Installation Guide
Connection
Use the passive PoE adapter to simultaneously supply power and transmit data to a passive PoE device.
Passive PoE Adapter
POE2412G/POE4818G/POE4824G
Installation
2. Attach the passive PoE adapter to the mounting bracket by sliding the
adapter in the direction of the arrows until it locks into place.
Package Contents: passive PoE adapter, power cord, and wall mount kit
Note: For the most secure attachment, install the passive PoE adapter with the Ethernet port facing upward.
1. Drill two holes in the wall and insert the plastic wall anchors. Secure
the mounting bracket to the wall. Make sure the shoulders at the
corners of the mounting bracket are on the outside and pointing
upward.
Note: Before connecting a passive PoE device, please check the required voltage in its product manual.
Note: POE2412G is used as an example throughout this guide. Other models may dier in appearance.
For technical support, replacement services, user guides, and more, please
visit https://support.omadanetworks.com/, or simply scan the QR code.
Passive PoE Adapter
AC Power Cord
Ethernet Device
(switch, gateway, etc.)
IP Camera
Passive PoE Devices
AP
©2025 TP-Link 7100001822 REV2.36.0
FAQ
A: Yes. Both the LAN and the PoE ports of the PoE adapter
comply with IEEE 802.3i and IEEE 802.3u standards and support
10/100Mbps Auto-Negotiation.
Q1. Can the PoE adapter supply power to a passive PoE device
that doesn’t have a gigabit Ethernet port?
Q2. Can the Passive PoE adapter supply power to all my PoE
devices?
A: If your devices support passive PoE and the voltage
standards of the devices match that of the passive PoE adapter,
the passive PoE adapter can supply power to them.
Specications
IEEE 802.3i, IEEE 802.3u, IEEE 802.3abStandards
General Specications
Ports
10/100/1000Mbps Auto-Negotiation RJ45 LAN port
10/100/1000Mbps Auto-Negotiation RJ45 PoE port
UTP/STP of Cat. 5e or above (based on the
standards that the connected devices comply with)
Cable Type
Output Power
PWRLED
POE2412G: 24V/0.5A
POE4818G: 48V/0.375A
POE4824G: 48V/0.5A
Operating Temperature 0˚C to 40˚C (32˚F to 104˚F)
Storage Temperature -40˚C to 70˚C (-40˚F to 158˚F)
Storage Humidity 5% to 90% RH non-condensing
Operating Humidity 10% to 90% RH non-condensing
Environmental and Physical Specications
LED & Button
CE Mark Warning
Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам нормативних
документів та вимогам, що передбачені чинними законодавчими актами України.
CAN ICES-003 (B)/NMB-003(B)
Industry Canada Statement
BSMI Notice
安全諮詢及注意事項
請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。
清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。
注意防潮，請勿將水或其他液體潑灑到本產品上。
插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆蓋開口。
請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉位置中。
請不要私自拆開機殼或自行維修，如產品有故障請與原廠或代理商聯繫。
請確保接入帶保護接地之插座。
限用物質含有情況標示聲明書
產品元件名稱
PCB
外殼
電源線
其他及其配件
限用物質及其化學符號
備考1： "○"系指該項限用物質之百分比含量未超出百分比含量基準值。
備考2： " - " 系指該項限用物質為排除項目。
○ ○ ○ ○○
○ ○ ○ ○ ○
鉛
Pb
○
○
○
-
鎘
Cd
○
○
汞
Hg
○
○
六價鉻
Cr
+6
○
○
多溴聯苯
PBB
○
○
多
溴二苯醚
PBDE
○
○
EU Declaration of Conformity
TP-Link hereby declares that the PoE adapter is in compliance with the essential requirements and
other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2009/125/EC, 2011/65/EU and
(EU)2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/support/ce/
UK Declaration of Conformity
TP-Link hereby declares that the PoE adapteris in compliance with the essential requirements and
other relevant provisions of the Electromagnetic Compatibility Regulations 2016 and Electrical
Equipment (Safety) Regulations 2016.
