1EN
Contents
1 Important 2
Important Safety Instructions 2
Hearing safety 4
Notice 5
2 Your portable DVD player 8
Introduction 8
What's in the box 8
Overview of the main unit 9
Overview of the remote control 11
3 Get started 13
Preparation (for in-car use) 13
Charge the battery 15
Install remote control battery 17
Connect additional equipment 18
4 Use your player 19
Turn on 19
Select OSD language 19
Play discs 20
Play from USB 20
Play options 21
Adjust brightness of screen backlight 21
5 Adjust settings 22
6 Product information 23
7 Troubleshooting 24
English
PD9030_85_UM_Sunplus_V3.0.indb 1 10/12/2012 4:35:09 PM
2 EN
1 Important
Important Safety Instructions
a Read these instructions.
b Keep these instructions.
c Heed all warnings.
d Follow all instructions.
e Do not use this apparatus near water.
f Clean only with dry cloth.
g Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
h Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including ampliers) that produce heat.
i For countries with a polarized mains, do not defeat the safety purpose
of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a
third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
Caution: To prevent electric shock, match the wide blade of the plug to the
wide slot, fully insert.
j Protect the power cord from being walked on or pinched, particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
k Only use attachments/accessories specied by the manufacturer.
PD9030_85_UM_Sunplus_V3.0.indb 2 10/12/2012 4:35:09 PM
3EN
l Use only with the cart, stand, tripod, bracket, or table specied by the
manufacturer or sold with the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to avoid injury from tip-over.
m Unplug this apparatus during lightning storms or when unused for long
periods of time.
n Refer all servicing to qualied service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
o Apparatus shall not be exposed to dripping or splashing.
p Do not place any sources of danger on the apparatus (e.g. liquid lled
objects, lighted candles).
q This product may contain lead and mercury. Disposal of these materials
may be regulated due to environmental considerations. For disposal
or recycling information, please contact your local authorities or the
Electronic Industries Alliance: www.eiae.org
Caution
• Use of controls or adjustments or performance of procedures other than herein may result in
hazardous radiation exposure or other unsafe operation.
English
PD9030_85_UM_Sunplus_V3.0.indb 3 10/12/2012 4:35:10 PM
4 EN
Warning
• Never remove the casing of this apparatus.
• Never lubricate any part of this apparatus.
• Never place this apparatus on other electrical equipment.
• Keep this apparatus away from direct sunlight, naked ames or heat.
• Never look into the laser beam inside this apparatus.
• Ensure that you always have easy access to the power cord, plug or adaptor to disconnect this
apparatus from the power.
Hearing safety
Listen at a moderate volume.
• Using headphones at a high volume can impair your hearing. This product can
produce sounds in decibel ranges that may cause hearing loss for a normal
person, even for exposure less than a minute. The higher decibel ranges are
offered for those that may have already experienced some hearing loss.
• Sound can be deceiving. Over time your hearing 'comfort level' adapts to
higher volumes of sound. So after prolonged listening, what sounds 'normal'
can actually be loud and harmful to your hearing. To guard against this, set
your volume to a safe level before your hearing adapts and leave it there.
To establish a safe volume level:
• Set your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly,
without distortion.
Listen for reasonable periods of time:
• Prolonged exposure to sound, even at normally 'safe' levels, can also cause
hearing loss.
• Be sure to use your equipment reasonably and take appropriate breaks.
Be sure to observe the following guidelines when using your headphones.
• Listen at reasonable volumes for reasonable periods of time.
• Be careful not to adjust the volume as your hearing adapts.
• Do not turn up the volume so high that you can't hear what's around you.
• You should use caution or temporarily discontinue use in potentially
hazardous situations. Do not use headphones while operating a motorized
vehicle, cycling, skateboarding, etc.; it may create a trafc hazard and is illegal
in many areas.
