HYMT5200X-1 Manual a3c4a7fb-4fbe-436c-92f9-c3a972572311

This is the main product document for model HYMT5200X-1. Additionally, the document applies to other Hyundai models: 5059608430004

The file format is pdf, 1 pages, you can download this manual here .

Give Review

Re-Filling Nylon Line Trimmer Head

Rotate the blue centre piece to align

the arrow mark with the holes.

Check that the two holes are aligned.

Pass the nylon rope through the two holes

until you have 2m each side.

Use 4m of 2.4mm nylon trimmer line.

Turn the blue centre piece clockwise until

there is 20cm of line remaining.

1 2

3 4

Phone

01646 687 880

[email protected]

Online Live Chat

www.hyundaipowerproducts.co.uk

Need Help?

www.hyundaipowerproducts.co.uk

New Trimming Head Coming Soon

File type: PDF

File name: 50231881_hymt5200x-1.pdf

File Language: English

Pages: 1

Author: Hyundai

Published: 2026-05-30

Updated: 2026-05-30

Source: Directly manufacturer

Download: Save file

Specifications

Brand: Hyundai

Model: HYMT5200X-1

Grass Trimmer Cutting Width mm: 430

Line Diameter mm: 2.4 - 2.5

Brushcutter Width mm: 255

Hedge Trimmer Cutting Length mm: 425

Hedge Trimmer Cutting Capacity mm: 24

Engine Size cc: 52

Fuel Capacity L: 1.2

Gross Weight kg: 15.65

Net Weight kg: 13.7

Fully Assembled Dimensions H x W x L mm: 265 x 250 x 1920 Brush Cutter 265 x 250 x 1880 Grass Trimmer 265 x 250 x 2000 Chainsaw 265 x 250 x 2220 Hedge Trimmer

Package Dimensions H x W x L mm: 300/120 x 290 x 1110

Engine Capacity CC: 50-100

Max Cutting Speed RPM Grass Trimmer: 6525

Max Cutting Speed RPM 3 Tooth Blade: 6900

Max Cutting Speed RPM Hedge Trimmer: 1550

Chain Lubrication: Automatic oil pump system

Chain Speed RPM m/s: 20

Handle Type: Loop and Bar

With Harness?: Yes

Engine Model: 52cc 2-Stroke EURO 5 emissions

Engine Type: 2-Stroke, Single Cylinder

Rated Speed RPM: 9200

Fuel: Unleaded Petrol Mixed 40:1 with Semi-Synthetic 2-Stroke Oil

Engine Oil: Unleaded Petrol Mixed 40:1 with Semi-Synthetic 2-Stroke Oil

Rated Power kW/kVA: 1.45/2

Fuel Type / Power Source: Petrol 2-Stroke Engine

Fuel/Power Source: Petrol 2-Stroke Engine

Indexed Terms: Multi Tool, Petrol
