INSTRUCTIONS FOR USE
HIGH PRECISION SCALE
SPECIFICATIONS
• High precision strain gauge sensor
• Stainless steel weighing platform
• Units of measure include: grams (g), ounces
(oz), carats (ct), grains (gn), Troy ounces (ozt),
Tael (tl) and Pennyweight (dwt)
• Tare function
• Low battery and overload indicators
• Auto-o after three minutes or manual-o
• Capacity: 7 oz / 200 g
• Accuracy: 0.001 oz / 0.01 g
• Platform dimensions:
3" x 2.5" / 76 mm x 64.6 mm
• Blue backlight LCD screen dimensions:
0.9" x 0.4" / 23.8 mm x 11 mm
BATTERIES
• Requires 2 AAA batteries
(included).
• Remove isolation sheet
before use.
2
LCD SCREEN
3
Negative
Value
Weights
Gram Ounce Grain Carat Tael Troy Ounce Pennyweight
Tare
function
Mode and unit
conversion
Turn ON
Turn OFF
BUTTONS
TO REPLACE BATTERIES
• Open battery case cover underneath the scale.
• Take out the used batteries and install new ones.
Make sure to respect the polarity.
• Close battery case cover.
TARE FUNCTION
To weigh dierent loads consecutively without
removing loads from the scale, put the first load
4
UNIT CONVERSION
• Press button to switch
the weight measure.
WEIGHING MODE
• Place the scale on a solid
and flat surface.
• Press button to turn
on the scale.
• Wait until LCD screen shows “0.0”
to start weighing.
• Press button to convert
to weight mode if needed.
• Load weighing object on scale.
Always place the object in the
center of the platform. LCD screen
will show the weight reading.
on the scale to obtain a weight reading. Press
button to reset the LCD reading to “0.00” before
adding next load. You can repeat operation.
INDICATORS
1. Please replace batteries.
2. Remove item to avoid damage.
Maximum capacity of this scale
is 7 oz / 200 g.
3. Place the scale on a flat
and stable position.
AUTO SHUT OFF & MANUALLY SHUT OFF
Auto shut o occurs if display
shows “0” or shows the same
weight reading for 3 minutes.
To maximize battery life, it is
recommended to shut o manually
the scale. Press button
for 3 seconds and the scale will
turn o.
5
6
ADVICE FOR USE & CARE
− Always use the scale on a hard fl at surface.
− Clean the scale with a slightly damp cloth.
− Avoid contact with water. DO NOT immerse
the scale in water.
− All plastic parts should be cleaned immediately
after contact with fat, spices, vinegar
and strongly fl avored /colored food.
− Avoid contact with acid citrus juices.
− DO NOT use chemical or abrasive
cleaning agents.
− Not for commercial use.
