Liebherr CBNBSD 576I Premium Fridge-Freezer BioFresh User Manual

User Guide

Quality, Design and Innovation

home.liebherr.com/fridge-manuals

Contents

1 The appliance at a glance..................................... 3

1.1 Delivered contents....................................................... 3

1.2 Appliance and equipment overview.......................... 3

1.3 SmartDevice.................................................................. 3

1.4 Range of appliance use............................................... 4

1.5 Conformity..................................................................... 4

1.6 SVHC substances according to REACH regulation. 4

1.7 EPREL Database........................................................... 4

2 General safety instructions.................................. 5

3 Start-up................................................................. 6

3.1 Turning on the appliance............................................ 6

3.2 Insert the equipment................................................... 6

3.3 Putting InfinitySpring into operation*...................... 6

4 Food management................................................. 7

4.1 Storing food.................................................................. 7

4.2 Storage times............................................................... 8

5 Energy saving........................................................ 9

6 Use......................................................................... 9

6.1 Controls and displays.................................................. 9

6.1.1 Status display..............................................................9

6.1.2 Navigation....................................................................9

6.1.3 Display symbols........................................................ 10

6.2 Operating logic............................................................. 10

6.2.1 Activating/deactivating settings...........................10

6.2.2 Selecting function value..........................................10

6.2.3 Activating/deactivating settings...........................10

6.2.4 Selecting the setting value......................................11

6.2.5 Calling up the customer menu................................ 11

6.3 Functions....................................................................... 11

Turn off appliance..................................................... 11

WiFi............................................................................. 11

Temperature...............................................................12

Temperature unit.......................................................13

BioFresh B-Value*.................................................... 13

D-Value....................................................................... 13

SuperCool................................................................... 13

VarioTemp.................................................................. 13

SuperFrost.................................................................13

PartyMode.................................................................. 13

HolidayMode.............................................................. 14

SabbathMode............................................................14

EnergySaver...............................................................14

HydroBreeze*.............................................................15

IceMaker / MaxIce*................................................. 15

Ice cubes*...................................................................16

TubeClean*.................................................................16

CleaningMode............................................................16

Display brightness.................................................... 16

Door alarm..................................................................16

Entry lock....................................................................16

Language.................................................................... 17

Info...............................................................................17

Reminder.....................................................................17

Reset............................................................................17

6.4 Error messages............................................................. 17

6.4.1 Warnings.....................................................................17

6.4.2 Message..................................................................... 18

6.4.3 DemoMode................................................................. 18

7 Equipment............................................................. 18

7.1 Door racks..................................................................... 18

7.2 Split shelf...................................................................... 19

7.3 VarioSafe....................................................................... 19

7.4 InfinitySpring*.............................................................. 20

7.5 Variable bottle shelf.................................................... 20

7.6 Drawers.......................................................................... 20

7.7 Fruit & Vegetable-Safe cover..................................... 21

7.8 Humidity control........................................................... 21

7.9 HydroBreeze*................................................................ 22

7.10 Glass shelves................................................................ 22

7.11 EasyTwist-Ice*.............................................................. 23

7.12 VarioSpace.................................................................... 23

7.13 Butter dish.................................................................... 24

7.14 Egg rack......................................................................... 24

7.15 Bottle rack..................................................................... 24

7.16 FlexSystem*.................................................................. 24

7.17 Freezer packs................................................................ 25

7.18 Ice cube tray with lid*................................................. 25

7.19 Flexible ice compartment divider*............................ 26

8 Maintenance.......................................................... 26

8.1 FreshAir carbon filter................................................... 26

8.2 Water tank*................................................................... 26

8.3 Water filter*.................................................................. 27

8.4 Disassembling / assembling pull-out systems...... 27

8.5 Defrosting the appliance............................................ 28

8.6 Cleaning the appliance............................................... 28

9 Customer support................................................. 30

9.1 Technical specifications............................................. 30

9.2 Operating noises.......................................................... 31

9.3 Technical faults............................................................ 31

9.4 Customer service......................................................... 33

9.5 Rating plate................................................................... 33

10 Decommissioning.................................................. 33

11 Disposal................................................................. 33

11.1 Preparing appliance for disposal.............................. 33

11.2 Disposing of the appliance in an environmentally

friendly manner............................................................ 33

The manufacturer is constantly working to improve all types

and models. Therefore, please be aware that we reserve the

2 * Depending on model and options

right to make changes to the shape, equipment and tech‐

nology.

Symbol Explanation

Read instructions

Please read the information in these instruc‐

tions carefully to understand all of the benefits

of your new appliance.

Full instructions on the internet

You can find detailed instructions on the

internet using the QR code on the front of

these instruction or by entering the service

number at home.liebherr.com/fridge-

manuals.

The service number can be found on the serial

tag:

Fig. Example illustration

Check appliance

Check all parts for transport damage. If you

have any complaints, please contact your

agent or customer service.

Differences

These instructions apply to a range of models,

so there may be differences. Sections that

apply to certain models only are indicated by

an asterisk (*).

Instructions and results

Instructions are marked with a .

Results are marked with a .

Videos

Videos about the appliances are available on

the YouTube channel of Liebherr-Hausgeräte.

These operating instructions apply to:

CBN (st) (bs) (be) (sd) (c) (d)

57..(i) / 77..(i)

Note

If your appliance has an N in its appliance designation, it is

a NoFrost appliance.

1 The appliance at a glance

1.1 Delivered contents

Check all parts for damage during transport. If you have any

complaints, please contact the dealer or Customer Service

(see 9.4 Customer service) .

Delivery contains the following parts:

Standalone appliance

Equipment (depending on your model)

Installation parts (depending on your model)

“Quick Start Guide”

“Installation Guide”

Service brochure

1.2 Appliance and equipment overview

Fig. 1 Example illustration

Temperature range

(A)

Fridge compartment (C) Freezing compartment

(B) BioFresh (D) Coldest zone

Equipment

(1)

Display in the door (13) Storage rack

(2) Fan with FreshAir acti‐

vated charcoal filter

(14) VarioBox

(3) Split shelf (15) Bottle holder

(4) VarioSafe (16) Bottle rack

(5) HydroBreeze* (17) Freezer drawer

(6) Lid for Fruit & Vege‐

table-Safe

(18) VarioSpace

(7) Variable bottle shelf (19) Drain hole

(8) Fruit & Vegetable-Safe (20) Serial tag

(9) Meat & Dairy-Safe/

Fisch & Seafood-Safe*

(21) Cold storage accumula‐

tors

(10) EasyTwist-Ice* (22) Ice cube scoop* / ice

cube tray*

(11) Egg tray (23) IceMaker*

(12) Butter dish (24) InfinitySpring*

Note

The shelves, drawers, and baskets are arranged for

optimal energy efficiency in the factory configuration.

However, changes to the arrangement within the given

insertion options – for example the arrangement of

shelves in the fridge compartment – have no effect on

energy consumption.

1.3 SmartDevice

SmartDevice is the networking solution for your fridge-

freezer.

The appliance at a glance

* Depending on model and options 3

If your appliance is SmartDevice-enabled or compatible, you

can quickly and easily connect your appliance to your WiFi.

With the SmartDevice app, you can operate your appliance

from a mobile device. Additional functions and setting

options are available in the SmartDevice app.

SmartDevice-

enabled appli‐

ance:*

Your appliance is equipped with the

SmartDeviceBox. In order to connect

your appliance to the WiFi, you need

to download the SmartDevice app.*

SmartDevice-

compatible appli‐

ance:*

Your appliance is compatible for use

with the SmartDeviceBox. You must

first purchase and install the Smart‐

DeviceBox. In order to connect your

appliance to the WiFi, you need to

download the SmartDevice app.*

More information

about SmartDe‐

vice:

smartdevice.liebherr.com

Purchase the

SmartDeviceBox in

the Liebherr-

Hausgeräte store:*

home.liebherr.com/shop/de/deu/

smartdevicebox.html*

Downloading the

SmartDevice app:

After installing and configuring the

SmartDevice app, you can connect

your appliance to the WiFi using the

SmartDevice app and the WiFi appli‐

ance function (see WiFi) .

Note

You cannot use the SmartDeviceBox in the following coun‐

tries: Russia, Belarus, Kazakhstan. The SmartDevice func‐

tion is not available.

1.4 Range of appliance use

Normal use

The appliance is only suitable for cooling food

for residential or other similar environments.

This includes the following types of uses

in staff kitchens, bed and breakfasts,

by guests in country homes, hotels, motels

and other types of accommodations,

for catering and similar wholesale services.

The appliance is not suitable as a built-in

unit;

All other types of uses are not permitted.

Foreseeable misuse

The following uses are specifically prohibited:

Storage and cooling of medication, blood

plasma, laboratory preparations or similar

substances and products in accordance

with the Medical Device Directive

2007/47/EC

Use in areas at risk of explosion

Incorrect appliance use can cause damage to

the stored products or cause them to spoil.

Climate ratings

The appliance is set to operate within

specific ambient temperature limits

according to its climate rating The climate

rating for your appliance is printed on the

rating plate

Note

To guarantee trouble-free operation,

comply with the indicated ambient temper‐

atures.

Climate rating for ambient temperatures from

SN 10 °C to 32 °C

N 16 °C to 32 °C

ST 16 °C to 38 °C

T 16 °C to 43 °C

SN-ST 10 °C to 38 °C

SN-T 10 °C to 43 °C

1.5 Conformity

The refrigerant circuit has been tested for leaks. The appli‐

ance complies with the applicable safety regulations and

with the corresponding directives.

For the EU

market:*

The appliance complies with directive

2014/53/EU.*

For the GB

market:*

The appliance complies with the Radio

Equipment Regulations 2017 SI 2017

No. 1206.*

The full text of the EU Declaration of Conformity is available

on the following website: www.Liebherr.com

The BioFresh compartment meets the requirements of a

cold storage compartment as set out in DIN EN 62552:2020.

1.6 SVHC substances according to

REACH regulation

You can check whether your appliance contains SVHC

substances according to REACH regulation at the following

link: home.liebherr.com/de/deu/de/liebherr-erleben/nach‐

haltigkeit/umwelt/scip/scip.html

1.7 EPREL Database

Details about energy labeling and ecodesign requirements

will be available on the European product database (EPREL)

from March 1, 2021. You can access the product database at

the following link: https://eprel.ec.europa.eu/ You will be

asked to enter the model ID. You can find the model ID on

the type plate.

The appliance at a glance

4 * Depending on model and options

2 General safety instructions

Please keep these operating instructions in a

safe place so you can refer back to them at

any time.

