en Table of contents
You can find additional information and explanations online.
Scan the QR code on the title page.
Table of contentsTable of contents
1Safety ............................................ 3
1.1 General information .................... 3
1.2 Intended use ................................ 3
1.3 Restriction on user group .......... 4
1.4 Safe installation ........................... 4
1.5 Safe use ........................................ 5
1.6 Damaged appliance ................... 7
1.7 Risk to children ........................... 7
2Preventing material damage ...... 8
2.1 Safe installation ........................... 8
2.2 Safe use ........................................ 9
3Environmental protection and
saving energy .............................. 9
3.1 Disposing of packaging ............. 9
3.2 Saving energy ............................ 10
4Installation and connection ...... 10
4.1 Scope of supply ........................ 10
4.2 Installing and connecting the
appliance .................................... 10
4.3 Drainage connection ................ 10
4.4 Drinking water connection ...... 11
4.5 Electrical connection ................ 11
5Familiarising yourself with
your appliance ........................... 12
5.1 Appliance .................................... 12
5.2 Controls ...................................... 13
6Programmes .............................. 15
6.1 Information for test institutes .. 17
6.2 Favourite ................................ 17
7Additional functions .................. 17
8Features ..................................... 18
8.1 Top basket ................................. 18
8.2 Etagere ........................................ 19
8.3 Bottom basket ........................... 19
8.4 Folding prongs .......................... 20
8.5 Cutlery drawer ........................... 20
8.6 Basket heights ........................... 21
9Before using for the first time .. 21
9.1 Performing the initial configur-
ation ............................................. 21
10 Water softening system ......... 21
10.1 Overview of water hardness
settings ..................................... 22
10.2 Setting the water softening
system ...................................... 22
10.3 Special salt .............................. 22
10.4 Switching off the water
softening system ..................... 23
10.5 Regeneration of the water
softening system ..................... 24
11 Rinse aid system .................... 24
11.1 Rinse aid .................................. 24
11.2 Setting the amount of rinse
aid .............................................. 25
11.3 Switching the rinse aid sys-
tem off ....................................... 25
12 Detergent ................................. 25
12.1 Suitable detergents ................ 25
12.2 Unsuitable detergents ............ 26
12.3 Information on detergents ..... 26
12.4 Adding detergent .................... 27
13 Tableware ................................ 28
13.1 Damage to glass and table-
ware ........................................... 28
13.2 Arrange tableware .................. 28
13.3 Removing tableware .............. 29
14 Basic operation ....................... 30
14.1 Switching on the appliance .. 30
14.2 Setting a programme ............. 30
14.3 Setting additional functions .. 30
14.4 Setting timer programming ... 30
14.5 Starting the programme ........ 30
14.6 Activating button lock ............ 31
2
Safety en
14.7 Deactivate button lock ........... 31
14.8 Interrupting programme ......... 31
14.9 Terminate programme ........... 31
14.10 Switching off appliance ....... 31
15 Basic settings .......................... 31
15.1 Overview of the basic set-
tings ........................................... 31
15.2 Changing basic settings ........ 33
16 HomeConnect ........................ 33
16.1 Setting up HomeConnect ..... 34
16.2 Remote Start .................... 34
16.3 Smart Start
1
............................. 34
16.4 Data protection ........................ 35
17 Cleaning and servicing ........... 35
17.1 Cleaning the tub ..................... 35
17.2 Cleaning products .................. 35
17.3 Tips on appliance care .......... 35
17.4 Machine Care ................... 36
17.5 Filter system ............................. 37
17.6 Cleaning spray arms .............. 38
18 Troubleshooting ...................... 39
18.1 Clean wastewater pump ........ 44
19 Transportation, storage and
disposal ................................... 45
19.1 Removing the appliance ....... 45
19.2 Protect appliance from
frost ........................................... 45
19.3 Transporting the appliance ... 45
19.4 Disposing of old appliance ... 45
20 Customer Service ................... 46
20.1 Product number (E-Nr.), pro-
duction number (FD) and
consecutive numbering (Z-
Nr.) ............................................. 46
21 Technical specifications ........ 46
21.1 Information regarding Free
and Open Source Software .. 47
22 Declaration of Conformity ...... 47
22.1 Statement of Compliance for
Great Britain ............................. 48
Safety 1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Do not connect the appliance if it has been damaged in transit.
1.2 Intended use
Only use this appliance:
¡ For cleaning household tableware.
¡ in closed rooms in the home and with similar applications, e.g.:
in canteens in shops, offices and other work environments; in
1
Depending on the appliance specifications
3
en Safety
agricultural businesses; use by customers in hotels, motels and
other typical home environments; in bed and breakfasts.
¡ Up to an altitude of 4000 m above sea level.
1.3 Restriction on user group
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Do not let children play with the appliance.
Cleaning and user maintenance must not be performed by chil-
dren unless they are being supervised.
Keep children under the age of 8 years away from the appliance
and power cable.
1.4 Safe installation
WARNING‒Risk of injury!
Improper installation may cause injury.
When installing and connecting the appliance, follow the instruc-
tions in the manual and installation instructions.
WARNING‒Risk of electric shock!
Incorrect installation is dangerous.
Connect and operate the appliance only in accordance with the
specifications on the rating plate.
Always use the supplied power cable for the new appliance.
Connect the appliance to a power supply with alternating cur-
rent only via a properly installed socket with earthing.
The protective conductor system of the domestic electrical in-
stallation must be properly installed.
Never equip the appliance with an external switching device,
e.g. a timer or remote control.
When the appliance is installed, the mains plug of the power
cord must be freely accessible. If free access is not possible, an
isolating switch must be integrated into the permanent electrical
installation according to the installation regulations.
4
Safety en
When installing the appliance, check that the power cable is not
trapped or damaged.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord and non-approved
adapters.
Do not use extension cables or multiple socket strips.
Only use adapters and power cords approved by the manufac-
turer.
If the power cord is too short and a longer one is not available,
please contact an electrician to have the domestic installation
adapted.
Contact between the appliance and installation lines may lead to a
defect in these lines, e.g. gas pipes and power lines. Gas from a
corroded gas pipe can ignite. A damaged power line can cause a
short circuit.
Check that there is a distance of at least 5cm between the ap-
pliance and installation lines.
WARNING‒Risk of burns!
If the appliance is not installed properly, this may result in burns.
With free-standing appliances, ensure that they are installed with
the back panel against a wall.
1.5 Safe use
WARNING‒Risk of serious harm to health!
Failure to comply with safety instructions and directions for use on
packagings of detergent and rinse aid products may cause seri-
ous harm to health.
Follow the safety instructions and directions for use on the
packagings of detergent and rinse aid products.
WARNING‒Risk of explosion!
Adding solvents to the interior of the appliance may cause explo-
sions.
Never add solvents to the interior of the appliance.
5
en Safety
Highly caustic alkaline or highly acidic cleaning agents in conjunc-
tion with aluminium parts in the interior of the appliance may
cause explosions.
Never use highly caustic alkaline or highly acidic cleaning
agents, in particular commercial or industrial products, in con-
junction with aluminium parts (e.g. grease filters of extractor
hoods or aluminium pans), e.g. for the Machine Care pro-
gramme.
WARNING‒Risk of injury!
Leaving the appliance door open may result in injury.
Only open the appliance door to load or unload tableware in or-
der to prevent accidents, e.g. through tripping.
Do not sit or stand on the appliance door when open.
Knives and utensils with sharp points can cause injuries.
Arrange knives and utensils with sharp points in the cutlery bas-
ket with the points downwards, on the knife shelf or in the cut-
lery drawer.
WARNING‒Risk ofscalding!
If you open the appliance door while the programme is running,
hot water may splash out of the appliance.
Open the appliance door carefully if the programme is still run-
ning.
WARNING‒Risk of tipping!
Overfilling the Baskets may cause the appliance to tip up.
Never overfill the Baskets with free-standing appliances.
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
Only use the appliance in enclosed spaces.
Never expose the appliance to intense heat or humidity.
Do not use steam- or high-pressure cleaners to clean the appli-
ance.
If the insulation of the power cord is damaged, this is dangerous.
Never let the power cord come into contact with hot appliance
parts or heat sources.
Never let the power cord come into contact with sharp points or
edges.
6
Safety en
Never kink, crush or modify the power cord.
1.6 Damaged appliance
WARNING‒Risk of electric shock!
If the appliance or the power cord is damaged, this is dangerous.
Never operate a damaged appliance.
Never operate an appliance with a cracked or fractured surface.
Never pull on the power cord to unplug the appliance. Always
unplug the appliance at the mains.
If the appliance or the power cord is damaged, immediately un-
plug the power cord or switch off the fuse in the fuse box and
turn off the water tap.
Call customer service.
Page46
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained
specialist staff.
Only use genuine spare parts when repairing the appliance.
If the power cord or the appliance power cable of this appliance
is damaged, it must be replaced with a special power cord or
special appliance power cable, which is available from the man-
ufacturer or its Customer Service.
1.7 Risk to children
WARNING‒Risk of suffocation!
Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
Keep packaging material away from children.
Do not let children play with packaging material.
Children may breathe in or swallow small parts, causing them to
suffocate.
Keep small parts away from children.
Do not let children play with small parts.
Children may become trapped in the appliance and suffocate.
Use the childproof lock if fitted.
Never let children play with or operate the appliance.
7
en Preventing material damage
WARNING‒Risk of harm to health!
Children can lock themselves in the appliance, thereby putting
their lives at risk.
With redundant appliances, unplug the power cord. Then cut
through the cord and damage the lock on the appliance door
beyond repair so that the appliance door will no longer close.
WARNING‒Risk of crushing!
With higher-level appliances, children can become crushed
between the appliance door and cabinet doors underneath.
Keep an eye on children when opening and closing the appli-
ance door.
WARNING‒Risk of chemical burns!
Rinse aid and detergent may cause chemical burns to the mouth,
throat and eyes.
Keep children away from detergent and rinse aid products.
Keep children away from the appliance when open. The water in
the interior of the dishwasher is not drinking water. It may con-
tain residues of detergents and rinse aid.
WARNING‒Risk of injury!
Children may get their fingers caught in the slots of the tablet col-
lecting tray and injure themselves.
Keep children away from the appliance when open.
Preventing material damage2 Preventing material
damage
2.1 Safe installation
ATTENTION
Improper installation of the appliance
may cause damage.
If the dishwasher is installed above
or below other domestic appli-
ances, follow the information on in-
stallation in combination with a
dishwasher in the installation in-
structions for the individual appli-
ances.
If there is no information or if the
installation instructions do not in-
clude the relevant information, con-
tact the manufacturer of these ap-
pliances to check that the dish-
washer can be installed above or
below these appliances.
If no information is available from
the manufacturer, the dishwasher
should not be installed above or
below such appliances.
To ensure the safe operation of all
domestic appliances, continue fol-
lowing the installation instructions
for the dishwasher.
8
Environmental protection and saving energy en
Do not install the dishwasher un-
der a hob.
Do not install the dishwasher near
heat sources, e.g. radiators, heat
storage tanks, ovens or other ap-
pliances that generate heat.
Contact between the appliance and
water pipes may lead to corrosion of
these pipes, possibly causing them
to leak.
Check that there is a distance of at
least 5cm between the appliance
and the water pipe. The pipes sup-
plied for the drinking water and
waste water connections are not
affected here.
Modified or damaged water hoses
may result in material damage and
damage to the appliance.
Never kink, crush, modify or cut
through water hoses.
Only use the water hoses supplied
with the appliance or genuine
spare hoses.
Never re-use water hoses that
have been used before.
If the water pressure is too high or
too low, the appliance may not be
able to operate properly.
Make sure that the water pressure
in the water supply system is min.
50kPa (0.5bar) and max.
1000kPa (10bar).
If the water pressure exceeds the
maximum value specified, a pres-
sure-reducing valve must be in-
stalled between the drinking water
connection and the hose set of the
appliance.
2.2 Safe use
ATTENTION
Escaping water vapour can damage
fitted units.
When the programme ends, leave
the appliance to cool down for a
while before opening the door.
Special salt for dishwashers can
damage the tub due to corrosion.
To make sure that any special salt
that escapes is washed out of the
tub, add the special salt to the dis-
penser for special salt immediately
before the programme starts.
Detergent may damage the water
softening system.
Only fill the dispenser of the water
softening system with special dish-
washer salt.
Unsuitable cleaning agents may dam-
age the appliance.
Do not use a steam cleaner.
So as not to scratch the finish on
the appliance, do not use sponges
with a rough surface or abrasive
cleaning agents.
To prevent corrosion, do not use
sponge cloths on dishwashers with
a stainless steel front or rinse such
cloths thoroughly several times be-
fore using them for the first time.
Environmental protection and saving energy3 Environmental protec-
tion and saving energy
3.1 Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
Sort the individual components by
type and dispose of them separ-
ately.
9
en Installation and connection
3.2 Saving energy
If you follow these instructions, your
appliance will use less electricity and
less water.
Use the Eco50° programme.
The Eco50° programme is en-
ergy-efficient and environmentally
friendly.
"Programmes", Page15
Installation and connection4 Installation and con-
nection
To ensure proper operation, connect
the appliance to the power and water
supply correctly. Observe the spe-
cified criteria and the installation in-
structions.
4.1 Scope of supply
After unpacking all parts, check for
any damage in transit and complete-
ness of the delivery.
If you have any complaints, contact
the dealer who sold you the appli-
ance or our Customer Service.
Note: The appliance has been tested
at the factory to check it is in working
order. It is possible that water has left
marks on the appliance. These
marks will disappear after the first
wash cycle.
The delivery consists of the following:
Dishwasher
Operating instructions
Installation Instructions
Further information documents
Installation material
Inlet hose
Salt filling aid funnel
1
Mains cable
Quick reference guide
4.2 Installing and connecting
the appliance
You can position your built-under or
integrable appliance in a fitted kit-
chen between wooden and plastic
walls.
1.
Follow the safety instructions.
Page3
2.
Follow the instructions for electrical
connection.
3.
Check the Scope of supply and
the condition of the appliance.
4.
Consult the installation instructions
for the installation dimensions re-
quired.
5.
Make the appliance level using the
height-adjustable feet.
Make sure that the appliance is
standing on the floor securely.
6.
Install the drainage connection.
Page10
7.
Install the drinking water connec-
tion.
Page11
8.
Connect the appliance to the
power supply.
4.3 Drainage connection
Connect your appliance to drainage
connection so dirty water is dis-
charged via the wash cycle.
Installing the drainage connection
1.
Consult the installation instructions
supplied for the steps required
here.
2.
Connect the wastewater hose to
the outlet connection of the siphon
using the enclosed parts.
3.
When doing so, check that the
wastewater hose is not kinked,
crushed or twisted.
1
Depending on the appliance specifications
10
Installation and connection en
4.
Also check that there is no cover
in the drainage system preventing
the wastewater from being dis-
charged.
4.4 Drinking water connection
Connect your appliance to a drinking
water connection.
Installing the drinking water con-
nection
Note: If you are replacing the appli-
ance, you must use a new water sup-
ply hose.
1.
Consult the installation instructions
supplied for the steps required
here.
2.
Connect the appliance to the drink-
ing water connection using the en-
closed parts.
Observe the Technical data.
3.
When doing so, check that the
drinking water connection is not
kinked, crushed or twisted.
4.5 Electrical connection
Connecting the appliance to the
electricity supply
Notes
Follow the Safety instructions
Page4
.
Please note that the water safety
system is only functional if there is
a power supply.
1.
Insert the non-heating appliance
plug of the power cable into the
appliance.
2.
Insert the mains plug of the appli-
ance's power cable in a socket
nearby.
The connection data of the appli-
ance can be found on the rating
plate.
3.
Check the mains plug is inserted
properly.
11
en Familiarising yourself with your appliance
Familiarising yourself with your appliance5 Familiarising yourself with your appliance
5.1 Appliance
You can find an overview of the parts of your appliance here.
1
2
3
4
5
6
7
8
9
10
11
12
Rating plate
Rating plate with E number and FD number
Page46
.
The data you need for Customer Service
Page46
.
Detergent dispenser
Add detergent to the detergent dispenser.
"Detergent", Page25
Bottom basket Bottom basket
Page19
12
Familiarising yourself with your appliance en
Filter system Filter system
Page37
Dispenser for special salt
Add the special salt to the dispenser for
special salt.
"Water softening system", Page21
Tablet collecting tray
During the wash cycle tablets automatically
fall out of the detergent dispenser into the
tablet collecting tray where they can fully
dissolve.
Top basket Top basket
Page18
Cutlery drawer Cutlery drawer
Page20
Cutlery shelf
1
Cutlery shelf
Page19
Upper spray arms
The upper spray arms wash the tableware
in the top basket.
If the tableware has not been washed prop-
erly, clean the spray arms.
"Cleaning spray arms", Page38
Lower spray arm
The lower spray arm washes the tableware
in the bottom basket.
If the tableware has not been washed prop-
erly, clean the spray arms.
"Cleaning spray arms", Page38
Dispenser for rinse aid
Add rinse aid to the dispenser for rinse aid.
"Rinse aid system", Page24
5.2 Controls
You can use the control panel to configure all functions of your appliance and
to obtain information about the operating status.
1
Depending on the appliance specifications
13
en Familiarising yourself with your appliance
With some buttons you can perform different functions.
1 2 3 4 5 6 7 8
910111213
ON/OFF button and reset
button
Switching on the appliance
Page30
Switching off the appliance
Page31
Terminating the programme
Page31
Programme buttons Programmes
Page15
Special salt refill indicator
Water softening system
"Adding special salt", Page22
Rinse aid refill indicator
Rinse aid system
"Adding rinse aid", Page24
WLAN display Home Connect
Page33
Water supply display Display for water supply
button
If you press for approx. 3
seconds, you can open the basic set-
tings.
