PRECAUTIONS - 2791477B892/A
e
PRECAUTIONS 27
General safety instructions 27
Installation 30
Appliance purpose 31
This user manual 31
Manufacturer’s liability 31
Identification plate 32
Disposal 32
To save energy 32
Information on power consumption in off/stand-
by mode 32
Light sources 32
How to read the user manual 32
DESCRIPTION 33
General description 33
USE 34
Preliminary operations 34
Basic functions 34
Using the hob 35
Cooking information tables for 145 mm zones
using the “” function 42
Cooking information tables for 210 mm zones
using the “” function 43
Cooking information table for ““ function 43
Settings menu 44
Power limitation menu 44
Error notifications 45
CLEANING AND MAINTENANCE 45
Cleaning the glass ceramic hob 45
What to do if... 46
INSTALLATION 46
Electrical connection 46
Section cut from the countertop 47
Mounting 47
Ventilation 48
Fastening to the built-in cabinet 48
Testing 48
Instructions for the installer 48
We advise you to read this manual carefully, which contains all the instructions for
maintaining the appliance’s aesthetic and functional qualities. For further information on the
product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• During use the appliance
and its accessible parts
become very hot. Keep
children well away from the
appliance.
• Protect hands with heat
resistant gloves during use.
• Never try to put out a fire or
flames with water: Turn off
the appliance and smother
the flames with a fire
blanket or other appropriate
cover.
• This appliance may only be
used by children aged 8
years and over, and by
people of reduced physical,
sensory or mental capacity,
or lacking in experience in
the use of electrical
appliances, provided that
they are supervised or have
been given instructions on
the safe use of the
appliance and of the
hazards associated with it.
• Children must not play with
the appliance.
• Keep children under the age
of eight at a safe distance
unless they are constantly
supervised.
• Keep children under the age
of 8 away from the
appliance when it is in use.
• Cleaning and maintenance
must not be carried out by
unsupervised children.
• Be aware of how rapidly
28 - PRECAUTIONS 91477B892/A
the cooking zones heat up.
Do not place empty pans on
the heat. Danger of
overheating.
• Activate the controls lock
when you have children or
pets which could reach the
hob.
• Do not touch or clean the
hob surface during
operation or when the
residual heat indicator
lights are still on.
• After use, switch off the
plates. Never rely solely on
the cookware detector.
• Supervise children carefully
as they cannot readily see
the residual heat indication.
After use the cooking zones
remain hot for a certain
period of time even if they
have been turned off. Keep
children away from the
cooking zones.
• The cooking process must
always kept under control.
A short cooking process
must be continuously
monitored.
• WARNING: Cooking foods
containing fat and/or oil
without monitoring them
can be dangerous and can
cause a fire.
• Fats and oils can catch fire
if they overheat. Do not
leave the appliance
unattended while preparing
foods containing oils or fats.
If fats or oils catch fire,
never put water on them.
Place the lid on the pan and
turn off the relevant cooking
zone.
• Do not use the Booster and/
or the Double Booster
functions (if present) to heat
fats or oils. Fire hazard.
• Do not place metal objects,
such as dishes or cutlery, on
the surface of the hob
during cooking as they may
overheat.
• Do not cook foods in closed
tins or containers or plastic
containers.
• Do not use magnetic tins.
• Do not use trivets or other
items between the bottom
of the pan and the glass
ceramic surface. Danger of
burns.
• Do not insert pointed metal
objects (cutlery or utensils)
into the slots in the
appliance.
• Do not use or store
flammable materials near
the appliance or directly
underneath the hob.
• Switch off the appliance
immediately after use.
• Do not pull the cable to
unplug the appliance (if
present).
•DO NOT USE AEROSOLS
IN THE VICINITY OF THIS
APPLIANCE WHILST IT IS
IN USE.
• DO NOT MODIFY THIS
APPLIANCE.
• Always wear personal
protective equipment (PPE)
PRECAUTIONS - 2991477B892/A
e
before carrying out any
work on the appliance
(installation, maintenance,
positioning or moving).
• Do not clean the appliance
if it is still hot or in
operation.
• After use the cooking zones
remain hot for a certain
period of time after they
have been turned off. Do
not touch the hob surfaces.
• Before performing any work
on the appliance, switch off
the power supply.
• Do not try to repair the
appliance yourself or
without the assistance of a
qualified technician.
• If the power cable becomes
damaged, contact technical
support immediately to
arrange for it to be replaced
in order to avoid possible
hazards.
• If cracks or fissures form, or
if the glass ceramic cooking
surface breaks, turn off the
appliance immediately.
Disconnect the power
supply and call Technical
Support.
• People who have
pacemakers or other similar
devices fitted must make
sure that the operation of
these devices is not
affected by the induction
field, the frequency range of
which is between 20 and
50 kHz.
Risk of damaging the appliance
• Do not use abrasive or
corrosive detergents (e.g.
scouring powders, stain
removers and metallic
sponges) on glass parts.
