter cartridge

straight out of the housing and

discard it.

3. Unpack the new ﬁlter cartridge.

Using the alignment guide, slide it

gently into the ﬁlter housing until it

stops against the snap-in connector

at the back of the housing.

4. Push ﬁrmly until the cartridge

snaps into place (you should hear a

click as the cartridge engages the

snap-in connector).

5. Press a drinking glass against the

water dispenser while checking for

any leaks at the ﬁlter housing. Any

spurts and sputters that occur as

the system purges air out of the

dispenser system are normal.

6. After ﬁlling one glass of water, con-

tinue ﬂushing the system for about

4 minutes.

7. Press and hold WATER FILTER on

the appliance control display for 3

seconds. When the display changes

from red to green, you have reset

the status.

FILTER REPLACEMENT

Replacing your air ﬁlter

f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak f;ad mva;’ak

Your air ﬁlter housing is located in the

upper rear center of the cabinet, behind a

removable stainless steel decorative plate.

To install the air ﬁlter element:

1. Grab the cover with your hand,

pulling until it releases from the

ﬁxed air ﬁlter housing. The air ﬁlter

element is mounted on the back of

the cover.

2. If the ﬁlter was previously installed,

remove the old ﬁlter and discard it.

3. Unpack the new ﬁlter and snap it

into the ﬁlter cover. The open face

(carbon media) of the ﬁlter should be

installed facing outward in the cover.

4. Reattach the air ﬁlter cover to the air

ﬁlter housing by aligning the cover

to the housing and ﬁrmly pushing it

until it snaps in place.

5. Press and hold REPLACE AIR

FILTER on the appliance control

display to reset it.

PureAir Produce Keeper™

Keep fruits and vegetables fresher longer

with PureAir Produce Keeper. Our

produce keeper absorbs ethylene gas, the

natural gas that causes produce to ripen

quicker. Reduce food waste, save money

and enjoy fresh-tasting produce with a

longer storage life. Your PureAir Produce

Keeper is included in your Literature

Pack. To order replacements, please visit

our online store at Frigidaire.com, by

calling toll-free at 1 (800) 372-4432, or by

visiting the dealer where you purchased

your unit.

Here are the product numbers to request

when ordering:

PureAir Produce Keeper™ FRPAPKRF

Installing the PureAir Produce Keeper:

Your ethelene absorber holder is attached to

the rear wall of the upper crisper. Remove it

to install the PureAir Produce Keeper.

;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;



;

CAUTION

DO NOT OPEN. Contents may irritate eyes

or skin. Keep out of reach of children.

FIRST AID: Contains potassium perman-

ganate. In case of contact with eyes or

skin, rinse immediately with water.

DO NOT EAT: If swallowed, seek medical

treatment immediately.

FILTER REPLACEMENT

1. Fully extend the crisper for easy

access. Grab the cover with your

hand pulling until it releases from

the crisper.

2. Remove the plastic wrapper. Insert

the unopened packet into the holder

in the crisper.

3. Reattach the Produce Keeper cover

by aligning the cover and ﬁrmly

pushing it until it snaps in place.

4. For optimal results, replace the

reﬁll every 6 months along with

your air ﬁlter.

CARE AND CLEANING

Protecting Your investment Vacation and Moving Tips

Short Vacations: Leave the unit operating

during vacations of less than 3 weeks.

Long Vacations: If the appliance will not

be used for several months:

• Remove all food and unplug the

power cord.

• Clean and dry the interior thoroughly.

• Leave the door open slightly, blocking

it open if necessary, to prevent odor

and mold growth.

Moving: When moving the unit, follow

these guidelines to prevent damage:

• Disconnect the power cord plug from

the wall outlet.

• Secure all loose items such drawers

and shelves by taping them securely

in place to prevent damage.

• In the moving vehicle, secure unit in

an upright position to prevent move-

ment. Also protect outside of the ap-

pliance with a blanket, or similar item.

Keeping your appliance clean maintains

appearance and prevents odor build-up.

Wipe up any spills immediately and clean

the appliance at least twice a year. When

cleaning, take the following precautions:

• Never use CHLORIDE or cleaners

with bleach to clean stainless steel.

• Do not wash any removable parts in

a dishwasher.

• Always unplug the electrical

power cord from the wall outlet

before cleaning.