"Changing basic settings", Page33
Start button
Starting the programme
"Starting the programme", Page30
Programme buttons and addi-
tional functions
Programmes
"Programmes", Page15
Additional functions
"Additional functions", Page17
Remote Start
"Remote Start ", Page34
Timer programming Setting timer programming
Page30
14
Programmes en
Display
The display shows information about
the remaining running time or the basic
settings. You can change the basic set-
tings via the display and the setting
buttons.
"Changing basic settings", Page33
Door handle
1
Open the appliance door.
Symbols on the display
1
The display shows the following sym-
bols depending on the model. See
here for an explanation.
Symbol Description
If the symbol for machine
care lights up on the dis-
play, run machine care.
"Machine Care ",
Page36
If the rinse aid refill indic-
ator lights up on the dis-
play, top up with rinse
aid.
"Adding rinse aid",
Page24
If the special salt refill in-
dicator lights up on the
display, add special salt
to the dispenser for spe-
Symbol Description
cial salt just before the
programme starts.
"Adding special salt",
Page22
If the appliance is con-
nected to a wireless
WLAN home network, the
symbol lights up on the
display.
"HomeConnect ",
Page33
If you have activated the
button lock, the symbol
lights up on the display.
"Activating button lock",
Page31
If the water inflow or
drainage malfunctions,
the symbol lights up or
flashes on the display.
"Troubleshooting",
Page39
Programmes6 Programmes
You can find an overview of the programmes that can be selected here. Differ-
ent programmes, which can be found on the control panel of your appliance,
are available depending on the appliance configuration.
The running time may vary depending on the programme selected. The running
time depends on the water temperature, the quantity of tableware, the level of
soiling and the Additional function
Page17
selected. The running time and
1
Depending on the appliance specifications
15
en Programmes
energy consumption will increase if the rinse aid system is switched off or if
rinse aid needs to be added.
The consumption values can be found in the quick reference guide. The con-
sumption values relate to normal conditions and a water hardness of 16 -
20°E. Different influencing factors such as water temperature or pipe pressure
may result in deviations.
Programme Use Programme sequence
Intensive 70°
Tableware:
Pots and pans, non-fragile
tableware and cutlery
Level of soiling:
Stubborn, burned or dried-on
food remnants containing
starch and protein
Intensive:
Pre-Rinse
Cleaning 70°C
Intermediate rinse
Final rinse 69°C
Dry
Auto 45-65°
Tableware:
Mixed tableware and cutlery
Level of soiling:
Common household food rem-
nants lightly dried on
Sensor-controlled:
Optimised by
sensors depending
on the soiling of the
washing water.
Eco 50°
Tableware:
Mixed tableware and cutlery
Level of soiling:
Common household food rem-
nants lightly dried on
Most economical pro-
gramme:
Pre-Rinse
Cleaning 50°C
Intermediate rinse
Final rinse 63°C
Drying
Silence 50°
Tableware:
Mixed tableware and cutlery
Level of soiling:
Common household food rem-
nants lightly dried on
Reduced noise:
Pre-Rinse
Cleaning 50°C
Intermediate rinse
Final rinse 65°C
Dry
Express 65° - 1h
Tableware:
Mixed tableware and cutlery
Level of soiling:
Common household food rem-
nants lightly dried on
Time-optimised:
Cleaning 65°C
Intermediate rinse
Final rinse 69°C
Dry
Machine Care
Use only if appliance is unloaded. Machine Care 70°C
Favourite
-
"Favourite ", Page17
-
Note: The relatively long running time
in the Eco50° programme is due to
16
Additional functions en
longer soaking and drying times. This
results in optimal consumption val-
ues.
6.1 Information for test insti-
tutes
Test institutes are provided with in-
formation for comparability tests, e.g.
according to EN60436.
These are the conditions for conduct-
ing the tests, however they are not
the results or consumption values.
Request by e-mail to:
The product number (E-Nr.) and the
production number (FD) are required
here. They can be found on the rat-
ing plate on the appliance door.
6.2 Favourite
You can save a combination of a pro-
gramme and an additional function to
the button.
Save the programme via the
HomeConnect app or on the appli-
ance.
The pre-rinse program is saved to
this button at the factory. Pre-rinse is
suitable for all types of tableware.
The tableware undergoes intermedi-
ate cleaning via cold rinsing.
When programmes have been down-
loaded and on delivery of the appli-
ance, the name of the programme
will be displayed in the app. The dis-
play alternately shows "APP" and the
remaining running time.
Tip: You can use the HomeConnect
app to download additional pro-
grammes and save them to the
button.
1
Saving Favourite on the appli-
ance
1.
Press .
2.
Press the right programme button.
3.
Press the button for the relevant
additional function.
4.
Press for 3 seconds.
The selected programme and the
additional function will flash.
flashes.
The programme and the additional
function are saved.
Tip: To reset the programme to the
pre-rinse programme stored at the
factory, use the HomeConnect app
1
or reset your appliance to the factory
settings.
Additional functions7 Additional functions
You can find an overview of the additional functions that can be selected here.
Different additional functions, which can be found on the control panel of your
appliance, are available depending on the appliance configuration. You can se-
lect certain additional functions depending on the programme.
1
Depending on the appliance specifications
17
en Features
Symbol Additional func-
tion
Use
Extra Dry For a better drying result the final rinse tem-
perature is increased and the drying phase
extended.
Especially suitable for drying plastic parts.
There is a slight increase in energy con-
sumption and the running time is extended.
IntensiveZone Switch on with mixed loads containing table-
ware with different soiling levels, e.g. place
very soiled pots and pans in the bottom bas-
ket and normally soiled tableware in the top
basket.
The spray pressure in the bottom basket is
increased and the maximum programme
temperature maintained longer. This will in-
crease the running time and energy con-
sumption.
SpeedPerfect+ The run time is shortened by 15% to 75%
1
depending on the rinse programme.
The additional function can be activated be-
fore the start of the programme and at any
time when the programme is running.
Energy and water consumption are in-
creased.
Features8 Features
You can find an overview of the pos-
sible features of your appliance and
how to use them here.
These features depend on the model
of your appliance.
8.1 Top basket
Arrange cups, glasses and small
items of tableware in the top basket.
1
Depending on the appliance specifications
18
Features en
You can adjust the height of the top
basket to make room for larger items
of tableware.
Adjusting top basket with side
levers
To wash large items of tableware in
the baskets, adjust the shelf position
of the top basket.
1.
Pull out the top basket.
2.
To prevent the basket from sud-
denly dropping down, hold the
side of the basket by the top edge.
3.
Press in the levers on the right and
left on the outside of the basket.
4.
Raise or lower the basket evenly to
the right level.
Check that the basket is level on
both sides.
5.
Release the levers.
The basket clicks into position.
6.
Slide the basket back in.
8.2 Etagere
Use the cutlery shelf and space un-
derneath for small cups and glasses
or for large items of cutlery, e.g.
cooking spoons or serving cutlery.
If you do not need the cutlery shelf,
you can fold it up.
8.3 Bottom basket
Arrange pans and plates in the bot-
tom basket.
Large plates up to a diameter of
31cm can be arranged in the bottom
basket as shown.
19
en Features
8.4 Folding prongs
Use the folding prongs to position
tableware securely, e.g. plates.
You can fold the prongs down to po-
sition pans, bowls and glasses
better.
1
Folding down prongs
1
If you do not need the prongs, fold
them down.
1.
Push the lever forwards and fold
down the prongs .
2.
To use the prongs again, fold them
back up.
The prongs audibly click into posi-
tion.
8.5 Cutlery drawer
Arrange cutlery in the cutlery drawer.
Arrange cutlery with the points and
sharp edges downwards.
Reorganising cutlery drawer
You can fold down the folding spines
to make more space for wider items
of cutlery.
1
Depending on the appliance specifications
20
Before using for the first time en
To fold down the folding spines,
push the lever forwards and fold
down the folding spines .
8.6 Basket heights
Set the baskets at the right height.
Appliance height 81.5cm with cutlery drawer
Level Top basket Bottom basket
1 max. ø 16 cm 30 cm/31 cm
Page19
2 max. ø 18.5 cm 27.5 cm
3 max. ø 21 cm 25 cm
Before using for the first time9 Before using for the
first time
9.1 Performing the initial con-
figuration
On initial start-up or after a reset to
the factory settings, you will need to
make settings.
Tip: Connect your appliance to a mo-
bile device. You can conveniently
change all settings via the
HomeConnect app.
"HomeConnect ", Page33
Requirement: The appliance has
been installed and connected.
Page10
1.
Add special salt.
Page22
2.
Add rinse aid.
Page24
3.
Switch on the appliance.
Page30
4.
Setting the water softening system.
Page22
5.
Set the amount of rinse aid to be
dispensed.
Page25
6.
Add detergent
Page25
.
7.
Start the Programme with the
highest cleaning temperature
without tableware.
Page30
To remove any marks from water
or other residues, we recommend
you operate the appliance without
tableware before using it for the
first time.
Tip: You can change these settings
and other Basic settings
Page31
at any time.
