1) Snap on to shelf, as shown.
2) When the clip is installed, the enclosure panel
wire will be snug in between the solid shelf
and the clip.
3) Repeat on all remaining clips.
Locks enclosure panel into place onto bottom solid shelf.
IMPORTANT: Please note the orientation of the clips in the above illustration.
Consists of…
• (2) right clips
• (2) left clips
INSTALLATION INSTRUCTIONS
Solid Shelving Clips
EG9892 Revised 02/24
CAUTION
INSPECT CONTENTS IMMEDIATELY AND FILE CLAIM WITH DELIVERING
CARRIER FOR ANY DAMAGE. SAVE YOUR BOX AND ALL PACKING MATERIALS.
YOU ARE RESPONSIBLE FOR DAMAGE TO YOUR UNIT IF RETURNED IMPROPERLY PACKED.
left clip
right clip
enclosure panel
wire
solid
shelf
right clip
right clip
in place
INSTRUCTION SHEET
#A228332
(End)
