Assembly
Your Eagle Group Height Adjustable table has come completely preassembled. No tools are required. It will not need any maintenance or
oil over its life time. The lift cylinders are self-contained and preassembled with the required volume of oil.
Warranty
1) Any modification will void your warranty.
2) Attempting to remove the top will void your warranty.
3) Exceeding the load capacity will void your warranty.
4) Use of soap, detergents or cleansers on lower extending leg will void your warranty.
Maintenance
1) All internal components are self contained requiring no maintenance.
2) The lower extending leg should be kept clean. Use only alcohol to wipe the leg. Use of soaps or detergents could
cause harm to fittings and bushings.
Operation
To raise the height adjustable table:
1) Gently raise handle into locked position (see figure 1).
2) Rotate handle clockwise.
3) Gently pull handle from locked position and lower until relaxed.
(see figure 2).
To lower the height adjustable table:
1) Gently raise handle into locked position (see figure 1).
2) Rotate handle counterclockwise.
3) Gently pull handle from locked position and lower until relaxed (see figure 2).
NOTE: If the table surface becomes un-level or stuck, rotate crank counterclockwise to lower table to its lowest possible setting. Apply
pressure, if needed, to any stuck legs (do not exceed weight capacity) until the table is level in its lowest setting. Once complete, the table
is operational again.
OPERATIONAL WARNINGS AND USE:
1) Do not exceed listed weight capacity (see chart below). Be aware of dynamic loading- sudden loading of the table
can create moment loads exceeding the table’s capacity. Avoid overloading the tables edges. Loads should be placed
toward the center of the table and evenly distributed.
2) Only operate table on hard flat surfaces.
3) All casters (if included) must be in the locked position to operate table.
Tables up to 48˝ long: 575 lbs.
Tables 49˝ to 72˝ long: 525 lbs.
Safe operation load capacity (evenly distributed load)
not to exceed the following specifications
ASSEMBLY INSTRUCTIONS
Height Adjustable Tables
CAUTION
inSPECt ContEntS iMMEDiAtELY AnD FiLE CLAiM WitH DELiVERinG CARRiER FoR AnY DAMAGE.
SAVE YOUR BOX AND ALL PACKING MATERIALS.
You ARE RESPonSiBLE FoR DAMAGE to YouR unit iF REtuRnED
iMPRoPERLY PACKED.
inStRuCtion SHEEt
#383839
Eagle Foodservice Equipment, Eagle MHC, SpecFAB
®
, and Retail Display are divisions of Eagle Group. ©2017 by the Eagle Group
• 100 Industrial Boulevard, Clayton, Delaware 19938-8903 U.S.A. • www.eaglegrp.com
• Phone: 302/653-3000 • (Foodservice) 800/441-8440 • (MHC/Retail) 800/637-5100
• Fax: 302/653-2065
EG9933 Revised 05/17
figure 2figure 1
