PRODUCT SPECIFICATIONS
© Copyright 2023, VOLT
®
Lighting, Lutz, FL USA 33549 • All rights reserved • 813.978.3700 • www.voltlighting.com
Project Name _______________________________________ Date ____________
Type or Model _______________________________________ Qty _____________
Smart MR16 Led Bulb
from a wide spectrum of colors, adjust the brightness, control
the color temperature (warm 2200K to crisp, bright 4000K), or
set up to zones through APP.
Ideal for applications where balanced, multi-colored
• Replacements for 35W Halogen MR16 lamps
• 38° or 60° beam spreads
•Desig
ned and optimized for compatibility with all current
• RGB + Cool White to Warm White
• Dimmable
PRODUCT DESCRIPTION
FEATURES & BENEFITS
PRODUCT DIMENSIONS
• Input Voltage: 8-1 5V, 50/60Hz AC
• Beam Angles: 38° or 60° beam spreads
• Correlated Color Temperature (CCT) : 2200K, 2700K,
3000K, 4000K
• Color Rendering Index (CRI): 85
• Operating Voltage: 12VAC
• Powered by: VOLT’s Low Voltage Transformer
• Watts: 5W
• Lumens: 250 at 2200K | 300 at 4000K I 75 at Red I 180 at
Green I 45 at Blue
SPECIFICATIONS
WARRANTY
Commercial: 5-Year Warranty
Smart MR16 Led Bulb
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device and its antenna(s) must not be co-located or operation in conjunction with
any other antenna or transmitter.
Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement in portable
exposure condition without restriction.