PD9030_85_UM_Sunplus_V3.0.indb 4 10/12/2012 4:35:10 PM
5EN
Notice
Any changes or modications made to this device that are not expressly approved
by Philips Consumer Lifestyle may void the user’s authority to operate the
equipment.
Recycling
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
When you see the crossed-out wheel bin symbol attached to a product, it means
the product is covered by the European Directive 2002/96/EC:
Never dispose of your product with other household waste. Please inform
yourself about the local rules on the separate collection of electrical and electronic
products. The correct disposal of your old product helps prevent potentially
negative consequences on the environment and human health.
Your product contains batteries covered by the European Directive 2006/66/EC,
which cannot be disposed of with normal household waste.
Please inform yourself about the local rules on separate collection of batteries. The
correct disposal of batteries helps prevent potentially negative consequences on
the environment and human health.
Environmental information
All unnecessary packaging has been omitted. We have tried to make the packaging
easy to separate into three materials: cardboard (box), polystyrene foam (buffer)
and polyethylene (bags, protective foam sheet.)
Your system consists of materials which can be recycled and reused if disassembled
by a specialized company. Please observe the local regulations regarding the
disposal of packaging materials, exhausted batteries and old equipment.
Always bring your product to a professional to remove the built-in battery.
English
PD9030_85_UM_Sunplus_V3.0.indb 5 10/12/2012 4:35:11 PM
6 EN
The making of unauthorized copies of copy-protected material, including computer
programs, les, broadcasts and sound recordings, may be an infringement of
copyrights and constitute a criminal offence. This equipment should not be used
for such purposes.
Recording and playback of material might require consent. See Copyright Act 1956
and The Performer’s Protection Acts 1958 to 1972.
This item incorporates copy protection technology that is protected by U.S.
patents and other intellectual property rights of Rovi Corporation. Reverse
engineering and disassembly are prohibited.
Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
DivX®, DivX Certied® and associated logos are trademarks of DivX, Inc. and
are used under license.
ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is
an ofcial DivX Certied® device that plays DivX video. Visit divx.com for more
information and software tools to convert your les into DivX video.
PD9030_85_UM_Sunplus_V3.0.indb 6 10/12/2012 4:35:12 PM
7EN
ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certied® device must be
registered in order to play purchased DivX Video-on-Demand (VOD) movies.
To obtain your registration code, locate the DivX VOD section in your device
setup menu. Go to vod.divx.com for more information on how to complete your
registration.
Covered by one or more of the following U.S. patents: 7,295,673; 7,460,668;
7,515,710; 7,519,274
This apparatus includes this label:
English
PD9030_85_UM_Sunplus_V3.0.indb 7 10/12/2012 4:35:12 PM
8 EN
2 Your portable DVD player
Congratulations on your purchase, and welcome to Philips! To fully benet from
the support that Philips offers, register your product at www.philips.com/welcome.
Introduction
Your portable DVD player plays digital video discs that conform to the universal
DVD Video standard. With it, you can play movies with true cinema picture quality
and stereo or multi-channel sound (depending on disc and playback set-up).
You can also select sound track, subtitle languages, and different angle of view
(again depending on DVD disc). Besides, you can restrict the play of discs that are
not suitable for children.
You can play the following discs on the DVD player (including CD-R, CD-RW,
DVD±R and DVD±RW):
• DVD-Video
• Video CD
• Audio CD
• MP3 CD
• DivX
• Discs with JPEG les
What's in the box
Check and identify the contents of your package:
• Portable DVD player
• Remote control
• AC power adaptor, AY5808/37 or DSA-9PFB-09 FUS090100
• Car adaptor
• AV cable
• Car mounting bracket
• User manual
PD9030_85_UM_Sunplus_V3.0.indb 8 10/12/2012 4:35:12 PM
9EN
Overview of the main unit
a Display panel
b OPTIONS
• Accesses options relating to the current activity or selection.
c SOURCE
• Switches between DVD and USB.