• Use wooden or plastic
utensils.
• Do not sit on the appliance.
• Do not use the glass
ceramic cooking surface as
a support surface.
• Do not use the appliance as
a support surface.
• Do not obstruct ventilation
openings and heat
dispersal slots.
• Do not use the hob if the
pyrolytic cycle is taking
place inside any oven
installed below.
• Do not use steam jets to
clean the appliance.
• Never leave the appliance
unattended during cooking
operations where fats or
oils could be released, as
these could then heat up
and catch fire. Be very
careful.
• Fire hazard: Never leave
objects on the cooking
surfaces.
• DO NOT FOR ANY
REASON USE THE
APPLIANCE AS A SPACE
HEATER.
• Cooking vessels or griddle
plates should be placed
inside the perimeter of the
hob.
• All pans must have smooth,
30 - PRECAUTIONS 91477B892/A
flat bottoms.
• If any liquid does boil over
or spill, remove the excess
from the hob.
• Take care not to spill acid
substances such as lemon
juice or vinegar on the hob.
• Do not spill sugar or sweet
mixtures on the hob during
cooking.
• Do not place materials or
substances that could melt
or catch fire (paper, plastic
or aluminium foil) on the
appliance while it is in use.
• Place the cookware directly
on the glass ceramic
surface.
• Do not put empty pans or
frying pans on switched on
cooking zones.
• Do not use rough or
abrasive materials or sharp
metal scrapers.
• The glass ceramic surface
is highly resistant to impact.
However, prevent hard,
solid objects from falling on
the cooking surface as they
may cause it to break.
• Do not use cleaning
products containing
chlorine, ammonia or
bleach on parts made of
steel or that have metallic
surface finishes (e.g.
anodizing, nickel- or
chromium-plating).
• This appliance is not
intended to be operated by
means of external timer or
separate remote control
system.
• To prevent scratching the
glass surface, avoid sliding
pots across it. Lift them and
place them gently where
needed instead.
Installation
• THIS APPLIANCE MUST
NOT BE INSTALLED IN
BOATS OR CARAVANS.
• Position the appliance into
the cabinet cut-out with the
help of a second person.
• Check that the carcase has
the required openings.
• Check that the carcase
material is heat resistant.
• Installation and servicing
should be carried out by
qualified personnel in
accordance with current
standards.
• Have the electrical
connection performed by
authorised technical
personnel.
• The appliance must be
connected to earth in
compliance with electrical
system safety standards.
• Use cables that can
withstand temperatures of
at least 90°C.
• Run the power cable in the
rear part of the unit. Make
sure that it does not come
into contact with the lower
part of the hob or a built-in
oven below it.
• Be careful when connecting
additional electrical
appliances. Connection
PRECAUTIONS - 3191477B892/A
e
cables must not come into
contact with hot cooking
zones.
• The tightening torque of the
screws of the terminal
supply wires must be 1.5 -
2 Nm.
• Do not attach the appliance
too tightly to the unit as this
could cause damage during
use or partially obstruct the
heat dispersal slots.
• The power cable must only
be installed or replaced by a
qualified technician.
• If the power cable becomes
damaged, contact technical
support immediately to
arrange for it to be replaced
in order to avoid possible
hazards.
• Always use any necessary/
required personal
protective equipment (PPE)
before performing any work
on the appliance
(installation, maintenance,
positioning or movement).
• Before performing any work
on the appliance, switch off
the power supply.
• Allow the appliance to be
disconnected after
installation, via an
accessible plug or a switch
in the case of a fixed
connection.
• Fit the power line with an
all-pole circuit breaker with
a contact separation
distance sufficient to
provide complete
disconnection in category III
overvoltage conditions,
pursuant to installation
regulations.
• This appliance can be used
up to a maximum altitude of
2,000 metres above sea
level.
Appliance purpose
This appliance is intended for
cooking food in the home
environment. Every other use
is considered improper. It
must also not be used:
• In kitchen areas provided
for employees in shops,
offices and other work
environments.
• in farms/farmhouses.
• By guests in hotels, motels
and other types of
residential environments.
• In bed and breakfasts.
This user manual
• This user manual is an integral part of
the appliance and must therefore be
kept in its entirety and within the user's
reach for the whole working life of the
appliance.
• Read this user manual carefully before
using the appliance.
• The explanations in this manual include
images, which describe all that regularly
appears on the display. However, it
should be kept in mind that the
appliance may be equipped with an
updated version of the system, and as
such, all that appears on the display
may differ from those in the manual.
Manufacturer’s liability
The manufacturer declines all liability for
damage to persons or property caused by:
• use of the appliance other than that
This appliance may only
be installed and used
indoors.
32 - PRECAUTIONS 91477B892/A
specified;
• failure to comply with the instructions in
the user manual;
• tampering with any part of the
appliance;
• use of non-original spare parts.
