C1, C2, C4 Home Bar Chiller User Manual
To ensure safe operation, please read this user manual thoroughly before use.
© Husky International. Husky International reserve the right to change specifications at any
time without notice. Images used are for illustration only. Stock not included.
Welcome to your new Husky
2
Thank you for buying this Husky chiller. It has been designed and manufactured for
many years of trouble-free service.
Operation is very simple, but please take a few minutes to read this user manual. It
contains important safety information, and tips to ensure you receive the best
possible service from your Husky unit.
CONTENTS
Important Notes ..................................................................................................................... 3
Safety instructions and warnings ..................................................................................... 3
Before using for the first time ..........................................................................................4
Operating Instructions ......................................................................................................5
Illustration ...........................................................................................................................6
Replacing LED lights .........................................................................................................7
Installing shelves ................................................................................................................7
Cleaning ..............................................................................................................................7
Circuit diagrams .................................................................................................................8
Troubleshooting .....................................................................................................................9
Warranty card and service conditions ..............................................................................10
All models
Important Notes
WARNING: RISK OF ELECTRICAL SHOCK HAZARD
If the power cable is damaged, it must be replaced by a qualified engineer to avoid
shock hazard. DO NOT ATTEMPT TO SERVICE THE ITEM YOURSELF. Ensure that
the unit is properly earthed. Stop using the chiller immediately if electric shock is
felt when touching the cabinet.
DISPOSAL OF OLD CHILLERS
BE SURE TO MAKE ANY LOCKS UNUSABLE. IF POSSIBLE, REMOVE THE
DOOR(S) AND DISCARD SEPARATELY.
WARNING – CHEMICAL HAZARD: DO NOT ALLOW CHILDREN TO PLAY WITH
OLD CHILLERS. CONTACT YOUR LOCAL AUTHORITY FOR PROPER DISPOSAL
PROCEDURES.
Before disposing of an old chiller, please make sure it is switched off and safe.
Unplug the chiller and break any locks in order to avoid children becoming trapped.
Please note: the chiller system contains gases and refrigerants which require
specialist waste disposal. The valuable materials contained in a chiller can be
recycled.
Contact your local waste disposal depot for proper disposal of an old chiller and
contact your local authority or dealer if you have any questions.
Ensure the pipework of your chiller is not damaged prior to disposal. You can
contribute to the environmental awareness by insisting on an appropriate non-
polluting method of disposal.
WEEE COMPLIANCE
Husky units are authorised to carry the CE (Conformité
Européene) and WEEE (Waste Electrical and Electronic
Equipment Directive) symbols.
The WEEE symbol on this unit indicates that the
product must not be disposed of with household
waste. To help prevent possible harm to health and the environment, the product
must be disposed of by recycling methods authorised as environmentally safe. For
more information on how to dispose of this product appropriately, contact your
dealer or the recycling department at your local authority.
Husky units and their components undergo strict product testing by independent
companies to comply or exceed all applicable local and international regulatory
standards.
SAFETY INSTRUCTIONS & WARNINGS
Before switching on your Husky unit, read the information in this user manual
carefully. The user manual contains important observa tions relating to the assembly,
operation and maintenance of the unit.
Please keep this user manual in a safe place for future reference. If you ever sell this
unit, hand this user manual to the new owner.
The manufacturer does not accept responsibility for any damages that may arise
due to non-observation of these instructions.
3
4
• Do not use the unit if it is damaged. If you are in any doubt, consult an
engineer.
• Connection and installation of your Husky unit are to be carried out in strict
compliance with the relative instructions in this user manual.
• Make sure there is a suitable power outlet (230 volts, 13 amps outlet) with
proper grounding to power the unit.
• For safety, the unit must be properly earthed in accordance with
specifications.
• Always remember to unplug the unit before cleaning. Never unplug this unit
by pulling on the power cable. Always grip plug firmly and pull straight out
from the socket.
• All electrical repairs must be carried out by a qualified engineer. Inadequate
repairs may be dangerous.
• Do not damage any parts of the unit which carry refrigerant by piercing,
perforating, crushing, twisting or scraping. If refrigerant comes into contact
with the eyes it may cause serious eye injury.
• Do not obstruct or cover the ventilation grille.
• Do not allow children to play with the unit, or to sit on it.
• This unit is not intended for use by persons (including children) with reduced
physical, sensory or mental capabil ities, or lack of experience and
knowledge, unless they have been given supervision or instruction
concerning use of the unit by a person responsible for their safety.
