Operating and installation
instructions
Wine conditioning unit
To avoid the risk of accidents or damage to the appliance, it is
essential to read these instructions before it is installed and used for
the first time.
en - AU, NZ M.-Nr. 12 794 630
Contents
2
Warning and Safety instructions ............................................................................... 5
Sustainability and environmental protection.......................................................... 13
Caring for the environment ...........................................................................................
13
How to save energy.......................................................................................................
14
Familiarising yourself with the appliance ................................................................ 15
Guide to the appliance ..................................................................................................
15
Display........................................................................................................................ 16
Settings mode ...........................................................................................................
17
Feature lighting.................................................................................................... 17
Lock function/.................................................................................................. 17
Switching off the wine conditioning unit.......................................................... 17
Sabbath mode ....................................................................................................... 17
Information on Sabbath mode............................................................................. 17
Time before door alarm is triggered...................................................................
17
Miele@home ....................................................................................................... 17
Keypad tone/................................................................................................... 18
Alarms and buzzers/ ...................................................................................... 18
Display brightness............................................................................................... 18
Temperature unit °C/°F............................................................................................ 18
Demo mode............................................................................................................ 18
Factory default settings ..................................................................................... 18
Information on the wine conditioning unit......................................................... 18
ActiveAirCleanfilter display .............................................................................. 19
Accessories supplied.....................................................................................................
19
Safety ...............................................................................................................................
19
Temperature alarm.................................................................................................... 19
Switching the temperature alarm off early............................................................ 19
Door alarm ................................................................................................................. 20
Adjusting the interior fittings ........................................................................................
20
Removing and reinserting the wooden shelves ................................................... 20
Adjusting the wooden shelf (FlexiFrame) to the bottle size............................... 21
Maximum capacity ................................................................................................... 21
Writing on the labelling strip (NoteBoard)............................................................ 21
Commissioning.............................................................................................................. 23
Before using for the first time.......................................................................................
23
Connecting the wine conditioning unit.................................................................. 23
Activating the charcoal filter (ActiveAirCleanfilter) ...................................... 23
Positioning the slats on the wooden shelves ....................................................... 23
Setting up the stacking aid...................................................................................... 23
Switching on the wine conditioning unit.....................................................................
24
Switching off the wine conditioning unit ....................................................................
24
Switching off for longer periods of time ................................................................ 24
Contents
3
Operation........................................................................................................................ 25
Setting the temperature ................................................................................................
25
Temperature range.................................................................................................... 25
Temperature display ................................................................................................. 25
Setting the humidity
(ActiveHumidity) in the lower wine conditioning zone .......................................
25
Humidity range.......................................................................................................... 25
Adjusting settings ......................................................................................................... 27
Explanation of the different settings............................................................................
27
Setting the brightness of the feature lighting................................................. 27
Switching the lock function/ on.................................................................... 27
Switching Sabbath mode on ............................................................................... 27
Switching Sabbath mode off............................................................................... 28
Changing the time before the door alarm is triggered ....................................
28
Setting up Miele@home for the first time............................................................ 28
Deactivating the Wi-Fi connection ........................................................................ 28
Activating the Wi-Fi connection............................................................................. 28
Switching off the keypad tone ......................................................................... 29
Switching on the keypad tone .......................................................................... 29
Changing the volume of the alarms and buzzers/ ..................................... 29
Changing the display brightness ....................................................................... 29
Changing the temperature unit °C/°F.................................................................... 30
Switching off demo mode.................................................................................... 30
Resetting the settings to their factory default settings ................................ 30
Activating the ActiveAirCleanfilter display..................................................... 30
Cleaning and care ......................................................................................................... 31
Cleaning agents ..............................................................................................................
31
Preparing the wine conditioning unit for cleaning .....................................................
31
Cleaning the interior of the appliance .........................................................................
31
Replacing the ActiveAirCleanfilter .............................................................................
32
Cleaning the door seal...................................................................................................
33
Cleaning the ventilation gaps .......................................................................................
33
After cleaning ..................................................................................................................
33
Automatic defrosting .....................................................................................................
33
Problem solving guide.................................................................................................. 34
Service............................................................................................................................. 39
Contact in case of fault..................................................................................................
39
Warranty ..........................................................................................................................
39
Optional accessories.................................................................................................... 40
Contents
4
Installation...................................................................................................................... 41
Installation site ...............................................................................................................
41
Climate range ............................................................................................................ 42
Ventilation........................................................................................................................
42
Side-by-side units ..........................................................................................................
42
Changing the door hinging ............................................................................................
43
Installation dimensions .................................................................................................
44
Niche/side view ........................................................................................................ 44
Connections .............................................................................................................. 45
Installing the wine conditioning unit............................................................................
46
To install the wine conditioning unit, you will need the following tools:........... 46
Preparing the wine conditioning unit..................................................................... 46
Pushing in the wine conditioning unit.................................................................... 46
Aligning the wine conditioning unit........................................................................ 47
Aligning the wine conditioning unit to taller furniture doors .............................. 49
Securing the wine conditioning unit in the niche................................................. 50
Electrical connection .....................................................................................................
51
Warning and Safety instructions
5
This wine conditioning unit complies with all current local and
national safety requirements. However, inappropriate use can lead
to personal injury and damage to property.
Read the operating and installation instructions carefully before
using the wine conditioning unit. They contain important
information on installation, safety, use and maintenance. This is to
protect yourself from injury, and from damaging your wine
conditioning unit.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in
“Installation”, as well as in the “Warning and safety instructions”.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these instructions in a safe place and pass them on to any
future owner.
Risk of injury from broken glass.
If installed at altitudes above 1500m, there is a risk of the glass in
the appliance door breaking because of changes in air pressure.
Shards of glass can cause severe injury.
Correct application
This appliance is designed for domestic use and for use in similar
environments by guests in hotel or motel rooms, bed & breakfasts
and other typical living quarters. This does not include common/
shared facilities or commercial facilities within hotels, motels or bed
& breakfasts. This wine conditioning unit is not suitable for outdoor
use.
The wine conditioning unit is intended exclusively for domestic use
for storing wine.
The wine conditioning unit is not suitable for freezing food.
The wine conditioning unit is suitable for integrated underbench
installation.
Any other usage is not permitted.
Warning and Safety instructions
6
This wine conditioning unit is not suitable for storing and keeping
cool medicines, blood plasma, laboratory preparations or similar
substances or products. Incorrect use of the wine conditioning unit
for such purposes may cause deterioration of the items stored. The
wine conditoning unit is also not suitable for use in areas where there
is a risk of explosion.
Miele cannot be held liable for damage resulting from incorrect or
improper use or operation of the appliance.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities or lack
of experience and knowledge, unless they have been given
supervision and instruction concerning its use by a person
responsible for their safety.
They may only use the appliance unsupervised if its operation has
been clearly explained to them and they are able to use it safely and
are able to understand and recognise the possible dangers caused by
incorrect operation.
Safety with children
Young children must not be allowed to use this appliance.
Older children may only use the wine conditioning unit if its
operation has been clearly explained to them and they are able to use
it safely. They must be able to understand and recognise the possible
dangers of misuse.
Cleaning work may only be carried out by older children under the
supervision of an adult.
Children should be supervised in the vicinity of the wine
conditioning unit. Never allow children to play with the wine
conditioning unit.
Danger of suffocation! Children may be able to wrap themselves in
packing material (e.g. foil) or pull it over their head with the risk of
suffocation. Keep packaging material away from children.
Technical safety
The refrigerant circuit has been checked for leaks. The wine
conditioning unit complies with all current local and national safety
requirements.
Warning and Safety instructions
7
Warning: fire hazard/flammable materials. This symbol is on the
compressor and indicates flammable materials. Do not remove this
sticker.
The refrigerant inside the appliance (details on the data plate) is
environmentally friendly but flammable.
The use of this refrigerant does, however, sometimes lead to a slight
increase in the noise level of the appliance. In addition to the noise of
the compressor, you might be able to hear the refrigerant flowing
around the system. Unfortunately, this cannot be avoided, but it does
not affect the performance of the wine conditioning unit.
When transporting and installing the wine conditioning unit, ensure
that no parts of the cooling circuit are damaged. Splashes of
refrigerant can damage the eyes and leaking refrigerant can ignite.
