EN QUICK GUIDE LED TV
CZ RYCHLÝ PRĢVODCE LED TV
SK RÝCHLY SPRIEVODCA LED TV
HU GYORS ÚTMUTATÓ LED TV
PL KRÓTKI PRZEWODNIK LED TV
SLE XXX802TCSB
2
Revision 11/2022
Copyright ©
2022, Fast ČR,a.s.
CONTENT / OBSAH / OBSAH / ZADOWOLONY / TARTALOM
English ....................................................................................... 3
Čeština ....................................................................................... 9
Slovenčina ................................................................................. 15
Magyar ...................................................................................... 21
Polski ........................................................................................27
Product Information Sheet .................................................................. 33
Informační list produktu ...................................................................... 33
Informačný list produktu ..................................................................... 33
Termékinformációs lap ....................................................................... 33
Arkusz informacji o produkcie ............................................................. 33
LICENSES:
Sencor SLE 32-43-50-55-65-US801TCSB QG EN CZ SK HU PL.indb 2 16.11.2022 19:20:26
EN 3
EN
Revision 11/2022
Safety instructions
1. Safety instructions
To be able to use this product properly, read
this user's manual carefully and keep it for
future reference. If you plan to give (sell)
this device to a third person, include all
documentation, including this manual, with the
transaction.
The lightning symbol inside a triangle indicates
the device has dangerous voltage that may
cause electric shock.
The exclamation point symbol inside an
isosceles triangle indicates important operation
and repair instructions in the included device
documentation.
WARNING
RISK OF ELECTRIC SHOCK – DO
NOT OPEN!
TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE THE COVER (OR BACK SIDE).
THERE ARE NO PARTS INSIDE THE DEVICE
REPLACEABLE BY THE USER. FOR REPAIRS,
CONTACT AND AUTHORIZED SERVICE
PROVIDER.
WARNING:
To prevent risk of lre or electric shock, do not
expose the device to rain or moisture. The
batteries must not be exposed to excessive
heat, for example sunlight, lre, etc.
This symbol indicates the device has
double insulation between dangerous
voltage from the network and user-
accessible parts. Replace parts with
identical spare parts only.
• Do not leave a static image on the LCD
panel for more than 2 hours. The panel
might get damaged.
• LCD screens are made using precision
technology to provide even tIFlnest
image details. Several defective pixels can
appear on the screen from time to time,
indicated as red, blue, green or black dots
(up to 0.001% of the total pixel count
of the screen). This does not affect the
characteristics and the effectiveness of
your TV set.
Before use, please read the detailed safety
information in the full user manual available
on the website www.sencor.com
2. Installing the stand
Use the supplied or recommended screws to
attach the stand. Make sure the supports are
properly attached to keep the TV stable. Then
connect the TV to the power supply.
3. Inserting batteries
Open the battery compartment. Insert two AAA
batteries. Place the cover back on.
Insert two AA batteries into the Magic
controller (UHD models only).
4 EN
EN
Revision 11/2022
Copyright ©
TV connectors
4. TV connectors
OPTICAL
USB2
HDMI1
ARC
HDMI2
USB1
RF IN
DVB-S2
RF IN
DVB-T2
COMMON INTERFACE(CI+)
EN 5
EN
Revision 11/2022Copyright © 2022, Fast ČR,a.s.
Remote controller
5. Remote controller
POWER: power ON/OFF.
TV/RAD: Switch to TV or radio.
: Search.
SUBTITLE: Subtitles On/Off.
: Enter the quick setup menu.
: Input source selection.
0-9: Numeric keys.
LIST: Channel list.
··· : Show other actions.
: Setting the volume.
: Channel switching.
AD: Enabling / disabling the AD function.
GUIDE: TV programme display.
:
: Mute.
: Play.
: Shows main menu.
X : Pause.
BACK: Back to the previous step.
EXIT: Closes the menu.
: Selects the currently highlighted option.
fFgG: The RIGHT/LEFT/UP/DOWN buttons
to move through the menu.
TEXT: Opens teletext.
T.OPT: Open the teletext function menu.
MOVIES: Movie search.
REC: Starts recording.
: Starts live playback.
: launches Netflix.
: launches Prime video.
: Correspond various color
functions in the menu or in the
teletext.
Sencor SLE 32-43-50-55-65-US801TCSB QG EN CZ SK HU PL.indb 5 16.11.2022 19:20:26
6 EN
EN
Revision 11/2022
Copyright ©
2022, Fast ČR,a.s.
