Intelligent Locations Infant Beacon (ILAT-LB100) User Manual
Introduction:
Intelligent Locations’ infant beacon safety devices are wearable Bluetooth Low Energy
(BLE) technology leg bracelets for tracking infants.
Infant safety bracelet is intended to be used alongside our Infant security System. The
beacon remains in a halt state after when no band is connected. At this state there is no
advertising or any other function and could last 4 years on a single battery.
Once a band is connected, it will begin advertising, change ad rates depending on
motion (1 second interval with motion, 3 second interval without motion).
After 1 second of band connection, the capacitive sensor is ready to sense skin against
the beacon. A flag in the advertisement packet relays the state.
If band is removed or cut, the beacon will advertise for 5 minutes before it stops back to
the halt state.
The specifications for the infant beacon are as follows:
PERFORMANCE
• 32 - Bit ARM ® Cortex ® - M3 with 76.8 Mhz
SENSOR
• Accelerometer & Internal Temperature Sensor
(-40°C to 105 °C)
CONNECTIVITY
• Bluetooth LE 5.2 (direction finding)
POWER
• 3vCR2032 Coin Cell Battery (non-serviceable)
• Expected Lifetime Approximately 3yrs
(configuration-dependent)
PHYSICAL DIMENSIONS
• Length - 1.34in (34.04mm)
• Width - 1.25in (31.75mm)
• Height - 0.25in (6.35mm
The infant beacons are shipped in bulk to a customer site location. The Intelligent
Locations Account team is responsible for installing these beacons.
Additional Information
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
Class B:
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radi-ate radio frequency energy and, if not in-
stalled and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