In the event of any damage:
- Avoid naked flames or anything which creates a spark.
- Disconnect the wine conditioning unit from the mains electricity
supply.
- Ventilate the room in which the wine conditioning unit is located
for several minutes.
- Call Miele.
The more coolant there is in a wine conditioning unit, the larger the
room should be in which it is installed. In the event of a leakage, if the
appliance is in a small room, there is the danger of a combustible
gas/air mixture building up. For every 8g of coolant, at least 1m
3
of
room space is required. The amount of coolant in the wine
conditioning unit is stated on the data plate inside the appliance.
Ensure that the connection data on the wine conditioning unit's
data plate (fuse rating, frequency and voltage) match the electricity
supply to prevent damage to the wine conditioning unit.
Compare this before connecting the appliance to the mains
electricity.
If in any doubt, consult a qualified electrician.
Warning and Safety instructions
8
The electrical safety of this wine conditioning unit can only be
guaranteed when continuity is complete between it and an effective
earthing system. It is most important that this basic safety
requirement is present.
If in doubt, the electrical installation should be checked by a qualified
electrician.
Temporary or permanent operation with a self-sufficient or non-
mains synchronous energy supply system (e.g. isolated networks,
back-up systems) is possible. A requirement for the operation is that
the energy supply system complies with all current local and national
requirements that apply to stand-alone, solar and/or battery systems.
The protective measures provided in the installation and in this Miele
product must also be assured in their function and operation in
isolated operation or in non-mains synchronous operation, or
replaced with equivalent measures in the installation.
If the electrical connection cable supplied is damaged, it must only
be replaced by an original spare part to prevent a hazard for the user.
Miele can only guarantee the safety of the appliance when original
Miele parts are used. For safety reasons, replacement may only be
carried out by a suitably qualified specialist or Miele Customer
Service.
Multi-socket adapters and extension leads do not guarantee the
required safety of the appliance (e.g. danger of overheating). Do not
use these to connect the wine conditioning unit to the mains
electricity supply.
If moisture gets into electrical components or into the mains
connection cable, it could cause a short circuit. Therefore, do not
operate this wine conditioning unit in areas which are exposed to
moisture (e.g in a garage or utility room).
This wine conditioning unit must not be installed and operated in
mobile installations (e.g. on a ship).
Damage to the wine conditioning unit can compromise your safety.
Before using the wine conditioning unit, check it for any visible
damage. Never use a damaged wine conditioning unit.
For safety reasons, this wine conditioning unit may only be used
when it has been built in.
Warning and Safety instructions
9
During installation, maintenance and repair work, the wine
conditioning unit must be completely disconnected from the mains
electricity supply. It is only completely isolated from the electricity
supply when:
- the mains circuit breaker is switched off, or
- the screw-out fuse is removed (in countries where this is
applicable), or
- it is switched off at the wall socket and the plug is withdrawn from
the socket, or it is switched off at the isolator. Pull on the plug and
not the cable when disconnecting it from the power supply.
Repairs and other work by unqualified persons could be
dangerous. Installation must be performed by a suitably qualified and
competent person. Maintenance and repairs must only be carried out
by a Miele authorised technician.
The manufacturer's warranty will be invalidated if the appliance is
not repaired by a Miele approved service technician.
Faulty components must only be replaced with genuine Miele
original spare parts. Miele can only guarantee the safety standards of
the appliance when Miele spare parts are used.
This wine conditioning unit is supplied with a special lamp to cope
with particular conditions (e.g. temperature, moisture, chemical
resistance, abrasion resistance and vibration). This lamp must only be
used for the purpose for which it is intended. The lamp is not suitable
for room lighting. Replacement lamps may only be fitted by an
authorised technician or Miele Customer Service. This wine
conditioning unit contains several light sources with at least energy
efficiency classG.
In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and its
surroundings clean at all times. Any damage caused by cockroaches
or other vermin will not be covered by the warranty.
Correct installation
When installing the refrigeration appliance, it is a mandatory
requirement to follow the installation instructions supplied with it.
Always wear protective gloves when transporting and installing the
wine conditioning unit.
Two people are required to install the wine conditioning unit.
Warning and Safety instructions
10
Change the door hinging (if necessary) as described in the
installation instructions supplied with the appliance.
Correct use
This wine conditioning unit is designed for use within specific
ambient temperatures (climate range). Do not use it in ambient
temperatures for which it is not designed. The climate range is stated
on the data plate inside the wine conditioning unit. A lower ambient
temperature will cause the compressor to switch off for longer
periods, meaning that the wine conditioning unit is unable to
maintain the required temperature in some circumstances.
To ensure proper air flow in and out of the appliance, the
ventilation gaps in the appliance and built-in structure must not be
covered or blocked in any way. This would also increase the energy
consumption and could cause damage to the appliance.
If the wine conditioning unit is used for storing food which
contains fat or oil, make sure that it does not come into contact with
plastic components. Any spillages of oil or fat could cause stress
cracks to the plastic and cause it to break or split.
Risk of fire and explosion! Do not store explosive materials in the
wine conditioning unit or any products containing propellants (e.g.
spray cans). Electrical components can cause flammable mixes of
gases to ignite.
Danger of explosion! Do not operate any electrical appliances
inside the wine conditioning unit. Danger of sparking and explosion.
Accessories and spare parts
Only use original Miele accessories. Using spare parts or
accessories from other manufacturers will invalidate the warranty,
and Miele cannot accept liability.
Miele will guarantee to supply functional spare parts for a
minimum of 10years and up to 15years following the discontinuation
of your wine unit.
Cleaning and care
Do not use any oils or grease on the door seals, as these will cause
the seals to deteriorate and become porous with time.
Warning and Safety instructions
11
The steam from a steam cleaning appliance could reach electrical
components and cause a short circuit.
Do not use a steam cleaning appliance to clean this appliance.
Warning: Do not use any mechanical tools or other types of aid
which are not recommended by the manufacturer to accelerate the
defrosting process.
Sharp edged objects will damage the evaporator, causing
irreversible damage to the wine conditioning unit. Therefore, do not
use sharp objects to:
- remove layers of ice.
- remove label residues, for example.
Transport
Always transport the wine conditioning unit upright and in its
packaging to avoid it being damaged.
Risk of injury and damage! The wine conditioning unit is very heavy
and must be transported by two people.
Disposal of your old appliance
Children playing could become trapped in the wine conditioning
unit and could suffocate.
- Remove the appliance door.
- Leave the wooden/metal shelves in the wine conditioning unit so
children cannot climb inside.
- If the wine conditioning unit has a door lock, make sure that
children cannot lock themselves inside while playing as this could
endanger their lives.
Risk of electric shock!
- Cut the electrical plug off the power supply cord.
- Cut the power supply cord off the old appliance.
Dispose of the electrical plug and power supply cord separately from
the old appliance.
During and after disposal, make sure that the wine conditioning
unit is not placed near petrol or other flammable gases and liquids.
Warning and Safety instructions
12
Risk of fire due to escaping oil or refrigerant!
The refrigerant and oil inside the appliance are flammable. In high
enough concentrations, escaping refrigerant or oil may ignite if they
come into contact with an external heat source.
During disposal, make sure that the cooling circuit is not damaged in
order to prevent refrigerant and oil escaping in an uncontrolled
manner (see the data plate for details of the refrigerant).
Splashes of coolant can damage the eyes. Be careful not to
damage any part of the pipework whilst awaiting disposal, e.g. by
- puncturing the refrigerant channels in the condenser,
- bending any pipework, or
- scratching the surface coating.
Symbol on the compressor (depending on model)
This information is only relevant for recycling. There is no risk during normal
operation.
The oil in the compressor can be fatal if swallowed or if it
penetrates the airways.
Sustainability and environmental protection
13
Caring for the environment
Disposal of the packing material
The transport and protective packaging
has been selected from materials which
are environmentally friendly for disposal,
and can normally be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also reduces
the amount of waste in landfill sites.
Ensure that any plastic wrappings, bags
etc. are disposed of safely and kept out
of the reach of babies and young
children. Danger of suffocation.
Only for Australia: Note for installer:
Expanded polystyrene (EPS) packaging
included. Please retain and dispose of
EPS packaging responsibly. For further
information, please contact Miele.