d SUBTITLE
• Selects DVD subtitle language.
e SETUP
• Accesses or exits the setup menu.
f DC IN
• Power supply socket.
g AV OUT
• Audio/video output jack.
a
e
c
b
d
f
g
h
i
j
k
o
p
l
m
n
q
English
PD9030_85_UM_Sunplus_V3.0.indb 9 10/12/2012 4:35:13 PM
10 EN
h
• Headphone jack.
i
• Connects a USB storage device.
j - VOL +
• Increases or decreases volume.
k (CHR)OFF•POWER•ON
• Turns on/off DVD player.
l , , ,
• Navigates menus.
• ,
• Searches backward/forward at different speeds.
• /OK
• Conrms an entry or selection.
• Starts, pauses or resumes disc play.
m CHR/IR/
• Charging indicator/Remote control sensor/Power indicator.
n ,
• Skips to the previous or next title, chapter, or track.
o DISC MENU
• For DVD, accesses or exits disc menu.
• For VCD, turns on or off PBC (Playback Control) mode.
• For VCD version 2.0 or SVCD with PBC turned on, returns to the
menu.
p STOP
• Stops disc play.
q OPEN
• Opens the disc compartment.
PD9030_85_UM_Sunplus_V3.0.indb 10 10/12/2012 4:35:16 PM
11EN
Overview of the remote control
a SOURCE
• Switches between DVD and USB.
b DISPLAY
• Displays play information.
c
• Adjusts brightness of the screen backlight.
j
k
l
m
n
g
i
abcd
h
OPTIONS
SOURCE
f
e
English
PD9030_85_UM_Sunplus_V3.0.indb 11 10/12/2012 4:35:17 PM
12 EN
d MENU
• For DVD, accesses or exits disc menu.
• For VCD, turns on or off PBC (Playback Control) mode.
• For VCD version 2.0 or SVCD with PBC turned on, returns to the
menu.
• For a USB device, accesses or exits the le menu.
e A-B
• Marks the section for repeat play.
f OPTION
• Accesses options relating to the current activity or selection.
g SUB
• Selects a DVD subtitle language.
h AUDIO
• For DVD, selects an audio language.
• For VCD, selects an audio mode.
i ZOOM
• Zooms into a video scene or picture.
j 0-9
• Inputs numbers.
k
• Stops disc play.
l SETUP
• Accesses or exits the setup menu.
m , , ,
• Navigates menus.
,
• Searches backward/forward at different speeds.
/OK
• Conrms an entry or selection.
• Starts, pauses or resumes disc play.
n /
• Skips to the previous or next title, chapter, or track.
PD9030_85_UM_Sunplus_V3.0.indb 12 10/12/2012 4:35:19 PM
13EN
3 Get started
Caution
• Use the controls only as stated in this user manual.
• Always follow the instructions in this chapter in sequence.
If you contact Philips, you will be asked for the model and serial number of your
player. The model number and serial number are on the bottom of your player.
Write the numbers here:
Model No. __________________________
Serial No. ___________________________
Preparation (for in-car use)
Warning
• Remove the mounting kit and the DVD player from the seat when the DVD player is not in use.
To use the player in a car, attach the player to the back of the front seat headrest.
A. DVD player fastening screw node
B. Viewing angle adjustment node
C. Buckle release button
D. Headrest mount bracket
1 Fix the headrest mount bracket on to the front seat headrest.
A
DCB
English
PD9030_85_UM_Sunplus_V3.0.indb 13 10/12/2012 4:35:19 PM
14 EN
a Position the bracket on the bars of the headrest.
b Fasten the screw to x the bracket rmly on the bars.
2 Fix the DVD mount bracket to the portable DVD player.
Note
• There are three holes on the bracket. Use any one as you like.
3 Aim the screw of the bracket to the screw nut on the back of the DVD
player.
• Screw tight the bracket onto the DVD player.