Water softening system10 Water softening sys-
tem
Hard water leaves limescale on the
tableware as well as the washing
tank, and parts of the appliance may
become blocked.
To ensure good dishwashing results,
you can treat the water with special
21
en Water softening system
salt and the water softening system.
To avoid damage to the appliance,
water with a hardness above 9°E
must be softened.
10.1 Overview of water hardness settings
You can find an overview of the water hardness values that can be selected
here.
You can find out how hard your water is from your local water company or by
using a water hardness tester.
Water hardness
°E
Hardness range mmol/l Setting value
0 - 8 Soft 0 - 1.1 H00
9 - 10 Soft 1.2 - 1.4 H01
11 - 12 Medium 1.5 - 1.8 H02
13 - 15 Medium 1.9 - 2.1 H03
16 - 20 Medium 2.2 - 2.9 H04
21 - 26 Hard 3.0 - 3.7 H05
27 - 38 Hard 3.8 - 5.4 H06
39 - 62 Hard 5.5 - 8.9 H07
Note: Set the water hardness determ-
ined on your appliance.
"Setting the water softening sys-
tem", Page22
With a water hardness of 0 - 8°E
you can dispense with special salt for
dishwashers and switch off the water
softening system.
"Switching off the water softening
system", Page23
10.2 Setting the water soften-
ing system
Set the water hardness on your appli-
ance.
1.
Determine the water hardness and
the appropriate setting value.
"Overview of water hardness set-
tings", Page22
2.
Press .
3.
To open the basic settings, press
for 3 seconds.
The display shows Hxx.
The display shows .
4.
Press repeatedly until the right
water hardness has been set.
The value H04 is set at the factory.
5.
To save the settings, press
for 3 seconds.
The water softening system has
been set.
10.3 Special salt
You can use special salt to soften
water.
Adding special salt
If the special salt refill indicator lights
up, add special salt to the dispenser
for special salt just before the pro-
gramme starts. The consumption of
special salt depends on the water
hardness. The higher the water hard-
ness, the greater the consumption of
special salt.
22
Water softening system en
ATTENTION
Detergent may damage the water
softening system.
Only fill the dispenser of the water
softening system with special dish-
washer salt.
Special salt for dishwashers can
damage the tub due to corrosion.
To make sure that any special salt
that escapes is washed out of the
tub, add the special salt to the dis-
penser for special salt immediately
before the programme starts.
1.
Unscrew the lid of the dispenser
for special salt and remove.
2.
On initial start-up: Fill the dispenser
right up with water.
3.
Note: Only use special salt for
dishwashers.
Do not use salt tablets.
Do not use table salt.
Add the special salt to the dis-
penser.
Funnel
1
Fill the dispenser right up with spe-
cial salt. The water in the dis-
penser is displaced and forced
out.
4.
Place the lid back on the dis-
penser and turn to close.
10.4 Switching off the water
softening system
If you find the special salt refill indic-
ator irritating, e.g. when using com-
bined detergents with salt replace-
ment substances, you can switch the
indicator off.
Note
To avoid damage to the appliance,
only switch off the water softening
system in the following cases:
The water hardness is max. 26°E
and you are using a combined de-
tergent with salt replacement sub-
stances. According to the manu-
facturers, combined detergents
with salt replacement substances
can generally only be used up to a
water hardness of 26°E without
adding special salt.
The water hardness is 0 - 8°E.
You do not need to use special
salt.
1.
Press .
2.
To open the basic settings, press
for 3 seconds.
The display shows Hxx.
The display shows .
3.
Press repeatedly until the dis-
play shows H00.
4.
To save the settings, press
for 3 seconds.
The water softening system is
switched off and the salt refill in-
dicator is deactivated.
Note: When switching from com-
bined detergents with salt replace-
ment substances to separate deter-
gents, please make sure to set the
1
Depending on the appliance specifications
23
en Rinse aid system
water softening system to the right
water hardness again.
"Setting the water softening sys-
tem", Page22
10.5 Regeneration of the water
softening system
In order to obtain fault-free function of
the water softening system, the appli-
ance performs regeneration of the
water softening system at regular in-
tervals.
Regeneration of the water softening
system takes place before the end of
the main rinse cycle in all pro-
grammes. It will increase the run time
and consumption values, e.g. water
and electricity.
Overview of consumption values
with regeneration the water
softening system
Here you can find an overview of the
maximum additional running time and
consumption values during regenera-
tion of the water softening system.
Regeneration of the water
softening system after x
washing programmes
6
Additional running time in
minutes
6
Additional water consump-
tion in litres
5
Additional power consump-
tion in kWh
0.05
The consumption values specified
are laboratory measurements determ-
ined in accordance with the currently
applicable standard using the Eco
50° programme and with the factory
value of the water hardness set to 16
- 20°E.
Rinse aid system11 Rinse aid system
11.1 Rinse aid
For optimum drying results, use rinse
aid.
Only use rinse aid for domestic dish-
washers.
Adding rinse aid
If the rinse aid refill indicator lights
up, top up with rinse aid. Only use
rinse aid for domestic dishwashers.
1.
Press the catch on the lid of the
dispenser for rinse aid and lift .
2.
Add rinse aid up to the max mark.
3.
If rinse aid spills out, remove it
from the tub.
Spilled rinse aid can cause ex-
cessive frothing during the wash
cycle.
4.
Close the lid of the dispenser for
rinse aid.
The lid clicks into position.
24
Detergent en
11.2 Setting the amount of
rinse aid
If there are streaks or water marks on
tableware, change the amount of
rinse aid.
1.
Press .
2.
To open the basic settings, press
for 3 seconds.
The display shows Hxx.
The display shows .
3.
repeatedly until the dis-
play shows the value r04 set at the
factory.
4.
Press repeatedly until the right
amount of rinse aid has been set.
– A low setting adds less rinse aid
during the wash cycle and re-
duces streaking on tableware.
– A higher setting adds more
rinse aid during the wash cycle,
reduces water marks and im-
proves the drying result.
5.
To save the settings, press
for 3 seconds.
The amount of rinse aid to be dis-
pensed has been set.
11.3 Switching the rinse aid
system off
If you find the rinse aid refill indicator
irritating, e.g. when using combined
detergents with a rinse aid compon-
ent, you can switch the rinse aid sys-
tem off.
Tip: The function of rinse aid is lim-
ited with combined detergents. You
will generally get better results using
rinse aid.
1.
Press .
2.
To open the basic settings, press
for 3 seconds.
The display shows Hxx.
The display shows .
3.
repeatedly until the dis-
play shows the value r04 set at the
factory.
4.
Press repeatedly until the dis-
play shows r00.
5.
To save the settings, press
for 3 seconds.
The rinse aid system is switched
off and the rinse aid refill indicator
is deactivated.
Note: When switching from com-
bined detergents with a rinse aid
component to separate detergents,
please make sure to set the rinse aid
system to the right amount of rinse
aid again.
"Setting the amount of rinse aid",
Page25
Detergent12 Detergent
12.1 Suitable detergents
Only use detergents that are suitable
for dishwashers. Both separate and
combined detergents are suitable.
For optimum washing and drying res-
ults, use separate detergent, adding
Special salt
Page22
and Rinse aid
Page24
separately.
Modern, powerful detergents mainly
use a low-alkaline formulation with
enzymes. Enzymes break down
starch and remove protein. Oxygen-
based bleaching agents are generally
used to remove coloured marks, e.g.
tea or ketchup.
Note: Follow the manufacturer's in-
structions for each detergent.
Tip: Suitable detergents are available
online via our website or from Cus-
tomer Service
Page46
.
25
en Detergent
Tabs
Tabs are suitable for all cleaning
functions and do not need to be
measured out.
With shorter programmes tabs some-
times do not dissolve entirely and
leave residues of detergent. This may
impair the cleaning effect.
Powder detergent
Powder detergent is recommended
for shorter programmes.
The dosage can be adjusted to the
level of soiling.
Liquid detergent
Liquid detergent works faster and is
recommended for shorter pro-
grammes without PreRinse.
Sometimes liquid detergent may leak
out despite the detergent dispenser
being closed. This is not a fault and
is non-critical if you remember the fol-
lowing:
Only choose a programme without
PreRinse.
Do not select timer programming
for starting the programme.
The dosage can be adjusted to the
level of soiling.
Separate detergents
Separate detergents are products
that do not contain components other
than detergent, e.g. powder deter-
gent or liquid detergent.
With powder and liquid detergent the
dosage can be individually adjusted
to the level of soiling of the table-
ware.
For better washing and drying results
and to avoid damage to the appli-
ance, please additionally use Special
salt
Page22
and Rinse aid
Page24
.
Combined detergent
Besides conventional separate deter-
gents, a number of products are
available with additional functions.
These products contain not only de-
tergent but also rinse aid and salt re-
placement substances (3in1) and,
depending on the combination (4in1,
5in1,...), additional components such
as glass protection or stainless steel
cleaner.