If you pass the appliance on, please hand

these operating instructions to the new

owner.

Read these operating instructions before use

in order to use the appliance safely and

correctly. Follow the instructions, safety

instructions and warning messages included

at all times. They are important for ensuring

you can operate and install the appliance

safely and without any problems.

Dangers for the user:

This appliance can be operated by children

as well as by persons with reduced phys‐

ical, sensory or mental capabilities or lack

of experience and knowledge if they are

supervised or have been instructed in the

safe use of the appliance and understand

the associated risks. Children must not play

with the appliance. Cleaning and user

maintenance must not be performed by

children unless they are supervised. Chil‐

dren between the ages of 3 and 8 may load

and unload the appliance. Children under

the age of 3 must be kept away from the

appliance if they are not constantly super‐

vised.

The socket must be easily accessible so

that the appliance can be disconnected

quickly from the electricity in an emer‐

gency. It must not be located in the area

behind the appliance.

When disconnecting the appliance from the

outlet, always take hold of the plug. Do not

pull on the cable.

Disconnect the power plug or switch off

the power if a fault occurs.

Do not damage the mains power line. Do

not operate the appliance from a defective

mains power line.

Repairs and work on the appliance may

only be carried out by after sales service or

other specifically trained qualified

personnel.

The appliance should only be assembled,

connected and disposed of in accordance

with the instructions.

The manufacturer is not liable for damage

arising from incorrect connection to the

water supply.*

Risk of fire:

The refrigerant contained within the appli‐

ance (specifications on the rating plate) is

environmentally friendly, but flammable.

Leaking refrigerant can ignite.

•

Do not damage the pipes of the refrig‐

erant circuit.

•

Do not handle ignition sources inside the

appliance.

•

Do not use electrical devices inside the

appliance (e.g. steam cleaners, heaters,

ice cream makers, etc.).

•

If refrigerant leaks: Remove naked flames

or ignition sources located near the area

of the leak. Air the room well. Contact the

customer service department.

Do not store explosive materials or spray

cans with flammable propellants, such as

e.g. butane, propane, pentane, etc. in the

appliance. You can recognize such spray

cans by the printed contents or a flame

symbol. Any leaking gasses can be ignited

by electrical components.

Keep lit candles, lamps and other objects

with naked flames away from the appliance

so they do not cause a fire.

Alcoholic beverages or other containers

holding alcohol must always be tightly

sealed for storage purposes. Any leaking

alcohol can be ignited by electrical compo‐

nents

Tipover hazard:

Do not stand or climb on the base, drawers,

doors, etc. This applies in particular to chil‐

dren.

Risk of food poisoning:

Do not consume food that has passed its

best before date.

Danger of frostbite, feelings of numbness

and pain:

Avoid prolonged skin contact with cold

surfaces or chilled/frozen food or take

protective measures, e.g. wear gloves.

Risk of injury and damage:

Hot steam may lead to injuries. Do not use

any electrical heating or steam cleaning

equipment, naked flames or defrosting

sprays for defrosting

Do not remove ice with sharp objects

Risk of crushing:

Do not reach into the hinge when opening

and closing the door. Fingers may get

trapped.

Symbols on the device:

General safety instructions

* Depending on model and options 5

The symbol can be on the compressor. It

refers to the oil in the compressor and

refers to the following danger: Can be

lethal if swallowed or inhaled. This notice

only applies for recycling. There is no

danger during normal operation.

The symbol is located on the compressor

and indicates the danger of inflammable

materials. Do not remove the label.

This label or a similar one may be located

on the rear of the appliance. This label indi‐

cates that there are vacuum insulation

panels (VIP) or perlite panels in the door

and/or housing. This notice only applies for

recycling. Do not remove the label.

Observe the warning messages and other

detailed information in the other sections:

DANGER

indicates a hazardous situation,

which if not avoided, will result in

death or serious injury.

WARNING indicates a hazardous situation,

which if not avoided, could result

in death or serious injury.

CAUTION indicates a hazardous situation,

which if not avoided, will result in

minor or moderate injury.

NOTICE indicates a hazardous situation,

which if not avoided, could result

in damage to property.

Note indicates useful advice and tips.

3 Start-up

3.1 Turning on the appliance

Make sure that the following requirements are met:

Appliance is set up and connected according to installa‐

tion instructions.

All adhesive strips, adhesive and protective films, as well

as transport safety devices in and on the appliance are

removed.

All advertising material has been removed from the

drawers.

Fig. 2

Switch on the appliance using the display.

Fig. 3

Select the language.

The status display appears.

The appliance starts in DemoMode:

If the appliance starts in DemoMode, you can deactivate

DemoMode within the next 5 minutes.

Fig. 4

Press DemoMode for 3 seconds.

DemoMode is deactivated.

Note

The manufacturer recommends:

Place the food inside: Wait for around 6 hours until the

set temperature is reached.

Store frozen foods at -18 °C or colder.

3.2 Insert the equipment

Note

Accessories can be purchased from the Liebherr-Hausg‐

eräte store at home.liebherr.com/shop/de/deu/

zubehor.html.

Insert the supplied equipment to help you make the most

of the appliance.

3.3 Putting InfinitySpring into opera‐

tion*

If your appliance is equipped with an InfinitySpring, before

the first use you must bleed the water system for the Infini‐

tySpring and clean the InfinitySpring.

Make sure that the following requirements are fulfilled:

The water supply is connected. See the Installation Guide

or installation instructions.

The water tank is fitted. See the Installation Guide or

installation instructions.

The water filter is fitted. See the Installation Guide or

installation instructions.*

Appliance is fully connected.

3.3.1 Vent the water system

Open the appliance door.

Start-up

6 * Depending on model and options

Push a glass against the lower part of the InfinitySpring

dispenser.

The upper part moves out and air escapes or water flows

into the glass.

Continue until the water flows evenly into the glass.

The water system is now bled.

3.3.2 Cleaning the InfinitySpring

(see 8.6.4 Cleaning the InfinitySpring*)

4 Food management

4.1 Storing food

WARNING

Danger of fire

Do not use electrical appliances inside the food storage

compartments of the appliance, unless they are of the

type recommended by the manufacturer.

Note

Insufficient ventilation results in an increase in energy

consumption and reduction of the refrigerating performance

Always keep the air slots unobstructed.

When storing food, remember these basic rules:

Do not obstruct the air vents on the back wall.

Do not obstruct the air vents on the fan.

Food is well sealed.

Food that easily absorbs or emits odor or taste, are in

sealed containers or are covered.

Raw meat or fish is in clean, sealed containers so that

other food cannot be touched or drip on them.

Liquids are in sealed containers.

Food is stored spaced apart to ensure good air circula‐

tion.

Note

Failure to follow these guidelines can lead to food perishing.

4.1.1 Fridge

The natural air circulation means the temperature varies in

different sections.

Arranging the food:

In the top section and in the door: butter and cheese,

preserves, and tubes.

The coldest zone Fig. 1 (D) is for: easily perishable food

such as prepared meals.

4.1.2 BioFresh

BioFresh allows some fresh food to be stored longer

compared to conventional cooling.

Food with a “use by” date must still be consumed by the

date indicated on the package

Note

If the temperatures drop below 0 °C foods may freeze to

each other.

Store cold-sensitive vegetables such as cucumbers,

aubergines, zucchini, and cold-sensitive tropical fruit, in

the refrigerator compartment.

Fruit & Vegetable-Safe

This provides a fresh storage climate with the lid closed. A

moist climate is suitable for storing unsealed food with a

high moisture content (e.g. salad, vegetables, fruit).

The humidity depends on the moisture content of the stored

items and how frequently the door is opened. You can regu‐

late the moisture.

Arranging the food:

Place unsealed fruit and vegetables.

Excessive moisture: Regulate the air humidity

(see 7.8 Humidity control) .

Meat & Dairy-Safe

The DrySafe provides a relatively dry storage environment. A

dry climate is suitable for dry or sealed food (e.g. dairy prod‐

ucts, meat, fish, sausage).*

The DrySafe provides a relatively dry storage environment. A

dry climate is suitable for dry or sealed food (e.g. dairy prod‐

ucts, meat, sausage).*

Arranging the food:

Place dry or sealed food.

Fish & Seafood-Safe *

A relatively dry storage climate is set here. This climate is

suitable for dry or packaged foods (e.g. dairy products,

meat, fish, seafood, sausage).

A Fish & Seafood tray that can be moved or removed is

included in the compartment.

The temperature can be adjusted via the display in the

control panel. Dividing the compartment into different

temperature zones is only possible when the tray is

inserted. (see Temperature)

The following temperature combinations are possible:

Fig. 5

Arranging the food:

Fig. 6

Position Fish & Seafood tray. The position shown gives

you an optimal cooling function (see Fig. 6) .

Zone -2 °C: Place fresh seafood or fish.

Zone 0 °C: Store dairy products or packaged meat.

Note

You can achieve the highest level of energy efficiency using

the temperature combination 0 °C / 0 °C.

Energy consumption is slightly higher using the temperature

combination -2 °C / 0 C° and -2 °C / -2 °C.

4.1.3 Freezer

This provides a dry, frosty storage climate at -18 °C. A frosty

climate is suitable for storing frozen food and goods for

several months, preparing ice cubes, or freezing fresh food.

Food management

* Depending on model and options 7

Freezing food

You can freeze as many kilograms of fresh food within 24

hours as indicated on the nameplate (see 9.5 Rating plate)

under "freezing capacity ... kg/24h".

To ensure that the food freezes quickly to the core, keep to

the following quantities per pack:

Fruit, vegetables up to 1 kg

Meat up to 2.5 kg

Before freezing, please note the following:

SuperFrost is activated (see 6.3 Functions) when the

amount of food to freeze exceeds approx. 2 kg.

With a small amount of frozen goods: SuperFrost is acti‐

vated approx. 6 hours prior.

With the maximum amount of frozen goods: SuperFrost is

activated approx. 24 hours prior.

Arranging the food:

CAUTION

There is a risk of injury from pieces of broken glass!

Bottles and cans containing drinks can split or crack when

frozen. This applies in particular to carbonated drinks.

The BottleTimer function must be used when freezing

bottles and cans with drinks.

With a small amount of frozen goods:

Place packaged groceries in the top drawer.

If possible, place groceries at the back of the drawer near

the rear wall.

With the maximum amount of frozen goods:

Distribute packaged groceries across all drawers, but do

not place any groceries in the lowest drawer.

If possible, place groceries at the back of the drawer near

the rear wall.

