1. Applications
2. Health & Safety Information
Important: EN149:2001+A1:2009 single-use respirators against solid and liquid aerosols are classied
according to one of three categories - FFP1, FFP2 and FFP3.
Check the category to which the respirator belongs to ensure suitable for your intended use - this is indicated
on the packaging and on the respirator.
• FFP1: Protection against non-toxic solid and liquid aerosols (e.g. oil-mists) in concentrations up to
4 x MAC/OEL/TLV, [i.e. NPF = 4 ] or 4 x WEL, [i.e. APF = 4].
• FFP2: Protection against non-toxic and low-to-average toxicity solid and liquid aerosols (e.g. oil-mists)
in concentrations up to 12 x MAC/OEL/TLV, [i.e. NPF = 12] or 10 x WEL, [i.e. APF = 10].
• FFP3: Protection against non-toxic, low-to-average toxicity and high toxicity solid and liquid aerosols
(e.g. oil-mists) in concentrations up to 50 x MAC/OEL/TLV,[i.e. NPF = 50] or 20 x WEL, [i.e. APF = 20].
*NOTE:
MAC = Maximum Admissible Concentration OEL = Occupational Exposure Limit.
TLV = Threshold Limit Value NPF = Nominal Protection Factor.
WEL = Workplace Exposure Limit APF = Assigned Protection Factor.
82480 - FFP1
WARNING! Failure to follow all instructions and limitations on the use of this product could
reduce the eectiveness of the mask and result in sickness or death.
• Never alter or modify this mask in any way.
• Only designed for single use and up to 8 hours. Do not use if damaged, clogged or removed in a
contaminated area.
• Inspect the mask for damage before use and if damaged do not use.
• Keep the mask in the packaging until required for use.
• Use only in adequately ventilated areas.
• Do not use in explosive atmospheres.
• Store in a dry, warm and frost-free area.
• Keep out of direct sunlight and away from solvents.
EN
Original Instructions
Version 2 – January 2026
DUST MASKS
82489/82567, 82569 - FFP3
21244 - FFP3
82482/82483/82486 - FFP2
82565/82566/82488 - FFP2
3. Using the Mask
1. Remove the mask from the packaging.
1 Fig.
2. Open the folded mask and place the lower strap over your head (1).
2 Fig.
3. Place the mask over your mouth and nose (2).
3 Fig.
4. Position the upper strap over and to the back of the head (3).
(1)
(3)
(2)
4. Explanation Of Symbols
5. Notied Body
4 Fig.
5. Squeeze the nose bar around your nose (4).
• Ensure a good seal is created around the mask.
(4)
Read the instruction manual
Warning!
D
This respirator passes the optional
Dolomite clogging test for more
comfortable breathing
NR
This respirator is limited to single shift
use only (with a maximum of 8 hours) and
shall not be re-used
BSI GROUP THE NETHERLANDS
John. M. Keynesplein 9
1066 EP Amsterdam
Netherlands
Notied Body Number: 2797
BS EN 149:2001+A01:2009
© Published by Draper Tools Limited 0126
Draper Tools Europe B.V.
Oude Graaf 8
6002 NL
Weert
Netherlands
Contact Details
Draper Tools Limited
Hursley Road
Chandler’s Ford
Eastleigh
Hampshire
SO53 1YF
UK
Website: drapertools.com
Email: [email protected]
Product Helpline: +44 (0) 23 8049 4344
Telephone Sales Desk: +44 (0) 23 8049 4333
General Enquiries: +44 (0) 23 8026 6355
Please contact the Draper Tools Product Helpline for repair and servicing enquiries.