Identification plate
The identification plate bears the technical
data, serial number and brand name of the
appliance. Do not remove the identification
plate for any reason.
Disposal
This appliance conforms to the WEEE
European directive (2012/19/EU) and
must be disposed of separately from
other waste at the end of its service life.
The appliance does not contain substances
in quantities sufficient to be considered
hazardous to health and the environment,
in accordance with current European
directives.
To dispose of the appliance:
• Cut the power cable and remove it.
• Deliver the appliance to the appropriate
recycling centre for electrical and
electronic equipment waste, or return it
to the retailer when purchasing an
equivalent product, on a one for one
basis.
Our appliances are packaged in non-
polluting and recyclable materials.
• Deliver the packing materials to the
appropriate recycling centre.
To save ener g y
• The diameter of the base of the pan
must not extend beyond the lines
printed on the glass ceramic surface.
• Pans must not be placed outside the
perimeter of the hob or on the display.
• When buying a pan, check whether the
diameter indicated is that of the base or
the top of the pan, as the top is almost
always larger than the base.
• When preparing dishes with long
cooking times, you can save time and
energy by using a pressure cooker,
which also helps to retain vitamins
contained in the food.
• Make sure that the pressure cooker
contains enough liquid as, if there is not
enough and it overheats, this may cause
damage to both the pressure cooker and
the cooking zone.
• If possible, always cover pans with a
suitable lid.
• Choose a pan suitable for the quantity
of food to be cooked. A large, half-
empty saucepan leads to a waste of
energy.
Information on power
consumption in off/stand-by
mode
Technical data on the appliance's power
consumption in off/stand-by mode can be
found at www.smeg.com under the page
corresponding to the product in question.
Light sources
• This appliance contains light sources
which cannot be replaced by the user
and must only be replaced by the
technical assistance service.
• This appliance contains light sources of
efficiency class "F".
How to read the user manual
This user manual uses the following reading
conventions:
Power voltage
Danger of electrocution
• Disconnect the mains power supply.
• Unplug the appliance.
Plastic packaging
Danger of suffocation
• Do not leave the packaging or any part
of it unattended.
• Do not let children play with the plastic
bags.
Under certain circumstances, if the
hob and the oven are used at the
same time, the maximum power
limit of the electrical system might
be exceeded.
Warning/Caution
DESCRIPTION - 3391477B892/A
e
DESCRIPTION
General description
1. Central cooking zone
2. Control panel button
Left: Left multizone zone
Right: Right multizone zone
*Power levels are approximate and may
vary according to the pan used or the
settings made.
Advantages of induction cooking
• Energy saving thanks to the direct
transmission of energy to the pan
(suitable magnetisable cookware is
required) compared to traditional
electric cooking.
• Improved safety as the energy is only
transmitted to the pan placed on the
hob.
• High level of energy transmitted from
the induction cooking zone to the base
of the pan.
• Rapid heating speed.
• Reduced danger of burns as the cooking
surface is only heated under the base of
the pan; foods which overflow do not
stick.
Power control
The hob is fitted with a power control
module that optimises/limits consumption. If
the overall set power level exceeds the
maximum limit permitted, the electronic
circuit board will automatically manage the
power supplied by the hot plates. The
module tries to maintain the maximum
deliverable power levels. Levels set by the
automatic control will appear on the
display.
Information/Advice
60
Zone
Dimensions H x L
(mm)
Maximum power
consumption Level
9 (W)*
Power draw in Boo-
ster function (W) *
Power draw in Dou-
ble Booster function
(W)*
Right - Left zone
(Single)
190 x 210 2100 2500 3000
Right - Left zone
(Multizone)
360 x 240 3000 3700 -
Zone 1 200 x 200 2300 3000 -
The appliance is equipped with an
induction generator for each cooking
zone. Each generator located under
the glass ceramic cooking surface
creates an electromagnetic field
which induces a thermal current in
the base of the pan. This means the
heat is no longer transmitted from
the hob to the pan but created
directly inside the pan by the
inductive current.
Priority is given to the last zone set.
34 - USE 91477B892/A
USE
Preliminary operations
• Remove any protective film from the
outside or inside of the appliance,
including any accessories (if present).
• Remove any labels (apart from the
technical data plate).
Cookware suitable for use in induction
cooking
Cookware used on the induction cooking
surface must be made of metal, with
magnetic properties and a sufficiently large
base.
Suitable cookware:
• Enamelled steel cookware with thick
bases.
• Cast iron cookware with an enamelled
base.
• Cookware in multilayer stainless steel,
ferritic stainless steel and aluminium
with a special base.
Unsuitable cookware:
• Copper, stainless steel, aluminium,
fireproof glass, wood, ceramic and
terracotta cookware.
If an unsuitable pan is placed on the
surface of the appliance, the display
shows a question mark at the top. If the
pan is selected on the display and a
power level is set, the selected power
level number is shown in red, indicating
that the operation cannot be
completed. Touch the question mark
icon to display the error message.