Magic Controller
6. Magic Controller
When paired with the TV, the Magic controller offers an additional cursor for control.
1: TV ON/OFF.
: STB ON/OFF.
1–9: numeric keys
: Channel list
: Short press: Number button / Long
press: Quick access
: Short press: Other actions
Long press: Audio description
:
: Mute.
: Setting the volume.
: Channel switching.
: Activates voice recognition.
: Shows main menu.
: Enter the quick setup menu.
WHEEL UP: Scroll up / Go to a higher channel
PRESSING THE WHEEL: Confirmation
WHEEL DOWN: Scroll down / Go to a lower
channel
fFgG: The RIGHT/LEFT/UP/DOWN buttons
to move through the menu.
: Go back.
GUIDE: TV programme display.
: Input source selection.
: Movie selection menu.
: Play.
X : Pause.
: launches Netflix.
: launches Prime video.
: Correspond various color
functions in the menu or in the
teletext.
The icons and positions of the remote control
buttons may vary depending on the model.
Sencor SLE 32-43-50-55-65-US801TCSB QG EN CZ SK HU PL.indb 6 16.11.2022 19:20:27
EN 7
EN
Revision 11/2022
TV control buttons
7. TV control buttons
: TV ON/OFF.
8. After you lrst turn on
the TV
When you lrst turn on your TV, you'll see a
welcome screen where you can select your
language and country. Next, select the signal
source and perform the initial tuning as
instructed on the screen.
9. Included accessories
• Magic Remote (UHD models only)
• Basic remote controller
• Quick guide
• 2 AAA batteries, 2 AA batteries (for Magic
controller only)
• Stand and lxing screws
10. Playing from USB disc
Connect a USB device. Press HOME on the
remote controller. Open the Photo & Video app.
Select the desired storage device. Select and
view the desired photo or video.
Compatibility with all USB devices is not
guaranUFFE6TFlMFTZTUFNFAT32/NTFS,
single partition, no protection. Formatting
permanently erases all contents of the
memory device! First, test the speed and
reliability of each USB device. When the result
is unsatisfactory, replace it with another one,
mainly faster. The speed of a USB storage
device is a prerequisite for reliable recording
and time-shifting.
Supported USB formats
Video: AVI, MP4, MPG, MKV, MOV, DAT, VOB
Audio: MP3, WAV, OGG, FLAC
Pictures: JPEG, JPG, PNG
11. Full text of the
operating instructions
The full instruction manual is available
directly on the TV.
8 EN
EN
Revision 11/2022
Copyright ©
Full text of the operating instructions
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL OF USED PACKAGING
Dispose of the packaging material at a public waste disposal site.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
The symbol on the product, its accessories or packaging indicates that the
product must not be disposed of in household waste. Dispose of the equipment
at an appropriate collection point for the recycling of electrical and electronic
equipment. Alternatively, in some European Union states or other European
countries you may return your products to your local retailer when buying an
equivalent new product.
Correct disposal of this product will help save valuable natural resources and
prevent any potential negative impacts on the environment and human health,
which could otherwise be caused by improper waste disposal. Contact your local
authority or nearest waste collection centre for more details. Improper disposal
of this type of waste may be subject to natJPOBMSVMFTPOlnes.
For business entities in the European Union
To dispose of electrical or electronic device, request the necessary information
from your vendor or supplier.
Disposal in other countries outside the European Union
To dispose of this product, request the necessary information about the correct
disposal method from local government departments or from your vendor.
Hereby FAST CR, a.s. declares that the type of SLE 65US802TCSB, SLE
55US802TCSB, SLE 50US802TCSB and SLE 43US802TCSB
The full text of the EU Declaration of Conformity is available at the following
website: www.sencor.com
Text, design and technical speDJlDations are subject to change without notice and we
reserve the right to make changes.