According to the manufacturers,
combined detergents generally only
function up to a water hardness of
26°E. With a water hardness above
26°E you will need to add special
salt and rinse aid. For the best wash-
ing and drying results we recom-
mend using special salt and rinse aid
from a water hardness of 17°E. If
you are using combined detergent,
the washing programme is adjusted
automatically to ensure the best pos-
sible washing and drying result.
12.2 Unsuitable detergents
Do not use detergent which could
cause damage to the appliance or
present a risk to health.
Hand washing-up liquid
Hand washing-up liquid can cause in-
creased frothing and damage the ap-
pliance.
Detergent containing chlorine
Chlorine residue on tableware may
present a risk to health.
12.3 Information on detergents
Follow the instructions on detergents
in everyday use.
Detergents marked as "organic" or
"ecological" (environmentally
friendly) generally contain lower
levels of active agents or com-
26
Detergent en
pletely dispense with certain sub-
stances. The cleaning effect may
be restricted here.
Set the rinse aid and the water
softening system to the separate
detergent or combined detergent
in use.
According to the manufacturers,
combined detergents with salt re-
placement substances can only be
used up to a certain water hard-
ness, usually 26°E, without
adding special salt. For the best
washing and drying results we re-
commend using special salt from a
water hardness of 17°E.
To prevent sticking, only touch de-
tergents in a water-soluble pouch
with dry hands and only ever place
them in a dry detergent dispenser.
Even if the rinse aid and special
salt refill indicators light up, wash-
ing programmes will run properly
with combined detergents.
The function of rinse aid is limited
with combined detergents. You will
generally get better results using a
separate rinse aid.
Use tablets with a special drying
performance.
12.4 Adding detergent
1.
To open the detergent dispenser,
press the locking latch.
2.
Add the detergent to the dry deter-
gent dispenser.
If you are using tablets, one is
enough. Insert the tablets in a hori-
zontal position.
If you are using powder or liquid
detergent, follow the manufac-
turer's instructions and quantities
for dosage in the detergent dis-
penser.
20ml–25ml detergent is suffi-
cient for normal soiling. If table-
ware is only lightly soiled, slightly
less than the amount of detergent
specified is usually sufficient.
3.
Close the lid of the detergent dis-
penser.
The lid clicks into position.
The detergent dispenser will open
automatically at the optimum time
during the programme. Powder or
liquid detergent will spread around
the washing tank and dissolve
there. Tablets will fall into the tab-
let collecting tray and dissolve in
27
en Tableware
the right dosage. In order to en-
sure that tablets can dissolve
evenly, do not place any other ob-
jects in the tablet collecting tray.
Tip: If you use powder detergent and
select a program with pre-rinse, you
can also add a little detergent to the
interior door of the appliance.
Tableware13 Tableware
Only clean tableware that is suitable
for dishwashers.
Note: Decorated glassware and parts
made of aluminium or silver may
fade or discolour with dishwashing.
Delicate types of glass may turn
cloudy after a few washing cycles.
13.1 Damage to glass and tableware
Only put glasses and china in the dishwasher if it is marked as dishwasher-safe
by the manufacturer. Avoid damage to glass and tableware.
Cause Recommendation
The following tableware is not dish-
washer-safe:
Items of cutlery and tableware
made from wood
Decorated glassware, antique and
hand-crafted tableware
Plastic parts not resistant to heat
Tableware made from copper or tin
Tableware soiled with ash, wax, lub-
ricating grease or paint
Very small items of tableware
Only put tableware in the dishwasher if
it is marked as dishwasher-safe by the
manufacturer.
The chemical composition of deter-
gent causes damage.
Use a detergent marked by the manu-
facturer as gentle on tableware.
Highly caustic alkaline or highly acidic
cleaning solutions, in particular com-
mercial or industrial cleaners, are not
safe to use in the dishwasher with alu-
minium.
If you are using highly caustic alkaline
or highly acidic cleaning agents, in par-
ticular commercial or industrial clean-
ing agents, do not put aluminium parts
in the dishwasher interior.
The water temperature of the pro-
gramme is too high.
Select a programme with lower temper-
atures.
After the programme has ended, take
glassware and cutlery out of the appli-
ance without delay.
13.2 Arrange tableware
Arrange tableware correctly to optim-
ise the dishwashing result and pre-
vent damage to both the appliance
and tableware.
Note: Load the baskets so that no
projecting items of tableware interfere
with closing of the door. Projecting
items of tableware may push the ap-
pliance door open during the pro-
gramme, so allowing steam to es-
28
Tableware en
cape and water to leak out around
the door. This could damage your kit-
chen units.
Tips
Using the appliance allows you to
save energy and water compared
to washing-up by hand.
See our website for examples of
how to load your appliance effi-
ciently.
To save energy and water, load
the machine with the number of
place settings specified (standard
load with tableware and cutlery).
"Technical specifications",
Page46
For better washing and drying res-
ults, position items with curves or
recesses at an angle so water can
run off.
1.
Remove large remnants of food
from tableware.
To save resources, do not pre-
rinse tableware under running wa-
ter.
2.
Observe the following when arran-
ging tableware:
– Put heavily soiled tableware in
the bottom basket, e.g. pans.
The more powerful the spray jet,
the better the dishwashing result
will be.
– To prevent damage to table-
ware, arrange it so it is stable
and cannot tip over.
– To prevent injury, arrange cut-
lery with the points and sharp
edges facing down.
– Position containers with the
openings facing down so no wa-
ter can collect in them.
– Do not block the spray arms -
make sure that they can turn
freely.
– Do not place small parts in the
tablet collecting tray and do not
block it with tableware so as not
to obstruct the lid of the deter-
gent dispenser.
13.3 Removing tableware
WARNING
Risk of injury!
Hot tableware can cause burns to the
skin. When hot, tableware is sensitive
29
en Basic operation
to shock, may crack and can result in
injury.
When the programme has ended,
do not empty the appliance until
the tableware has cooled down for
a while.
1.
To prevent water dripping on the
tableware, unload it starting at the
bottom and working up.
2.
Check the washing tank and ac-
cessories for soiling and clean if
necessary.
"Cleaning and servicing",
Page35
Basic operation14 Basic operation
14.1 Switching on the appli-
ance
Press .
The Eco 50° programme is set by
default.
The Eco 50° programme is espe-
cially environmentally friendly and
ideal for normally soiled tableware.
It is the most efficient programme
for the combination of energy/wa-
ter consumption for this type of
tableware and evidences conform-
ity with the EU Ecodesign Direct-
ive.
If you do not perform any actions
on the appliance for 10 minutes,
the appliance will automatically
switch off.
14.2 Setting a programme
To adjust the washing programme to
the soiling level of the tableware, se-
lect a suitable programme.
Requirement: The appliance door is
closed.
Press the right programme button.
The programme is set and the pro-
gramme button flashes.
The remaining running time of the
programme appears on the dis-
play.
14.3 Setting additional func-
tions
You can set additional functions to
complete the washing programme
selected.
Note: The additional functions which
can be used depend on the pro-
gramme selected.
Press the button for the relevant
additional function.
"Additional functions", Page17
The additional function is set and
the additional function button
flashes.
14.4 Setting timer program-
ming
You can delay the start of the pro-
gramme by up to 24hours.
1.
Press .
"h:01" appears in the display.
2.
Use to set the required start
time for the programme.
3.
Press .
This activates timer programming.
Tip: To deactivate timer program-
ming, press repeatedly until "h:00"
appears in the display.
14.5 Starting the programme
Press .
The programme has ended when
the display shows "0h:00m".
Notes
If you want to add more tableware
while the appliance is running, do
not use the tablet collecting tray as
30
Basic settings en
a handle for the top basket. You
might touch the partially dissolved
tablet.
You can only change a pro-
gramme when running if you can-
cel it.
"Terminate programme",
Page31
The appliance switches off auto-
matically 1minute after the end of
the programme to save energy. If
you open the appliance door im-
mediately after the programme has
ended, the appliance will switch off
after 4 seconds.
14.6 Activating button lock
The button lock prevents the appli-
ance from being operated accident-
ally or incorrectly while running.
Press for approx. 3seconds.
The button lock is activated and
will be automatically deactivated at
the end of the programme.
When the appliance is operated,
flashes on the display.
The button lock remains activated
with a power failure.
14.7 Deactivate button lock
Press for approx. 3seconds.
14.8 Interrupting programme
Note: When you open the appliance
door once the appliance has heated
up, leave the door slightly ajar for a
few minutes and then close it. This
will help prevent excess pressure
building up in the appliance and stop
the appliance door bursting open.
1.
Press .
The programme is saved and the
appliance switches off.
2.
Press to resume the pro-
gramme.
14.9 Terminate programme
To end a programme early or to
switch from a programme that has
already started, you will need to can-
cel it first.
Press for approx.
4seconds.
The programme is terminated and
the appliance is reset. All LEDs
light up for approx. 1 minute.
As soon as the LEDs are off, the
display shows "0h:01m" and the
residual water is pumped out.
The programme is cancelled and
ends after approx. 1minute.
14.10 Switching off appliance
1.
Please note the information on
Safe use
Page9
.
2.
Press .
3.