Touch the icon again to close the
error message. To resolve the issue,
remove the current pan and use one
suitable for induction cooking.
Cookware diameters
To ensure that the appliance detects the
containers correctly and for best results, use
the pan sizes indicated in the following
table.
Bear in mind the following:
• Pans should not extend beyond the lines
marked on the surface of the appliance.
• Do not place pans near to the edges of
the hob or close to the control panel.
• Any griddle must have a maximum size
of 36 x 19 cm.
• Do not use a griddle on zone 1.
Basic functions
First connection to the power
When the appliance is first connected
to the power supply, or after a power
cut and subsequent restoration, the
display shows the factory-set time for
about 20 seconds.
Switching on and off
Press the button to switch the
appliance on or off. When switched on, the
display shows the main screen
The power control module does not
affect the total power consumption
of the appliance.
See General safety instructions.
Cooking zones
Minimum dia-
meter (mm)
Recommended
diameter (mm)
Left (Single) 110 180
Left (Multizone) 190 220
Right (Single) 110 180
Right (Multi-
zone)
190 220
1 110 200
2 90 160
The factory-set display language is
English. To change the language,
see “Settings menu”.
USE - 3591477B892/A
e
accompanied by an audible signal:
Below the clock indicator is the menu bar,
which groups together the icons associated
with the following functions (see “Menu bar
functions”):
To switch the device off, press the
button until an acoustic signal is emitted.
The current time is displayed for approx. 20
seconds.
Lighting
When the appliance is switched on, the
LED light at the base of the hob comes
on and remains lit for the entire
duration of use.
The LEDs also stay on when the hob is
switched off, indicating that the zone is
still hot. They go out once the
temperature has dropped and the “H”
symbol disappears (see “Residual heat”
chapter).
Summary table of power levels
The pans shown on the display appear
in different colours according to the
power level.
•Level 0: blue.
• 1-1.5-2-2.5-3-3.5: blue / red.
• 4-4.5-5-5.5-6-6.5: red
• 7-7.5-8-8.5-9: red / orange.
•B e B²: orange
Using the hob
Automatic activation of cooking zones
After switching on the appliance:
1. Position a pan (suitable for induction
cooking and not empty) on the
cooking zone you wish to use.
• The zone on the display
corresponding to the zone on which
the container has been placed turns
on in automatically.
Controls lock
Independent timer
Pause function
Settings menu
Power level Suitable for:
0 OFF position
1 to 2
Cooking small quantities of
food (minimum power)
3 to 4 Cooking
5 to 6
Cooking large quantities of
food, roasting larger portions
7 to 8
Roasting, slow frying with
flour
9Roasting
B/B²
Bringing large quantities of
water to a boil (maximum
power, see “Booster fun-
ction”)
The hob is equipped with a pan
detection system that
automatically selects the zones
on which a suitable pan has
been placed.
If a pan is moved from one zone
to another on the hob, the
display automatically shows the
new zone where it is placed and
all previously set parameters are
maintained (if it is moved while
the “pause” function is active,
the settings are not transferred).
36 - USE 91477B892/A
Adjusting the cooking zones
After placing a pan and ensuring that
the zone has been activated:
1. Press the zone you wish to control.
The buttons and and the power
level scroll bar will now appear.
2. Press to select a power level from 1
to 9, or activate the Booster or
Double Booster functions (see
dedicated chapters).
The display of the zone being used will
indicate the selected power level.
Switching the cooking zones off
1. Select the desired zone and set the
power level to “0”, or press twice in
the centre of the cooking zone you
wish to switch off.
Booster Function
After switching on the hob and having
selected a zone to activate the function:
1. Press the B button.
2. The Booster function is now activate
and the cooking zone display will
show the letter “B”.
To deactivate the Booster function,
simply reduce the power level of the
cooking zone or press twice in the
centre of the zone you wish to switch
off.
Double Booster Function
The Double Booster function allows
more power to be supplied compared
to the Booster function.
To activate it, after selecting a cooking
zone, press the B² icon.
To cancel the function, simply set a
different power level or press twice in
the centre of the zone you wish to
switch off.
Multizone function
After switching on the hob:
1. Press the icon .
• The two zones now become one single
larger one.
2. Press the centre of the zone and set the
desired power level or select a function.
Depending on the level set, the
zone changes colour: from blue
for level “0” to orange for the
“Booster” mode.
To switch off more than one
cooking zone at the same time,
simply switch the appliance off
using the key .
• The Booster function remains
active for a maximum of 15
minutes, after which the
power level automatically
drops to 9.
• If the internal temperature is
too high, the Booster function
will be temporarily disabled.
See General safety instructions.
• The Double Booster function
remains active for a
maximum of 15 minutes, after
which the power level
automatically drops to 9.
• If the internal temperature is
too high, the Booster function
will be temporarily disabled.
