MILWAUKEE TOOL
l
www.milwaukeetool.com
13135 W. LISBON RD., BROOKFIELD, WI 53005
Drwg. 1
SERVICE PARTS LIST
BULLETIN NO.
PN0013331
SPECIFY CATALOG NO. AND SERIAL NO. WHEN ORDERING PARTS
REVISED BULLETIN
DATE
Jan. 2026
Rechargeable Flat Flashlight w/ Green Laser
WIRING INSTRUCTION
CATALOG NO. 2016R SERIAL NO. S01A
NAMEPLATE SPECIFICATIONS: INPUT:5 V 1A Contains 6.475 Wh Li-Ion
CAN ICES-3(B)/NMB-3(B)
FIG. NOTES
3, 5 A clean, dry surface is essential for proper performance for
any adhesive system. The area intended for application of any
adhesive label or nameplate must be prepared by cleaning with
isopropyl alcohol. The solvent is to be applied with a clean, lint
free applicator and the surface allowed to dry before applying
the label or nameplate.
1
2
3
4
5
1
2
6
FIG. 5 Place the warning labels as shown from the 10-22-2020
warning label replacement sheet over the area where the
existing warning symbols may have worn off. See notes below
for pre-application instructions. (Label sheet may have extra
icons that won't be applicable and can be discarded.)
FIG. PART NO. DESCRIPTION OF PART NO. REQ.
1 --------------- M3.5 x 4mm Screw (1)
2 --------------- Belt Clip (1)
3 12-20-2019 Service Nameplate (1)
4 42-44-1211 USB-C to USB-C 2' Cable (Optional) (1)
5 10-22-2020 Warning Label Replacement Sheet (1)
(see instructions above)
6 14-46-9119 Belt Clip Kit (1)
SCREW TORQUE SPECIFICATIONS
FIG. PART NO. WHERE USED
SEAT TORQUE
kgf-cm lb-in
1 --------------- Belt Clip 5-7 4-6