Disposing of your old appliance
Electrical and electronic appliances
contain many valuable materials. They
also contain certain materials,
compounds, and components which
were essential for their correct
functioning and safety. These could be
hazardous to human health and to the
environment if disposed of with general
waste or if handled incorrectly. Please
do not, therefore, dispose of your old
appliance with your household waste.
Take care not to damage your
refrigeration appliance before or during
disposal in an authorised,
environmentally friendly manner.
This is to ensure that refrigerant in the
cooling circuit and oil in the compressor
is contained, and will not leak into the
environment.
Please dispose of it at your local
community waste collection/recycling
centre for electrical and electronic
appliances, or contact Miele. You are
also responsible for deleting any
personal data that may be stored on the
appliance prior to disposal. You should
remove any old batteries which are not
securely enclosed by the appliance and
remove any lamps without destroying
them, where this is possible. These
must be taken to a suitable collection
point where they can be handed in free
of charge. Please ensure that your old
appliance presents no danger to
children while being stored awaiting
disposal.
Sustainability and environmental protection
14
How to save energy...
Installation site The wine conditioning unit has to cool more often at higher
ambient temperatures and consumes more energy in the
process. Therefore, you should:
- Install the wine conditioning unit in a well-ventilated room.
- Do not install the wine conditioning unit near to a heat source
(heater element, cooker).
- Protect the wine conditioning unit from direct sunlight.
- Ensure an ideal ambient temperature of 20°C.
- Clean the ventilation openings on a regular basis to remove any
dust.
Temperature
setting
The colder the temperature, the higher the energy consumption.
The following settings are recommended:
- +12 to +14°C.
Use Energy consumption is increased by heat input and impeded air
circulation. Therefore, you should:
- only open the appliance door when necessary and for as short
a time as possible arrange the wine bottles in a way that
makes them easy to find in the appliance
- always close the appliance door properly after opening it
- keep wooden shelves arranged as they were when the
appliance was delivered
- avoid overfilling the wooden shelves to allow air to circulate
- keep the fan air ducts in the wine conditioning unit clear
Familiarising yourself with the appliance
15
Guide to the appliance
12
°C
a
Charcoal filter (ActiveAirCleanfilter)
b
Display
c
Interior lighting and feature lighting:
Thanks to the use of LEDs, the wine will not be adversely affected by heat or UV
light.
d
Dry rear wall for preventing the formation of condensation
e
Wooden shelves with labelling strips (NoteBoards)
f
Glass door: the safety glass door with UV filter protects your wine from harmful
UV rays.
g
Stacking aid for optimised bottle storage
h
Ventilation grille
Familiarising yourself with the appliance
16
Display
The display can be scratched by pointed or sharp objects, e.g. pens.
Only touch the display with your fingertips.
It is possible that the display will not react to finger contact if your fingers are
cold.
12
°C
2
4
5
1
3
a
Demo mode display
(only visible when the Demo mode function has been switched on)
b
Temperature display sensor control for setting the temperature
c
Feature lighting sensor control
For switching the interior lighting on and off when the appliance door is closed
d
Display for Miele@home connection status
(only visible when the Miele@home function has been set up)
e
Settings mode sensor
For adjusting various functions in Settings mode
Operating the wine conditioning unit via the display
Touch the area/symbol you want on the touch display.
Swipe left or right across the display until the value/symbol you want is shown in
the middle.
Tap on the option you want in the display to confirm.
The selected value/symbol will light up orange (except for a few exceptions).
To leave the Settings level, tap on or OK.
Familiarising yourself with the appliance
17
Settings mode
Feature lighting
The interior lighting can be set to remain
on when the appliance door is closed so
your wines can be on display at all
times.
The feature lighting is switched on and
off using the sensor control in the
display. When the feature lighting is
switched on, the sensor control
lights up orange.
The feature lighting can be set at
different brightness levels or switched
off completely (see “Adjusting
settings”).
Lock function/
When the lock function is switched on,
it protects the wine conditioning unit
from being switched off unintentionally
and being adjusted unintentionally by
unauthorised persons, e.g. children.
If you just want to adjust the
temperature quickly, for example, you
can deactivate the lock function
temporarily (see “Adjusting settings”).
Switching off the wine conditioning
unit
You can switch off the wine conditioning
unit here (see “Commissioning –
Switching the wine conditioning unit
off”).
Sabbath mode
The wine conditioning unit offers a
Sabbath mode for the purposes of
religious observance (see “Adjusting
settings”).
When Sabbath mode is switched on,
the following are deactivated
temporarily:
- the interior lighting when the
appliance door is opened
- feature lighting when the appliance
door is closed
- the display
- all audible and visual signals
- an active Wi-Fi connection
- reminders (e.g. ActiveAirCleanfilter
display): the set time interval is
paused
All other functions switched on
previously remain activated.
When Sabbath mode is switched on,
you cannot adjust any settings on your
wine conditioning unit.
Information on Sabbath mode
You can call up the Sabbath mode
version here.
Time before door alarm
is triggered
You can set the time before the
appliance door alarm is triggered here
(see “Adjusting settings”).
Miele@home
Your wine conditioning unit is
equipped with an integrated Wi-Fi
module.
Networking is deactivated at the
factory.
Here you can set up the Miele@home
function for the first time, deactivate
and activate the Wi-Fi or reset the
network configuration (see “Adjusting
settings”).
To use this feature, you will need:
- a Wi-Fi network
- the Miele App
Familiarising yourself with the appliance
18
- a Miele user account. You can create a
user account via the Miele App.
The Miele App will guide you as you
connect your wine conditioning unit to
your home Wi-Fi network.
Once your wine conditioning unit is
connected to your Wi-Fi network, you
can use the App to carry out the
following activities, for example:
- Call up information on the operating
status of your wine conditioning unit
- Change the settings on your wine
conditioning unit
Connecting your wine conditioning unit
to your Wi-Fi network will increase
energy consumption, even when the
wine conditioning unit is switched off.
Make sure that the signal of your Wi-
Fi network is sufficiently strong in the
place where you want to set up your
wine conditioning unit.
Keypad tone
/
You can switch the keypad tone on or
off here (see “Adjusting settings”).
Alarms and buzzers/
You can change the volume of the
alarms and buzzers (e.g. in the event of
a door alarm or a fault message) here.
Alternatively, you can switch the alarms
and buzzers off completely if you find
them annoying (see “Adjusting
settings”).
Display brightness
You can adjust the display brightness to
the lighting conditions in the room here
(see “Adjusting settings”).
Temperature unit °C/°F
You can set the required temperature
unit (°Celsius or °Fahrenheit) here (see
“Adjusting settings”).
Demo mode
You can switch off demo mode here if it
has been switched on as a default
setting ( will appear in the display) (see
“Adjusting settings”).
Demo mode allows the wine
conditioning unit to be presented in
the showroom without the cooling
system being switched on. Do not
activate this setting for domestic use.
Factory default settings
You can reset the wine conditioning
unit's settings to their factory default
settings here (see “Adjusting settings”).
Useful tip: Reset the settings to the
factory default settings when disposing
of your wine conditioning unit, selling it
or putting a used wine conditioning unit
into operation. This will reset the
network configuration so that your
personal data is deleted from the wine
conditioning unit. This will also ensure
that a previous owner is no longer able
to access the wine conditioning unit.
Information on the wine conditioning
unit
You can call up the model identifier and
serial number of your wine conditioning
unit here.
Keep this appliance data to hand:
- for integrating the wine conditioning
unit into your Wi-Fi network (see
“Adjusting settings – Setting up
Miele@home for the first time”)
Familiarising yourself with the appliance
19
- when reporting an appliance fault to
Miele Customer Service (see
“Service”)
ActiveAirCleanfilter display
Filtering the air through the
ActiveAirCleanfilter ensures that the
air remains free from dust and odours.
The ActiveAirCleanfilter display
will remind you approx. every
12months that the
ActiveAirCleanfilter has to be
replaced (see “Cleaning and care –
Replacing the ActiveAirCleanfilter
(active charcoal filter)”).
You can activate the
ActiveAirCleanfilter display here
(see “Adjusting settings”).
Accessories supplied
Charcoal filter (ActiveAirCleanfilter)
The Active AirClean filter ensures
optimum air quality in the wine
conditioning unit by filtering the
incoming air.