With the maximum amount of frozen goods:

Once SuperFrost deactivates automatically, place food

into the drawer.

Defrosting food

- in the fridge compartment

- in the microwave

- in the oven/fan oven

- at room temperature

WARNING

Danger of food poisoning!

Do not re-freeze defrosted food.

Use defrosted foodstuff as quickly as possible.

Remove only the food you need for now.

Use defrosted food as quickly as possible

4.2 Storage times

The storage times given are guidelines

Food with a “use by” date must still be consumed by the

date indicated on the package

4.2.1 Fridge

The best-before date stated on the packaging applies.

4.2.2 BioFresh

Guideline storage times for the Meat & Dairy-Safe

Butter at 1 °C up to 90 days

Hard cheese at 1 °C up to 110 days

Guideline storage times for the Meat & Dairy-Safe

Milk at 1 °C up to 12 days

Sausage, cold cuts at 1 °C up to 8 days

Poultry at 1 °C up to 6 days

Pork at 1 °C up to 6 days

Beef at 1 °C up to 6 days

Game at 1 °C up to 6 days

Note

Note that higher-protein foods spoil more quickly So,

shellfish and crustaceans perish faster than fish, and fish

perishes faster than meat.

Guideline storage times for the Fruit & Vegetable-Safe

Vegetables, lettuce

Artichokes at 1 °C up to 14 days

Celery at 1 °C up to 28 days

Cauliflower at 1 °C up to 21 days

Broccoli at 1 °C up to 13 days

Endives at 1 °C up to 27 days

Mâche at 1 °C up to 19 days

Peas at 1 °C up to 14 days

Kale at 1 °C up to 14 days

Carrots at 1 °C up to 80 days

Garlic at 1 °C up to 160 days

Cabbage turnip at 1 °C up to 14 days

Iceberg lettuce at 1 °C up to 13 days

Herbs at 1 °C up to 13 days

Leeks at 1 °C up to 29 days

Mushrooms at 1 °C up to 7 days

Radishes at 1 °C up to 10 days

Brussels sprouts at 1 °C up to 20 days

Asparagus at 1 °C up to 18 days

Spinach at 1 °C up to 13 days

Savoy cabbage at 1 °C up to 20 days

Fruit

Apricots at 1 °C up to 13 days

Apples at 1 °C up to 80 days

Pears at 1 °C up to 55 days

Blackberries at 1 °C up to 3 days

Dates at 1 °C up to 180 days

Strawberries at 1 °C up to 7 days

Figs at 1 °C up to 7 days

Blueberries at 1 °C up to 9 days

Raspberries at 1 °C up to 3 days

Red currants at 1 °C up to 7 days

Cherries, sweet at 1 °C up to 14 days

Kiwi at 1 °C up to 80 days

Food management

8 * Depending on model and options

Guideline storage times for the Fruit & Vegetable-Safe

Peaches at 1 °C up to 13 days

Plums at 1 °C up to 20 days

Cranberries at 1 °C up to 60 days

Rhubarb at 1 °C up to 13 days

Gooseberries at 1 °C up to 13 days

Grapes at 1 °C up to 29 days

Guideline storage times for the Fish & Seafood-Safe*

Seafood

Crab at -2 °C up to 4 days

Mussels at -2 °C up to 6 days

Sushi at -2 °C up to 4 days

Fish at -2 °C up to 4 days

4.2.3 Freezer

Guidelines for storage periods for various foods

Ice cream at -18 °C 2 to 6 months

Sausage, ham at -18 °C 2 to 3 months

Bread, bakery prod‐

ucts

at -18 °C 2 to 6 months

Game, pork at -18 °C 6 to 9 months

Fish, fatty at -18 °C 2 to 6 months

Fish, lean at -18 °C 6 to 8 months

Cheese at -18 °C 2 to 6 months

Poultry, beef at -18 °C 6 to 12 months

Vegetables, fruit at -18 °C 6 to 12 months

5 Energy saving

Always ensure good ventilation. Do not obstruct ventila‐

tion openings or grilles.

Never block air slits in the fan.

Do not install the appliance in direct sunlight or next to a

stove, heater or similar heat source.

Energy consumption depends on installation conditions

such as the ambient temperature (see 1.4 Range of appli‐

ance use) . A warmer ambient temperature can increase

the energy consumption.

Avoid opening the appliance door for any longer then

necessary

The lower the temperature is set the higher the energy

consumption.

Sort your food items: home.liebherr.com/food.

All food stored in the appliance should be well wrapped

and covered. This prevents frost buildup.

Only take food out for as long as necessary so that it

does not get too warm.

Insertion of warm foods: first let the food cool down to

room temperature.

Defrost frozen food in the fridge

For longer periods of absence, use HolidayMode (see

HolidayMode) .

6 Use

6.1 Controls and displays

The display gives you a quick overview of the temperature

setting and the status of functions and settings. Select or

adjust functions by activating/deactivating or selecting a

value.

6.1.1 Status display

Fig. 7

(1)

Fridge compartment

temperature display*

(3) Freezer compartment

temperature display*

(2) BioFresh temperature

display

(Fish & SeaFood-Safe)*

Fig. 8

(1)

Fridge compartment

temperature display*

(3) Freezer compartment

temperature display*

(2) Temperature display

BioFresh*

The Status display shows the set temperatures and is the

home display. From there, you can navigate to the options

and settings.

6.1.2 Navigation

Navigate in the menu to access the individual functions. An

audible signal sounds after confirming a function or setting.

If no selection is made after 10 seconds, the display

switches to the Status display.

Navigation

Description

Press briefly

Activate/deactivate function.

Confirm selection.

Open submenu.

Long press (3 seconds)

Activate/deactivate function.

Increasing/decreasing bar appears in

the display.

Confirm selection.

Reset appliance/values.

Switch appliance on/off.

Energy saving

* Depending on model and options 9

Navigation Description

Swipe

Navigating in the menu.

Search for values.

Briefly press "Back" symbol

Display goes back one level.

No action for 10

seconds

Display switches to the Status display.

6.1.3 Display symbols

The display symbols provide information about the current

appliance status.

Symbol

Appliance status

Standby

The appliance or temperature zone

is turned off.

Flashing number

Appliance is working. Temperature

flashes until the set temperature is

reached.

Flashing symbol

Appliance is working. Setting is

made.

6.2 Operating logic

6.2.1 Activating/deactivating settings

You can activate/deactivate the following functions:

Symbol

Function

SuperCool

SuperFrost

IceMaker and MaxIce

PartyMode

HolidayMode

EnergySaver

Symbol Function

HydroBreeze*

VarioTemp

When function is on, the appliance works harder. This

means appliance noise when operating may be louder for a

short while, and more energy will be consumed.

Swipe left in the display until the function appears.

Confirm selected function with a short tap.

You hear the confirmation tone.

Status appears in the menu.

Function is on/off.

6.2.2 Selecting function value

With the following functions you can set a value in the

submenu:

Symbol

Function

Cool:

Setting the temperature

Turn on/off the temperature zone

Freeze:

Setting the temperature

Turn on/off the temperature zone

VarioTemp:

Setting the temperature

Turn on/off the temperature zone

Swipe left in the display until the function appears.

Confirm selected function with a short tap.

Select the setting value by swiping the display.

Press briefly to confirm the selected value.

6.2.3 Activating/deactivating settings

You can activate/deactivate the following settings:

Symbol

Setting

WiFi

Entry lock

SabbathMode

Cleaning Mode

Reminders

Reset

Switch off

Swipe left in the display until Settings

appears.

Confirm settings by tapping.

Swipe until you can see the setting you want.

Activate setting (short press)

Use

10 * Depending on model and options

Tap briefly to confirm.

You hear the confirmation tone.

Status appears in the menu.

Setting is activated / deactivated.

Activate setting (long press)

Press selection for 3 seconds to confirm.

You hear the confirmation tone.

Status appears in the menu.

Display changes.

6.2.4 Selecting the setting value

With the following settings you can set a value in the

submenu:

Symbol

Settings

Brightness

Door alarm

Temp. unit

Language

Swipe the display to the left until the settings are

displayed.

Confirm the settings by tapping.

Swipe until you can see the setting you want.

Tap briefly to confirm.

Select the desired setting value by swiping the display.

Tap briefly to confirm.

You hear the confirmation tone.

Status appears briefly in the submenu.

Display switches back to the menu.

6.2.5 Calling up the customer menu

The customer menu provides the following settings:

Symbol

Function

BioFresh B-Value

D-Value

TubeClean

Ice cube

Software

Swipe left in the display until the settings

appear.

Tap settings.

The submenu appears.

Swipe left in the display until the appliance information

appears.

Press for 3 seconds.

The input menu for a numerical code appears.

Enter the numerical code 151.

The customer menu appears.

Swipe left in the display until the desired setting

appears.

Select the setting value

Tap briefly to confirm.

You hear the confirmation tone.

Status appears briefly in the display.

The display switches back to the menu.

Activate setting

To confirm, press the display for 3 seconds.

You hear the confirmation tone.

Status appears in the display.

The symbol flashes as long as the appliance is working.

6.3 Functions

Turn off appliance

This setting turns off the whole appliance.

Switch off whole appliance

Fig. 9

Turning off the IceMaker .*

Activating/deactivating (see 6.2 Operating logic) .

Off: Display turns black.

WiFi

Use this function to connect your appliance to the WiFi. You

can then operate it via the SmartDevice app on a mobile

device. You can also use this function to disconnect or reset

the WiFi connection. To connect your appliance to the WiFi,

you need the SmartDeviceBox. For more information about

the SmartDeviceBoxand how to use the SmartDevice app:

(see 1.3 SmartDevice)

Note

You cannot use the SmartDeviceBox in the following coun‐

tries: Russia, Belarus, Kazakhstan. The SmartDevice func‐

tion is not available.

Establishing a WiFi connection

Make sure that the following requirements are fulfilled:

You have a SmartDeviceBox and it is switched on.

(see 1.3 SmartDevice) *

You have installed the SmartDevice app (see

apps.home.liebherr.com).

Registration in the SmartDevice app is completed.

Use

* Depending on model and options 11

Fig. 10

Activate the setting. (see 6.2 Operating logic)

Connection is established: Connecting appears. The

symbol flashes.

Connection is established: WiFi appears, the display

turns blue.

Connection failed: WiFi Error appears.

Disconnecting from the WiFi

Deactivate the setting. (see 6.2 Operating logic)

Fig. 11

There is no connection: Symbol

is permanently

visible.