The original UK declaration of conformity may be found at https://www.tp-link.com/support/ukca/
FCC compliance information statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received, including interference
that may cause undesired operation.
Any changes or modications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
We, TP-Link Systems Inc., has determined that the equipment shown as above has been shown to
comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in
the equipment and the equipment is properly maintained and operated.
Issue Date: 2025/07/24
Product Name: Passive PoE Adapter
Model Number: POE2412G/POE4818G/POE4824G
Power
On: Power on
O: Power o
Responsible party:
TP-Link Systems Inc.
Address: 10 Mauchly, Irvine, CA 92618
Website: https://www.tp-link.com/us/
Tel: +1 626 333 0234
Fax: +1 909 527 6804
E-mail: [email protected]
Explanation of the symbols on the product label
產品標籤上符號的解釋
Note: The product label can be found at the bottom of the product.
Symbols may vary from products.
注意：產品標籤可在產品底部找到。符號可能因產品而異。
Symbol
符號
Explanation
說明
Class II equipment
II類設備
Class II equipment with functional earthing
具有功能接地的II類設備
Alternating current
交流
Direct current
直流
Polarity of d.c. power connector
輸出端點的極性
For indoor use only
僅供室內使用
Dangerous voltage
危險電壓
Caution, risk of electric shock
請注意，有觸電的危險
Energy eciency Marking
能源效率標誌
Protective earth
保護接地
Earth
接地
Frame or chassis
功能接地
Functional earthing
功能接地
Caution, hot surface
請注意，表面過熱
Caution
警告
Operator's manual
操作手冊
Stand-by
待機
"ON"/"OFF" (push-push)
“開啟”/”關閉”（按壓式）
Fuse
保險絲
Fuse is used in neutral N
保險絲用於中性線 N
RECYCLING
回收
This product bears the selective sorting symbol for Waste electrical
and electronic equipment (WEEE). This means that this product must
be handled pursuant to European directive 2012/19/EU in order to be
recycled or dismantled to minimize its impact on the environment.
User has the choice to give his product to a competent recycling
organization or to the retailer when he buys a new electrical or electronic
equipment.
這個產品帶有歐盟指令 2012/19/EU 中關於廢棄電氣電子設備（WEEE）的
選擇性分類標誌。這意味著，該產品必須按照該指令處理，以便進行回收
或拆解，從而最大限度地減少對環境的影響。
用戶可以選擇將產品交給有資格的回收機構，或在購買新的電器或電子設
備時將其交給零售商進行回收。
Caution, avoid listening at high volume levels for long periods
請小心，避免長時間以高音量收聽。
Disconnection, all power plugs
斷線，所有電源插頭
m
Switch of mini-gap construction
迷你間隙結構開關
µ
Switch of micro-gap construction (for US version)
Switch of micro-gap / micro-disconnection construction (for other
versions except US)
小間隙結構開關（US 版本）
小間隙/小斷開結構的開關（非 US 版）
ε
Switch without contact gap (Semiconductor switching device)
無接觸間隙的開關（半導體開關設備）
Wall Mounting Requirements
To mount the device on a wall, use 2 screws which complies with ANSI
B1.1 4#, (5#), 6# standard and are more than 7 mm in length. When the
screws are xed on the wall, the distance between the screwhead and
the wall should be no more than 1.5 mm.
牆面安裝要求
將設備安裝到牆上，需使用 2 顆符合 ANSI B1.1 4#、(5#)、6# 標準、長度大於 7mm 的螺絲，
螺絲固定在牆上時，螺絲頭與牆面的距離應大於 1.5mm。
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/ TV technician for help.
Safety Information
Keep the device away from water, re, humidity, or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
The plug on the power supply cord is used as the disconnect device, the
socket-outlet shall be easily accessible.
Plug the product into the wall outlets with earthing connection through the power supply cord.
The PoE ports shall not be used to charge lithium batteries or devices supplied by lithium batteries.
Please read and follow the above safety information when operating the device. We cannot guarantee that
no accidents or damage will occur due to improper use of the device. Please use this product with care
and operate at your own risk.