To prevent damage from dripping
water, turn the water tap off tight
(not applicable to appliances with
Aqua-Stop).
Tip: If you press during the wash
cycle, the programme currently run-
ning will be interrupted. When you
switch the appliance back on, the
programme continues automatically.
Basic settings15 Basic settings
You can configure the basic settings
for your appliance to meet your
needs.
15.1 Overview of the basic settings
The basic settings depend on the features of your appliance.
31
en Basic settings
Basic setting Display text Selection Description
Water hardness H04
1
H00 - H07 Set the water softening sys-
tem to your water hardness.
"Setting the water softening
system", Page22
Level H00 switches the water
softening system off.
Rinse aid dis-
pensing
r04
1
r00 - r06 Set the amount of rinse aid to
be dispensed.
Switch the rinse aid system
off with level r00.
Intensive drying d00
1
d00 - d01 The temperature is increased
during the final rinse, which
improves the drying result.
This may increase the run
time slightly.
Note: Not suitable for delicate
items of tableware.
Switch Extra Dry on "d01" or
off "d00".
Hot water A00
1
A00 - A01 Set cold water or hot water
connection. Only set the ap-
pliance to hot water if this
can be prepared with little en-
ergy and a suitable installa-
tion is available, e.g. solar
heating system with circula-
tion line. The water temperat-
ure should be at least 40°C
and max. 60°C.
Switch hot water on "A01" or
off "A00".
Wi-Fi Cn0 Cn0 - Cn1 Switch the wireless network
connection on or off.
Level "Cn0" switches the wire-
less network connection off.
This basic setting is not avail-
able until you have connected
1
Factory setting (may vary according to model)
32
HomeConnect en
Basic setting Display text Selection Description
the appliance with the
HomeConnect app.
"HomeConnect ",
Page33
Remote Start rc1 rc0 - rc2 Activate or deactivate .
"Remote Start ",
Page34
The following settings are
possible:
With the setting "rc0", the
function is permanently de-
activated.
With the setting "rc1", the
function can be selected
via the button.
"Activating Remote Start
", Page34
With the setting "rc2", the
function is permanently ac-
tivated.
This basic setting is not avail-
able until after you have con-
nected the device with the
HomeConnect app.
"HomeConnect ",
Page33
Factory setting rE Start with
YES
Confirm with
Restore changed settings to
the factory settings.
The settings for initial start-up
must be configured.
15.2 Changing basic settings
Tip: Connect your appliance to a mo-
bile device. You can conveniently
change all settings via the
HomeConnect app.
"HomeConnect ", Page33
1.
Press .
2.
To open the basic settings, press
for 3 seconds.
The display shows Hxx.
The display shows .
3.
Press repeatedly until the
display shows the required setting.
4.
Press repeatedly until the dis-
play shows the right value.
You can change several settings.
5.
To save the settings, press
for 3 seconds.
HomeConnect 16 HomeConnect
This appliance is network-capable.
Connect your appliance to a mobile
device to control its functions via the
HomeConnect app.
33
en HomeConnect
The HomeConnect services are not
available in every country. The avail-
ability of the HomeConnect function
depends on the availability of
HomeConnect services in your coun-
try. You can find information about
this at:
www.home-connect.com
.
To be able to use HomeConnect,
you must first set up the connection
to the WLAN home network (Wi-Fi
1
)
and to the HomeConnect app.
The HomeConnect app guides you
through the entire login process. Fol-
low the instructions in the HomeCon-
nect app to configure the settings.
Tip: Please also follow the instruc-
tions in the HomeConnect app.
Note: Please note the safety precau-
tions in this instruction manual and
make sure that they are also ob-
served when operating the appliance
via the HomeConnect app.
"Safety", Page3
16.1 Setting up HomeConnect
Requirements
The appliance is receiving signals
from the WLAN home network (Wi-
Fi) at its installation location.
The appliance door is closed.
1.
Scan the following QR code.
You can install the HomeConnect
app and connect your appliance
via the QR code.
2.
Follow the instructions in the
HomeConnect app.
16.2 Remote Start
You can use the HomeConnect app
to start the appliance with your mo-
bile device.
Tip: If you select "rc2" in the Basic
settings
Page33
of this function,
the function is permanently activated
and you can start your appliance with
a mobile device at any time.
Activating Remote Start
When you have selected "rc1" in the
basic settings of this function, activ-
ate the function on your appliance.
Requirements
The appliance is connected to your
WLAN home network.
The appliance is connected to the
HomeConnect app.
"rc1" is selected in the Basic set-
tings
Page33
of this function.
A programme is selected.
Press .
If you open the appliance door, the
function is automatically deactiv-
ated.
button lights up.
Tip: To deactivate the function, press
.
16.3 Smart Start
2
Smart Start automatically determines
the optimal time for the programme
to start.
You can use the HomeConnect app
to activate or deactivate the function.
1
Wi-Fi is a registered trademark of the Wi-Fi Alliance.
2
Depending on the appliance specifications
34
Cleaning and servicing en
Activating Smart Start
Requirements
Smart Start is activated via the
HomeConnect app.
Preferences for time and energy
are set in the HomeConnect app.
1.
Press .
"EnG" lights up in the display.
The display shows the optimal
start time and the duration of the
selected programme.
2.
Press .
Smart Start is active.
The programme starts as soon as
the optimal time is reached.
Tip: Deactivate the function a single
time by pressing .
16.4 Data protection
Please see the information on data
protection.
The first time your appliance is re-
gistered on a home network connec-
ted to the Internet, your appliance will
transmit the following types of data to
the HomeConnect server (initial re-
gistration):
Unique appliance identification
(consisting of appliance codes as
well as the MAC address of the
Wi-Fi communication module in-
stalled).
Security certificate of the Wi-Fi
communication module (to ensure
a secure data connection).
The current software and hardware
version of your appliance.
Status of any previous reset to
factory settings.
This initial registration prepares the
HomeConnect functions for use and
is only required when you want to
use the HomeConnect functions for
the first time.
Note: Please note that the
HomeConnect functions can only be
utilised with the HomeConnect app.
Information on data protection can be
retrieved in the HomeConnect app.
Cleaning and servicing17 Cleaning and servi-
cing
To keep your appliance working effi-
ciently for a long time, it is important
to clean and maintain it carefully.
17.1 Cleaning the tub
WARNING
Risk of harm to health!
Using detergents containing chlorine
may result in harm to health.
Never use detergents containing
chlorine.
1.
Remove any coarse soiling in the
interior with a damp cloth.
2.
Add detergent to the detergent dis-
penser.
3.
Select the programme with the
highest temperature.
4.
Start the programme without table-
ware.
Page30
17.2 Cleaning products
Only use suitable cleaning products
to clean your appliance.
"Safe use", Page9
17.3 Tips on appliance care
Follow the tips on appliance care to
make sure your appliance functions
properly at all times.
Action Benefit
Wipe the door
seals, the front of
the dishwasher
and the control
This ensures the
parts of the appli-
ance will remain
35
en Cleaning and servicing
Action Benefit
panel regularly
using a damp
cloth and wash-
ing-up liquid.
clean and hy-
gienic.
Action Benefit
If the appliance
is not going to
be used for a
while, leave the
door slightly ajar.
This will prevent
unpleasant
odours.
17.4 Machine Care
Deposits, e.g. from remnants of food and limescale, can cause your appliance
to malfunction. To avoid such faults and reduce odours, we recommend clean-
ing your appliance at regular intervals.
Machine Care combined with machine care products and machine cleaners is
the right programme for the care of your appliance.
Tip: You can get our tested and approved Dishwasher Care and Machine
Cleaner for Dishwashers online at
https://www.bosch-home.com/store
or from
customer service.
Machine Care is a programme which removes various deposits in one washing
cycle. Cleaning takes place in two phases:
Phase Removal of Detergent Placement
1 Grease and limes-
cale
Liquid machine care
product or machine
descaler in powder
form.
Appliance interior, e.g.
bottle hung in the cut-
lery basket or powder
in the interior.
2 Food remnants and
deposits
Machine cleaner Detergent dispenser
To ensure optimum cleaning perform-
ance, the programme doses the de-
tergents independently of each an-
other during the relevant cleaning
phase. Correct placement of the de-
tergents is necessary here.
Run Machine Care without tableware
if the indicator for Machine Care
lights up on the control panel or if ad-
vised to do so by the display. The in-
dicator will go out after you have run
Machine Care. If your appliance does
not have a reminder function, we re-
commend performing Machine Care
every 2months.
Running Machine Care
Notes
Run the Machine Care programme
without any tableware in the dish-
washer.
Only use machine care products
and machine cleaners specially
designed for dishwashers.
Make sure that there are no alu-
minium parts, e.g. extractor hood
grease filters or aluminium pans, in
the interior of the appliance.
If you have not run Machine Care
after 3 washing cycles, the indic-
ator for Machine Care will go out
automatically.
36
Cleaning and servicing en
For optimum cleaning perform-
ance, ensure the correct place-
ment of cleaners.
Follow the safety instructions given
on the packagings of the machine
care products and machine clean-
ers.
1.