Resetting the WiFi connection

Reset settings. (see 6.2 Operating logic)

Fig. 12

The connection and other settings are reset to the

factory settings.

Temperature

The temperature depends on the following factors:

the number of times the door is opened

The duration the door is opened

the room temperature of the installation location

the type, temperature and amount of food

Temperature zone

Recommended setting

Fridge

5 °C

Temperature zone Recommended setting

Freezing

compartment

-18 °C

BioFresh

(see BioFresh B-Value*)

Setting the temperature in the refrigerator compartment

Fig. 13

Complete the steps.

Temperature is set.

Setting the temperature in the freezer compartment

Fig. 14

Complete the steps.

Temperature is set.

Switching off the temperature zone

You can switch off the fridge compartment separately.

If you switch off the freezing compartment, all temperature

zones are switched off.

Deactivate IceMaker. *

Set the value. (see 6.2 Operating logic) .

appears.

Setting the temperature in the BioFresh

You can set the temperature using the BioFresh B-Value in

the customer menu. (see BioFresh B-Value*)

Use

12 * Depending on model and options

Temperature unit

This setting allows you to change between Celsius and

Fahrenheit as the temperature unit.

Selecting the setting value

Set the value (see 6.2 Operating logic) .

BioFresh B-Value*

In the delivery condition of the appliance, the value is set to

B5. The status indicator on the display shows the appro‐

priate target temperature in the BioFresh.

You can change this value slightly if a higher or lower

ambient temperature makes it necessary. When setting the

value, note:

Value

Description

B1 Lowest temperature

B1-B4 The temperature can drop to below 0 °C, so food

can freeze easily.

B5 Default temperature

B9 Highest temperature

BioFresh B-Value

Choosing the setting

Make your settings in the Customer menu (see 6.2 Oper‐

ating logic) .

D-Value

The D-Value is preset for your appliance and may not be

changed.

SuperCool

Select this function for the maximum cooling setting, to

reach lower cooling temperatures.

This function is relevant to the fridge section Fig. 1 (A)

Use:

Cool large amounts of food quickly.

Activating/deactivating settings

Using the fridge section: activate the function when you

add the goods.

Activating/deactivating (see 6.2 Operating logic) .

-or-

Activate/deactivate using the SmartDevice app.*

The function automatically turns off. The appliance goes

back to normal mode. The temperature adjusts itself to the

set level.

VarioTemp

This function allows you to use the freezer compartment as

an additional cooling zone. You can set the temperature

from -2 °C to 14 °C. If you activate this function, it may

cause more noise. However, the appliance is still fully func‐

tional.

For storage of foodstuff in the freezer compartment with

the VarioTemp function activated, Liebherr recommends:

Temperature

range

Foodstuff

4 °C to 9 °C Cooked foods, cheese, preserves

0 °C Packaged fruit and vegetables

-2 °C Fresh fish and seafood

10 °C to 14 °C Cold-sensitive foodstuffs such as

sweet potatoes, pumpkin or exotic

fruits, food or drinks that should not be

eaten too cold

Activating/deactivating the function

Activating the function: Make sure that the following

requirements are fulfilled:*

The IceMaker has been cleaned. (see 8.6.6 Cleaning the

EasyTwist-Ice*) *

The EasyTwist-Ice has been cleaned. (see 8.6.6 Cleaning

the EasyTwist-Ice*) *

Activating/deactivating (see 6.2 Operating logic) .

The VarioTemp function is active/inactive.

Setting the temperature

Select the optimum temperature depending on the appli‐

cation.

Set the value (see 6.2 Operating logic) .

The temperature slowly adjusts to the set value.

WARNING

Danger of food poisoning!

Do not re-freeze defrosted food.

Use defrosted foodstuff as quickly as possible.

SuperFrost

Select this function for the maximum freezing setting, to

reach lower freezing temperatures.

This function is relevant to the freezer section Fig. 1 (C).

Use:

To freeze more than 2 kg fresh food a day.

Freezing fresh food quickly to the core.

Increasing the cold reserves in the stored goods before

defrosting the appliance.

Activating/deactivating settings

With a small volume of frozen goods:

Activate 6 hours before use.

With the maximum volume of frozen goods:

Activate 24 hours before use.

Activating/deactivating (see 6.2 Operating logic) .

-or-

Activate/deactivate using the SmartDevice app.*

The function automatically turns off. The appliance goes

back to normal mode. The temperature adjusts itself to the

set level.

PartyMode

This option offers an assortment of special functions and

settings that are useful if you are having a party.

The following functions are activated:

SuperCool

SuperFrost

Use

* Depending on model and options 13

IceMaker and MaxIce*

InfinitySpring*

You can set any functions you like. Your changes are lost

when the option is switched off.

Activating/deactivating settings

Activating/deactivating (see 6.2 Operating logic) .

On: All functions are activated at the same time.

Deactivated: Previously set temperatures are restored.

The function is automatically switched off after 24 hours.

HolidayMode

This function minimizes the energy consumption during an

extended absence. The temperature of the refrigerator

compartment is set to 15 °C and this is displayed on the

status screen when the temperature has been reached.

The set freezer temperature remains unchanged.

This function is relevant to the fridge section Fig. 1 (A).

Use:

Save energy if you plan to be away for a while.

Avoid coming home to bad smells and mold.

Activating/deactivating settings

Empty everything from the fridge section.

Activating/deactivating (see 6.2 Operating logic) .

On: Fridge temperature is raised.

Off: The previously set temperature is restored.

SabbathMode

With this function you can activate or deactivate the

SabbathMode. If you activate this function, some electronic

functions will be switched off. This allows your device to

meet religious requirements on Jewish holidays such as the

Sabbath and comply with STAR-K Kosher certification.

Appliance status with active SabbathMode

The status display continuously shows SabbathMode.

All functions in the display except the Deactivate

SabbathMode function are locked.

Active functions remain active.

The display stays lit when you close the door.

The interior lighting is switched off.

Reminders are disabled. The set time intervals are paused.

Reminders and warnings are not displayed.

There is no door alarm.

There is no temperature alarm.

The IceMaker is out of operation.*

The InfinitySpring is out of operation.*

The defrost cycle only works for the specified time without

taking account of appliance use.

After a power failure, the appliance returns to

SabbathMode.

Appliance status

Note

This appliance has certification from the “Institute for

Science and Halacha”. (www.machonhalacha.co.il)

You can find a list of STAR-K-certified appliances at

www.star-k.org/appliances.

Activating SabbathMode

WARNING

Danger of poisoning from spoiled food!

If you have SabbathMode activated and a power failure

occurs, no message appears in the status display about the

power failure. Once the power is restored, the appliance

continues to operate in SabbathMode. The power failure

may mean that food spoils and the consumption of this food

could lead to food poisoning.

After a power failure:

Do not consume food that has been frozen and thawed.

Call up the settings menu. (see 6.2 Operating logic)

Swipe left or right until the corresponding function is

displayed.

Fig. 15

Complete the steps (see Fig. 15) .

SabbathMode is activated.

Status display continuously shows SabbathMode.

Deactivating SabbathMode

Call up the settings menu. (see 6.2 Operating logic)

Swipe left or right until the corresponding function is

displayed.

Fig. 16

Complete the steps (see Fig. 16) .

SabbathMode is deactivated.

EnergySaver

This function activates or deactivates the energy-saving

mode. When you activate this function, the energy

consumption decreases and the temperature increases by

2 °C in the appliance. The food remains fresh, but the shelf

life is shortened.

Temperature zone

Recom‐

mended

setting

Temperature

when Ener‐

gySaver activated

Fridge compart‐

ment

5 °C 7 °C

Freezer compart‐

ment

-18 °C -16 °C

Temperatures

Use

14 * Depending on model and options

Activating EnergySaver

Swipe left or right until corresponding function is

displayed.

Fig. 17

Complete the steps (see Fig. 17) .

Energy-saving mode is activated.

Deactivating EnergySaver

Swipe left or right until corresponding function is

displayed.

Fig. 18

Complete the steps (see Fig. 18) .

Energy-saving mode is deactivated.

HydroBreeze*

HydroBreeze creates a fine mist in the drawer every 90

minutes for 4 seconds when the door is closed. This func‐

tion is also activated when you open the door. The function

is not activated when the appliance is delivered.

Use:

For storing unpackaged salad, vegetables and fruit with

high natural moisture levels.

The following settings are possible:

•

1: Function duration when the door is opened 4 s

•

2: Function duration when the door is opened 6 s

•

3: Function duration when the door is opened 8 s

•

Off: HydroBreeze is deactivated.

Activating/deactivating settings

Activating/deactivating (see 6.2 Operating logic) .

-or-

Activating/deactivating in the Liebherr SmartDevice-

App.*

IceMaker / MaxIce*

You can activate or deactivate ice cube production with the

IceMaker function. Use the MaxIce function to increase the

number of ice cubes in the IceMaker.

More information on the number

of ice cubes:

(see 9.1 Technical

specifications)

More information on the size of

the ice cubes:

(see Ice cubes*)

More information on cleaning the

lines of the IceMaker:

(see TubeClean*)

Activating IceMaker

Make sure that the following requirements are fulfilled:

The water supply is established at the fixed water

connection. See Assembly Manual.*

IceMaker is put into operation.

Swipe left or right until corresponding function is

displayed.

Fig. 19

Complete the steps (see Fig. 19) .

-or-

Activate with the SmartDevice app.

IceMaker is activated. It can take up to 24 hours for the

IceMaker to produce the first ice cubes.

Activating the IceMaker with MaxIce

If you have not activated the IceMaker function before,

make sure that the following requirements are met:

The water supply is established at the fixed water

connection. See Assembly Manual.*

IceMaker is put into operation.

Swipe left or right until corresponding function is

displayed.

Fig. 20

Complete the steps (see Fig. 20) .

-or-

Activate with the SmartDevice app.

The IceMaker is activated with MaxIce.

Changing between the IceMaker and MaxIce

If you have activated IceMaker and would like to change to

MaxIce:

Swipe left or right until corresponding function is

displayed.

Fig. 21

Complete the steps (see Fig. 21) .

The IceMaker is activated with MaxIce.

If you have activated MaxIce and would like to change to

IceMaker:

Use

* Depending on model and options 15

Swipe left or right until corresponding function is

displayed.

Fig. 22

Complete the steps (see Fig. 22) .

IceMaker is activated.

MaxIce is deactivated.

Deactivating the IceMaker / MaxIce

Swipe left or right until corresponding function is

displayed.

Fig. 23 Example illustration of the active IceMaker function

Complete the steps (see Fig. 23) .