33
Revision 11/2022Copyright © 2022, FBTUĂ3BT
Product Information Sheet
COMMISSION DELEGATED REGULATION (EU) 2019/2013 with regard to energy labelling of
electronic displays
Parameter Parameter or value and
precision
1. Supplier's name or trademark. SEN
COR
Supplier's address. -
2. SLE 43US802TCSB
3. Energy Efficiency Class for Standard Dynamic Range
(SDR)
F
4. On mode
power demand in SDR
51,0
5. Energy Efficiency Class for High Dynamic Range
(HDR)
G
6. On mode
power demand in HDR, if implemented
7. Off mode, power demand, if applicable 0,
0
8. Standby mode powe
r demand, if applicable
0,
5
9. N
etworked standby mode power demand, if applic-
able
2,
0
10. Ele
ctronic display category
Television
11. Size ratio 16 : 9
12. Screen resolution 3 840 x 2 160
13. Screen diagonal 108,0
14. Screen diagonal 43
15. Visible screen area 49,9
16. Pane
l technology used
LED LCD
17. No
18. Voice recognition sensor available No
19. Room presence sensor available No
20. Image refresh frequency rate (default) 60
21.
firmware updates (from the date of end of the
place
ment on the market)
8
22. Minimum guaranteed availability of spare parts
(from the date of end of the placement on the mar-
ke
t)
7
23. Minimum guarante
ed product support
8
by the supplier
2
24. Power supply type Inter
nal
External power supply (non standardized and included in the product box)25.
i -
ii Input voltage -
iii Output voltage -
26. External standardised power supply (or suitable one if not included in the product box)
i -
ii Required output voltage -
iii Re
quired delivered current (minimum)
-
iv Required current frequency -
Unit
W
W
W
W
W
pixels
cm
inches
dm²
Hz
Years
Years
Years
Years
V
V
V
A
Hz
Parameter or value and
precision
SENCOR
-
SLE 50US802TCSB
G
68,0
G
103,0
0,
0
0,
5
2,
0
Television
16 : 9
3 840 x 2 160
126,0
50
67,6
LED LCD
No
No
No
60
8
7
8
2
Inter
nal
-
-
69,0
Product Information Sheet
COMMISSION DELEGATED REGULATION (EU) 2019/2013 with regard to energy labelling of
electronic displays
Parameter Parameter or value and
precision
1. Supplier's name or trademark. SENCOR
Supplier's address. -
2. SLE 55US802TCSB
3. Energy Efficiency Class for Standard Dynamic Range
(SDR)
F
4. On mode power demand in SDR 65,0
5. Energy Efficiency Class for High Dynamic Range
(HDR)
G
6. On mode power demand in HDR, if implemented
7. Off mode, power demand, if applicable 0,0
8. Standby mode power demand, if applicable 0,5
9. Networked standby mode power demand, if applic-
able
2,0
10. Electronic display category Television
11. Size ratio 16 : 9
12. Screen resolution 3 840 x 2 160
13. Screen diagonal 139,0
14. Screen diagonal 55
15. Visible screen area 82,3
16. Panel technology used LED LCD
17. No
18. Voice recognition sensor available No
19. Room presence sensor available No
20. Image refresh frequency rate (default) 60
21.
firmware updates (from the date of end of the
placement on the market)
8
22. Minimum guaranteed availability of spare parts
(from the date of end of the placement on the mar-
ket)
7
23. Minimum guaranteed product support 8
by the supplier
2
24. Power supply type Internal
External power supply (non standardized and included in the product box)25.
i -
ii Input voltage -