Chalk pen
Use the chalk pen supplied to label the
NoteBoards on the wooden shelves. By
labelling the NoteBoards you will have a
good overview of the types of wine
being stored.
Safety
Temperature alarm
The wine conditioning unit is equipped
with a temperature alarm so that the
temperature cannot rise or fall
unnoticed and therefore damage the
wine.
If the temperature becomes too warm
or too cold,
will light up red in the
temperature display.
An alarm will also sound until the cause
of the alarm is rectified or the alarm is
switched off.
The set temperature determines when
the appliance recognises a temperature
as being too warm or too cold.
The audible and visual signals may be
activated in the following situations:
- Too much warm ambient air enters
the wine conditioning unit when
you are rearranging or taking out
wine bottles.
- You are storing a large number of
wine bottles.
- There was a power cut.
- There is a fault with the wine
conditioning unit.
Switching the temperature alarm off
early
Before you switch the temperature
alarm off, you must determine the
cause and rectify it.
You can switch the alarm off early if you
wish.
Tap
.
goes out and the alarm will stop.
The warmest temperature recorded in
the wine conditioning zone will flash for
about 1minute in the temperature
display. Then the temperature display
will change to the current temperature
in the wine conditioning zone.
Familiarising yourself with the appliance
20
Door alarm
The wine conditioning unit is fitted
with a door alarm to avoid increased
energy consumption if the door is left
open and prevent the stored wine
bottles being affected by temperature
fluctuations.
If the appliance door is left open for a
longer period of time,
will light up
yellow in the display. An alarm will also
sound and the interior lighting will flash.
The amount of time until the door alarm
is triggered can be changed (see
“Adjusting settings – Changing the time
before the door alarm
is triggered”).
The door alarm’s audible signal can also
be switched off (see “Adjusting settings
– Changing the volume of the alarms
and buzzers/”).
The alarm will stop and
will go out in
the display as soon as the appliance
door is closed.
Switching the door alarm off early
Tap
.
The alarm will stop,
will go out and
the interior lighting will light up
constantly.
If the appliance door is not closed, the
door alarm will sound again after a
short time.
Adjusting the interior fittings
Removing and reinserting the wooden
shelves
2
3
1
1
Pull the wooden shelf out until it
stops .
Press in the latches on both sides
of the wooden shelf and lift the
wooden shelf upwards .
To reinsert the wooden shelf, first
place it on the rear of the extended
rails so that it clicks into place.
Press the front section of the wooden
shelf down onto the extended rails so
that the latches click into place.
Risk of injury from falling wine
bottles.
Wine bottles may become wedged in
the wooden shelves above and fall
out of the wine conditioning unit/
refrigeration appliance when the
shelves are pulled out.
Always pull out the wooden shelves
slowly and carefully.
Familiarising yourself with the appliance
21
Risk of damage and injury from
broken glass.
If wooden shelves and bottles
protrude too far forwards, they may
damage the glass door when it is
closed.
Please ensure that the wooden
shelves and wine bottles do not
protrude.
Adjusting the wooden shelf
(FlexiFrame) to the bottle size
You can remove or move individual
wooden slats on the wooden shelf as
required.
This makes it easy to adjust the wooden
shelf to suit the size of your wine
bottles.
The slats in the bottom shelf cannot be
adjusted.
Maximum capacity
A maximum of 44Bordeaux-style
bottles (0.75l) can be stored.
Risk of damage due to
overloading.
Exceeding the maximum
recommended capacity can lead to
damage to the wooden shelves.
Do not exceed the maximum load-
bearing capacity of 25kg for each
wooden shelf.
Do not stack bottles on the wooden
shelves in more than two layers.
Writing on the labelling strip
(NoteBoard)
For quick and easy identification of the
wines stored, you can write on the
NoteBoards on the wooden shelves.
1
Familiarising yourself with the appliance
22
Pull the wooden shelf out a little
towards the front.
The labelling strip can be wiped clean
with a damp cloth.
Risk of damage from unsuitable
cleaning agents.
Cleaning the labelling strips
(NoteBoards) with a cleaning agent
may damage the coating on them.
Use clean water only to wipe the
NoteBoards.
Label the NoteBoard with the chalk
pen supplied.
Alternatively, we recommend the
following products for labelling:
- liquid chalk pens,
such as an edding4095 chalk marker
- traditional blackboard chalk
Risk of damage due to writing
with the wrong products.
Never write on the NoteBoard with a
ballpoint pen, crayon or pencil,
correction pencil, wax crayon, oil
chalk or felt-tip pen (e.g. permanent
marker, highlighter, foil pen, etc.).
They are difficult or impossible to
remove from the NoteBoard.
Only use the products recommended
to write on the NoteBoard as these
can be removed easily.
Commissioning
23
Before using for the first time
Remove all packaging material and
protective film.
The short, cross-fixed slats are only
used to attach the remaining slats to
the wooden shelf.
The short slats can be removed and
safely disposed of with household
waste. These slats come from surplus
production and are used as transport
safety devices for reasons of
sustainability.
Clean the inside of the appliance and
the accessories (see “Cleaning and
care”).
Connecting the wine conditioning unit
Connect the wine conditioning unit to
the electricity supply as described in
“Installation – Electrical connection”.
Mielewill then appear in the appliance
display, followed by.
Activating the charcoal filter
(ActiveAirCleanfilter)
Activate the Active AirCleanfilter
display (see “Adjusting settings –
Activating the ActiveAirCleanfilter
display”).
Positioning the slats on the wooden
shelves
1
Position the slats at equal intervals on
the wooden shelf and lock them into
position.
This provides space on the wooden
shelf for the maximum number of
bottles (0.75l; Bordeaux-style bottles).
Setting up the stacking aid
The stacking aid helps to achieve the
maximum capacity in the wine
conditioning unit.
Insert the stacking aid on the right
and left between the two outer slats
on the wooden shelf.
Commissioning
24
Switching on the wine
conditioning unit
Tap on the display.
If you do not interact with the display
for a certain period of time, it switches
to energy-saving mode and goes dark.
The wine conditioning unit will start to
cool and the interior lighting will come
on when the appliance door is opened.
Depending on the ambient temperature
and the temperature setting, it can take
the appliance a few hours to reach the
temperature required and for this
temperature to then be shown as a
constant temperature in the display.
Switching off the wine
conditioning unit
Tap.
Swipe left or right until is shown in
the middle.
Tap.
The cooling and interior lighting are
switched off.
will appear in the display.
Please note: the wine conditioning
unit is not disconnected from the
power supply when it is switched off.
Switching off for longer periods of
time
If, during a long absence, the wine
conditioning unit is switched off but
not cleaned and the door is left shut,
there is a danger of mould building up
inside the appliance.
The wine conditioning unit must be
cleaned.
If the wine conditioning unit is not going
to be used for a longer period of time,
observe the following:
Switch the wine conditioning unit off.
Switch off at the wall and withdraw
the plug from the socket, or switch off
the mains circuit breaker.
Clean the wine conditioning unit and
leave the door ajar to air the wine
conditioning unit and avoid odours
building up inside it.
Operation
25
Setting the temperature
A temperature of between 12 and
14°C is recommended to store wine
over the long term.
Touch the temperature display on the
display.
Swipe left or right until the
temperature you want is shown in the
middle.
Tap the temperature you want to
confirm.
To leave this Settings level, tap.
The temperature display will then
change back to the current temperature
in the wine conditioning zone.
The temperature in the wine
conditioning unit will rise:
- the more often the appliance door is
opened and the longer it is kept open.
- the more wine bottles there are being
stored.
- the warmer the newly stored wine
bottles are.
- the higher the ambient temperature
surrounding the wine conditioning
unit. This wine conditioning unit is
designed for use within specific
ambient temperatures (climate range).
Do not use it in ambient temperatures
for which it is not designed.
Temperature range
The temperature can be adjusted from 5
to 20°C.
Temperature display
In normal operation, the temperature
display shows the current average
temperature inside the wine
conditioning unit.
Depending on the ambient temperature
and the temperature setting, it can take
the appliance a few hours to reach the
temperature required and for this
temperature to then be shown as a
constant temperature in the display.