-or-

Deactivate with the SmartDevice app.

IceMaker and MaxIce are deactivated.

If ice cubes are currently being made, the system

completes the process.

The IceMaker goes off automatically.

Ice cubes*

With this setting, you can choose the ice cube size.*

Choosing the setting*

Make your settings in the Customer menu (see 6.2 Oper‐

ating logic) .

TubeClean*

This setting cleans the IceMaker pipes.*

Make sure that the following requirements are met:*

IceMaker cleaning process is ready (see 8.6.7 Cleaning

the IceMaker*) .

Activate setting*

Activate the setting in the customer menu (see 6.2 Oper‐

ating logic) .

TubeClean is prepared (max. 60 min.): The symbol

flashes.

Water pipes are rinsed: Symbol flashes.

Rinsing process is complete: Function turns off automati‐

cally.

CleaningMode

This setting makes it easy to clean the appliance.

This setting is relevant to the fridge section Fig. 1 (A).

Use:

Clean the fridge section manually.

Clean the InfinitySpring.*

What happens with the appliance when this setting is on:

The display shows CleaningMode permanently.

The refrigerator compartment is switched off.

The internal light is on.

Reminders and warnings are not shown. There is no

acoustic signal.

InfinitySpring is out of use.*

Activating/deactivating settings

Activate/deactivate setting (see 6.2 Operating logic) .

On: Fridge compartment is switched off. Light stays on.

Off: preset temperature is restored.

The setting is automatically deactivated after 60 minutes.

Then the appliance continues operation in normal mode.

Display brightness

With this setting, you can choose a brightness level for the

display.

You can set the following brightness levels:

40%

60%

80%

100%

Choosing the setting

Set the level (see 6.2 Operating logic) .

Door alarm

Set the time before the door alarm (see Close the door)

sounds.

Options are as follows:

1 min

2 min

3 min

Off

Choosing the setting

Set the level (see 6.4 Error messages) .

Entry lock

This setting avoids accidental operation of the appliance,

e.g. by children.

Use:

Avoid unintentional changing of settings and functions.

Avoid unintentional switching off of the appliance.

Avoid unintentional temperature adjustments.

Use

16 * Depending on model and options

Activating/deactivating settings

Activating/deactivating (see 6.2 Oper‐

ating logic) .

Language

This setting lets you choose the language of the display.

Choose from the following languages:

German

English

French

Spanish

Italian

Dutch

Czech

Polish

Portuguese

Russian

Chinese

Activating/deactivating settings

Activating/deactivating (see 6.2 Operating logic) .

Info

This setting allows the appliance information to be read out

as well as access to the customer menu.

It provides the following information:

Model name

Index

Serial number

Service number

View appliance data

Swipe in the display until Settings appears.

Confirm the display.

Swipe in the display until About appears.

Read the appliance data.

Reminder

Reminders are displayed acoustically by a beep and visually

by a symbol in the display. The signal gets louder until the

alert stops.

Replace water filter*

This message appears when the water filter needs

replacing.

Replace the water filter every 6 months.

Confirm the message with OK.

The service interval resets.

The water filter guarantees the best water quality.

Replace the FreshAir active carbon filter

This message appears when the air filter needs replacing.

Replace the air filter every six months.

Confirm the message with OK.

The service interval resets.

The air filter guarantees the air quality in the fridge.

Activate setting

Activating/deactivating (see 6.2 Operating logic) .

Reset

This function resets all settings to the factory settings. All

settings that you have made thus far will be reset to their

original values.

Activate the setting

Activating (see 6.2 Operating logic) .

6.4 Error messages

Error messages appear in the display. There are two catego‐

ries of error message:

Category

Meaning

Message Reminder of general procedures. You can carry

out these procedures to eliminate the message.

Warning Appears when there are malfunctions. A signal

sounds in addition to the display. The signal

becomes louder until you acknowledge by

tapping the display. You can eliminate simple

defects yourself. For more serious defects, you

must contact customer service.

6.4.1 Warnings

Close the door

This message appears if the door is open too long.

You can set the time before this message appears .

Stop alarm: Confirm the message.

-or-

Close the door.

Power failure.

This message appears if the freezer temperature rises after

a power outage. When the power outage is over, the appli‐

ance will continue to operate at the last temperature

setting.

Stop alarm: Confirm the message.

Temperature alarm appears (see Temperature alarm) .

Temperature alarm

This message appears if the freezer temperature does not

match the set temperature.

Temperature differences may be caused by:

Hot fresh food was placed in the appliance.

When sorting and removing food from the appliance, too

much warm ambient air got in.

There has been a prolonged power outage.

The appliance is faulty.

When the cause is eliminated, the appliance will continue to

operate at the last temperature setting.

Confirm the display.

Warmest temperature is displayed.

Confirm the display again.

The status display is displayed.

Current temperature is displayed.

Use

* Depending on model and options 17

Error

This message appears when there is a fault with the appli‐

ance. An appliance component has an error.

Open the door.

Take note of the error code.

Confirm the message.

The signal tone stops.

The status display appears.

Close the door.

Contact customer service. (see 9.4 Customer service)

6.4.2 Message

Insert IceMaker drawer*

This message appears if the IceMaker drawer is open.

Push in the IceMaker drawer.

The message disappears.

The IceMaker produces ice cubes.

6.4.3 DemoMode

If “D” appears in the display, demo mode is on. This feature

is designed for retailers. The cooling features are disabled.

Switching off DemoMode

When you see a time counting down:

Confirm within the countdown.

DemoMode is off.

If there is no countdown:

Disconnect the power plug.

Reconnect the power plug.

DemoMode is off.

7 Equipment

7.1 Door racks

7.1.1 Moving/removing door racks

Fig. 24

Slide racks up.

Pull to the front.

Re-insert in reverse order.

Fig. 25

You can use just one or both VarioBoxes. To store oversized

bottles, suspend just one box over the bottle rack.

Move the VarioBox shelf:

Fig. 26

Pull up and out.

Replace at any position.

Moving the VarioBoxes:

Fig. 27

If the door rack is removed:

Remove boxes.

Fig. 28

Place the shelf on the table.

Fig. 29

Pull off the middle holder Fig. 29 (1).

Insert the middle holder in the second position Fig. 29 (2).

Fig. 30

Replacing boxes.

Equipment

18 * Depending on model and options

7.1.2 To dismantle door racks

The door racks can be disassembled for cleaning.

Fig. 31

Fig. 32

Disassemble the door racks.

7.2 Split shelf

7.2.1 Using the split shelf

Extension stops secure the shelves against being acciden‐

tally pulled out

Fig. 33

Push the split shelf underneath as in the illustration

Fig. 34

Adjusting heights:

Pull the glass panels out Fig. 34 (1) from the front, one at

a time.

Pull the support rails out of their retainers and snap into

place at the height you want them.

Slide in the glass panels one at a time.

Flat pull-out stoppers at the front, right behind the

support rail.

Taller pull-out stoppers at the back.

Using both shelves:

Hold the bottom glass panel with one hand and pull it to

the front.

The glass panel Fig. 34 (1) with the trim strip is at the

front.

The stops Fig. 34 (3) point downward.

7.3 VarioSafe

The VarioSafe provides space for small food, packs, tubes,

and jars.

7.3.1 Using the VarioSafe

You can remove the drawer and slide it back in at two

different heights. This is to accommodate taller small items

in the drawer.

Fig. 35

Remove the drawer.

Slide in at any height Fig. 35 (1) or Fig. 35 (2).

7.3.2 Moving the VarioSafe

You can shift the height of the entire VarioSafe unit.

Fig. 36

Pull to the front.

Side recess to shelf position.

Raise or lower to any height.

Slide to the rear.

7.3.3 Removing the VarioSafe completely

You can remove the entire VarioSafe unit.

Pull to the front.

Side recess to shelf position.

Equipment

* Depending on model and options 19

Fig. 37

Tilt and pull to the front.

7.3.4 Disassembling the VarioSafe

The VarioSafe can be dismantled for cleaning.

Fig. 38

Dismantling the VarioSafe.

7.4 InfinitySpring*

The built-in water dispenser provides convenient drinking

water. The water temperature depends on the temperature

in the fridge.

Fig. 39

Push the glass against the button pushbutton of the

dispenser.

The outlet unit moves out: water pours into the glass.

Avoid splashes: Remove the glass slowly.

If dispensing larger quantities of water:

If the water flow stops, remove the water tank and push

your container against the button push button of the

dispenser again.

7.5 Variable bottle shelf

7.5.1 Using the bottle shelf

Use the variable bottle shelf or the glass panel placed on

the fridge floor.

Fig. 40

Remove the glass shelf and store separately.

Place the bottles with the base pointing backwards

facing the rear wall

Note

If the bottles protrude over the front of the bottle shelf:

Move the bottom door rack higher up.

7.5.2 Removing the bottle shelf

You can remove the bottle shelf for cleaning.

Remove the glass panel above the bottle shelf.

Fig. 41

Lift the bottle shelf at the front and pull out.

Note

Liebherr recommends the following:

Do not place any goods on the drawer cover below.

7.5.3 Inserting the bottle shelf

Fig. 42

Slide in the bottle shelf until it engages and push down.

The lugs at the back of the bottle shelf are connected

automatically.

LED lights up.

7.6 Drawers

You can remove the drawers for cleaning.

You can remove the drawers to use VarioSpace.

The way to remove/insert the drawers varies depending on

the pull-out system. Your appliance can contain a variety of

pull-out systems.

Note

Insufficient ventilation results in an increase in energy

consumption and reduction of the refrigerating perform‐

ance.

Leave the bottom drawer in appliance!

Never obstruct the vents on the interior rear wall!

7.6.1 Drawer on telescopic rails

The drawer runs on full-extension rails (telescopic rails).

There are full-extension telescopic rails and telescopic rails

with partial pull-out. Drawers which are full extension can

be pulled out fully from the appliance. Drawers with partial

pull-out cannot be pulled out fully from the appliance. The

system in your appliance depends on the type of appliance.

Equipment

20 * Depending on model and options

Full extension

If you have full-extension rails, there is a clamp located at

the back on the left and right of the rail.

Removing drawer

Fig. 43

Pull out drawer as far as it will go.

Lift left clamp and simultaneously pull drawer forwards

on the left. Fig. 43 (1)

Lift right clamp and simultaneously pull drawer forwards

on the right. Fig. 43 (2)

Remove drawer to the front. Fig. 43 (3)

Slide rails in.

Inserting drawer

Fig. 44

Slide rails in.

Place drawer on rails.