4 Install the DVD player to the headrest.
• Buckle DVD bracket into the headrest mount bracket.
PD9030_85_UM_Sunplus_V3.0.indb 14 10/12/2012 4:35:20 PM
15EN
5 Adjust the viewing angle.
a Release the node.
b Adjust the viewing angle as desired.
c Fasten the node.
6 Press the release button to release the DVD player from headrest.
Charge the battery
Caution
• Risk of product damage. Ensure that the power supply voltage corresponds to the voltage printed
on the bottom of the player.
• Use only the supplied AC adaptor to charge the battery.
English
PD9030_85_UM_Sunplus_V3.0.indb 15 10/12/2012 4:35:21 PM
16 EN
Note
• The type plate is located on the bottom of the player.
To fast charge the battery,
1 Slide the OFF•POWER•ON switch to OFF position.
2 Connect the supplied AC adaptor to the player and to the AC outlet.
» The CHR indicator turns on (red).
» When the battery is fully charged, the CHR indicator turns off.
You can also charge the battery during playback.
1 To charge the battery, connect the supplied AC adaptor to the player and to
the AC outlet.
PD9030_85_UM_Sunplus_V3.0.indb 16 10/12/2012 4:35:21 PM
17EN
Install remote control battery
Caution
• Risk of explosion! Keep batteries away from heat, sunshine or re. Never discard batteries in re.
• Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent
type.
• Batteries contain chemical substances, they should be disposed of properly.
• Perchlorate Material - special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate.
For rst-time use:
1 Remove the protective tab to activate the remote control battery.
To replace the remote control battery:
1 Open the battery compartment.
2 Insert one CR2025 battery with correct polarity (+/-) as indicated.
3 Close the battery compartment.
1
2
3
English
PD9030_85_UM_Sunplus_V3.0.indb 17 10/12/2012 4:35:22 PM
18 EN
Connect additional equipment
Caution
• Turn off your player before connecting to any additional equipment.
You can connect the player to a TV or an amplier to enjoy DVDs.
Match the color of the AV cables (the AV cable connected to TV is not supplied)
with the jacks:
• the yellow cable is for the yellow video jack
• the red/white cable is for the red/white audio jacks.
L
R
VIDEO IN
PD9030_85_UM_Sunplus_V3.0.indb 18 10/12/2012 4:35:23 PM
19EN
4 Use your player
Turn on
Slide the OFF•POWER•ON switch to the ON position.
» The indicator turns on (green).
Select OSD language
You can choose a different language for the on-screen display text.
1 Press SETUP.
» The setup menu appears.
2 Select [General] > [Language].
3 Press to select an option.
4 Press OK to conrm.
5 Press SETUP to exit.
English
PD9030_85_UM_Sunplus_V3.0.indb 19 10/12/2012 4:35:23 PM
20 EN
Play discs
1 Slide OPEN on the player.
2 Insert the disc with label side facing up.
3 Push down to close the disc compartment.
» Play starts automatically. If not, press /OK.
• If a menu is displayed, select an item, then press /OK to start play.
• To pause, press /OK. Press again to resume play.
• To stop, press STOP twice.
• To select the previous/next item, press or .
• To start search within video/audio, press or once or more.
Play from USB
You can play DivX, VOB, MP3, or JPEG les that are stored on a USB storage
device.
1 Connect the USB device to the player.
» The content menu is displayed.
2 Press SOURCE to switch to USB mode.
3 Select a le, then press .
» Play starts.
4 To stop play, press .
PD9030_85_UM_Sunplus_V3.0.indb 20 10/12/2012 4:35:24 PM
21EN
Play options
1 During play, press OPTIONS to select some play options.
2 Follow the on-screen instructions.
Adjust brightness of screen backlight
Note
• You can adjusts brightness of the screen backlight to match lighting conditions.
During play, press repeatedly to select an option.
• [High]
• [Normal]
• [Dim]
Tip
• For the longest playtime, select [Dim].