Setting the humidity
(ActiveHumidity) in the lower
wine conditioning zone
An ambient temperature of between
19 and 28°C is required to ensure that
the humidity level is set correctly.
Tap the temperature display for the
lower wine conditioning zone.
Swipe left until is shown in the
middle.
Tap .
Swipe left or right until the humidity
( or ) you want is shown in the
middle.
Tap the setting you want to confirm.
To leave this Settings level, tap .
Depending on the ambient
temperature and the set humidity
level, it can take the appliance a few
days to reach the set humidity level.
Humidity range
You can set the humidity to 2levels and
therefore adapt it to your individual
needs.
- : Low humidity
- : High humidity
If you would like to use the lower wine
conditioning zone for the long-term
storage of wine bottles with natural
corks, we recommend setting a high
humidity level.
Operation
26
Please bear in mind that energy
consumption will increase slightly as
the set humidity level is increased.
Adjusting settings
27
Explanation of the different
settings
The door alarm and other warnings are
automatically disabled when the
appliance is in Settings mode.
Setting the brightness of the feature
lighting
The feature lighting can be set at
different brightness levels or switched
off completely.
Tap.
Swipe left or right until is shown in
the middle.
Tap.
Select the brightness you want by
swiping the segment bar to the left or
right (level 1–7).
If you want to switch the feature
lighting off completely, swipe to the
left until the segment bar goes out
completely.
Confirm the setting you want by
tapping the segment bar.
Alternatively: confirm the setting you
want by tapping .
To leave this Settings level, tap.
Close the appliance door.
The modified setting will not be visible
until after the appliance door has been
closed.
Switching the lock function/ on
Tap.
Swipe left or right until is shown in
the middle.
Tap.
When the lock function is switched on,
will light up orange.
To leave this Settings level, tap.
Close the appliance door. Only then
will the lock function be active.
Deactivating the lock function/
temporarily
If you want to adjust the temperature,
for example, you can deactivate the lock
function temporarily:
Touch the temperature display.
Touch for approx. 6seconds.
The display switches to the temperature
controls.
Now select the required settings.
Closing the appliance door will
reactivate the lock function.
Switching the lock function/ off
completely
Tap .
Touch for approx. 6seconds.
Swipe left or right until is shown in
the middle.
Tap .
When the lock function is switched off,
will light up white.
To leave this Settings level, tap .
Switching Sabbath mode on
When Sabbath mode is switched on,
you cannot adjust any settings.
Tap.
Swipe left or right until is shown in
the middle.
Tap.
lights up orange.
To leave this Settings level, tap.
Adjusting settings
28
If Sabbath mode is switched on, this
is indicated in the display for approx.
3seconds.
The display then switches off.
Ensure that the appliance door is
properly closed, as visual and audible
alarms are switched off.
Switching Sabbath mode off
The Sabbath mode function will
switch off automatically after approx.
80hours.
However, you can switch the Sabbath
mode function off early.
Tap on the black display.
will appear in the display.
Tap.
lights up orange.
Tap the icon again.
When Sabbath mode is switched off,
will light up white.
To leave this Settings level, tap.
Changing the time before the door
alarm
is triggered
Tap .
Swipe left or right until
is shown
in the middle.
Tap
.
Swipe left or right until the time you
want between 30seconds and
3minutes 30seconds is shown in the
middle.
Tap the setting you want to confirm.
To leave this Settings level, tap .
Setting up Miele@home for the first
time
Tap.
Swipe left or right until is shown in
the middle.
Tap.
Tap on the connection method you
wish to use (App or WPS).
After you have successfully logged in,
will appear in the display.
If a connection could not be created,
will appear.
In this case, start the process again.
To leave this Settings level, tap.
Deactivating the Wi-Fi connection
Tap.
Swipe left or right until is shown in
the middle.
Tap.
Tap to deactivate the Wi-Fi
connection.
will appear in the display.
To leave this Settings level, tap.
Activating the Wi-Fi connection
Tap.
Swipe left or right until is shown in
the middle.
Tap.
Tap to activate the Wi-Fi
connection.
will appear in the display.
To leave this Settings level, tap.
When the Wi-Fi connection is active,
will light up in the display.
Adjusting settings
29
Resetting the network configuration
Tap.
Swipe left or right until is shown in
the middle.
Tap.
Swipe right until is shown in the
middle.
Tap.
Tap.
To leave this Settings level, tap.
All entered settings and values for
Miele@home are reset to the default
settings.
The Wi-Fi connection has been
deactivated. will go out in the start
display.
Reset the network configuration if
you are disposing of or selling your
refrigeration appliance, or if you are
putting a used refrigeration appliance
into operation. All personal data is
removed from the refrigeration
appliance. This will also ensure that a
previous owner is no longer able to
access the appliance.
Switching off the keypad tone
Tap.
Swipe left or right until
is shown
in the middle.
Tap
.
If the keypad tone is switched off,
will light up white.
To leave this Settings level, tap.
Switching on the keypad tone
Tap.
Swipe left or right until
is shown
in the middle.
Tap
.
If the keypad tone is switched on,
will light up orange.
To leave this Settings level, tap.
Changing the volume of the alarms
and buzzers/
Tap.
Swipe left or right until is shown in
the middle.
Tap.
Select the volume you want by
swiping the segment bar to the left or
right (level 1–7).
If you want to switch the alarms and
buzzers off completely, swipe to the
left until the segment bar goes out
completely.
Confirm the setting you want by
tapping the segment bar.
When the alarms and buzzers are
switched off, will light up white.
When the alarms and buzzers are
switched on, will light up orange.
To leave this Settings level, tap.
Changing the display brightness
Tap.
Swipe left or right until is shown in
the middle.
Tap.
Select the brightness you want by
swiping the segment bar to the left or
right (level 1–7).
Confirm the setting you want by
tapping the segment bar.
To leave this Settings level, tap.
Adjusting settings
30
Changing the temperature unit °C/°F
Tap.
Swipe left or right until°C or °F is
shown in the middle.
Tap °C or °F to change the
temperature unit.
°C or °F will appear in the display.
To leave this Settings level, tap.
Switching off demo mode
Tap.
Tap.
Swipe left or right until is shown in
the middle.
Tap.
After demo mode has been switched
off, the refrigeration appliance shuts
down and must be switched on again.
Resetting the settings to their factory
default settings
Tap.
Swipe left or right until is shown in
the middle.
Tap.
will appear in the display.
Tap.
The refrigeration appliance shuts down
and must be switched on again.
Activating the ActiveAirCleanfilter
display
Tap.
Swipe left or right until is shown in
the middle.
Tap.
If the ActiveAirCleanfilter display is
activated, will light up orange.
To leave this Settings level, tap.
Cleaning and care
31
The data plate located inside the wine
conditioning unit must not be
removed. It contains information
which is required in the event of a
fault.
Do not let water get into the
electronic unit or the lighting.
Risk of damage due to moisture
ingress.
The steam from a steam cleaning
appliance can damage plastic parts
and electrical components.
Do not use a steam cleaner to clean
the wine conditioning unit.
Health risk due to soiling entering
the appliance.
Soiling that enters the appliance from
outside (such as food or drink
residues) can cause fungus to form in
the wine conditioning unit at
increased temperature and humidity
levels.
Only place clean wine bottles and
clean accessories in the wine
conditioning unit.
Cleaning agents
Cleaning and care products used
inside the wine conditioning unit
must be food safe.
To avoid damaging the surfaces of your
appliance, do not use:
- cleaning agents containing soda,
ammonia, acid or chloride
- cleaning agents containing descaling
agents
- abrasive cleaning agents, e.g. powder
cleaners and cream cleaners
- solvent-based cleaning agents
- stainless steel cleaners
- dishwasher cleaners
- oven sprays
- cleaning agents for ceramic glass
cooktops (except to clean the glass
front)
- glass-cleaning agents (except to clean
the glass front: for this a glass-
cleaning agent containing a little
alcohol, but no citric or similar
additives, may be used)
- hard, abrasive sponges and brushes,
e.g. pot scourers
- dirt eraser sponges
- sharp metal scrapers
We recommend using lukewarm water
with a little washing-up liquid to clean
the appliance.
Preparing the wine conditioning
unit for cleaning
Switch the wine conditioning unit off.
appears in the display and the cooling
system is switched off.