Slide in drawer to the back.

Drawer latches in audibly at the back.

Partial pull-out freezing compartment*

Note

If the magnet on the top drawer in the freezing compart‐

ment is damaged or removed, the door sensor will malfunc‐

tion.

Do not damage or remove the magnet.

Removing drawer

Fig. 45

If the drawer is in the top freezer:

Pull out drawer as far as it will go.

Lift up drawer at the front. Fig. 45 (1)

Remove drawer to the front. Fig. 45 (2)

Slide rails in.

-or-

Fig. 46

If the drawer is in the middle of the freezing compart‐

ment:

Pull out drawer halfway.

Lift drawer from below at the back. Fig. 46 (1)

Remove drawer to the front. Fig. 46 (2)

Slide rails in.

Inserting drawer

Fig. 47

Slide rails in.

Guide drawer around the stoppers Fig. 47 (1).

Place drawer on rails.

Slide in drawer to the back.

7.7 Fruit & Vegetable-Safe cover

The compartment lid can be removed for cleaning.

7.7.1 Removing the compartment lid

Make sure that the following requirements are fulfilled

Bottle shelf is removed (see 7.5 Variable bottle shelf) .

Fig. 48

If the drawers are removed:

Pull the lid up at the front in the retaining parts to the

opening Fig. 48 (1).

Lift from the back and pull it up and out Fig. 48 (2).

7.7.2 Inserting the compartment lid

Fig. 49

If the text THIS SIDE UP is on top:

Insert the lip of the cover over the opening of the rear

bracket Fig. 49 (1) and click into place Fig. 49 (2).

Position the cover where you want it (see 7.8 Humidity

control) .

7.8 Humidity control

You can regulate the moisture in the drawer yourself by

adjusting the compartment cover.

Equipment

* Depending on model and options 21

The compartment cover is on the drawer itself and can be

covered with shelves or additional drawers.

Fig. 50

Low air humidity

Open the drawer.

Pull the drawer cover to the front.

If the drawer is closed: Gap between lid and compart‐

ment.

Switch off HydroBreeze.*

Moisture levels lower in the Safe.

High air moisture:

Open the drawer.

Slide the compartment cover to the back.

If the drawer is closed: The cover seals the compartment.

Activate the HydroBreeze.*

Moisture levels rise in the Safe.

If there is too much moisture in the compartment:

Choose a “low moisture setting”.

-or-

Remove the moisture with a cloth.

Note

With the “low humidity” setting, the Fruit & Vegetable-Safe

can also be used as a Meat & Dairy-Safe.

Choose a “low moisture” setting.

7.9 HydroBreeze*

HydroBreeze emits a mist over the refrigerated goods to

provide moisture every time the door is opened.

The HydroBreeze and its water tank are located in the

adjustable bottle shelf.

Make sure that the following requirements are fulfilled

The water tank is clean .

The water tank is properly engaged.

Moisture is set to “high moisture” (see 7.8 Humidity

control) .

HydroBreeze is on (see HydroBreeze*) .

7.9.1 Fill the water tank

WARNING

Contaminated water!

Poisoning.

Fill with drinking water only.

HydroBreeze is off: Empty the water tank.

HydroBreeze is out of use for a prolonged period: Empty

the water tank.

NOTICE

Sugary liquids!

Damage to the HydroBreeze.

Fill with drinking water only.

Note

Use filtered, decarbonized water to provide the best-quality

drinking water and keep the HydroBreeze working smoothly.

This water quality can be achieved using a table water filter

of the kind available in trade retail outlets.

Fill the water tank with filtered, decarbonized drinking

water.

The water tank is built into the adjustable bottle shelf

(see 1.2 Appliance and equipment overview) .

Fig. 51

Press on the back-left corner of the front glass plate.

The glass panel folds upwards.

Lift the glass panel and fold to the back as far as it will

go Fig. 51 (1).

The glass panel is upright.

Slide the slider Fig. 51 (2) to the left.

The water tank jumps out of its recess.

Remove the water tank Fig. 51 (3).

Cleaning the water tank .

Angular opening:

Fill with drinking water up to the level mark.

Insert the water tank, bottom first, into the recess.

Slowly lower the front part and push the tank in.

Water tank is engaged.

7.9.2 Disassembling the water tank

You can disassemble the water tank for cleaning.

Fig. 52

Disassemble the water tank.

7.10 Glass shelves

You can remove the glass shelf under the drawers for

cleaning.

You can remove the glass shelf under the drawers to use

VarioSpace.

7.10.1 Removing / inserting the glass shelf

Make sure that the following requirements are fulfilled:

Glass shelf under the drawer: Drawer has been removed.

(see 7.6 Drawers)

Equipment

22 * Depending on model and options

Removing glass shelf

Fig. 53 Example illustration of glass shelf

Lift glass shelf at the front. Fig. 53 (1)

Remove glass shelf to the front. Fig. 53 (2)

Inserting the glass shelf

Fig. 54 Example illustration of glass shelf

Position glass shelf at an angle behind the stoppers. (see

Fig. 54)

Lower glass shelf.

Slide in glass shelf to the back.

7.11 EasyTwist-Ice*

The EasyTwist-Ice produces ice cubes when the water tank

is inserted.

The EasyTwist-Ice is used exclusively for the production of

ice cubes in standard household quantities.

Note

Do not change the position of the EasyTwist-Ice.

Make sure that the following conditions are met:

The EasyTwist-Ice has been cleaned (see 8.6.6 Cleaning

the EasyTwist-Ice*)

The water tank has been cleaned.

The EasyTwist-Ice drawer is fully inserted.

7.11.1 Filling the water tank

WARNING

Risk of poisoning due to contaminated water!

Fill the water tank with potable water only.

NOTICE

Sugary liquids!

Damage to the EasyTwist-Ice.

Fill with cold drinking water only.

Note

Using filtered, decarbonized water ensures the best-tasting

drinking water for your ice cubes.

This water quality can be achieved using a table water filter

of the kind available in trade retail outlets.

Always fill the water tank only with filtered, decarbonized

drinking water.

The water for the EasyTwist-Ice is supplied from a water

tank.

Fig. 55

Lift up the water tank at the rear Fig. 55 (1) and take it out

upwards Fig. 55 (2).

Fill with drinking water up to the mark.

Insert the water tank by reversing the steps described

above.

7.11.2 Producing ice cubes

The production capacity depends on the freezer tempera‐

ture. The lower the temperature, the more ice cubes that

can be produced in a certain period.

Maximum capacity of the ice cube drawer – 40 cubes (2x ice

cube production).

Time required for ice cube production – at least 5 hours.

Releasing the ice cubes

Turn the knob to the right to its stop limit.

If necessary, repeat several times and turn the knob a

little more.

7.12 VarioSpace

Fig. 56

You can remove drawers and glass panels from your appli‐

ance. This provides more room for large food items such as

poultry, joints of meat, large game and bulky baked goods.

You can then freeze these items whole for later preparation.

Note the load limits on the drawers and glass panels

(see 9.1 Technical specifications) .

Equipment

* Depending on model and options 23

7.13 Butter dish

7.13.1 Opening/closing the butter dish

Fig. 57

7.13.2 Dismantling the butter dish

You can disassemble the butter dish for cleaning.

Fig. 58

Disassemble the butter dish.

7.14 Egg rack

You can pull out and turn the egg rack. You can use both

sides of the egg rack so you can label specifics like the

purchase date.

7.14.1 Using the egg rack

Fig. 59

Top section: store hen eggs.

Bottom section: store quail eggs.

7.15 Bottle rack

7.15.1 Using the bottle rack

Fig. 60

Slide the bottle rack at the edges.

Stops bottles from tipping over.

7.15.2 Removing the bottle rack

Fig. 61

Slide the bottle rack all the way to the right edge.

Remove to the back.

7.16 FlexSystem*

7.16.1 Using the FlexSystem

The FlexSystem helps you store and arrange food clearly

and in the way you want. It lets you clearly divide your food

into fruit, vegetables or by use-by dates, for example.

Equipment

24 * Depending on model and options

Fig. 62

Move the inside tray.

7.16.2 Removing the FlexSystem

Fig. 63

Lift the FlexSystem at the back.

Pull up and out.

7.16.3 Inserting the FlexSystem

Fig. 64

Insert front of the FlexSystem first.

Lower the back part.

7.16.4 Disassembling the FlexSystem

The FlexSystem can be dismantled for cleaning.

Fig. 65

Dismantling the FlexSystem.

7.17 Freezer packs

The freezer packs prevent the temperature from rising too

fast in the event of a power failure.

The freezer packs are in the drawer.

7.17.1 Using the freezer packs

Fig. 66

When the freezer packs are fully frozen:

Place on the frozen goods in the top, front part of the

freezer.

7.18 Ice cube tray with lid*

7.18.1 Using the ice cube tray

Fig. 67

When water is frozen:

Hold the ice cube tray briefly under warm water.

Remove the lid.

Gently turn the ends of the ice cube tray in opposite

directions.

Release the ice cubes.

7.18.2 Dismantling the ice cube tray

You can dismantle the ice cube tray for cleaning.

Fig. 68

Disassemble the ice cube tray.

Equipment

* Depending on model and options 25

7.19 Flexible ice compartment divider*

The IceMaker’s ice cube drawer has a flexible ice compart‐

ment divider. This allows you to store larger quantities of ice

cubes or additional food items as needed. You can move or

remove the ice compartment divider.

7.19.1 Moving the flexible ice compartment

divider

Fig. 69 Example illustration of the ice compartment divider

Move the ice compartment divider to the desired position.

7.19.2 Removing the flexible ice compartment

divider

Make sure that the following requirements are fulfilled:

Ice cube drawer is removed. (see 7.6 Drawers)

Fig. 70

Lift the rear part of the ice compartment divider.

Fig. 70 (1)

Remove the ice compartment divider upwards. Fig. 70 (2)

7.19.3 Putting in the flexible ice compartment

divider

Make sure that the following requirements are fulfilled:

Ice cube drawer is removed. (see 7.6 Drawers)

Fig. 71

Insert the front part of the ice compartment divider.

Fig. 71 (1)

Lower the rear part of the ice compartment divider to the

drawer bottom. Fig. 71 (2)

8 Maintenance

8.1 FreshAir carbon filter

The FreshAir carbon filter is located in the compartment

above the fan.

It guarantees the best air quality.

Change the carbon filter every 6 months.

When the reminder is set, a message on the display

prompts you to change it.

You can dispose of the carbon filter with the regular

household waste.