• For the best view, select [High].
English
PD9030_85_UM_Sunplus_V3.0.indb 21 10/12/2012 4:35:24 PM
22 EN
5 Adjust settings
To maximize your play experience, use SETUP to ne tune your settings.
1 Press SETUP.
» The setup menu is displayed.
2 Use navigation keys to select an option and press OK to conrm.
[General]
[Language] Select on-screen display language
[PBC settings] Set playback control function on/off.
[DivX (VOD)] Get DivX registration code.
[DivX subtitles] Select DivX subtitle language.
[Parental(DVD)] Select parental options.
[Set password] Change existing password.
[Factory settings] Restore factory settings.
[Video]
[LCD Display] Set screen display aspect ratio.
[TV standard] Set video output format to TV system.
[Brightness] Adjust screen brightness.
[Contrast] Adjust screen contrast.
[ Audio]
[Dolby] Set Dolby output.
[Version] Check the version information.
3 Press to go back to the previous menu.
4 Press SETUP to exit.
PD9030_85_UM_Sunplus_V3.0.indb 22 10/12/2012 4:35:24 PM
23EN
6 Product information
Note
• Product information is subject to change without prior notice.
Dimensions 239 x 39 x 178 mm
Weight 1.1 kg
Power supply Input: 100-240V~ 50/60Hz
Output: DC 9V 1.0A
Power consumption 9 W
Operating temperature
range
0-45°C
Laser wavelength 650 nm
Video output
Format PAL & NTSC
Output level 1Vp - p ± 20%
Load impedance
75
Audio line out
Audio out (analog audio) Output level: 2V ± 10%
Load impedance
10 K
Audio distortion + noise
-80 (1KHz)
Frequency response 20Hz-20KHz ± 1dB
Signal/noise ratio
80 dB
Channel separation
80 dB
Dynamic range
80 dB
English
PD9030_85_UM_Sunplus_V3.0.indb 23 10/12/2012 4:35:25 PM
24 EN
7 Troubleshooting
Warning
• Risk of electric shock. Never remove the casing of the player.
To keep the warranty valid, never try to repair the system yourself.
If you encounter problems when using the player, check the following points
before requesting service. If the problem remains unsolved, register your player
and get support at www.philips.com/welcome.
No power
• Ensure that both plugs of the mains cord are properly connected.
• Ensure that there is power at the AC outlet.
• Check if the built-in battery is drained.
No sound
• Ensure that the AV cable is connected correctly.
Distorted picture
• Clean the disc. With a clean, soft, lint-free cloth, wipe the disc outwards from
the center.
• Make sure that the video output format of the disc is compatible with the TV.
• Change the video output format to match your TV or program.
• The LCD is manufactured using high precision technology. You may, however,
see tiny black points and/or bright points(red, blue, green) that continuously
appear on the LCD. This is a normal result of the manufacturing process and
does not indicate a malfunction.
Cannot play disc
• Ensure the disc label is upwards.
• Clean the disc. With a clean, soft, lint-free cloth, wipe the disc outwards from
the center.
• Check if the disc is defective by trying another disc.
No response to the remote control
• Ensure that the path between the remote control and the player is clear
from obstacles.
• From a close distance, point the remote control directly at the player.
PD9030_85_UM_Sunplus_V3.0.indb 24 10/12/2012 4:35:25 PM
25EN
• Replace the remote control batteries.
• The function does not work for this disc. Refer to the disc instructions.
The player feels warm
• When the player is in use for a long period of time, its surface will be heated.
This is normal.
English
PD9030_85_UM_Sunplus_V3.0.indb 25 10/12/2012 4:35:26 PM
Specifications are subject to change without notice
© 2012 Koninklijke Philips Electronics N.V.
All rights reserved.
PD9030_85_UM_V3.0
PD9030_85_UM_Sunplus_V3.0.indb 56 10/12/2012 4:35:46 PM