BEFORE USING FOR THE FIRST TIME
IMPORTANT: Before switching the unit on, we recommend you allow it to
stand upright for 8 hours. Failure to do this may result in damage to the unit.
• To ensure correct operation, it is important that the unit is level. The cabinet
may be leveled by turning either or both of the adjustable feet in the front
corners. Use a spirit level to check.
• Before operation, we recommend that the cabinet is cleaned for reasons of
hygiene and to remove any residue left from manufacture.
• For good circulation, vents must not be blocked. Keep a minimum of 100mm
of clear space around the chiller. Your Husky unit should be placed on flat
and firm surface for quieter operation.
• Do not expose the unit to direct sunlight or a heat source such as ovens,
radiators, heaters, etc.
• Do not under any circumstances place heated food or beverages in your
Husky unit.
• Do not open the door more often than necessary to lessen the escape of
cold air.
• For better air circulation, do not overfill the unit.
• Adjust the thermostat according to the amount of product and the ambient
temperature.
IMPORTANT: This appliance is intended to operate in a climate where the
maximum temperature is 25 degrees Celsius and the humidity do not exceed 60%.
5
Operating Instructions
TO OPERATE THE THERMOSTAT
The controller is positioned on the inside back wall of the appliance.
The settings 0 (MIN) – 7 (MAX) regulate the interior temperature.
Setting 0 (or MIN) = lowest setting (warmest internal temperature)
Setting 7 (or MAX) = highest setting (coldest internal temperature).
INTERIOR LIGHT
The interior light may be switched on or off using the rocker switch inside of the
cabinet.
DEFROSTING
The surface of the evaporator ices up when the appliance is working normally. It can
also occur when the door has been left open or the thermostat has been set too
high. If the frost layer is more than 3mm/1⁄8” thick, the appliance must be defrosted
and cleaned to avoid unnecessary energy consumption and inefficient operation.
1. Remove all items inside and unplug the appliance.
2. After defrosting, clean the appliance (see instructions above) and allow it
to dry.
6
Access can be obtained
to the compressor room
at the rear of the unit.
WARNING: Parts maybe hot. Ensure the unit is unplugged
at the mains before accesssing.
7
REPLACING LED LIGHTS
1. Disconnect the chiller from the power supply.
2. Remove the light cover, pull out the wires and remove the LED lights.
3. Install the new LED lights, connect the wires, and replace the light cover.
4. Reconnect the chiller to the power supply.
INSTALLING SHELVES
Fit the shelf clips to the ladder racks and install the shelves horizontally. Ensure the
clips are located firmly and the shelves are secure before loading the chiller.
EASY MAINTENANCE ACCESS
Switch the unit off and disconnect from the mains supply. To access the compressor
compartment, simply remove the screws securing the rear access panel. Any
repairs or maintenance, other than CLEANING (see below) must be carried out by
QUALIFIED ENGINEERS ONLY.
CLEANING
If the condenser coil is not cleaned quarterly, the energy efficiency of the appliance
will decrease significantly and it will reduce the life of the appliance. Switch the unit
off and disconnect from the mains supply. Use a vacuum cleaner fitted with a soft
brush attachment to remove dust carefully from the condenser, the components
and grilles .
The external and internal surfaces of the unit should be cleaned regularly. Switch
the unit off and disconnect from the mains supply. Clean the external and internal
surfaces of the unit with a mild soap solution, then wipe dry. Do NOT use cleansers
containing chlorine or other harsh cleansing agents, as these can damage the
stainless steel surfaces and components. Use mild soapy water to clean the gasket
and seals.
GETTING SERVICE ASSISTANCE
The cooling system is a hermetically sealed circuit and does not require any
maintenance other than regular cleaning (see ‘Cleaning’).
If the unit fails to work, first check the power supply. If you cannot locate the reason
for the failure, please contact your supplier, stating the model and serial number of
the cabinet. You may find this information on the rating plate, which is affixed inside
the unit on the top right-hand interior wall.
8
Circuit Diagrams
C1 Home Bar
C2 Home Bar
C4 Home Bar
9
Troubleshooting
Before calling Technical Support, please check the following points; you may be
able to solve any problem yourself.
Problem
The chiller does not
work properly.
The chiller’s internal
temperature is too
high or too low.
The chiller is noisy in
operation or makes
unusual noises.
• Note: It is normal to
hear some noises as
refrigerant flows
through the
compressor.