Note

FreshAir activated charcoal filters can be purchased from

the Liebherr-Hausgeräte store at home.liebherr.com/

shop/de/deu/zubehor.html.

8.1.1 Removing the FreshAir carbon filter

Fig. 72

Pull out the compartment Fig. 72 (1).

Remove the carbon filter Fig. 72 (2).

8.1.2 Inserting the FreshAir carbon filter

Fig. 73

Insert the carbon filter as shown in the diagram

Fig. 73 (1).

The carbon filter clicks into place.

If the carbon filter is pointing downwards:

Push the compartment in Fig. 73 (2).

The carbon filter is now ready for use.

8.2 Water tank*

The InfinitySpring is located behind the lowest drawer in the

fridge section.

Maintenance

26 * Depending on model and options

8.2.1 Removing the water tank

Turn off the water tap.

Run the InfinitySpring for 30 seconds and collect the

remaining water in a glass.

Remove the drawer.

Turn the water tank all the way to the left and pull it out.

Water dripping out is collected in the drip tray.

Drain the water from the drip tray.

Clean the drip tray with a cloth or in the dishwasher.

8.2.2 Inserting the water tank

Fig. 74

Remove the drawer.

Insert the water tank and turn approx. 90° to the right

until it engages.

Check that the water tank is sealed and no water leaks

out.

Insert the drawer.

Turn on the water tap.

Bleed the water system. (see 3.3.1 Vent the water

system)

Instead of the water filter, you can use an additional water

tank.

Note

The water tank is available as a spare part.

8.2.3 Removing / inserting the drip tray

You can remove the drip tray for cleaning.

Fig. 75

Pull out the drip tray to the front.

8.3 Water filter*

The water filter is located behind the lowest drawer in the

fridge section.

It absorbs deposits in the water and reduces the taste of

chlorine.

Replace the water filter at least every 6 months under

the specified usage conditions or if the flow rate drops

significantly.

The water filter contains carbon and can be disposed of

with the regular household waste.

Note

The water filter can be purchased from the Liebherr-Hausg‐

eräte store at home.liebherr.com/shop/de/deu/

zubehor.html.

8.3.1 Removing the water filter

Remove the drawer.

Turn the water filter all the way counterclockwise and

pull it out.

Water dripping out is collected in the drip tray.

Clean the drip tray with a cloth or in the dishwasher.

8.3.2 Installing the water filter

Fig. 76

Remove the drawer.

Insert the water filter and turn clockwise approx. 90°

until it engages.

Make sure the filter does not leak and no water is coming

out.

Insert the drawer.

CAUTION

New water filters may contain particulate matter.

Draw 3 l of water from the InfinitySpring and dispose of

it.

The water filter is now ready for use.

8.4 Disassembling / assembling pull-

out systems

8.4.1 Notes on disassembly

You can disassemble some of the pull-out systems for

cleaning. Your appliance can contain a variety of pull-out

systems.

The following pull-out systems can be disassembled or

cannot be disassembled:

Pull-out system

can be disassembled /

cannot be disassembled

Full extension cannot be disassembled

Partial pull-out

freezer compart‐

ment*

can be disassembled (see Partial

pull-out freezing compartment*) *

Maintenance

* Depending on model and options 27

8.4.2 Drawer on telescopic rails

Partial pull-out freezing compartment*

Disassembling pull-out system

Make sure that the following requirements are fulfilled:

Drawer has been removed.

Glass shelf has been removed. (see 7.10 Glass shelves)

Fig. 77 Glass shelf with rails

Push up front click-in hooks. Fig. 77 (1)

Slide pull-out rails to the side Fig. 77 (2) and backwards

Fig. 77 (3).

Installing pull-out system

Fig. 78 Glass shelf with rails

Hook in rail at the back. Fig. 78 (1)

Hook in rail at the front. Fig. 78 (2)

8.5 Defrosting the appliance

8.5.1 Defrosting the refrigerator compartment

Defrosting is performed automatically. The water from the

thawing process runs out via the drain opening and is

evaporated.

Clean the drain opening regularly (see 8.6 Cleaning the

appliance) .

8.5.2 Defrosting the freezer compartment with

NoFrost

Defrosting is performed automatically by the NoFrost

system. The moisture condenses on the evaporator and is

periodically defrosted and evaporated.

The appliance does not have to be defrosted.

8.6 Cleaning the appliance

8.6.1 Preparation

WARNING

Danger of electric shock.

Unplug refrigerator or disconnect power.

WARNING

Danger of fire

Do not damage the refrigerant circuit.

Empty appliance.

Pull out the power plug.

-or-

Activate CleaningMode. (see CleaningMode)

8.6.2 Cleaning the housing

NOTICE

Improper cleaning!

Damage to the appliance.

Only use soft cleaning cloths and ph-neutral all-purpose

cleaners.

Do not use steel wool or sponges that scour or scratch.

Do not use caustic or abrasive cleaning materials or

those containing sand, chloride, or acids.

WARNING

Risk of injury or damage due to hot steam.

Hot steam can cause scalding/burns and damage to

surfaces.

Do not use steam cleaners.

Wipe the housing down with soft, clean cloth. If very

dirty, use lukewarm water with a neutral cleaner. Glass

surfaces can also be cleaned with glass cleaner.

8.6.3 Cleaning the interior

NOTICE

Improper cleaning!

Damage to the appliance.

Only use soft cleaning cloths and ph-neutral all-purpose

cleaners.

Do not use steel wool or sponges that scour or scratch.

Do not use caustic or abrasive cleaning materials or

those containing sand, chloride, or acids.

Plastic surfaces: clean by hand with a soft clean cloth,

lukewarm water and a little detergent.

Metal surfaces: clean by hand with a soft clean cloth,

lukewarm water and a little detergent.

Drain hole: remove any deposits with a thin item such as

a cotton bud.

8.6.4 Cleaning the InfinitySpring*

You can clean the InfinitySpring outlet and around it without

disconnecting the appliance from the mains.

We recommend cleaning in the following situations:

Initial commissioning

If out of use for longer than 5 days.

Press the bottom pushbutton of the dispenser.

The outlet unit moves out.

Clean the water outlet and around it with a soft, damp

cloth, lukewarm water and a little washing up liquid.

Release the bottom pushbutton.

Dispense 2 l of water through the InfinitySpring and pour

away.*

8.6.5 Cleaning the HydroBreeze*

We recommend cleaning in the following situations:

Initial commissioning

HydroBreeze was off for longer than 48 hours.

Refill the water tank.

Make sure that the following requirements are fulfilled

HydroBreeze is off (see HydroBreeze*) .

Water tank was removed and cleaned in the dishwasher.

Maintenance

28 * Depending on model and options

Wipe out the recess with a damp cloth.

Insert the water tank.

Activate the HydroBreeze.

8.6.6 Cleaning the EasyTwist-Ice*

Cleaning must be conducted in the following situations:

Operating for the first time

Non-use for longer than 48 hours

When the appliance requires cleaning

When operating for the first time, longer periods of disuse

and when the appliance requires cleaning

Fig. 79

Take out the water tank Fig. 79 (1) and ice cube drawer

Fig. 79 (2).

Take out the freezer drawer with EasyTwist-Ice.

Fig. 80

Press the lug Fig. 80 (1), lift up the EasyTwist-Ice at the

back and take it out of the freezer drawer.

Fig. 81

Press the lugs Fig. 81 (1) on both sides of the EasyTwist-

Ice simultaneously and take off the cover Fig. 81 (2)

upwards.

Fig. 82

Press all lugs Fig. 82 (1) one after another and remove the

cover Fig. 82 (2).

Clean the Ice cube drawer, water tank and EasyTwist-Ice

with water and a little detergent.

Assemble the EasyTwist-Ice.

Fig. 83

Maintenance

* Depending on model and options 29

Insert the axles Fig. 83 (1) on the EasyTwist-Ice in the

guides and push the rear side Fig. 83 (2) until the lug

engages.

Push in the EasyTwist-Ice drawer.

WARNING

Risk of poisoning due to contaminated water!

Fill the water tank with potable water only.

Fill the water tank and insert it. (see 7.11.1 Filling the

water tank)

With unfiltered water:

Dispose of ice cubes that were produced within 24 hours

of the first ice cube production.

With filtered water:

Dispose of ice cubes that were produced within 48 hours

of the first ice cube production.

8.6.7 Cleaning the IceMaker*

There are various options for cleaning the IceMaker.

We recommend cleaning in the following situations:

Initial commissioning

If out of use for longer than 5 days.*

Make sure that the following requirements are met:

IceMaker drawer is emptied.

IceMaker drawer is fully inserted.

The IceMaker has been activated. (see 6.2 Operating

logic)

On first use or if not used for prolonged periods

Clean the IceMaker with TubeClean.

Put an empty 1.5 l vessel (max. height 10 cm) in the

drawer under the IceMaker.

Activate the TubeClean function. (see 6.2 Operating logic)

The rinse process is prepared (max. 60 min.): The symbol

flashes.

Water pipes are rinsed: Symbol flashes.

Rinsing process is complete: Function turns off automati‐

cally.

Take out the IceMaker drawer and remove the container.

Clean the IceMaker drawer with warm water and a little

detergent.

Push in the IceMaker drawer.

Ice cube production starts automatically.

Without water filter*

Dispose of any ice cubes that are produced within 24

hours of the first ice cube production.*

With water filter:*

Dispose of any ice cubes that are produced within 48

hours of the first ice cube production.*

-or-

Draw 2 l of water from the InfinitySpring and dispose of

it.*

When cleaning is required

Clean the IceMaker manually.

Remove the IceMaker drawer and clean with warm water

and a little detergent.

Push in the IceMaker drawer.

Ice cube production starts automatically.

8.6.8 After cleaning

Wipe dry the appliance and items of equipment

Connect and switch on the appliance.

Activate SuperFrost (see 6.3 Functions) .

When the temperature is sufficiently cold

Place the food inside.

Repeat cleaning regularly.