This function allows you to operate
two cooking zones (front and rear)
at the same time when using pans
such as fish kettles or rectangular
containers.
This function can only be activated
with the left or right zones.
It is not possible to activate the
Booster or Double Booster function
on the relevant zones when this
function is active.
USE - 3791477B892/A
e
If a large, oval or oblong pan is being used,
make sure that it is placed in the centre of
the cooking zone.
To deactivate the function:
Press the “x” button; the two zones can now
be adjusted separately.
Residual heat
After a cooking zone has been
switched off, if it is still hot, the
symbol will appear on the display; this
also applies when the hob is switched
off. The LEDs remain lit to indicate that
the zone is still hot. The symbol clears
once the temperature drops below
60°C.
Controls lock
This function is useful when cleaning
the appliance and to prevent accidental
interactions.
To activate the control lock:
1. Press the key for at least one
second.
2. To deactivate the control lock, hold
down the button as shown in the
figure below.
Autonomous timer
This function is used to set a timer
which will sound a buzzer at the end of
the set time. It does not stop the
operation of the cooking zones but
rather informs the user when the set
minutes have run out.
After having switched on the hob,
If part of the pan is moved outside
the zone, the function is deactivated.
If an error occurs while the function
is active, it will automatically be
deactivated.
This function is designed to lock
all hob keys.
The timer can be set from 1
minute to 99 minutes.
38 - USE 91477B892/A
without having selected any zone:
1. Press the button.
2. Set the desired time and press the
button.
Pause function
To activate the Pause function:
1. Press the pause button .
To deactivate the Pause function:
2. Pres in the centre of the display.
3. The pause function has now been
deactivated and the previously set
functions are restored.
Temperature holding
To activate the function, after switching
on the hob, select a previously used
cooking zone:
To quickly reset the timer to
00:00, press the
button.
Using the minute minder does
not stop the operation of the
cooking zones but rather informs
the user when the set minutes
have run out.
This function pauses the
operation of all the cooking
zones.
During the Pause function, the
cooking duration limit, residual
heat indicators and control lock
function remain active.
When the power comes back on
after a power failure, the pause
function deactivates.
This function allows food to be
kept at a certain temperature or
to maintain water at boiling
point. It can be activated, for
example, during the “frying” or
“boiling” functions.
Before activating the function,
the pan must have already
reached the desired
temperature.
USE - 3991477B892/A
e
1. Press the button and select .
2. Press the icon again.
3. Use the arrow keys to increase or
decrease the temperature.
To deactivate the function, press twice
in the centre of the zone you wish to
switch off, select another function, or
press “OFF”.
Boiling
To activate the function, after switching
on the hob, select a cooking zone:
1. Press the button and select .
2. Follow the instructions shown on
the display.
3. To deactivate the function, press
twice in the centre of the zone you
wish to switch off, or select another
function.
Pasta
To activate the function, after switching
on the hob, select a cooking zone:
1. Press the button and select .
The icon flashes; when it
becomes steady, the function
can be adjusted.
When the function is active, it is
possible to set an automatic
switch-off timer. To do so, select
the zone and press the
button. Set the desired duration,
after which an audible signal will
sound and the zone will switch
off. Press to stop the sound.
This function allows you to boil
water.
Only use water that is at room
temperature.
When the function is active, it is
possible to set an automatic
switch-off timer. To do so, select
the zone and press the
button. Set the desired duration,
after which an audible signal will
sound and the zone will switch
off. Press to stop the sound.
This function allows pasta to be
cooked; follow the instructions
shown on the display.
Do not add any additional liquid
once the function is active.
Only use water that is at room
temperature.
40 - USE 91477B892/A
2. Follow the instructions shown on
the display.
3. To deactivate the function, press
twice in the centre of the zone you
wish to switch off, or select another
function.
Roasting
To activate the function, after switching
on the hob, select a cooking zone:
1. Press the button and select .
2. Follow the instructions shown on
the display.
3. Select the level according to what
you wish to cook.
4. Confirm with the button.
5. To deactivate the function, press
twice in the centre of the zone you
wish to switch off, select another
function, or press “OFF”.
Steam cooking
To activate the function, after switching
on the hob, select a cooking zone:
1. Press the button and select .
2. Press the icon again.
3. Use the arrow keys to increase or
decrease the steam level.
4. To deactivate the function, press
twice in the centre of the zone you
wish to switch off, select another
function, or press the “OFF” button.
When the function is active, it is
possible to set an automatic
switch-off timer. To do so, select
the zone and press the
button. Set the desired duration,
after which an audible signal will
sound and the zone will switch
off. Press to stop the sound.
Do not add water after the pasta
has been placed in the pan.
This function allows you to fry
foods in the best way.
When the function is active, it is
possible to set an automatic
switch-off timer. To do so, select
the zone and press the
button. Set the desired duration,
after which an audible signal will
sound and the zone will switch
off. Press to stop the sound.
