1. Compliance
These safety goggles have been designed to comply with PPE Regulation (EU)
2016/45 ,directive EN1632-1:2022 and essential Health and Safety
Requirements through a risk assessment for its intended use.
2. Specication
2.1 Product
Stock No. 29578
Part No. SG
Model No JG101
Frame markings 16321 JI D 1-M CE
Lens markings JI 1 D CE
Head form 1 - M (EU Medium)
Ocular material PC (thickness 1.9mm)
Impact protection ‘D’ (80m/s)
Applicable standard EN1632-1:2022
EU-type CE approved DIN CERTO
EN
29578
Version 3
June 2025
GOGGLES
SAFETY
2.2 General
Marking Meaning
Supplier logo
EN 16321 The European standard number for Personal Eye Protection Specications
1 Optical class
2.3 Fields of Use Symbols
Code Protection Field of use
None Basic Unspecied mechanical hazards and hazards arising
from ultraviolet, visible, infrared and solar radiation
3 Liquids Liquids (droplets or splashes)
4 Large dust particles Dust with a particle size of >5µm
5 Gas and ne dust particles Gases, vapours, sprays, smoke and dust with
a particle size of <5µm
6 Liquids Stream of liquid
7 Heat Radiant heat
9 Molten metal and hot solids Splashes of molten metal and penetration of hot solids
2.4 ImpactProtection
Code Protection Parameters
C Basic impact level Ø6mm / 45m/s Orbital protection zone (OPZ)
D Medium impact level
Ø6mm / 80m/s Extended orbital protection zone
(EOZ)
E High Impact level Ø6mm / 120m/s Face protection zone (FPZ)
CT
Impact level C (45m/s) at extreme
temperatures
-5°C / +55°C
DT
Impact level D (80m/s) at extreme
temperatures
-5°C / +55°C
ET
Impact level E (120m/s) at extreme
temperatures
-5°C / +55°C
3. HealthandSafetyInstructions
3.1 GeneralSafetyInstructions
• Always check with your supervisor or safety ocer to conrm that the protection
oered by these goggles is adequate for your work environment.
• Draper Tools recommends that these goggles are not worn over prescription
frames as impact energy may be transmitted to the prescription frame and
create a hazard for the wearer.
• Googles that have been subject to impact shall not be used and shall be
discarded and replaced.
• The material used in the product has been deemed hypo-allergenic; however,
susceptible persons may still experience some allergic reactions.
− The user should check for any such reaction and stop using the product
if any reaction occurs.
• Draper Tools recommends that these goggles are kept in a protective bag
or box when not in use.
• The lifetime/obsolescence of this product is no more than two years.
3.2 SafetyWarnings
• If the symbols C, D,E are not present on both the lens and frame then the lower
grade applies to the complete product.
• Check the goggles regularly for scratching, pitting or any other damage to the
lens as this can seriously reduce the impact protection provided by the product.
− Discard and replace damaged products immediately.
4. PackagingRequirementsforTransportation
These goggles must be transported in their original packaging. If there is no
packaging, use packaging that protects the product from shock, thermal hazards
and exposure to moisture and light, and protects it from any product or material
or substance that may cause it to deteriorate.
When not in use and during transportation, store the goggles in a cool, dry place
away from light and frost, and where no chemicals or sharp objects may fall and
damage it. Also ensure that the goggles will not be crushed.
5. StorageInstructions
Store these goggles at ambient temperatures between 5–40°C, RH 90% and
keep them away from solvents, solvent vapours and any corrosive materials as
these may seriously reduce the impact protection provided by the goggles.
6. CleaningInstructions
Clean these goggles using soap and warm water. Though the lens is hard-coated
to provide a degree of scratch resistance, they are not scratch-proof. Keep wiping
of the lens to a minimum and use a soft, non-abrasive cloth.
7. NotiedBodies
DINCERTCO
Gesellschaft für
Konformitätsbewertung mbH
Alboinstraße 56
12103 BERLIN
GERMANY
NotiedBodynumber:0196
Draper Tools Limited
Hursley Road, Chandler’s Ford,
Eastleigh, Hampshire, SO53 1YF. UK
Delta International BV
Oude Graaf 8, 6002 NL,
Weert, The Netherlands
Website: drapertools.com
Email: [email protected]
Product Helpline: +44 (0) 23 8049 4344
Telephone Sales Desk: +44 (0) 23 8049 4333
General Enquiries: +44 (0) 23 8026 6355
© Published by Draper Tools Limited
Please visit drapertools.com/manuals for the latest version for this manual.
