Technical Specification__Audience 52
Technical Specification__Audience 52
Sensitivity (2.83 V/1 m): 86 dB
Recommended Amp. Power: Small size rooms: >25 watts
Medium size rooms: >65 watts
Large size rooms: -- watts
IEC Long Term Power Handling: 150 watts
Impedance, Nominal: 4 ohms
Impedance, (20-200 Hz): 3.7 - 11 ohms
Impedance, (200-20 kHz): 3.7 - 9.6 ohms
Impedance, Phase Shift (20-200 Hz): -32° - +31°
Impedance, Phase Shift (200-20 kHz): -11° - +29°
Impedance, HF (200 kHz): 5.8 ohms
Frequency Response (+/- 3 dB): 52 Hz - 24 kHz
Resonance Frequency: 47 Hz
Internal Cabinet Volume: 10 litres
Bass Principle: Bass reflex
Weight: 6.9 kg
Dimensions (W x H x L): 204 x 330 x 256 mm
Crossover: 2 way.
The crossover is impedance corrected
Crossover Frequencies: 2700 Hz
Crossover Slope: Woofer 6 dB/oct; Tweeter 12 dB/oct
Connection: CE compliant insulated gold binding posts
Recommended Placing: Stand
Remarks: Tweeter: 28 mm soft dome.
Magnetic fluid.
Pure aluminium wire voice coil.
Rear chamber.
Woofer: 17 cm polypropylene cone.
75 mm pure aluminium wire voice coil.
Cabinet: Front baffle 19 mm MDF.
Port plugs included.
Bitumen damped enclosure.