Only use water that is at room
temperature.
The use of an accessory is
required for steam cooking.
Useful for steaming food.
The icon flashes; when it
becomes steady, the function
can be adjusted.
When the function is active, it is
possible to set an automatic
switch-off timer. To do so, select
the zone and press the
button. Set the desired duration,
after which an audible signal will
sound and the zone will switch
off. Press to stop the sound.
USE - 4191477B892/A
e
Melting
To activate the function, after switching
on the hob, select a cooking zone:
1. Press the button and select .
2. To deactivate the function, press
twice in the centre of the zone you
wish to switch off, or select another
function.
Keep warm
To activate the function, after switching
on the hob, select a cooking zone:
1. Press the button and select .
2. To deactivate the function, press
twice in the centre of the zone you
wish to switch off, or select another
function.
Simmer
To activate the function, after switching
on the hob, select a cooking zone:
Time (min) Food Quantity
15
Chicken breast around 300 g
10 - 15
Fish fillet around 600 g
6
Eggs
6 medium
eggs
6 - 7
Broccoli around 350 g
20 - 30
Small whole
potatoes
around 400 g
15 - 20
Peas around 400 g
Useful for keeping food hot or
melting chocolate.
The temperature is kept
constant at 44 °C.
The icon flashes; when it
becomes steady, the function is
active.
When the function is active, it is
possible to set an automatic
switch-off timer. To do so, select
the zone and press the
button. Set the desired duration,
after which an audible signal will
sound and the zone will switch
off. Press to stop the sound.
Useful for keeping food hot.
The temperature is kept
constant at 70 °C.
The icon flashes; when it
becomes steady, the function is
active.
When the function is active, it is
possible to set an automatic
switch-off timer. To do so, select
the zone and press the
button. Set the desired duration,
after which an audible signal will
sound and the zone will switch
off. Press to stop the sound.
Useful for keeping food hot.
The temperature is kept
constant at 94 °C.
42 - USE 91477B892/A
1. Press the button and select .
2. To deactivate the function, press
twice in the centre of the zone you
wish to switch off, or select another
function.
Cooking information tables for 145 mm zones using the “ ” function
The icon flashes; when it
becomes steady, the function is
active.
When the function is active, it is
possible to set an automatic
switch-off timer. To do so, select
the zone and press the
button. Set the desired duration,
after which an audible signal will
sound and the zone will switch
off. Press to stop the sound.
Level Food
Weight
(g)
Quantity of oil (ml)
Time
(minutes)
1 Melted butter 40 - 2
2 Vegetables 70 15 9
3 Omelette 120 5 (butter) 3
3 Scrambled eggs 120 5 (butter) 30 sec
3Pancakes80 5 6
3Crêpes80 3 2
4Escalopes80 15 5
4Bacon50 - 5
4 Roast fish fillet 120 5 20
4Steak12010 6
4 Beef fillet 200 15 8
4 Sausages 120 10 15
4 French toast 40 15 (butter) 8
4 Seafood 150 15 6
4 Omelette 2 eggs 15 8
4 Chicken breast 150 15 12
5 Beef fillet (rare) 200 15 6
5 Breaded vegetables 50 15 9
5 Fried eggs 1 10 2
The times shown in the table are indicative.
All the listed recipes were prepared using SMEG pots and pans.
USE - 4391477B892/A
e
Cooking information tables for 210 mm zones using the “ ” function
*The appliance may not be equipped with the zones featured in the recipe book (see
“General description” chapter).
Cooking information table for “ “ function
Level Food
Weight
(g)
Quantity of oil (ml)
Time
(minutes)
1 Melted butter 80 - 1
1 Guanciale 80 - 9
2 Vegetables 140 30 10
3 Omelette 240 15 (butter) 3
3 Scrambled eggs 240 10 (butter) 30 sec
3 Pancakes 120 3 5
3 Crêpes 120 5 2
4 Escalopes 160 15 7
4 Bacon 100 - 5
4 Roast fish fillet 250 5 21
4 Steak 180 15 5
4 Beef fillet 400 20 8
4 Sausages 240 10 23
4 French toast 80 15 (butter) 8
4 Seafood 300 30 4
4 Omelette 4 eggs 15 8
4 Chicken breast 300 15 12
5 Beef fillet (rare) 400 (2x200) 20 6
5 Breaded vegetables 200 20 7
5 Fried eggs 3 15 2
The times shown in the table are indicative.
All the listed recipes were prepared using SMEG pots and pans.
Food Weight (g) for 145 mm zones Weight (g) for 210 mm zones
Time
(minutes)
Chicken breast 150 300 13
Fish fillet 100 200 8
Boiled eggs 2 4 18
Broccoli 125 250 17
Peas 125 250 6
Potatoes 2 medium sized 4 medium sized 25
Bao buns 2 4 18
Shellfish 300 300 10
The times shown in the table are indicative.