iii Output voltage -
26. External standardised power supply (or suitable one if not included in the product box)
i -
ii Required output voltage -
iii Required delivered current (minimum) -
iv Required current frequency -
Unit
W
W
W
W
W
pixels
cm
inches
dm²
Hz
Years
Years
Years
Years
V
V
V
A
Hz
Parameter or value and
precision
SENCOR
-
SLE 65US802TCSB
F
100
E
84,0
0,0
0,5
2,0
Television
16 : 9
3 840 x 2 160
164,0
65
114,8
LED LCD
No
No
No
60
8
7
8
2
Internal
-
-
98,0
34
Revision 11/2022
Copyright ©
2022, FBTUĂ3BT
#CZ SK HU PL
1
Název nebo ochranná
známka dod
Adresa dodavatele "ESFTBEPEäWBUFāB Adres dostawcyA szállító címe
avatele
Meno dodávaUFāBBMFCP
jeho ochranná známka
A szállító neve vagy
védjegye
Nazwa dostawcy lub
znak towarowy
2
IdentJlkBĐOð[OBĐka modelu IdentJlkBĐný kód modelu modellazonosító IdenUZlkator modelu
3
5ĎðEBenergetickìøĐJnnosti
u standardního dynamické
ké
ho rozsahu (SDR)
ho rozsahu (HDR)
Trieda energetickej
øĐJnnosti pre štan dardný
dynamický
ký
rozsah (SDR)
rozsah (HDR)
Energiahatékonysági
osztály szabványos
dinamikatartomány (SDR)
esetében
KlBTBFGFLUZXOPġDJ
energetycznej dla
standardowego zakresu
dynamicznego (SDR)
4
1Ďðkon v zapnutém stavu
v SDR
WSFÇJNVWZTPDFEZOBNJD
Príkon v rFÇJNFzapnutia
pre SDR
beA kapcsolt üzemmód
energiaigénye szabványos
dinamikatartomány (SDR)
esetében
Pobór mocy w
USZCJFXĬczenia dla SDR
5
5ĎðEBenergetickìøĐJnnosti
Trieda energetickej
øĐJnnosti
pre vysoky dynamic
esetében
E
nagy dinamikatartomány
(HDR)
nergiahatékonysági
osztály
KlBTBFGFLUZXOPġDJ
energetycznej dla saerokiego
zakresu dynamicznego (HDR)
6
1Ďðkon v zapnutém
stavu v
HDR, je-li k dispozici
Príkon v rFÇJNFzapnutia
pre HDR, ak je k dispozícii
beA kapcsolt
üzemmód energiaigénye
Energiaigény
nagy dinamikatartomány
(HDR) megléte esetén
Pobór mocy w
USZCJFXĬczenia dla HDR
w stosownych przypadkach
w stosownych przypadkach
w stosownych przypadkach
7
Vypnutý stavQĎðkon
ÅOûDIQĎðQBEFDIWQĎðTMV
Príkon v rFÇJNFWZQOVtia,
ak j ek dispozícii
ak j ek dispozícii
ak j ek dispozícii
Kikapcsolt
üzemmódban,(adott esetben)
Energiaigény
Energiaigény
Keszenléti
üzemmódban,(adott esetben)
üzemmódban,(adott esetben)
Pobór mocy w trybie XZĬczenia,
8
1Ďðkon v pohotovostním r
WQĎðTMVÅOûDIQĎðQBEFDI
1Ďðkon v pohotovostním
rFÇJNVQĎðQĎðQPKFOðOBTJU
Príkon v rFÇJNFQPIPUPvosti,
Pobór mocy w
trybie czuwania,
9
Príkon v rFÇJNFQPIPUPvosti
pri zapojení v sieti
hálózatvezérelt
készenléti
Pobór mocy w
trybie czuwania
przy QPEĬczeniudo sieci,
10
Kategorie
elektronického displeje
Kategória elektronického
displeja
Elektronikus kijel[Ē
kategóriája
KategoSJBXZġXJFUlacz
elektronicznego
11 PoNđSTUran Pomer strán Képarány Format obrazu
12 Rozlišení obrazovky Rozlíšenie obrazovky KépernZĒGFMCPntás RozdzielczPġĜFkranu
13
ÚhMPQĎðĐka obrazovky
jednotky
Képátló PrzFLĬUOBFkranu
14 ÚhMPQĎðĐka obrazovky
jednotky
UhMPQSJFĐka zobrazovacej
jednotky
UhMPQSJFĐka zobrazovacej
Képátló PrzFLĬUOBFkranu
15 Viditelná plocha obrazovky
VJEJUFāOäQMocha
zobrazovacej
Látható kijelzĒGFMúMFU
Widoczna powierzchnia
ekranu
16
PoVÇJUäUechnologie panFMė
PoVÇJUäUechnológia panelu
Alkalmazott
paneltechnológia
Zastosowana technologia
panelu
17
Dostupné automatické
ovládání jasu (ABC)
K dispozícii je automatická
regulácia jasu (ABC)
