Radioshack
WIRELESS HEADPHONES
Model 3304466
USER MANUAL
Package content:
Wireless headphones
Type-C charging cable
User manual
Specifications:
Specifications are subject to change and improvement without notice.
The actual product may vary from the images found in this document
1. Charging port: Type-C
2. Playing time: up to 20 hours, 50% volume
3. Battery capacity: 3.7V,400mAh
4. BT version: V6.0
5. Wireless Headphones driver:40mm
6. Frequency response:20Hz-20kHz(Speaker)
7. Sensitivity:93±5dB(Speaker)
8. Sensitivity:-12±4dB(Mic)
9. BT connection range:approx.10m
.
To… Button Press
Turn on headphone and hold 3 sec
Turn off headphone
and hold 3 sec
Play/Pause
×
1
Answer/end call
Reject an incoming cal
×
1
l
Volume up / dow
×2
n
+/-
≥1
Go to next track
+
and hold
Go to previous track
-
and hold
Turn on/off ANC
×
1
Note:
Music playback is paused during call functions and resumes
when the calls ended.
on/off button
Vol +
Vol -
Charging port
ANC button
How to use:
A. Charge
：
1. Connect the Type-C charging cable to the headphone and a USB
source;
2. LED lights red when charging
3. When fully charged, the LED light turns blue.
B. Pairing:
1. With the headphones turn on, enter pairing model, LED rapidly
flashes blue.
2. On your device, turn on the Bluetooth function, and set it to search
for Bluetooth devices.
3. Select (RS3304466) from the list of found devices.
4. When paired, the LED lights up blue.
Note:
During pairing, if the headphones are not connected to a device
within 5 minutes, they automatically turn off.
C. Pairing Troubleshooting Pairing Issues:
If you encounter problems while pairing, you may need to clear
previous BT connections from the headphones or your device.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
-Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help
Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
