STEP 1: STEP 1: STEP 2: STEP 3:
Caution
Cut hole only in ductwork
to prevent accidental
cutting of wires or
refrigerant pipes
Make a starting hole and
then use a metal shear to
create two openings
Test fit the device to
ensure proper fit for flush
mount
Use sheet metal screws
provided to secure the UV air
sanitizer
INSTALLATION TEMPLATE
Place this label on
desired location
for installation
Use a 2-1/4” drill to
create two openings
ELECTRICAL INPUT: 24V DC 50/60Hz 1A
WARNING: AVOID EXPOSING UNPROTECTED
EYES AND BARE SKIN TO UV-C
REPLACE LAMP ANNUALLY OR AS ADVISED
To order replacement lamp: www.BioShieldUV.com
OR
For 2-1/4 Drill Bit For 2-1/4 Drill Bit
BioShield18
Ultraviolet Treatment Systems
