Installation Preparation Worksheet
110V Models
Water
• Incoming Pressure: 3-6 bar (45-90psi)
Flow: 0.5 GPM min
• 3/8” BSP or Compression Male w/ shut-off
• Must be located within 4 feet of machine
Filter
• Proper water filtration is highly recommended. Any
damage determined to be caused by water quality will
not be covered by warranty.
• Ensure filter is rated to reduce/eliminate scale and
chloramines (ice maker filters are detrimental for
espresso use)
• Check with your local service provider for water
treatment recommendations in your area
• Hardness: 3-5gpg / TDS: 50-125ppm / Free Chlorine:
0.5ppm max / Total Chlorine: 1 ppm max / pH: 6.5-7.5
Drain
• 1.25” minimum open gravity drain
• Must be located within 4 feet of machine
Counter
• 2.5” access hole with collar (no sharp edges)
• Hole centered under rear of machine
Please use this reference to ensure your site is ready for installation. When
ready, complete the online Installation Request Form by clicking the link or
scanning the QR Code below. PLEASE NOTE: It is the customer’s
responsibility to ensure the site is ready for installation. The included
installation must be performed in one trip. Payment for any return trips
needed if the site is not ready will be the customer’s responsibility.
For setup and calibration of unit, please ensure “Day of Install” requirements
are available: 2lbs minimum whole bean coffee in grinder/shot glass/staff.
*Technicians may provide basic machine operational training to staff at time
of install. They are not authorized to conduct Café/Barista training or
additional visits to conduct training at a later date.
If you have any questions about the requirements or would like assistance
with verifying site readiness, please email:
unic.usa.service@electroluxprofessional.com
Power
• NEMA 5-20R receptacle required
• 110V / 20A / 60Hz / 1700W
• Must be located within 4 feet of machine
Business Name:
____________________________
Street Address:
____________________________
City/State/Zip:
____________________________
Serial# (Not PO or Invoice#):
____________________________
Customer Name:
____________________________
Customer Phone Number:
____________________________
Scan code or click link
to access online
request form
https://forms.bluecatreports.com/uAGFda60/electrolux-professional-espresso-
machine-installation-request