Take any wine bottles out of the wine
conditioning unit and store them in a
cool place.
If necessary, take out all removable
parts for cleaning (see “Familiarising
yourself with the appliance –
Adjusting the interior fittings”).
Take out any removable accessories
for cleaning.
Cleaning the interior of the
appliance
Clean the wine conditioning unit
regularly, or at least once a month.
Cleaning and care
32
If soiling is left on for any length of
time, it may become impossible to
remove under certain circumstances.
Surfaces may suffer discolouration or
damage.
Remove any soiling immediately.
Clean the interior with a clean
sponge, lukewarm water and a little
washing-up liquid.
Rinse all parts by hand. Do not wash
in a dishwasher.
The wooden shelves should only be
wiped with a well wrung-out moist
cloth. They must not be allowed to
get wet.
Risk of damage from unsuitable
cleaning agents.
Cleaning the labelling strips
(NoteBoards) with a cleaning agent
may damage the coating on them.
Use clean water only to wipe the
NoteBoards.
After cleaning, wipe with a damp
cloth and dry with a soft cloth.
Leave the door open to air the wine
conditioning unit sufficiently for a
short while and to prevent odour
build-up.
Clean the appliance door with a
proprietary glass cleaner.
Replacing the
ActiveAirCleanfilter
New Active AirClean filters are
available from Miele Customer
Service, from a specialist dealer or on
the Miele website.
Press in the filter holder, release it
again and pull it out.
Remove the used
ActiveAirCleanfilter.
Used ActiveAirCleanfilters can be
disposed of with normal household
waste.
Insert the new ActiveAirCleanfilter.
Cleaning and care
33
Push the filter cover in as far as it will
go.
Cleaning the door seal
Risk of damage due to incorrect
cleaning.
If you treat the door seal with oils or
grease, it can become porous.
Do not use any oils or grease on the
door seals.
The door seal should be cleaned
regularly with clean water, and then
wiped dry with a soft cloth.
Cleaning the ventilation gaps
A build-up of dust will increase the
energy consumption of the appliance.
The ventilation gaps should be
cleaned on a regular basis with a
brush or vacuum cleaner (you could
use a Miele Vacuum Cleaner dusting
brush, for example).
After cleaning
Refit all shelves and accessories in
the wine conditioning unit.
Switch the wine conditioning unit on.
Place the wine bottles in the wine
conditioning unit and close the
appliance door.
Automatic defrosting
The wine conditioning unit defrosts
automatically.
Problem solving guide
34
Many malfunctions and faults can be easily remedied. You can save time and
money in many cases, as you do not need to contact Customer Service.
More information to help you remedy faults yourself can be found at
www.miele.com.au/support/customer-assistance or
www.miele.co.nz/support/customer-assistance.
To prevent cold from escaping, open the appliance as little as possible until the
fault has been corrected.
Problem Possible cause and remedy
The compressor is
switching on more
frequently and for longer
periods of time. The
temperature in the wine
conditioning unit is
falling.
The ventilation openings are covered or have become
too dusty.
Do not block the ventilation openings.
Clean the dust from the ventilation openings on a
regular basis.
The appliance door has been opened too frequently. A
large number of wine bottles have been placed in the
appliance.
Only open the appliance door when necessary and
for as short a time as possible.
After a while, the temperature will return to normal by
itself.
The appliance door is not properly closed.
Close the appliance door.
After a while, the temperature will return to normal by
itself.
The ambient temperature is too high. The higher the
ambient temperature, the longer the compressor runs.
See the information in “Installation – Installation
site”.
The temperature in the wine conditioning unit is set
too low.
Correct the temperature setting.
Problem solving guide
35
General problems with the wine conditioning unit
Problem Possible cause and remedy
There is no audible alarm
even though the
appliance door has been
open for a long time.
This is not a fault. The alarm has been switched off in
Settings mode. If you want to switch the audible alarm
back on again:
Tap.
Swipe left or right until is shown in the middle.
Tap.
Select the volume you want by swiping the segment
bar to the right.
Confirm the setting you want by tapping the
segment bar.
When the alarms and buzzers are switched on,
orangewill appear.
Messages in the display
Message Possible cause and remedy
lights up in the display
and the wine
conditioning unit is not
getting cold. However,
the appliance and the
interior lighting are
working fine.
Demo mode has been activated.
Tap.
Tap.
Swipe left or right until is shown in the middle.
Tap.
After demo mode has been switched off, the wine
conditioning unit shuts down and must be switched
on again.
Nothing is visible in the
display. The display is
dark.
Sabbath mode is switched on: the interior lighting
is switched off and the wine conditioning unit is
cooling.
Tap on the black display.
will appear in the display.
Tap.
lights up orange.
Tap the icon again.
When Sabbath mode is switched off, the symbol
will light up white.
Energy-saving mode is switched on: if you do not
interact with the display for a certain period of time, it
switches to energy-saving mode and goes dark.
Problem solving guide
36
Message Possible cause and remedy
lights up in the
display and the wine
conditioning unit cannot
be used.
The lock function has been activated.
Unlock the wine conditioning unit temporarily or
switch the lock function off completely (see
“Adjusting settings”).
lights up in the
display and a buzzer
sounds.
The ActiveAirCleanfilter display is reminding you
that the ActiveAirCleanfilter needs to be changed.
Replace the ActiveAirCleanfilter (see “Cleaning and
care – Replacing an Active AirClean filter (charcoal
filter)”). Confirm that you have changed the
ActiveAirCleanfilter by touching in the display.
will go out in the display.
will light up yellow in
the display; an alarm will
also sound and the
interior lighting will
flash.
The door alarm has been activated.
Tap
.
The alarm will stop,
will go out and the interior
lighting will light up again constantly.
lights up red in the
display and an alarm
also sounds.
The temperature alarm has been activated; the
temperature has risen higher or fallen lower than the
temperature set.
Possible reasons for this include:
– The appliance door has been opened too
frequently.
– The ventilation openings have been blocked.
– A prolonged power cut (mains outage) has
occurred.
Tap
.
goes out and the alarm will stop.
The warmest temperature recorded in the wine
conditioning unit will flash for about 1minute in the
temperature display. Then the temperature display will
change to the current temperature.
You can exit the flashing temperature display early:
Touch the temperature display.
The warmest temperature displayed will disappear.
The temperature display then reverts to showing the
current temperature in the wine conditioning unit.
Rectify the cause of the alarm.
Problem solving guide
37
Message Possible cause and remedy
lights up red in the
display and an alarm
also sounds.
Indication of a power failure: the temperature in the
wine conditioning unit over the last few days or hours
has risen too high because of a power failure or
interruption to the power supply.
Tap
.
goes out and the alarm will stop.
The warmest temperature recorded in the wine
conditioning unit will flash for about 1minute in the
temperature display. Then the temperature display will
change to the current temperature.
You can exit the flashing temperature display early:
Tap the temperature display.
The warmest temperature displayed will disappear.
The temperature display will revert to showing the
current temperature. The wine conditioning unit will
go back to the last temperature setting when the
power is back on.
Rectify the cause of the alarm.
lights up red in the
display and a fault code
F with numbers may
appear. An alarm tone
also sounds.
There is a fault.
Tap on the display to switch the alarm off.
Call Customer Service.
To report the fault, you need the fault code and also
the model identifier and serial number of your wine
conditioning unit. You can access this information in
the display.
To do this, touch in the display.
The appliance data required will be shown in the
display.
Confirm with to exit the information display and the
fault code will be shown again in the display.
The wine conditioning unit can be switched off directly
from the fault message display.
There is an appliance fault: this display always has
priority over any settings which have just been
selected.
An appliance fault has priority over any current door
and/or temperature alarms in the display.
Problem solving guide
38
Interior lighting
Problem Possible cause and remedy
Risk of electric shock due to exposed, live electrical components!
When removing the lighting cover, there is a risk of coming into contact with
live electrical components.
Do not remove the lighting cover. The LED lighting must only be repaired or
replaced by a qualified technician.
Danger of injury from LED lighting.
This lighting corresponds to risk group RG2. If the cover is defective, there is a
risk of eye injury.
Do not look from a close range directly into the lighting with optical
instruments (e.g. magnifying glass or similar).
