RF3621CTD99 / RF3621CTD00
8
9
Installation
Handle installation
Scheme of installation of
cold storage door handle
Inner socket head cap
screw for handle fixing
Bolt
Bolt
Inner socket head cap
screw for handle fixing
Chilling chamber
door handle
Assembly Instructions of Cold Storage Door
Handle:
1. Take the handle set bolts out from the
refrigerator, use cross recessed
screwdriver to set the bolt on the door.
Fix it tight with all the screw thread
twisted through the hole, as shown in
the figure;
2. After the first step is completed, take
the Cold storage door handle out from
the box, place it as per direction shown
in the figure (Note: i.e. the direction
which both screw holes on the handle
are close to the edge), and hang the
handle above the set bolt;
3. Use the small hexagon spanner supplied
in the box to set the handle fixing
socket head cap screws into both the
small screwed holes on the handle.
After they are screwed down, gently
shake the handle to test if the handles
are well erected.
The assembly steps of the refrigeration door
handle are same as the cold storage door
handle. Please note, the direction of tapping
holds are downward to the ground when
assemble the refrigerator.
Assembly Instructions of The Refrigeration
Door Handle:
10