• Remove adhesive labels by hand. Do

not use razor blades or other sharp

instruments which can scratch the

appliance surface.

• Do not remove the serial plate.

Do not use abrasive cleaners such as win-

dow sprays, scouring cleansers, brushes,

ﬂammable ﬂuids, cleaning waxes, concen-

trated detergents, bleaches or cleansers

containing petroleum products on plastic

parts, interior doors, gaskets or cabinet

liners. Do not use paper towels, metallic

scouring pads, or other abrasive cleaning

materials or strong alkaline solutions.

Before cleaning your appliance, turn o

power to your appliance by unpluging the

power cord from the electrical outlet.



NOTE

Do not use razor blades or other sharp

instruments which can scratch the

appliance surface when removing ad-

hesive labels. Any glue left from tape or

labels can be removed with a mixture

of warm water and mild detergent, or,

touch the glue residue with the sticky

side of tape you have already removed.

Do not remove the serial plate.

CAUTION

• Pull the appliance straight out to

move it. Shifting it from side to side

may damage ﬂooring.

• Damp objects stick to cold metal

surfaces. Do not touch refrigerated

surfaces with wet or damp hands.

CARE AND CLEANING

Care & Cleaning Tips

Part What To Use Tips and Precautions

Interior & Door

Liners

• Soap and water

• Baking soda

and water

Use 2 tbsp of baking soda in 1 qt of warm

water. Be sure to wring excess water out

of sponge or cloth before cleaning around

controls, light bulb or any electrical part.

Door Gaskets • Soap and water Wipe gaskets with a clean soft cloth.

Drawers

& Bins

• Soap and water Use a soft cloth to clean drawer runners

and tracks. Do not wash any removable

items (bins, drawers, etc.) in dishwasher.

Glass Shelves

• Soap and water

• Glass cleaner

• Mild liquid sprays

Allow glass to warm to room temperature

before immersing in warm water.

Exterior &

Handles

• Soap and water

• Non-Abrasive

Glass Cleaner

Do not use commercial household cleaners,

ammonia, or alcohol to clean handles. Use a

soft cloth to clean smooth handles. Do not

use a dry cloth to clean smooth doors.

Exterior

& Handles

(Stainless Steel

Models Only)

• Soap and water

• Ammonia

• Stainless Steel

Cleaners

Never use CHLORIDE to clean stainless

steel. Clean stainless steel front and

handles with non-abrasive soapy water

and a dishcloth. Rinse with clean water

and a soft cloth. Wipe stubborn spots

with an ammonia-soaked paper towel,

and rinse. Use a non-abrasive stainless

steel cleaner. These cleaners can be

purchased at most home improvement or

major department stores. Always follow

manufacturer’s instruction.

NOTE: Always, clean, wipe and dry with

grain to prevent cross-grain scratching.

Wash the rest of the cabinet with warm

water and mild liquid detergent. Rinse

well, and wipe dry with a clean soft cloth.

1-800-265-8352 (Canada)

Frigidaire.ca

1-800-374-4432 (United States)

Frigidaire.com

TROUBLESHOOTING

Let us help you troubleshoot your concern! This section will help you with common

issues. If you need us, visit our website, chat with an agent, or call us. We may be able

to help you avoid a service visit. If you do need service, we can get that started for you!

CONCERN CAUSE SOLUTION

APPLIANCE OPERATION

Appliance does

not run.

• Appliance is plugged

into a tripped Ground

Fault Interrupt (GFI).

• Appliance may not

be plugged in or plug

is loose.

• House fuse blown or

tripped circuit breaker.

• Power outage.

• Appliance must be plugged into a

dedicated circuit with standard outlet.

Contact a certiﬁed electrician to check.

• Ensure plug is tightly pushed into outlet.

• Check/replace fuse with a 15-amp

time-delay fuse. Reset circuit breaker.

• Check house lights. Call the local

electric company.

Appliance

temperature is

warmer than

preferred.

• The appliance tem-

perature is set too high.

• Items are blocking the

multi-port air ﬂow sys-

tem, which may aect

cooling performance.

• Set control to a colder setting until

appliance temperature is satisfacto-

ry. Allow 24 hours for the tempera-

ture to stabilize.