Outer surfaces are
wet
Inner surfaces are
wet
Possible Cause
The chiller is not plugged in.
The plug and/or the power cable
are faulty.
The fuse has blown.
The chiller is faulty.
The wrong temperature is
selected.
The factory default settings for
the controller are incorrect.
The condenser is blocked by an
accumulation of dust.
The doors are not fully closed.
The chiller is close to a heat
source or the ambient
temperature is too high.
The ventilation grille is blocked.
The chiller is not on a level, firm
surface, or the unit may be
touching other items.
The chiller is vibrating against a
neighbouring object.
Chiller may be close to a water
source or leak.
The door may be opened too
often or kept open too long.
Action
Connect the plug to the
power supply
Call your supplier or a
qualified engineer.
Replace the fuse with one
of the same rating.
Call your supplier or a
qualified engineer.
Check the controller and
adjust the set temperature.
Call your supplier or a
qualified engineer.
Clean using a vacuum
cleaner and soft brush
attachment (see p8)
Check the unit is level and
the seals are not damaged.
Move the chiller to a better
location and check it is out
of direct sunlight.
Move the chiller to improve
free movement of air.
Check location and
position using a spirit level.
Relocate the chiller or the
object.
Dry surfaces thoroughly
and move the chiller.
Try to minimise opening of
the doors for better
cooling performance.
10
WARRANTY CARD & SERVICE CONDITIONS
Distributed by
Thank-you for choosing Husky Refrigeration, and we hope you enjoy your new appliance for many
years to come.
Please read your user manual carefully to ensure proper installation, working operation and
maintenance of your new product.
REGISTRATION
To ensure we provide you with the highest grade of support we strongly recommend you register your
product. Please use one of the following methods to register and have your purchase receipt, model
number and serial number details ready:
a) Please visit https://huskybrand.com.au/ and click on the Service & Support tab to register your
product whilst also gaining access to other Husky services/support documents.
b) Please contact us on the appropriate Arisit Service Hotline outlined on the bottom of this page to
register over the phone with one of our friendly customer service staff.
NOTICE TO AUSTRALIAN CONSUMERS
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You
are entitled to a replacement or refund for a major failure and compensation for any other reasonably
foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not amount to a major failure.
NOTICE TO NEW ZEALAND CONSUMERS
Our goods come with guarantees that cannot be excluded under the Consumer Guarantees Act 1993.
This warranty should not be construed as any attempt to contract out of or exclude any or the guarantees
available to any consumers under this Act provided that you agree that the provisions of the Consumer
Guarantees Act 1993 will not apply if you are acquiring the goods for the purpose of a business.
HOW TO MAKE A CLAIM
In the unfortunate event you do need to make a claim please follow the process below to ensure service is
initiated to you as quickly as possible for a resolution:
Step 1: Please ensure you have checked that all product settings are set according to the user manual to
ensure the product is operating as intended
Step 2: Please have your purchase receipt, model number and serial number ready. If you have already
pre-registered your serial number details will only be required.
Should you need to make a claim the responsibility of proof of ownership of the equipment is on
you. If a service/claim is initiated and the fault is found to be an exclusion of the warranty terms
and conditions you will be subject to a No Fault Found charge plus Administration Fee as advised
by the Customer Service Staff upon making a claim.
Step 3: Please contact the appropriate Arisit Service Hotline outlined below based on your place of
residence:
Arisit Service Hotline (AUSTRALIA) PH: 1300 762 219
Arisit Service Hotline (NEW ZEALAND) PH: 9306 1020
https://huskybrand.com.au/
AUSTRALIA
Arisit Pty Ltd (AUS)
40-44 Mark Anthony Drive
Dandenong South, Victoria 3175
Email: arisit.warranti[email protected]
NEW ZEALAND
Arisit Pty Ltd (NZ)
1A Howe Street
Newton, Auckland 1145
Email: [email protected]
Warranty card for Arisit 260718 PRINT.indd 1 02/08/2018 08:39
11
06.08.25
www.husky-international.com
Welcome to Husky, the home of smart refrigeration. We are a
leading global refrigeration specialist with over 25 years
experience in commercial refrigeration for convenience and
hospitality professionals. Whatever your requirements, we’re
sure to have a good looking energy-efficient model that’s
perfect for you.
AUSTRALIA
Arisit Pty Ltd (AUS)
40-44 Mark Anthony Drive
Dandenong South, Victoria 3175
Email: [email protected]
