Smart Plug（US）Specification
V1.0
1.Introduction
The Smart power plug is an intelligent plug to facilitate your daily life, users can control
appliances with a single switch from App as well as check appliances energy usage at any time.
Furthermore, users can control appliances power by scheduling to fit their needs and avoid
unnecessary energy waste.
The Smart Power Plug has overload protection mechanism. When overload is detected, power
will be turned off automatically to ensure the safety.
It meet matter standard，With Matter, users are no longer tied to specific platforms and works
with all certified smart home platforms, such as Apple Home, Amazon Alexa, Google Home and
Samsung SmartThings. You can control all your smart home devices from a single app, reducing
the need for multiple apps for different devices.
All Matter-certified devices in your local area network (LAN) will work smoothly even when your
home internet goes offline. Matter allows effective communication directly between devices,
without the need for a specific 'forwarding' device. For example, a Matter smart switch or sensor
can turn on/off a Matter bulb directly without being connected to a cloud service, or other
specific action. Once configured, communication and control between Matter devices can be
achieved directly on the local network.
2. Features
• Meet Matter protocol
• Works with all certified smart home platforms
• Control from anywhere: The Smart Plug enables you to remotely control lights, fans, and other
ordinary appliances from your smart phone.
• Schedule and timer: Supports schedule and timer set through the app to help you automate
your daily routines around the house.
• Energy Monitoring – monitors daily power consumption, which helps to save energy.
• Fire Retardant & Compact Design.
3. Specification
Item
Description
Model number
HPL-J135
Communication
IEEE 802.11b/g/n
Input Power
110~240 VAC +/- 10%, 60Hz
Max Load Current
15A
Energy Monitoring
Support
Overtemperature
Support（optional）
Overload
Support（optional）
Button
1 x On/Off
LED
• 1
Certification
ETL
Dimension
70*38*31.5mm
Operating Temperature
-10~55℃
Operating Humidity
10~90%RH
FCC Warning
Model Number: HPL-J135、HPL-J933
FCC ID: 2BXYIHPLJ135
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions:(1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Any Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC RF exposure statement:
The equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance between 20cm the radiator your body.