Problem Possible cause and remedy
The interior lighting is
not working.
The wine conditioning unit is not switched on.
Switch the wine conditioning unit on.
Sabbath mode is switched on: the display is dark
and the wine conditioning unit is cooling.
Tap on the black display.
will appear in the display.
Tap.
lights up orange.
Tap the icon again.
When Sabbath mode is switched off, will light up
white.
To avoid overheating, the interior lighting switches
itself off automatically after approx. 15minutes if the
appliance door is left open. If this is not the case,
there is a fault.
Call Customer Service.
The interior lighting is on
even when the appliance
door is closed.
This is not a fault. The feature lighting is switched on.
To switch off the feature lighting, touch the sensor
control for the feature lighting in the display.
The sensor control no longer lights up orange.
Service
39
You can find information on how to
remedy faults yourself at
www.miele.com.au/support/
customer-assistance or
www.miele.co.nz/support/customer-
assistance and about Miele spare
parts at www.miele.com.au/service or
www.miele.co.nz/service.
Contact in case of fault
In the event of a fault which you cannot
remedy yourself, please contact Miele.
You can book a Miele customer service
call-out online at www.miele.com.au/
service or www.miele.co.nz/service.
Contact information for Miele can be
found at the end of this booklet.
Please quote the model and serial
number of your appliance when
contacting Miele. Both of these can be
found on the data plate inside the
refrigeration appliance or, depending on
the model, in the settings mode under
information.
Warranty
The manufacturer's warranty for this
appliance is 2years.
For more information about country-
specific warranty terms and conditions,
please contact Miele.
Optional accessories
40
Miele all purpose microfibre
cloth
Light soiling and fingerprints on
stainless steel fronts, control panels and
furniture can be easily removed with
this microfibre cloth.
Charcoal filter
(ActiveAirCleanfilter)
The Active AirClean filter ensures
optimum air quality in the wine
conditioning unit by filtering the
incoming air.
Optional accessories can be ordered
from the Miele webshop. They can
also be ordered directly from Miele
(see end of this booklet for contact
details).
Installation
41
Installation site
Risk of damage and injury from
the wine conditioning unit tipping
over.
The wine conditioning unit is very
heavy and can tip forward when the
appliance door is open.
Keep the appliance door shut until
the wine conditioning unit has been
built in and secured in its building-in
niche in accordance with these
operating and installation
instructions.
Fire risk and danger of damage
from open flames!
Open flames can set fire to the wine
conditioning unit.
Keep open flames (e.g. a candle)
away from the wine conditioning unit.
Fire hazard and risk of damage
from appliances that give off heat.
Appliances which give off heat can
catch fire and set fire to the wine
conditioning unit.
This wine conditioning unit must not
be installed underneath a cooktop.
Risk of damage caused by
appliances discharging vapours.
Installing appliances that discharge
vapours behind the wine conditioning
unit will put it at risk of damage.
Do not install appliances that
discharge air or vapours behind the
wine conditioning unit. Provide a
separate air guide or install a partition
wall between the appliances.
Risk of damage due to high
humidity.
In environments with high humidity,
condensation can build up on the
external wine conditioning unit
panels.
This condensate can cause corrosion
on external appliance panels.
Install the wine conditioning unit with
sufficient ventilation in a dry and/or
air-conditioned room.
After installation, please make sure
that the appliance door closes
properly and that the specified
ventilation openings are adhered to.
This appliance should be installed in a
dry, well-ventilated room.
When deciding on the installation site,
please bear in mind that the energy
consumption increases if the wine
conditioning unit is installed near a
heater, a cooker or another appliance
that gives off heat. Direct sunlight
should also be avoided.
The higher the room temperature, the
longer the compressor runs and the
higher the energy consumption is.
When installing the wine conditioning
unit, please note the following:
- The mains socket must not be located
directly behind the appliance and
should be easily accessible.
- The mains plug and power supply cord
must not touch the rear of the wine
conditioning unit as they could be
damaged by vibrations from the wine
conditioning unit.
- Other appliances should not be
plugged into a socket located directly
behind this wine conditioning unit.
Installation
42
- When installing the wine conditioning
unit, make sure that the power supply
cord does not get trapped or
damaged.
- Do not position or operate multi-
socket adapters, distributor strips or
other electronic devices (such as
halogen transformers) at the rear of
the appliance.
- The floor at the installation site must
be horizontal and level and must be as
high as the surrounding floor.
Risk of injury from broken glass.
If installed at altitudes above 1500m
there is a risk of the glass in the door
breaking because of changes in air
pressure. Shards of glass can cause
severe injury.
The wine conditioning unit must not
be installed at altitudes above
1500m.
Climate range
This wine conditioning unit is designed
for use within specific ambient
temperatures (climate range). Do not
use it in ambient temperatures for
which it is not designed. The climate
range is stated on the data plate inside
the wine conditioning unit.
Climate range Ambient
temperature
SN 10to32°C
N 16to32°C
ST 16to38°C
T 16to43°C
SN-ST 10to38°C
SN-T 10to43°C
A lower ambient temperature will cause
the compressor to switch off for longer
periods, meaning that the wine
conditioning unit is unable to maintain
the required temperature in some
circumstances.
Ventilation
Ventilation takes place through a
ventilation grille in the wine
conditioning unit plinth.
Risk of fire and damage due to
insufficient ventilation!
If the wine conditioning unit is not
ventilated sufficiently, the
compressor will run more frequently
and for longer periods. This will result
in increased energy consumption and
a higher operating temperature of the
compressor. This, in turn, can result
in damage to the compressor.
Please ensure that there is adequate
ventilation around the wine
conditioning unit.
It is essential to observe the required
ventilation openings.
The ventilation openings must not be
covered or blocked in any way.
They must also be cleaned on a
regular basis to remove dust.
Side-by-side units
This wine conditioning unit can be
installed side by side with another
refrigeration appliance.
Installation
43
The side-by-side installation kit is
available from Miele.
Miele will be able to advise you which
combination of models is possible
with your wine conditioning unit.
Instructions for installing appliances
side by side can be found in the side-
by-side installation kit installation
instructions.
Changing the door hinging
Danger of injury and damage to
the appliance due to heavy door.
There is an increased danger of injury
and damage if the door hinging is
installed by a single person.
Always change the door hinging with
the help of a second person.
Risk of crushing at the hinge.
Fingers can get trapped in or around
the hinge.
Do not reach into the hinge when
opening and closing the door.
The wine conditioning unit is supplied
with right-hand hinging. If left-hand
hinging is required, the door hinging
must be changed (see accompanying
installation instructions) before the wine
conditioning unit is installed in the
niche.
Useful tip: Place a suitable cover on the
floor in front of the wine conditioning
unit to protect the appliance door and
your floor from damage.
Risk of injury and damage!
The glass door can drop.
When changing the door hinging,
make sure that all fixing parts are
securely screwed into position.
Be careful not to damage the door
seal. If the door seal is damaged, the
appliance door may not close
properly and cooling will be
insufficient.
Installation
*INSTALLATION*
44
Installation dimensions
Niche/side view
All dimensions are given in mm.
The wine conditioning unit will function correctly if the specified ventilation
openings are kept clear.
560
580
+4
≥150cm²
580
≤35
58
+54
100 717
60
21
Installation
*INSTALLATION*
45
Connections
All dimensions are given in mm.
3
+60
≥150cm²
a
Front view
b
Power supply cord, length = 2200mm
c
No connections permitted in the rear panel
Installation
46
Installing the wine conditioning
unit
To install the wine conditioning unit,
you will need the following tools:
Useful tip: Store the enclosed metal rod
in a safe place. It is required for
adjusting the rear appliance feet.
Preparing the wine conditioning unit
Position the wine conditioning unit in
front of the housing unit.
Grasp the plinth panel at the side and
pull it off towards the front.
Fit the bracket in the opening in the
appliance lid.
Bend the bracket at the perforated
point.
Pushing in the wine conditioning unit
Risk of damaging the power
supply cord.
When pushing the wine conditioning
unit into its niche, the power supply
cord can get trapped and damaged.
Push the wine conditioning unit
carefully into the niche.
Risk of damaging the floor.
Moving the wine conditioning unit
can cause damage to the floor.
Move the wine conditioning unit
carefully on floors that are sensitive
to scratching.