• Make sure the items are not placed

directly in front of the cold air ex-

haust ports.

Appliance is

noisy or vibrates.

• The cabinet is not level.

• Floor is weak.

• Adjust the leveling feet. See Leveling

in the INSTALLATION section.

Appliance runs

too much or

too long.

• Room or outside

weather is hot.

• Appliance has recently

been disconnected for

a period of time.

• Large amounts of

warm or hot food have

been stored recently.

• Door is opened too

frequently or too long.

• Door may be

slightly open.

• Temperature control

is set too low.

• Gaskets are dirty,

worn, cracked, or

poorly ﬁtted.

• It’s normal for the appliance to work

longer under these conditions.

• It takes 24 hours for the appliance to

cool down completely.

• Warm food will cause appliance

to run more until the desired

temperature is reached.

• Warm air entering the appliance causes

it to run more. Open door less often.

• See DOOR PROBLEMS in

TROUBLESHOOTING section.

• Turn control knob to a warmer

setting. Allow several hours for the

temperature to stabilize.

• Clean or change gasket. (See Care

and Cleaning Tips in the CARE AND

CLEANING section). Worn, cracked or

poorly ﬁtting gaskets should be replaced.

APPLIANCE TEMPERATURES

Interior appli-

ance tempera-

ture is too cold.

• Temperature control

is set too low.

• Set control to a warmer setting.

Allow several hours for temperature

to stabilize.

CONCERN CAUSE SOLUTION

APPLIANCE TEMPERATURES (cont’d)

Temperature in-

side appliance

is too warm.

• Temperature control is

set too warm.

• Door is opened too

frequently or too long.

• Door may not be

seating properly.

• Large amount of

warm or hot food has

been stored recently.

• Unit has recently

been disconnected

for a period of time.

• Turn control to a colder setting.

Allow several hours for temperature

to stabilize.

• Warm air enters the appliance every

time the door is opened. Open door

less often.

• Look for food items on the shelves

or in the door bins keeping the door

from closing completely.

• Wait until the appliance has

had a chance to reach its selected

temperature.

• Appliance may take up to 24 hours

to cool down completely.

is displayed

on control.

• The control has

been locked.

• Press for 3 seconds to unlock.

Sb is displayed

on the control.

• The control is in

Sabbath Mode.

• Press — and TEMP F/C for 5 seconds.

DEMO is

displayed in

the control.

• The control is

in DEMO mode.

Cooling has stopped

functioning.

• To exit DEMO mode, simultaneously

press and hold — and WATER FIL-

TER for 10 seconds.

SOUND AND NOISE

Louder sound

levels when-

ever appliance

is on.

• Modern appliances

have increased

storage capacity

and more stable

temperatures. They

require heavy-duty

compressors.

• This is normal. When the surround-

ing noise level is low, you might hear

the compressor running while it

cools the interior.

Popping or

cracking sound

when compres-

sor comes on.

Bubbling or

gurgling sound.

• Metal parts under-

go expansion and

contraction, as in hot

water pipes.

• Refrigerant (used to

cool refrigerator) is

circulating through-

out the system.

• This is normal. Sound will level o

or disappear as appliance continues

to run.

• This is normal.

Vibrating or

rattling noise.

• Appliance is not level. It

rocks on the ﬂoor when

it is moved slightly.

• Floor is uneven or weak.

• Appliance is touching

the wall.

• Level the appliance. Refer to Level-

ing in the INSTALLATION section.

• Ensure ﬂoor can adequately support

the appliance. Level the appliance by

putting wood or metal shims under

part of the appliance.

• Re-level appliance or move appli-

ance slightly. Refer to Leveling in the

INSTALLATION section.

TROUBLESHOOTING

CONCERN CAUSE SOLUTION

WATER / MOISTURE / FROST INSIDE APPLIANCE

Moisture forms

on inside ap-

pliance walls.

• Weather is hot and

humid, which increas-

es internal rate of

frost buildup.

• Door is slightly open.

• Door is kept open

too long.

• This is normal.

• Look for food items on the shelves

or in the door bins keeping the door

from closing completely.

• Open the door less often.

ODOR IN APPLIANCE

Odors in

appliance.

• Interior needs to

be cleaned.

• Foods with strong odors

are in the appliance.

• The air ﬁlter needs to

be replaced.

