Before assembly:
Unscrew the leveling foot
from each post.
EG9988 Revised 03/24
ASSEMBLY INSTRUCTIONS
Dolly Truck
CAUTION
INSPECT CONTENTS IMMEDIATELY AND FILE CLAIM WITH DELIVERING
CARRIER FOR ANY DAMAGE. SAVE YOUR BOX AND ALL PACKING MATERIALS.
YOU ARE RESPONSIBLE FOR DAMAGE TO YOUR UNIT IF RETURNED IMPROPERLY PACKED.
frame
post
post
leveling foot
leveling foot
Step 1 - Attach posts to frame
using leveling feet.
(continued on back page)
Eagle Foodservice Equipment, Eagle MHC, and SpecFAB
®
are divisions of Eagle Group. ©2024 by the Eagle Group
• 100 Industrial Boulevard, Clayton, Delaware 19938-8903 U.S.A.
• Phone: 302/653-3000 • 800/441-8440 • Fax: 302/653-2065
• www.eaglegrp.com • www.eaglemhc.com
INSTRUCTION SHEET
#A218901
ASSEMBLY INSTRUCTIONS
Dolly Truck
Step 2 - Attach bottom shelf.
Repeat Step 2, attaching each additional shelf at desired height, working from bottom to top,
until all shelves are attached.
Snap split sleeve onto the
bottom groove of each post
(the wider part of the taper
goes toward the bottom).
For each shelf, snap split sleeve onto
each post at the same height (the
wider part of the taper goes toward
the bottom).
split
sleeves
split
sleeve
shelf
collar
post
dolly truck fully assembled.
Lower shelf onto split sleeves.
(End)