The water quantities recommended in the table may vary depending on the type of
food, its weight and the cooking time.
All the listed recipes were prepared using SMEG pots and pans.
44 - USE 91477B892/A
Settings menu
To access the appliance settings, press
the button.
Scroll from right to left to select the
desired function.
To exit the menu, press the “x” in the
top right corner.
Customise
Allows you to choose which functions
appear on the main screen.
Screen lock
This function prevents accidental
operation of the hob. Select “ON” or
“OFF”. When active, the hob will be
locked the next time it is switched on.
Hold down the centre area to
deactivate the function.
Sound
Allows you to adjust the volume of the
appliance’s sounds.
Brightness
Allows you to regulate the display
brightness.
Clock
Allows you to set the desired time.
Language
Allows you to choose the appliance’s
interface language.
Reset settings
Allows all settings to be restored to
their original factory values.
Power limitation menu
To access the menu, follow these
instructions:
1. Switch the appliance on and then off
immediately.
Molluscs 300 300 10
Cream caramel 80 x 2 80 x 3 18
Chocolate custard
dessert
80 x 2 80 x 3 15
Stewed apples 1 pc 2 pcs 20
Fruit salad 1 apple and 1 pear 1 apple and 1 pear 20
Food Weight (g) for 145 mm zones Weight (g) for 210 mm zones
Time
(minutes)
The times shown in the table are indicative.
The water quantities recommended in the table may vary depending on the type of
food, its weight and the cooking time.
All the listed recipes were prepared using SMEG pots and pans.
This function allows you to
personalise the appliance
interface.
The default language is English.
This function allows the hob’s power
consumption to be limited.
By default, the power is set to 11.1
kW.
CLEANING AND MAINTENANCE - 4591477B892/A
e
2. Touch any point along the lower part of
the display, either on the right or on the
left, as shown in the figure below.
3. The menu will then appear on the
display.
4. Scroll to select the desired power level.
5. Touch the button to confirm.
To exit the menu, press the “x” button or the
“ON/OFF” button.
Error notifications
If the appliance malfunctions or operates
incorrectly, the associated error code
appears on the display.
The error codes always begin with the letter
“E” or “Er” followed by a series of digits (e.g.
“Er47-30”).
Errors coded as:
• “E02”
•“E2”
• “Er21”
Indicate that the appliance or part of it is
overheating. If this occurs, you should
switch off the appliance immediately,
remove all pans and let it cool down.
If these errors persist or if other errors
appear, make a note of the code and
contact Technical Support.
CLEANING AND MAINTENANCE
Cleaning the glass ceramic hob
Cleaning the surfaces
To keep the surfaces in good condition, they
should be cleaned regularly after use. Let
them cool first.
Ordinary daily cleaning
Always and only use specific products that
do not contain abrasives or chlorine-based
acids. Pour the product onto a damp cloth
and wipe the surface, rinse thoroughly and
dry with a soft cloth or a microfibre cloth.
Weekly cleaning
Clean and maintain the hob once a week
using an ordinary glass ceramic cleaning
product. Always follow the manufacturer’s
instructions. The silicon in these products
creates a protective, water-repellent
membrane which also resists dirt. All marks
stay on the membrane and can therefore be
removed easily. After cleaning, dry the
surface with a clean cloth. Make sure that
there is no detergent left on the cooking
surface as it might undergo an aggressive
reaction when heated up and could modify
the structure of the cooking surface.
Food stains or residues
Light coloured marks from pans with
aluminium bases can be easily cleaned off
with a cloth moistened in vinegar. Remove
any burnt-on residues after cooking; then
rinse with water and dry thoroughly with a
clean cloth. Dirt, which may have fallen on
the hob while cleaning lettuce or potatoes,
can scratch the hob when moving pans.
Consequently, remove any dirt from the
cooking surface immediately. Changes in
colour do not affect the operation and
stability of the glass. These are not
alterations to the material of the hob but
just residues which have not been removed
and have then carbonised. Shiny surfaces
can form due to the bases of pans,
especially aluminium ones, rubbing on the
surface, and due to the use of unsuitable
detergents. They are difficult to remove
using conventional cleaning products. It
may be necessary to repeat the cleaning
process several times. Use of corrosive
detergents or rubbing of pan bases can
If a logo appears, wait for it to
disappear.
If no action is taken within 2
minutes, the menu automatically
closes.
See General safety instructions.
In case of stubborn dirt, clean when
cold using a damp kitchen sponge
and neutral detergent; then dry with
a microfibre cloth.
46 - INSTALLATION 91477B892/A
wear away the decoration on the hob over
time and contribute to the formation of
stains.
Frame cleaning
Always and only use products that do not
contain abrasives or chlorine-based acids.
Never use abrasive sponges. Pour the
product onto a damp cloth and wipe the
surface, then dry with a soft or microfibre
cloth.
What to do if...
The hob does not work:
• Make sure that the hob is connected and
that the main switch is turned on.