Remove any coarse soiling in the
interior with a damp cloth.
2.
Clean the filters.
3.
Place the machine care product in
the appliance interior.
Only use machine care products
specially designed for dishwash-
ers.
4.
Pour the machine cleaner into the
detergent dispenser until it is filled
completely.
Do not place any additional ma-
chine cleaner in the appliance in-
terior.
5.
Press .
6.
Press .
Machine Care is run.
Once the programme has ended,
the indicator for Machine Care
goes out.
17.5 Filter system
The filter system removes coarse
soiling from the dishwashing cycle.
1
2
3
Micro filter
Fine filter
Coarse filter
Cleaning filters
Soiling in the dishwashing water may
block the filters.
1.
After each wash check the filters
for residue.
2.
Turn the coarse filter anticlockwise
and remove the filter system .
Check that no foreign objects
fall into the sump.
3.
Pull down the micro filter to re-
move.
37
en Cleaning and servicing
4.
Press the locking catches to-
gether and lift the coarse filter out
.
5.
Clean the filter elements under run-
ning water.
Carefully clean the rim of dirt
between the coarse and the fine fil-
ter.
6.
Re-assemble the filter system.
Make sure that the locking catches
on the coarse filter click into posi-
tion.
7.
Insert the filter system into the ap-
pliance and turn the coarse filter
clockwise.
Make sure that the arrow mark-
ings match up.
Tip: Connect your appliance to a mo-
bile device. The HomeConnect app
will tell you as soon as you need to
clean the filters.
"HomeConnect ", Page33
17.6 Cleaning spray arms
Limescale and soiling in the dish-
washing water may block the nozzles
and bearings on the spray arms.
Clean the spray arms regularly.
1.
Unscrew the upper spray arms
and pull down to remove .
2.
Pull up the lower spray arm to re-
move.
3.
Check the outlet nozzles on the
spray arms for blockages under
running water and remove any for-
eign objects.
4.
Insert the lower spray arm.
The spray arm clicks into position.
5.
Insert the upper spray arms and
screw firmly in place.
38
Troubleshooting en
Troubleshooting18 Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshoot-
ing information before contacting after-sales service. This will avoid unneces-
sary costs.
Tip: You can find further information and explanations on troubleshooting on-
line by scanning the QR code on the title page and on our website
www.bosch-
home.com
.
WARNING
Risk of electric shock!
Improper repairs are dangerous.
Repairs to the appliance should only be carried out by trained specialist
staff.
Only use genuine spare parts when repairing the appliance.
If the power cord or the appliance power cable of this appliance is damaged,
it must be replaced with a special power cord or special appliance power
cable, which is available from the manufacturer or its Customer Service.
Fault Cause and troubleshooting
Display "Check water
supply" flashes
A technical fault is present.
1.
Press .
2.
Unplug the appliance or switch off the fuse.
3.
Wait at least 2minutes.
4.
Insert the mains plug of the appliance in a socket or
switch on the fuse.
5.
Switch the appliance on.
6.
If the problem occurs again:
Press .
Turn off the water tap.
Pull out the mains plug.
Contact Customer Service
Page46
and give
the error code.
E:30-00 will light up
alternately.
Water protection system is activated.
1.
Turn off the water tap.
2.
Call Customer Service
Page46
.
E:31-00 will light up
alternately.
Water protection system is activated.
1.
Turn off the water tap.
2.
Call Customer Service
Page46
.
E:32-00 will light up
alternately or indicator
for water supply lights
up.
Supply hose is kinked.
Install the inlet hose without kinks.
Water tap is turned off.
Turn on the water tap.
39
en Troubleshooting
Fault Cause and troubleshooting
E:32-00 will light up
alternately or indicator
for water supply lights
up.
Water tap is jammed or furred up.
Turn on the water tap.
The flow rate must be at least 10 l/min when the wa-
ter supply is open.
The filters in the water connection of the supply or
AquaStop hose are blocked.
1.
Switch off the appliance.
2.
Pull out the mains plug.
3.
Turn off the water tap.
4.
Unscrew the water connection.
5.
Remove the filter from the inlet hose
6.
Clean the filter.
7.
Re-insert the filter in the inlet hose.
8.
Screw the water connection back on.
9.
Check the water connection for leaks.
10.
Restore the power supply.
11.
Switch the appliance on.
E:34-00 will light up
alternately.
Water is continuously running into the appliance.
1.
Turn off the water tap.
2.
Call Customer Service
Page46
.
E:61-02 will light up
alternately.
Not an appliance fault. Wastewater pump is blocked or
the cover of the wastewater pump is loose.
1.
Clean the wastewater pump.
"Clean wastewater pump", Page44
2.
Secure the cover of the wastewater pump so it clicks
into position.
"Clean wastewater pump", Page44
40
Troubleshooting en
Fault Cause and troubleshooting
E:61-03 will light up
alternately. Water is
not drained.
Not an appliance fault. Siphon connection is still closed
or the wastewater hose is kinked or blocked.
1.
Check the connection to the siphon and open if ne-
cessary.
2.
Install wastewater hose without kinks.
3.
Remove residues.
Not an appliance fault. Wastewater pump is blocked or
the cover of the wastewater pump is loose.
1.
Clean the wastewater pump.
"Clean wastewater pump", Page44
2.
Secure the cover of the wastewater pump so it clicks
into position.
"Clean wastewater pump", Page44
E:92-40 will light up
alternately.
Filters are soiled or blocked.
Clean the filters.
"Cleaning filters", Page37
All LEDs lit up or
flashing.
A software update is possibly installing.
1.
Wait until the software update has been installed.
This process can take approx. 30minutes.
2.
If the appliance is not ready to use after 30minutes,
perform a reset.
Press the main switch button for approx.
4seconds.
Your appliance is resetting.
41
en Troubleshooting
Fault Cause and troubleshooting
All LEDs lit up or
flashing.
Electronics have detected a fault.
1.
Press the main switch button for approx. 4seconds.
"Controls", Page13
The appliance is reset and restarted.
2.
If the problem occurs again:
Switch off the appliance.
Pull out the mains plug or switch off the fuse in
the fuse box.
Wait at least 2minutes.
Switch on the fuse in the fuse box or insert the
mains plug.
Switch the appliance on.
3.
If the problem occurs again:
Contact customer service.
"Customer Service", Page46
Remnants of food on
tableware.
Tableware is placed too close together or basket is
overfilled.
1.
Arrange tableware with sufficient space in between.
The spray jets must reach the surfaces of the table-
ware.
2.
Avoid points of contact.
Spray arm rotation is blocked.
Arrange tableware so that it does not obstruct spray
arm rotation.
Spray arm nozzles are blocked.
Clean the spray arms.
"Cleaning spray arms", Page38
Filters are soiled.
Clean the filters.
"Cleaning filters", Page37
Filters are inserted incorrectly and/or not engaged.
1.
Insert the filters properly.
"Filter system", Page37
2.
Engage the filters.
42
Troubleshooting en
Fault Cause and troubleshooting
Remnants of food on
tableware.
Washing programme selected too weak.
Select a more intensive washing programme.
"Programmes", Page15
Tableware has been precleaned too intensely. The
sensors chose a weaker programme. Stubborn soiling
cannot be entirely removed.
Only remove large remnants of food and do not
prerinse tableware.
Tall narrow receptacles in corner areas are not rinsed
adequately.
Do not position tall narrow receptacles at too great
an angle or in corner areas.
Top baskets on right and left are not set to same
height.
Set the upper basket on the left and right to the
same height.
"Top basket", Page18
Removable streaks
are present on
glasses, glassware
with a metallic appear-
ance and cutlery.
Amount of rinse aid to be dispensed is set too high.
Set the rinse aid system to a lower setting.
"Setting the amount of rinse aid", Page25
No rinse aid has been added.
Add rinse aid.
"Adding rinse aid", Page24
Detergent residue is present in the final rinse. Lid of the
detergent dispenser is blocked by tableware items and
will not open fully.
1.
Arrange tableware in the top basket tableware so
the tab collecting tray is not obstructed by tableware.
"Arrange tableware", Page28
Items of tableware are blocking the dispenser lid.
2.
Do not place tableware or fragrance dispensers in
the tablet collecting tray.
Tableware has been precleaned too intensely. The
sensors chose a weaker programme. Stubborn soiling
cannot be entirely removed.
Only remove large remnants of food and do not
prerinse tableware.
Rust spots on cutlery. Cutlery is not sufficiently rust-resistant. Knife blades are
often more severely affected.
Use rust-resistant tableware.
43
en Troubleshooting
Fault Cause and troubleshooting
Rust spots on cutlery. Cutlery may also rust if washed together with rusting
items.
Do not wash rusting items.
Salt content in washing water is too high.
1.
Remove any spilled special salt from the tub.
2.
Screw the cap of the special salt dispenser on tight.
Detergent residue is
present in the deter-
gent dispenser or the
tablet collecting tray.
Spray arms were blocked by tableware so detergent
was not rinsed out.
Check that the spray arms are not blocked and can
rotate freely.
Detergent dispenser was damp when detergent was
added.