Risk of damaging the appliance
feet.
The appliance feet can break off.
The feet should be almost fully
screwed in when you push the wine
conditioning unit into the niche.
Installation
47
Useful tip: Loosen the two rear feet by
half a turn before pushing the appliance
in. After pushing it into the niche, the
feet will be easier to adjust from the
front (see “Aligning the wine
conditioning unit”).
Position the power supply cord so
that the wine conditioning unit can be
connected easily once installed.
Useful tip: To help you push the
appliance into position, tie a piece of
string around the mains plug to
“increase” the length of the power
supply cord.
Then pull the power supply cord by the
end of the string through the housing
unit.
If the wine conditioning unit is
pushed too far into the niche, the
appliance door may not close
properly once the furniture panel has
been fitted. This can cause ice to
build up, condensate to accumulate
and lead to faults in the appliance.
These can all lead to increased
energy consumption.
Push the wine conditioning unit into
the building-in niche, making sure a
gap of 42mm is maintained all round
between the appliance carcase and
the front of the housing unit side
walls.
Push the refrigeration appliance into
the niche until the front edges of the
hinges at the top and bottom are flush
with the front edge of the housing unit
side wall.
This will create a gap all round of
42mm to the front edges of the
housing unit side walls.
With furniture with door fittings (e.g.
stubs, seals etc.) the dimension of
these must be taken into account
when making sure there is a gap all
round of 42mm.
Pull the wine conditioning unit
forwards by the appropriate
dimension.
Check again to make sure there is a
gap of 42mm to the front edges of
the door fittings.
Useful tip: If possible, remove door
fittings and push the wine conditioning
unit into the niche until all fixing
brackets at the top and bottom are in
line with the front edge of the housing
unit side wall.
Aligning the wine conditioning unit
When securing the wine conditioning
unit in the niche at the top, it should sit
lightly tensioned between the floor and
the worktop.
Adjust the front and rear feet
alternately according to the niche
height and make sure the wine
conditioning unit is correctly aligned.
Proceed as follows:
Installation
48
Adjust both rear feet with appropriate
screws at the front right and left in the
appliance plinth using the rod
supplied and a flat-tip screwdriver.
Unscrew the two front feet alternately
with the rear ones. The maximum
adjustment range is 6cm.
Useful tip: As soon as the feet have
been unscrewed slightly, you can adjust
them with a screwdriver at the bottom
of the foot.
The foam attached to the
ventilation grille ensures the airflow is
separated to prevent malfunctioning
of the appliance.
Replace the plinth panel with the
ventilation grille, but do not fix it in
place yet.
Without a continuous plinth panel:
Pull the plinth panel forwards until
the ventilation slots are in alignment
with adjacent cabinet plinth panels.
Hold the plinth panel securely and
attach it to the right and left using the
bolts supplied.
With the plinth panel attached, the
rear feet can only be adjusted when
the plinth panel is fully inserted.
Otherwise, the rod is not long enough.
With a continuous plinth panel:
Push the plinth panel with the
ventilation grille right up against
the wine conditioning unit, and attach
it to the right and left using bolts.
If a continuous plinth panel is to be
fitted, a suitable ventilation gap will
need to be made in it for the
ventilation grille of the wine
conditioning unit.
Trim the furniture plinth panel (U) to
the correct height.
Adjust the height (V) along the niche
width (W) underneath the appliance
plinth.
Installation
49
Aligning the wine conditioning unit to
taller furniture doors
If adjacent furniture doors are taller
than the wine conditioning unit door, the
wine conditioning unit can be aligned to
the adjacent furniture doors using a filler
panel.
The filler panel must be made exactly to
measure. Please also take into account
the door hinge when having the filler
panel made (depending on the model).
A fixing bracketis required to secure
the filler panel. This is available from
Miele Customer Service or from
specialist dealers. The fixing bracket is
fitted on the wine conditioning unit:
Fix the fixing bracket to the back of
the filler panel .
Pull the wine conditioning unit as far
as you need to out of the niche so
that you can tilt it towards you.
Loosely screw the fixing bracket
with the filler panel to the wine
conditioning unit.
Align the filler panel to the wine
conditioning unit door to give a flush
finish.
Now tighten the screws.
You can now push the wine
conditioning unit into the niche.
Installation
50
Securing the wine conditioning unit in
the niche
Screw the wine conditioning unit in
place underneath the worktop with
two screws in each case.
Installation
51
Electrical connection
The refrigeration appliance must only be
connected to an earthed socket using
the connection cable supplied.
The socket should be easily accessible
after the refrigeration appliance has
been installed. If the socket is not easily
accessible, ensure that a suitable
means of disconnection is provided on
the installation side for each pole.
Risk of fire from overheating.
Connecting the appliance to a multi-
socket plug adapter or to an
extension lead can overload the
cable.
For safety reasons, do not use an
extension cable or multi-socket
adapter.
All electrical work must be carried out
by a suitably qualified and competent
person in strict accordance with
national and local safety regulations.
For safety reasons, we recommend
using a suitable residual current device
(RCD) in the relevant electrical
installation for connecting the
refrigeration appliance.
If the mains connection cable is
damaged, it must only be replaced with
a specific mains connection cable of the
same type (available from Miele).
The data plate indicates the nominal
power consumption and the connection
data. Compare this information with the
data of the on-site electrical connection.
If in any doubt, consult a qualified
electrician.
Temporary or permanent operation with
a self-sufficient or non-mains
synchronous energy supply system (e.g.
isolated networks, back-up systems) is
possible. A requirement for the
operation is that the energy supply
system complies with all current local
and national requirements that apply to
stand-alone, solar and/or battery
systems.
The protective measures provided in the
domestic installation and in this Miele
product must also be assured in their
function and operation in isolated
operation or in non-mains synchronous
operation, or replaced with equivalent
measures in the installation.
Connecting the appliance
Insert the plug connector into the
back of the appliance.
Make sure that the plug connector has
locked into position correctly.
Insert the plug of the appliance into
the socket and switch it on.
The appliance is now connected to the
electricity supply.
Thailand
Miele Appliances Ltd.
BHIRAJ TOWER at EmQuartier
43rd Floor Unit 4301-4303
689 Sukhumvit Road
North Klongton Sub-District
Vadhana District
Bangkok 10110, Thailand
Miele Global Headquarters Germany
Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Federal Republic of Germany
Malaysia
Miele Sdn Bhd
Suite 12-2, Level 12
Menara Sapura Kencana Petroleum
Solaris Dutamas No. 1, Jalan Dutamas 1
50480 Kuala Lumpur, Malaysia
Phone: +603-6209-0288
Fax: +603-6205-3768
Singapore
Miele Pte. Ltd.
29 Media Circle
#11-04 ALICE@Mediapolis
Singapore 138565
Tel: +65 6735 1191
Fax: +65 6735 1161
E-mail: [email protected]
Internet: www.miele.sg
Miele (Pty) Ltd
63 Peter Place, Bryanston 2194
P.O. Box 69434, Bryanston 2021
Tel.: (011) 875 9000
Fax: (011) 875 9035
E-mail: [email protected]
Internet: www.miele.co.za
South Africa
India
Miele India Pvt. Ltd.
1st Floor, Copia Corporate Suites,
Commercial Plot 9,
Mathura Road, Jasola,
New Delhi - 110025
E-mail: [email protected]
Website: www.miele.in
Miele Australia Pty. Ltd.
ACN 005 635 398, ABN 96 005 635 398
Miele Head Office Melbourne:
Level 4, 141 Camberwell Road
Hawthorn East, VIC 3123
Miele New Zealand Ltd.
IRD 98 463 631
Head Office:
8 College Hill
Freemans Bay, Auckland 1011
1300 464 353 (1300 4 MIELE)
www.miele.com.au
0800 464 353 (0800 4 MIELE)
www.miele.co.nz
Miele (Hong Kong) Ltd.
41/F - 4101, Manhattan Place
23 Wang Tai Road, Kowloon Bay
Hong Kong
Tel.: (852) 2610 1025
Fax: (852) 3579 1404
E-mail: [email protected]
Website: www.miele.hk
Hong Kong, China
M.-Nr. 12 794 630 / 01en - AU, NZ
KWTUS 7054 ...
