PureGear Universal Cradle Vent Mount
Type-C charging cable
*1
User Manual
*1
1. Connect the power supply
and power up the product.
2. Place the phone/ear-
phone/watch in the
corresponding charging
position and charge it
normally.
1. Smartphone： For non-MagSafe phones, please use an
extra
magnetic ring or MagSafe case to use this product.
2. Input compatibility: PD2.0-3.0 and other protocols
3. When the input is greater than 15V/3A, charge the phone
25W, headphones 5W, and watch 2.5W simultaneously
4. The maximum charging power is 25W for the iPhone
16-17 series and 15W for the iPhone 12-15 series; Samsung
phones have a maximum charging power of 10W; The
maximum charging power supported by Huawei
Android and other mobile phones are 5W.
Package
Functional component
Applicable Devices
LED intelligent indicator
Use steps
Product specification
1. Do not over-squeeze or collide with the equipment.
Caution
2. Please do not place it too close to the magnetic card (ID card,
bank card, etc.) with a magnetic stripe or chip to avoid magnetic
card failure.
3.Do not use 5V adapter as insufficient power which may cause
charging interruption. Please use15V adapter for power supply.
Size: 60x90mm
Material: 105G copperplate paper
Folding: Folding
Double-sided printing
1. Power On: Indicator light illuminates.
2. Standby: Indicator light remains on.
3. Charging Indicator: Indicator light is off while the phone is
charging.
4. Metal Detection: Indicator light flashes when a foreign object
is detected while the phone is charging.
1.
Mobile phone Wireless
PureGear Universal
Cradle Vent Mount
Charging Area
2.
Apple Watch
USER MANUAL
Wireless
Charging Area
3.
Charging indicator light
4.
Earphone charging area
5.
Type-C interface
1
2
3
4
5
• Material: PC+ABS+UV
• Input：9V⎓3A, 12V⎓3A, 15V⎓3A
• Earphone output: 5W
• Watch output: 2.5W
• Phone output: 5W, 7.5W, 10W, 15W, 25W
• Transmission Distance: ≤6mm
• Charging Efficiency: 86% MAX
• Frequency:
Earphone: 115-205KHz
Mobile phone: 115-205KHz, 360KHz
Watch: 320-330KHz
• Magnet: 16*N52 Magnets
• Pulling Force: 1.2kg MAX
FCC Statement
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two
conditions: (1) This device may not cause harmful interference,
and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
Note: This equipment has been tested and found to comply with
the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable
protection against harmful interference in a residential installation.
This equipment generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or
more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from
that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for
help.
Note: The Grantee is not responsible for any changes or
modifications not expressly approved by
the party responsible for compliance. such modifications could
void the user's authority to
operate the equipment.
The device has been evaluated to meet general RF exposure
requirement.
To maintain compliance with FCC's RF exposure guidelines, the
distance must be at least 20 cm
between the radiator and your body, and fully supported by the
operating and installation
configurations of the transmitter and its antenna(s).
*1