Aut
omatikus
fénZFSĒTzabályozó (ABC)
rendelkezésre áll
DPTUĭQOPġĜGVOkcji
automatycznej regulacji
jBTOPġDJ"#$
18
Dostupný snímBĐQro
rozpoznávání hlasu
K dispozícii je snímBĐ
rozpoznávania rFĐJ
HaOHGFMJTNFSĒ
érzékFMĒ rendelkezésre áll
DPTUĭQOPġĜczujnika
rozpoznawania mowy
19
Dostupný detektor
QĎðUomnosti v místnosti
K dispozícii je snímBĐQSð
tomnosti v miestnosti
JelenlétérzékFMĒ
rendelkezésre áll
DPTUĭQOPġĜczujników
obeDOPġDJXQomieszczeniu
20
Obnovovací frekvence
obrazu (výchozí)
ObnovovaDðLNJUPĐFU
obrazovky (predvolený)
Képfrissítési frekvencia
(alapértelmezett)
$[ĭTUPUMJwPġĜPEġXJFĩania
obrazVEPNZġMOB
wprowadzania do obrotu)
21
Minimální
zaSVĐ
ená dostupnost
aktualizací softwaru a
l
VLPOĐFOPVWäEFOðOBUSI
VLPOĐFOPVWäEFOðOBUSI
rmwaru (od date, kdy bylo
(od date, kdy bylo
Minimálna zaSVĐená
EPTUVQOPTěBLU
ualizá cií
softvéru a lrmvéru (od dátumu
ked sa výrobok prestáva
EPEäWBěOBUSI
A szoftver- és lrmware-
frissítések minimális garantált
rendelkezésre állása (a forga
JEĒQPOUKäUóMT[äNðUWB
lomba hozatal befejezésének
Minimalna gwarantowana
EPTUĭQOPġĜBLUualizacjio
programowania i oprogramowania
VLadowego (od daty zakonczenia
wprowadzania do obrotu)
(od daty zakonczenia
22
Minimální zaSVĐená
dostupnost náhradních
EðMė
ked sa
výrobok prestáva EPEäWBěOBUSI
Minimálna zaSVĐená
EPTUVQOPTěOäIrad ných
dielov (
od dátumu
minimális garantált
rendelkezésre állása (a forga
JEĒQPOUKäUóMT[äNðUWB
lomba hozatal befejezésének
A tartalék alkatrészek
Minimalna gwarantowana
EPTUĭQOPġĜc[ĭġDJ
zamiennych
35
Revision 11/2022Copyright © 2022, FBTUĂ3BT
#CZ SK HU PL
23
Minimální
Minimální doba trvání obecné
záruky nabízená dodavatelem
[BSVĐFOä
podpora
výrobku
Minimálna
Minimálne trvanie celkovej
záruky, ktorú ponúka
dodávatel
zaSVĐená
podpora výrobkov
G
NJOJNBMJTJEĒUBSUBNB
arantált
terméktámogatás
Mini
Minimalny okres ogolnej
gwarancji oferowanej przez
EPTUBXDĭ
malne gwarantowane
p serwisowane roduktu
24
2
26
5
Typ napáj
-- - -
-- - -
7OđKÅðOBQäKFDð[ESPKKJO
ý
OFÇOPSNBMJ[PWBO
ý a souĐäst
balení v
ýrobku)
7OđKÅðOPSNBMJ[PWBOý napájecí
[ESPKOFCPWIPEO
ý[ESPKUPIPUP
typu,pokud není sou
Đástí balení
v
ýrobku)
ení Typ zdroja napájania A tápegység típusa Typ zasilacza
i
i
Externý zdroj napájania
OFOPSNBMJ[PBO
ý, súĐast
balenia výrobku)
kúMTĒUäQFHZTìHOFNT[BCW
ányos,és a termékdobozban
UBMäMIBUP
zasilacz zFXOĭUS[
OJF[OPSNBMJ[PXBOZJ
dostarczony w opakowaniu
z produktem)
ny
VTUVQOðOBQđtí Vstupné napätie Bemeneti feszültség NBQJĭDJFXeKġDJPXF
VûTUVQOðOBQđtí Výstupné napätie Kimeneti feszültség NBQJĭDJFXyKġDJPXF
ii
ii
iii
iv
iii
Externý normalizovaný zdroj
napájaOJBBMFCPWIPEOû
belenia výrobku)
szabványos LúMTĒUäQFHZTìH
WBHZBOOBLNFHGFMFMĒIBB
termékdoboznak nem része)
znormali
zowany zasilacz
[FXOĭUS[OZMVCPEQPXJFEOJ
dostarczony w opakowaniu
z produtktem)
PPÇadované výstupní
OBQđtí
PPÇadované výstupné
napätie
&MĒðSULJNeneti feszültség
WymaganFOBQJĭDJF
wyKġDJPXF
PPÇadovaný dodávaný
proVENJOJNäMOð NJOJNäMOZ
PPÇadovaný prúd &MĒðSUTzállított árBNFSĒTTìH
NJOJNVN
Wymagane naUĭĩenie
QSĬEVNJOJNBMOF
PPÇadovanûLNJUPĐFU
proudu
PPÇadovaná frekvencia
prúdu
&MĒðSUäramfrekvencia
Wymagana c[ĭTUPUMJwPġĜ
QSĬEV
36
Revision 11/2022
CopyrigIt ©
2022, FBTUĂ3BT
www.sencor.cz
Designed in Europe by Sencor
®
, Made in China
