H07
Ultra-long range
Air conduction wireless earphones
H07
Instructions
Compatible with Bluetooth enabled electronic products such as iOS and
Android smartphones/tablets
Air conduction wireless earphones
Pause/Play
Connect incoming
calls
Hang up call
Game/Music Mode
Reject incoming calls
Long press for 2 seconds to
open the voice assistant
(Release after beeping)
Long
press
Long press for 2 seconds to go to the previous track
(Release after beeping)
Click Volume+
Click
Touch
keys
Click
Double
click
Long
press
+Key
- Key
Long
press
Long press for 2 seconds
Next track
(Release after beeping)
Click Volume-
Indicator light
MIC
Press and hold for 2 seconds to power on
(Blue light flashing three times, red and blue flashing)
Long press for 5 seconds to power off
(Blue light flashing three times, red and blue flashing)
First Pairing Of Earphones
1. Take the earphones out of the packaging box and wear them properly
2. Press and hold the Volume key "+" for 2 seconds until you hear the sound "Power
On"
3. Turn on the Bluetooth function of your phone, search for device H07, click and
complete pairing
4. Once you've connected the device, it will automatically connect when you turn the
earphone on in future use, no need to pair them again.
Note: lf necessary, please turn off the headphones and repeat the above steps to
reconnect
USBUSB
Dedicated magnetic suction charging wireDedicated magnetic suction charging wire
earphonesearphones
Correct illustration Error demonstration
Product Charging Precautions
1. Use the original magnetic suction dedicated charging cable to connect the 5V-lA charger
to charge the headphones.
2. lf there is no mobile phone charger with corresponding charger parameters, other Dc5V
charging adpator can also be used to charge the product.
3. Note: the power of the mobile phone charging should be less than 24W (such as 9V --2A
power 18W), exceeding this power can easily damage the battery. Do not use wired
charging such as car charging, seat charging, USB wall charging, USB plug in, fast charging
power bank, etc, as the output power is high and unstable, which is prone to abnormal
power consumption (shortened battery life), and even unstable signals.
4. lf the magnetic suction charging contact is dirty, please wipe it clean and dry before
charging
5.The magnetic suction charging wire has a demagnetization design inside to prevent the
positive and negative poles from being inserted backwards. It should be pulled in
smoothly and not forcibly charged in the opposite direction. Operate as shown in the
following figure.
1
Function Explanation
ENC call noise reduction: when answering a call, this function will automatically tur
on without manual operation;
Game low latency mode: Users can manually switch from music mode to game mode
while playing games, improving the synchronization of sound and picture, this mode
can greatly accelerate the transmission of Bluetooth data.
One drag two function: Earphones can support connecting two phones at the same
time.
Voice Assistant: When connected and working, long press key "+" for 2 seconds,
release the key when you hearing "beep".
Advantages
IPX5 waterproof, ENC Call noise reduction, Extra Long Range Diamond cutting
technology, LED digital display, Low game latency, Skin friendly soft rubber memory
head bow which does not deform
Precautions
1. lf not necessary, please do not cover the earphones with your hands to prevent
human obstruction from seriously affecting the transmission of wireless signals.
2. When wearing and using, there must be no strong signal interference obstacles
between the phone and the earphones, and it is necessary to ensure the distance
between the two to avoid affecting the signal transmission between the phone and
the earphones.
3. During daily use, if there is an occasional disconnection issue, it is a normal
phenomenon as it belongs to wireless signal transmission, just like WiFi networks,
occasional instability is a normal phenomenon, and the signal transmission may be
interfered with at this time, Please wait for a moment or change the position to solve
it.
Product Specifications
Model: H07
Bluetooth Version: 5.4
Power input: DC 5V
Charging interface: Magnetic contact charging
Battery capacity:100mAh
Charging time: about 1 hours
Supporting agreement: HSP/HFP/A2DP/AVRCP
Play time: 15 hours (volume determines battery
life)
Packing List
1.Air conduction wireless
earphones
2.Dedicated magnetic
suction charging wire
3.User manual
After-sale service
The warranty period is 12 months. During the warranty, if any malfunction is caused by
the quality of the product itself, please contact us for help.
Non Warranty Regulations
1. Nomal wear and dirt caused by daily use, such as scratches, damage caused by
contact with chemical reagents,sharp objects, etc
2. Damage caused by self disassembly;
3. Mechanical damage such as malfunctions caused by water ingress, falling, or
squeezing.
4. Failure or damage caused by force majeure;
5.The warranty period has expired:
6. The situation does not comply with the performance faults listed in the "Earphone
Performance Fault Table”: Due to other abnormal use, this product and accessories
have perfommance faults listed in the "Earphone Performance Fault Table".
Function Explanation
1. Please read this user manual carefully and keep it properly before using the product.
2. Forfirst use, please fully charge this product first, lf the product needs to be unused
for more than one month, please fully charge it before storing it properly. During this
period, it is recommended to fully charge it every month, which can greatly extend the
service life of the product. Otherwise, the batteries inside the product will continue to
self discharge due to their own characteristics. Excessive discharge will cause complete
damage to the product, making it unusable and not covered by the
warranty.
3. You must choose a charger produced by a legitimate manufacturer and certified by
the National CCC to charge the product.
4. lf the phone is unable to search for earphones, please confirm whether the earphones
are in the state of waiting for pairing on. lf the earphones are not successfully paired or
connected for a long time, the earphone pairing function will be turned of (turned off),
and the earphones need to be restarted and in the pairing state, if there is an error in the
phone program, please restart the phone. if there is an error in the earphone program,
please restart the earphones.
Earphone performance
fault table
1. Earphones cannot hear sound
2. During a call, the other party cannot hear sound
3. Unable to charge earphones
4. Earphones cannot be tumed on and used
Warning
1. Do not remove or repair or modify headphones for any reason, as this may cause a
fire, electronic breakdown, or even complete damage to the product. This behavior is
not related to our company and the consequences will be borne by the buyer.
2. Do not place the device in an environment with a temperature below 0 ° C or above
45 °C.
3. Do not use this device in thunderstorm weather, as thunderstorms may cause the
device to malfunction.
4. Do not use oil or other volatile chemical liguids to wipe the surface ofthis product,
but alcohol can beused for daily cleaning and maintenance of the product.