• Clean interior with sponge, warm wa-

ter, and baking soda. Replace air ﬁlter.

• Cover the food tightly.

• Refer to PureAir Ultra II Air Filter the

in FILTER REPLACEMENT section.

DOOR PROBLEMS

Door will

not close.

• Appliance is not level. It

rocks on the ﬂoor when

it is moved slightly.

• Floor is uneven or weak.

• This condition can force the cabinet

out of square and misalign the door.

Refer to Leveling in the INSTALLA-

TION section.

• Ensure ﬂoor can adequately support

appliance. Level the appliance by

putting wood or metal shims under

part of the appliance.

• Look for food items on the shelves

or in the door bins keeping the door

from closing completely.

LIGHTING PROBLEMS

Cabinet light is

not working.

• LED has burned out. • Call a Frigidaire service technician.

LIMITED WARRANTY

Your appliance is covered by a two-year limited warranty. For two years from your date of

delivery, Electrolux will pay all costs for repairing or replacing any parts of this appliance

that prove to be defective in materials or workmanship when such appliance is installed,

used and maintained in accordance with the provided instructions.

Exclusions

If You Need Service

This warranty does not cover the following:

1. Products with original serial numbers that have been removed, altered or cannot be

readily determined.

2. Product that has been transferred from its original owner to another party or

removed outside the USA or Canada.

3. Rust on the interior or exterior of the unit.

4. Products purchased “as-is” are not covered by this warranty.

5. Food loss due to any Appliance or freezer failures.

6. Products used in a commercial setting.

7. Service calls which do not involve malfunction or defects in materials or

workmanship, or for appliances not in ordinary household use or used other than in

accordance with the provided instructions.

8. Service calls to correct the installation of your appliance or to instruct you how to use

your appliance.

9. Expenses for making the appliance accessible for servicing, such as removal of trim,

cupboards, shelves, etc., which are not a part of the appliance when it is shipped

from the factory.

10. Service calls to repair or replace appliance light bulbs, air ﬁlters, water ﬁlters, other

consumables, or knobs, handles, or other cosmetic parts.

11. Surcharges including, but not limited to, any after hour, weekend, or holiday service

calls, tolls, ferry trip charges, or mileage expense for service calls to remote areas,

including the state of Alaska.

12. Damages to the ﬁnish of appliance or home incurred during installation, including but

not limited to ﬂoors, cabinets, walls, etc.

13. Damages caused by: services performed by unauthorized service companies; use of parts

other than genuine Electrolux parts or parts obtained from persons other than authorized

service companies; or external causes such as abuse, misuse, inadequate power supply,

accidents, ﬁres, or acts of God.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES

CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY

SHALL BE PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS

BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY

OR FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE

SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE YEAR. ELECTROLUX

SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS

PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH

OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES

AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL

OR CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON THE DURATION OF IMPLIED

WARRANTIES, SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS

WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE

OTHER RIGHTS THAT VARY FROM STATE TO STATE.

This warranty only applies in the USA and Canada. In the USA, your appliance is warranted

by Electrolux Major Appliances North America, a division of Electrolux Home Products,

Inc. In Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux

authorizes no person to change or add to any obligations under this warranty. Obligations

for service and parts under this warranty must be performed by Electrolux or an

authorized service company. Product features or speciﬁcations as described or illustrated

are subject to change without notice.

Keep your receipt, delivery slip, or some other appropriate payment record to establish

the warranty period should service be required. If service is performed, it is in your best

interest to obtain and keep all receipts. Service under this warranty must be obtained by

contacting Electrolux at the addresses or phone numbers below.

USA

1-800-374-4432

Frigidaire

10200 David Taylor Drive

Charlotte, NC 28262

Canada

1.800.265.8352

Electrolux Canada Corp.

5855 Terry Fox Way

Mississauga, Ontario, Canada

L5V 3E4

Frigidaire.com

1-800-374-4432

Frigidaire.ca

1-800-265-8352

owner support

accessories

service

Our home is your home. Visit us if you

need help with any of these things:

registration

(See your registration card

for more information.)

welcome home

Frigidaire PRDA1922AF Professional Single-Door Refrigerator

Product's Documents

Use and Care Manual.

Specifications

Frigidaire PRDA1922AF Questions and Answers