Only add detergent to a detergent dispenser when
dry.
Special salt refill indic-
ator lights up.
Insufficient special salt.
Add Special salt
Page22
.
Sensor does not detect special salt tablets.
Do not use special salt tablets.
18.1 Clean wastewater pump
Large remnants of food or foreign
bodies can block the waste water
pump. As soon as the rinsing water
no longer drains properly, the waste
water pump must be cleaned.
WARNING
Risk of injury!
Sharp and pointed objects or frag-
ments of glass may block the waste
water pump and cause injury.
Remove any foreign bodies care-
fully.
1.
Disconnect the appliance from the
mains.
2.
Remove the top and bottom bas-
ket.
3.
Remove the filter system.
4.
Scoop out any water.
Use a sponge if necessary.
5.
Prise off the pump cover using a
spoon and grip it by the
crosspiece.
6.
Lift the pump cover inwards at an
angle and remove.
You can now reach the impeller
with your hand.
7.
Remove any remnants of food and
foreign bodies in the area of the
impeller.
44
Transportation, storage and disposal en
8.
Insert the pump cover and press
down .
The pump cover clicks into posi-
tion.
9.
Install the filter system.
10.
Insert the top and bottom basket.
11.
Connect the appliance to the
mains.
Transportation, storage and disposal19 Transportation, stor-
age and disposal
19.1 Removing the appliance
1.
Disconnect the appliance from the
mains power supply.
2.
Turn off the water tap.
3.
Detach the drainage connection.
4.
Detach the drinking water connec-
tion.
5.
Loosen any screws fastening the
appliance to cabinet parts.
6.
Remove the base panel if fitted.
7.
Pull the appliance out carefully,
along with the hose behind it.
19.2 Protect appliance from
frost
If there is a risk of frost where the ap-
pliance will be standing, e.g. in a holi-
day home, empty the appliance com-
pletely.
Empty the appliance.
"Transporting the appliance",
Page45
19.3 Transporting the appli-
ance
To avoid damage to the appliance,
empty it before transporting.
Note: Always transport the appliance
upright to prevent residual water get-
ting into the machine's controls and
damaging the appliance.
1.
Remove tableware from the appli-
ance.
2.
Secure loose parts.
3.
Turn on the water tap.
4.
Switch on the appliance.
Page30
5.
Select the programme with the
highest temperature.
"Programmes", Page15
6.
Start the programme.
Page30
7.
To drain the appliance, terminate
the programme after approx.
4minutes.
"Terminate programme",
Page31
8.
Switch off the appliance.
Page31
9.
Turn off the tap.
10.
To empty the residual water out of
the appliance, detach the supply
hose and let the water drain out.
19.4 Disposing of old appli-
ance
Valuable raw materials can be re-
used by recycling.
WARNING
Risk of harm to health!
Children can lock themselves in the
appliance, thereby putting their lives
at risk.
With redundant appliances, unplug
the power cord. Then cut through
the cord and damage the lock on
the appliance door beyond repair
45
en Customer Service
so that the appliance door will no
longer close.
1.
Unplug the appliance from the
mains.
2.
Cut through the power cord.
3.
Dispose of the appliance in an en-
vironmentally friendly manner.
Information about current disposal
methods are available from your
specialist dealer or local authority.
This appliance is labelled
in accordance with
European Directive
2012/19/EU concerning
used electrical and elec-
tronic appliances (waste
electrical and electronic
equipment - WEEE).
The guideline determines
the framework for the re-
turn and recycling of
used appliances as ap-
plicable throughout the
EU.
Customer Service20 Customer Service
Function-relevant genuine spare parts
according to the corresponding Eco-
design Order can be obtained from
Customer Service for a period of at
least 10 years from the date on
which your appliance was placed on
the market within the European Eco-
nomic Area.
Note: Under the terms of the manu-
facturer's warranty the use of Cus-
tomer Service is free of charge.
Detailed information about the war-
ranty period and the warranty condi-
tions in your country is available via
the QR code on the enclosed docu-
ment on service contacts and war-
ranty conditions, from our customer
service or on our website.
If you contact Customer Service, you
will require the product number (E-
Nr.), the production number (FD) and
the consecutive numbering (Z-Nr.) of
your appliance.
You can find the contact details for
our customer service via the QR
code on the enclosed document on
service contacts and warranty condi-
tions or on our website.
20.1 Product number (E-Nr.),
production number (FD)
and consecutive number-
ing (Z-Nr.)
You can find the product number (E-
Nr.), the production number (FD) and
the consecutive numbering (Z-Nr.) on
the appliance's rating plate.
The rating plate is located inside the
appliance door.
"Familiarising yourself with your ap-
pliance", Page12
Make a note of your appliance's de-
tails and the Customer Service tele-
phone number to find them again
quickly.
Technical specifications21 Technical specifications
Weight Max.: 45kg
Voltage 220 - 240V, 50Hz or 60Hz
Power rating 2000 - 2400W
Fuse 10-16A
46
Declaration of Conformity en
Water pressure min. 50kPa (0.5bar)
max. 1000kPa (10bar)
Inlet rate Min. 10l/min
Water temperature Cold water.
Hot water max.: 60°C
Capacity 10place settings
More information about your model
can be found online at
https://
eprel.ec.europa.eu/qr/2365304
1
.
This web address is linked to the offi-
cial EU EPREL product database.
21.1 Information regarding
Free and Open Source
Software
This product includes software com-
ponents that are licensed by the
copyright holders as free or open
source software.
The applicable licence information is
stored on your home appliance. You
can also access the applicable li-
cence information via your
HomeConnect app: "Profile -> Legal
information -> Licence Information".
2
You can download the licence in-
formation on the brand product web-
site. (Please search on the product
website for your appliance model
and additional documents). Alternat-
ively, you can request the relevant in-
formation from oss-
[email protected] or BSH Hausger-
äte GmbH, Carl-Wery-Str. 34, 81739
Munich, Germany.
The source code will be made avail-
able to you on request.
Please send your request to oss-
[email protected] or BSH Hausger-
äte GmbH, Carl-Wery-Str.34, 81739
Munich, Germany.
Subject: „OSSREQUEST“
The cost of performing your request
will be charged to you. This offer is
valid for three years from the date of
purchase or at least as long as we
offer support and spare parts for the
relevant appliance.
Declaration of Conformity22 Declaration of Conformity
BSH Hausgeräte GmbH hereby declares that the appliance with Home Connect
functionality conforms to the essential requirements and other relevant provi-
sions of Directive 2014/53/EU.
A detailed RED Declaration of Conformity can be found online at
www.bosch-
home.com
among the additional documents on the product page for your ap-
pliance.
1
Only applies to countries in the European Economic Area
2
Depending on the appliance specifications
47
en Declaration of Conformity
Hereby, BSH Hausgeräte GmbH declares that the appliance with HomeCon-
nect functionality is in compliance with relevant statutory requirements.
1
A detailed Declaration of Conformity can be found online at
www.bosch-
home.co.uk
among the additional documents on the product page for your
appliance.
1
2.4 GHz band (2400–2483.5MHz): Max. 100mW
5-GHz band (5150–5350MHz + 5470–5725MHz): max. 180mW
BE BG CZ DK DE EE IE EL ES
FR HR IT CY LI LV LT LU HU
MT NL AT PL PT RO SI SK FI
SE NO CH TR IS UK (NI)
5GHz WLAN (Wi-Fi): For indoor use only.
AL BA MD ME MK RS UK UA
5GHz WLAN (Wi-Fi): For indoor use only.
22.1 Statement of Compliance
for Great Britain
The full Statement of Compliance ac-
cording to the Product Security and
Telecommunications Infrastructure
(Security Requirements for Relevant
Connectable Products) Regulations
2023 can be found online at
www.bosch-home.co.uk among the
additional documents on the product
page for your appliance.
Product type
This statement of compliance covers
the products described in this inform-
ation for use whose model identifier
group is seen on the title page. The
full model identifier is made up of the
characters before the slash in the
product number (E no.) which can be
found on the rating plate. Alternat-
ively, you can also find the model
identifier in the first line of the UK En-
ergy Label.
Name and address of manufacturer
BSH Hausgeräte GmbH, Carl-Wery-
Strasse 34, 81739 München, Ger-
many
This statement of compliance is pre-
pared by the manufacturer.
The manufacturer, BSH Hausgeräte
GmbH deems that it has complied
with
provision 5.1-1 of ETSI EN 303
645 v2.1.1 and, where relevant,
provision 5.1-2 of ETSI EN 303
645 v2.1.1;
provision 5.2-1 of ETSI EN 303
645 v2.1.1;
provision 5.3-13 of ETSI EN 303
645 v2.1.1.
Support period
BSH Hausgeräte GmbH will provide
security updates that are necessary
1
Only applies to Great Britain
48
Declaration of Conformity en
to maintain the main functions free of
charge until at least 28/02/2034.
49
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service
directory.
BSH Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München, GERMANY
www.bosch-home.com
A Bosch Company
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
*9002020228*
9002020228 (050605) 442 V1
en