• Make sure that there is no power failure.
• Make sure that the fuse has not blown.
In this case replace the fuse.
• Make sure that the circuit breaker of the
residential electrical system has not
tripped. In this case, reset the circuit
breaker.
The cooking results are unsatisfactory:
• Make sure that the cooking temperature
is not too high or too low.
• Make sure that the hob is properly
ventilated and that the air inlets are
unobstructed.
• Use cookware that is certified and
tested for induction cooking.
The hob smokes:
• Let the hob cool down and clean it once
cooking is complete.
• Make sure that the food has not spilled
out of the pan and use a larger cooking
vessel, if needed.
The fuses blow or the circuit breaker of the
residential electrical system trips
repeatedly.
• Call Technical Support or an electrician.
There are cracks or fissures in the hob:
• Turn off the appliance immediately,
disconnect the power supply and
contact Technical Support.
INSTALLATION
Electrical connection
General information
Check the mains characteristics against the
data indicated on the plate.
The identification plate bearing the
technical data, serial number and brand
name is visibly positioned on the appliance.
Do not remove this plate for any reason.
The appliance must be connected to ground
using a wire that is at least 20 mm longer
than the other wires.
The device can be connected in the
following ways:
Fixed connection
Fit the power line with an all-pole circuit
breaker with a contact separation distance
sufficient to provide complete disconnection
in category III overvoltage conditions,
We recommend the use of cleaning
products distributed by the
manufacturer.
After cleaning, dry the appliance
thoroughly to prevent any water or
detergent from interfering with its
operation or creating unsightly
marks.
See General safety instructions.
220-240V 3~
4 x 6 mm ²
four-core cable
380-415V 2N~
4 x 6 mm ²
four-core cable
380-415V 3N~
5 x 2.5 mm ²
five-core cable
For all types of connection, use the
jumper provided.
The values indicated refer to the
cross-section of the internal lead.
The power cables are sized taking
into account the coincidence factor
(in compliance with standard EN
60335-2-6).
INSTALLATION - 4791477B892/A
e
pursuant to installation regulations.
For the Australian/New Zealand market:
The circuit breaker incorporated in the fixed
connection must comply with AS/NZS 3000.
Section cut from the countertop
Safety instructions for positioning and
installation
• Installation can be carried out on various
materials such as masonry, metal, solid
wood or plastic laminated wood as long
as they are heat resistant (>90°C).
• Veneers, adhesives or plastic coatings
on adjacent furniture should be
temperature-resistant (>90°C),
otherwise they might warp over time.
• If the piece of furniture does not have
the required recess opening, either it will
have to be cut or masonry work carried
out by a competent technician.
• The minimum clearance between
exhaust hoods and the cooking surface
must be at least the distance indicated
in the exhaust hood installation
instructions.
• The minimum clearances must also be
respected for the edges of the hob on
the back as indicated in the assembly
instructions.
• If the appliance is to be installed above
an oven, the oven must be fitted with a
cooling fan.
Appliance overall dimensions (mm)
Mounting (mm)
Mounting
Over built-in oven unit
The clearance between the hob and the
kitchen units or other built-in appliances
must be enough to ensure sufficient
ventilation and air discharge. If installed
above an oven, a space must be left
between the bottom of the hob and the top
of the appliance installed below.
On an empty kitchen
If there are other pieces of furniture under
the hob, a double-layer wooden base must
be installed at least 20 mm from the bottom
of the hob to avoid any accidental contact. It
must only be possible to remove the
double-layer base using suitable
See General safety instructions.
L
80 cm model 927
A B C D E
min. 150 min. 460 min. 750 20 ÷ 60 min. 50
L X Y
900 750 490
1 Opens on bottom
2 Opens on bottom and back
48 - INSTALLATION 91477B892/A
equipment.
Ventilation
The illustrations below show an example of
installation suitable for proper ventilation
and one example of incorrect installation to
be avoided.
Fastening to the built-in cabinet
To ensure the hob is fixed and centred as
accurately as possible, the clips provided
must be positioned as described below:
1. Fit the clips by gently pressing them
horizontally into the appropriate space.
2. Then turn them upwards to fix them in
place.
Testin g
At the end of installation, carry out a brief
inspection test. If it fails to work, after
making sure that you have carried out the
instructions correctly, contact Technical
Support.
Instructions for the installer
• If you use a plug (if present) to connect
to the power supply, the plug must be
accessible after installation.
• Do not bend or trap the power cable.
• The appliance must be installed
according to the installation diagrams.
• If the appliance does not work correctly
after having carried out all the checks,
contact your local Authorised Service
Centre.
• Once the appliance has been installed,
please explain to the user how to use it
correctly.
1 Opens on bottom
2 Opens on back
A min. 20 mm - max. 50 mm
B max. 50 mm
C max. 50 mm
Failure to install the double-layer
wooden base exposes the user to
possible accidental contact with
sharp or hot parts.
