OWNER’S MANUAL AND SAFETY INSTRUCTIONS
10FT PADDLE BOARD
ITEM # 99260
SAVE THIS MANUAL. KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATION, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S
SERIAL NUMBER ON THE BACK OF THE MANUAL, OR THE MONTH AND YEAR OF PURCHASE IF
PRODUCT HAS NO SERIAL NUMBER
FOR QUESTIONS, PLEASE CALL CUSTOMER SERVICE: 909.628.0880
SAFETY WARNINGS
Read all safety warnings and instructions. Failure to follow the warnings and instructions
may result in injury and/or property damage. Save all warnings and instructions for
future reference.
The warning and safety instructions in this manual are not meant to cover all possible conditions and
situations that may occur. Common sense, caution and care must be exercised when operating or
cleaning tools and equipment. Always contact your dealer, distributor, service agent or manufacturer
about problems or conditions you do not understand before operating the product.
1
Stand Up Paddle (abbreviated SUP) boards can be very dangerous and physically demanding.
The user of this product should understand that participating in stand up paddling may involve
serious injury or death.
Seek SUP instruction from a licensed or certied instructor.
Always check weather forecasts prior to using the SUP board. Never use the SUP board in
thunderstorms and lighting conditions.
Always use appropriate protective gear and wear a personal otation device. Wear the correct
protective clothing for the conditions such as a wetsuit or a UV top. Cold water and cold weather
can result in hypothermia. Always carry identication.
Wear a helmet when appropriate.
Do not exceed the maximum weight capacity.
Do not operate the SUP board under the inuence of drugs and/or alcohol.
This model is designed to be used in at waters (lake, rivers, sea shore) in standing and seating
position. It is not recommended to use the SUP board in high waves nor for surng.
Beware of offshore winds and currents as they can take you out to sea.
Tie the included leash to your SUP board at all times.
Check your equipment prior to each use for signs of wear, leaks or failure.
Do not allow children to use the SUP without adult supervision.
Always inform someone your paddling route, the time and place of departure and your intended
time and place of arrival. Paddling alone is not recommended.
Never leave your SUP board for an extended period of time on a warm surface like a beach or
other surfaces. This can cause damage to your board.
SAFETY WARNINGS ASSEMBLY
1 2
INFLATING THE PADDLE BOARD
1. Remove all sharp edged and pointed objects from the surface in order to avoid damaging the SUP
board.
2. Inate the SUP board with the included hand pump.
3. Unscrew the valve cap 1 . Push the button 2 in and turn approximately 90 degrees so it is in the “OUT”
position.
4. Insert the pump hose end piece and inate it until you will reach the required pressure. After ination
tighten all the valve cap (clockwise). Only the valve cap can ensure nal AIR TIGHTNESS.
5. To release air from the SUP board, remove the valve cap 1 and push the button 2 in and turn
approximately 90 degrees so it is in the “IN” position.
WARNING: The correct pressure for this SUP board is maximum 1 bar / 15 PSI (=1000 mBar) DO NOT
EXCEED THIS.
WARNING: Using an electrical pump or air compressor is at your own risk. This can lead to damaging
the SUP board.
DETACHABLE SKEG ON BACKSIDE OF SUP BOARD
It is recommended to use the detachable skeg in deep water, where it will allow you to move forward
in a straight line. Do not use it in shallow water because then the skeg can hit the bottom. The Skeg
can be placed on the SUP board if this is inated or deated. To assemble the skeg push the skeg in the
black part on the back side of the SUP board. To lock the skeg push the lock pin in the skeg base hole.
ASSEMBLY AND MAINTENANCE
3
ASSEMBLY INSTRUCTIONS INCLUDED PADDLE
The included paddle consists of 3 pieces. To adjust the paddle to the required length:
• Insert the bottom of pole 2 in to the top of pole 3. This can be xed when the pin on pole 2 is clicked
in the hole of pole 3.
• Open the button on top of pole 2 by pulling the button.
• Insert the bottom of pole 1 and choose the length that suits you. Click the pin (behind the button) of
pole 2 in to the hole of pole 1.
• The paddle length is adjustable from minimum length 1.70 mtr to maximum length 2.10 mtr.
ATTACHING THE LEASH
Before you start to use the SUP board rst attach included leash to the SUP board and yourself.
• Attach the leash to the metal ring on top of the SUP board.
• Attach the other side of the lease to your ankle. When you fall in the water the leash ensures that the
SUP board will not oat away.
MAINTENAINING THE SUP BOARD
• Clean and check the SUP board and all accessories. Use a mild, non scouring cleanser.
• Make sure the SUP board is completely dry before placing it in the backpack. Otherwise this may
cause mold, foul odor and the skin/hull or the inside chambers of the SUP board will suffer from water
damage.
REPAIRS
Although the SUP board has been manufactured of a reinforced and tough material, it is still possible to
cause holes or cracks when the SUP board is handled improperly. For the repair of a small damage a
repair kit is included.
• Prepare a round patch with repair material with correct measurements.
• Clean the repair material and the area around the leak with alcohol.
• Apply 3 thin, even coats of glue to both the surface of the board and the repair material. Wait 5
minutes between each coat.
• After the 3rd coat, wait 10-15 minutes before applying the repair material. Use a handroller to apply
the repair material evenly. Pay special attention to the edges
• Wait at least 24 hours before re-inating.
4
ASSEMBLY AND MAINTENANCE
DISCLAIMER
4
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE
OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED
TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR DISTRIBUTOR
EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN
BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES
ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR
REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT
PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available
individually as replacement parts.
MADE IN CHINA