9 Customer support

9.1 Technical specifications

Temperature zone

Cool: 3 °C to 9 °C

BioFresh 0 °C to 3 °C

BioFresh Profes‐

sional*

(Fish & SeaFood)*

-2 °C to 0 °C*

Possible settings (see Fish &

Seafood-Safe *) :*

0 °C | 0 °C*

-2 °C | 0 °C*

-2 °C | -2 °C*

Freezing -26 °C to -15 °C

Maximum freezing quantity/24 h

Freezer See “Freezing capacity …/24 h” on

the type plate

Max. equipment capacity

Equipment Appliance

width

550 mm

(see instal‐

lation

instruc‐

tions,

appliance

dimen‐

sions)

Appliance

width

600 mm

(see

installa‐

tion

instruc‐

tions,

appliance

dimen‐

sions)

Appliance

width

700 mm

(see instal‐

lation

instruc‐

tions, appli‐

ance

dimen‐

sions)

Partial pull-out

freezer compart‐

ment*

(see 7.6.1 Drawer

on telescopic rails)

12 kg* 15 kg* --*

Ice cube production with IceMaker*

Ice cube produc‐

tion/24 h

At a temperature of -18 °C: 1.2 kg of

ice cubes

Maximum ice cube

production/24 h

When the MaxIce function is active:

1.5 kg of ice cubes

Ice cube production with EasyTwist-Ice*

Time required at -18 °C approx. 5.5 h

Time required with SuperFrost activated approx. 3 h

Time required to reach various temperatures with Vario‐

Temp

Initial tempera‐

ture

Target tempera‐

ture

Time required to

reach target temper‐

ature

-18 °C 0 °C >8 h

-18 °C 8 °C >12 h

8 °C 14 °C >6 h

14 °C -18 °C >4 h

Customer support

30 * Depending on model and options

Lighting

Energy efficiency class

Light source

This product contains one or more energy

efficiency class G light sources.

LED

The appliance may contain light sources with different

energy efficiency classes. The lowest energy efficiency class

is indicated.

For appliances with a WiFi connection:*

Frequency specification*

Frequency band 2.4 GHz

Maximum radiated

power

< 100 mW

Purpose of the

wireless equipment

Integration in the local WiFi network

for data communication

9.2 Operating noises

The appliance makes noises while in operation.

At less cooling output the appliance saves energy but

takes longer to cool items. The volume is lower.

At a higher cooling output the food cools more quickly.

The volume is higher.

Examples:

•

Activated functions (see 6.3 Functions)

•

Running fan

•

Freshly sorted food

•

High ambient temperature

•

Door opened for long periods

Noise

Possible cause Type of noise

Bubbling and

splashing

Coolant is flowing

into the cooling

circuit.

Normal noise

Spitting and

hissing

Coolant is spraying

into the cooling

circuit.

Normal noise

Humming The appliance

cools. The volume

depends on the

cooling output.

Normal noise

Noise Possible cause Type of noise

Sipping noises The self-closing

door is being

opened and

closed.

Normal noise

Whirring and

murmuring

The fan is running. Normal operating

noise

Clicking Components are

being switched on

and off.

Normal switching

noise

Rattling or

humming

Valves are active. Normal switching

noise

Noise Possible

cause

Type of noise How to

resolve

Vibration Unsuitable

setup

Error noise Adjust the

feet to make

sure the

appliance is

horizontal.

Clattering Equipment,

Objects

inside the

appliance

Error noise Secure

equipment

parts.

Leave a gap

between

items.

9.3 Technical faults

Your appliance is designed and manufactured for reliable

operation and a long service life. If a malfunction nonethe‐

less occurs during operation, please check whether the

malfunction is due to an operating error. In this case, you

will have to be charged for the costs incurred, even during

the warranty period.

You may be able to rectify the following faults yourself.

9.3.1 Appliance function

Defect

Cause Remedy

The appliance does

not work.

→ The appliance is not switched on.

Switch on the appliance.

→ The power plug is not properly

inserted in the wall socket.

Check the power plug.

→ The powerfuse in the wall socket is

not OK.

Check the fuse.

→ Power failure.

Keep the appliance closed.

Protect your food: Lay freezer packs on top of the food or

use another freezer if the power is off for a prolonged

period.

Do not re-freeze defrosted food.

→ The appliance connector is not

correctly inserted in the appliance.

Check the appliance connector.

Customer support

* Depending on model and options 31

Defect Cause Remedy

The temperature is

not cold enough

→ This means that the door of the

appliance is not closed properly

Close the appliance door

→ Insufficient ventilation

Clear and clean the ventilation grille.

→ The ambient temperature is too

high

Solution: (see 1.4 Range of appliance use) .

→ The appliance was opened too

frequently or for too long

Wait to see whether the required temperature resets

itself by itself. If not, contact Customer Service

(see 9.4 Customer service) .

→ Too much fresh food was placed

inside without SuperFrost.

Solution: (see SuperFrost)

→ The temperature is incorrectly set

Set to a colder temperature and check after 24 hours.

→ The appliance is too near to a heat

source (stove, heater etc).

Change location of appliance or the heat source.

The door seal is

defective or should

be replaced for

other reasons.

→ The door seal is interchangeable.

You can replace it without the use

of any special tools.

Contact Customer Service (see 9.4 Customer service) .

The appliance is

iced up or conden‐

sation is building.

→ The door seal may have slipped out

of its groove.

Check the door seal is well placed in the groove.

The outside

surfaces of the

appliance are hot*.

→ The heat of the refrigerant circuit is

used to prevent condensate from

forming

This is normal.

9.3.2 Equipment

Defect Cause Remedy

The IceMaker

cannot be

switched on.*

→ The appliance and therefore the

IceMaker are not connected.

Connect the appliance (see Installation Guide).

The IceMaker is

not making any ice

cubes.*

→ The IceMaker is not switched on.

Activate the IceMaker.

→ The drawer of the IceMaker is not

properly closed

Close the drawer properly

→ The water connection is not open

Open the water connection*

The IceMaker is

not working.*

→ There is air in the system.

Vent the water system (see Installation Instructions,

Water Connection).

The InfinitySpring

is not working.*

→ The ice cube tray rotates.

Tray again after 1 minute.*

→ There is air in the system.

Vent the water system (see Installation Instructions,

Water Connection).

→ The water connection is not open

Open the water connection*

The water flow at

the InfinitySpring

is irregular.*

→ The aerator is not clean.

Replace the aerator. Contact Customer Service

(see 9.4 Customer service) .

HydroBreeze is not

keeping refriger‐

ated foods moist.*

→ HydroBreeze is not activated.

Activate the HydroBreeze.

→ There is not enough water in the

water tank

Fill the water tank.

→ There is dirt upstream of the

concentrator.

Clean the HydroBreeze.

Customer support

32 * Depending on model and options

Defect Cause Remedy

→ The water tank is not properly

locked into place.

Make sure the water tank clicks in properly.

→ The lid of the Fruit & Vegetable-

Safe is set to “low air moisture”.

Adjust the lid of the Fruit & Vegetable-Safe to “high air

moisture”.

The interior light

does not turn on.

→ The appliance is not switched on.

Switch on the appliance.

→ The door was open for longer than

15 min.

The interior light automatically switches itself off if the

door stays open for approx. 15 min.

→ The LED interior light is faulty or

the lid is damaged.

Contact Customer Service (see 9.4 Customer service) .

9.4 Customer service

First check if you can fix the error yourself (see 9 Customer

support) . If this is not the case, please contact customer

service.

Please refer to the enclosed “Liebherr Service” brochure for

the address.

WARNING

Unprofessional repair!

Injuries.

Repairs and work on the appliance and the power supply

cable not described in the Manual (see 8 Maintenance)

should only be carried out by a qualified service provider.

A damaged power cable may only be replaced by the

manufacturer, the manufacturer’s Customer Service or a

similarly qualified person.

For appliances with an IEC connector, the change can be

made by the customer.

9.4.1 Contact Customer Service

Make sure to have the following appliance information to

hand:

Appliance name (model and index)

Service no. (service)

Serial no. (S no.)

Showing appliance info on the display (see Info) .

-or-

Referring to appliance info on the nameplate

(see 9.5 Rating plate) .

Take note of the appliance information.

Inform Customer Service: Tell us the problem and the

appliance details.

This will help us give you fast and accurate support.

Further instructions from customer service will follow.

9.5 Rating plate

The nameplate is located behind the drawers on the inside

of the appliance.

Fig. 84

(1) Appliance name (3) Serial no.

(2) Service no.

Information from the nameplate.

10 Decommissioning

Empty appliance.

Switch off the IceMaker .*

Switch off the appliance .

Pull out the power plug.

Remove the appliance connector if necessary: Pull it out

and, at the same time, move it from the left to the right.

Clean the appliance (see 8.6 Cleaning the appliance) .

Leave the door open to prevent bad smells

11 Disposal

11.1 Preparing appliance for disposal

Liebherr uses batteries in some of its appli‐

ances. In the EU, for environmental reasons,

legislation obliges the end user to remove

these batteries before disposing of the old

appliances. If your appliance contains

batteries, a corresponding notice is attached to

the appliance.

Lamps If you can remove the lamps yourself without

destroying them, also remove these before

disposal.

Take the appliance out of operation.

Appliance with batteries: Remove the batteries. For

description, see Maintenance chapter.

If possible: Remove lamps without destroying them.

11.2 Disposing of the appliance in an

environmentally friendly manner

The appliance still contains

valuable materials and must be

collected separately from

unsorted municipal waste so it

can be recycled.

Decommissioning

* Depending on model and options 33

Dispose of batteries separately

from the old appliance. You can

do this by returning the

batteries free of charge to

retailers or taking them to recy‐

cling centers and collection

centers for recyclable materials.

Lamps Dispose of removed lamps via

the respective collection

systems.

For Germany: You can dispose of the appli‐

ance free of charge via the class

1 collection containers at the

local recycling and recyclable

material collection centers.

When purchasing a new fridge/

freezer, if the sales area > 400

, retailers will also take back

the old appliance free of charge.

WARNING

Leaking refrigerant and oil!

Fire. The refrigerant contained within the appliance is envi‐

ronmentally friendly, but flammable. The oil contained

within the appliance is flammable. Escaping refrigerant and

oil can ignite if they are of high enough concentration and

are exposed to an external heat source.

Do not damage the pipelines of the coolant circuit and

the compressor.

Transport the appliance away without damaging it.

Dispose of batteries, lamps, and the appliance according

to the above specifications.

Disposal

34 * Depending on model and options

Disposal

* Depending on model and options 35

home.liebherr.com/fridge-manuals

Combined fridge-freezer with BioFresh

Issue date: 20230725

Part number index: 7080476-00

Liebherr-Hausgeräte Marica EOOD

Bezirk Plovdiv

4202 Radinovo

Bulgarien

Liebherr CBNBSD 576I Premium Fridge-Freezer BioFresh Technology and NoFrost Features CBNBSD 576I PRIME BIOFRESH NOFROST

Product's Documents

Operating instructions

Specifications

Liebherr CBNBSD 576I PRIME BIOFRESH NOFROST Questions and Answers
