QUICK USER GUIDE
V9
CORDLESS VACUUM CLEANER
ATTENTION: Please read all of the instructions carefully before using
this product.
1.Please do not use the vacuum cleaner to suck the detergent, kerosene, glass slag, needles,
soot, wet dust, water, sewage, matches and other items.
2.Please do not use a vacuum cleaner to suck up small particles such as cement, gypsum
powder, wall powder, or large objects such as toy paper balls, otherwise it will cause the
vacuum cleaner to block and the motor to burn out.
3.Please do not let the vacuum cleaner close to fire sources and other hot places.
4.When using the vacuum cleaner, please pay attention to install the filter assembly and
ground brush brush.
5.Please do not dump water or other liquid into the machine to cause short circuit to burn
the machine.
6.When using a new battery or the battery used for the first time after long-term storage,
please fully charge the battery. When storing and not using the machine for a long time,
please ensure that it is charged and discharged at least once every three months.
7.When your vacuum cleaner is fully charged and needs cleaning or maintenance, please
unplug the power adapter in time, and do not pull the cord of the power adapter.
8.When cleaning the vacuum cleaner, use a dry cloth to wipe it can, do not use gasoline,
banana water and other easy to make the shell crack or fade the cleaner.
9.Please do not use or store the vacuum cleaner in high temperature, low temperature and
other adverse conditions, it is recommended at the ambient temperature (0-40°C) for
indoor use in a cool and dry place without long sunlight exposure.
10.Do not allow the children to use or play with this machine.
11.When this machine is fully charged and cannot work, it must test and repair at the
designated maintenance point.Please do not disassemble the machine without permis-
sion.
12.Before discarding the appliance, the battery must be removed from the appliance. When
removing the battery, the appliance must be powered off.
13.Discarded battery packs should be recycled and disposed of safely, and please do not
discard them randomly.
14.If the cord of the power adapter is damaged, in order to avoid danger, you must go to
the manufacturer's local maintenance department or similar department to replace it.
IMPORTANT SAFETY WARNING
SAVE THESE INSTRUCHTIONS
Do not use near open
flames
Do not store near heat
sources
Do not pick up water or
liquids
Do not use near open
flames
Do not put hands near the brush
bar when the machine is in use
Do not place on or
near the cooker
EN
1. Know Your Product
Floor Brush Head
Roller
LED Light
Electrically Brush The
Lock
Long Crevice
Nozzle
Sofa Brush
Wall Mount
(Screws included*3,
expansion tube*3)
Conductive Tube
Removal Button
Dust Cup Bottom
Release Button
Dust Cup
Display Screen
Switch
Battery Pack
Battery Release Button
Aromatherapy Cap
Dust Cup Release
Button
Telescopic Tube
EN
Hose
2. Charging
Extra HEPA Filter&
Sponge Filter
Mini Cleaning
Brush
Charger
Aromatherapy
Tablets
EN
Suction Adjustment Button
Blockage Tips
Power is Divided into 3 levels
AUTO Mode
Battery High-temperature Icon
Wrong Charger Icon
Battery Icon
Ground Brush Blocked
Turn off the power before charging
Charging Method
Please fully charged the battery before use.
Please ensure that it is charged and discharged at least once every three months.
Be sure to use the charger included in the box, other chargers may damage the
battery.
Connect the main body to charge
①
Hang on the wall mount to charge
②
3. Assembling
Install the Battery Pack
Aromatherapy tablet replacement
Assembling Cleaning Accessories
Install Wall Mount
Charge the battery directly
③
Red light flashing (Charging)
Battery indicator light
EN
4. Operating
Power Button
Select Cleaning Mode
Abnormal Indicator
Four modes: Touch “ ” and starts at low/eco suction. Touch again to switch
modes, ECO-MID-MAX-AUTO in sequence.
AUTO mode: The AUTO light is on, and the vacuum cleaner automatically changes
the suction power according to the garbage sucked.
Wrong charger. (Current>1.2A, Voltage>39V) Please use the original charger.
Battery temperature indicator. If the temperature is too high, please wait
until it drops before using it. The device cannot be turned on at low
temperatures. (<10°C)
Press the switch button to turn it on and again to turn it off. It is not necessary to
press all the time!
ECO MID MAX AUTO
EN
5. Cleaning
Clean the Main Body
Empty the Dust Cup
Turn off the power before cleaning the body.
Please use a neutral detergent, wipe the body with a half-wet cloth.
Press the dust empty button to empty the dust.
When using, if the garbage in the dust cup exceeds MAX line, please empty it in
time.
Icon flashes, floor brush is blocked. Clean the hair on the roller brush or
replace it, then restart the machine.
Icon flashes, the dust cup or pipe is blocked. Clear the dust cup, filter, or
vacuum cleaner air inlet blockage, and then start the vacuum cleaner again.
The battery icon is flashing. The battery is low, please charge the battery.
EN
Changing and Cleaning the Dust Cup Filter
In order to achieve the best performance, empty the dust cup container and clean
the dust cup filter after each use.
Remove the dust cup by pressing and holding the dust cup release buttons on the
left and right sides of the cup.
Rotate and pull out the dust cup filter
Empty the dust from the dust cup container
Rinse the dust cup filter in cold water
NOTE:Assemble it when totally dry.
EN
6. Maintenance
Clean the Brush Roller
Take out the roller brush.
The brush side used to clean metal mesh, inlet filter;
The knife side used to remove the tangled hairs from brush roller.
Install the roller brush.
Please clean your vacuum cleaner regularly to prolong its life.
It is recommended that the floor brush be cleaned regularly to keep it in effective
use and maintain suction power.
It is recommended to change the HEPA filter every 2 months to ensure excellent
performance. Do not use the filter when it is damaged or worn out.
Only the original charger can be used in the machine.
NOTE:You can clean it with or without water. Please remember to use the roller
after it is completely dry.
EN
7. Troubleshooting
8. Warranty
If there is any problem or malfunction during use, please send your
question and order number to our email.
(Format of order number: 000-0000000-0000000)
We will provide you a good after-sales service within 24 hours.
Email: support@fieety.com
EN
VACUUM WILL
NOT OPERATE
No power in electrical
outlet
1. Dust cup container is full
2. Dust cup filter is not
installed correctly
Puncture/hole is dust
VACUUM WILL
NOT PICK-UP OR
SUCTION
POWER IS WEAK
1.Check fuse or breaker
2.Replace fuse/reset breaker
1.Empty dust cup container
2.Remove dust cup filter and
check for object(s) in air duct
and remove
3.Clean or replace dust cup
filter
4.Charge unit
1.Empty dust cup container
2.Review dust cup filter
installation instructions
DUST ESCAPING
FROM VACUUM
http://www.fieety.com/pages/manuals
Scan and Download the Full
Version of User Manual
