Finale 2-IN-1
Finale DX 2-IN-1
BOOSTER CAR SEAT
4358-8689
04.15.25
8689
KEEP INSTRUCTIONS FOR
FUTURE USE.
Read all instructions before
using this car seat.
WARNING Failure to follow the
warnings on the labels and in the
instruction manual can result in
serious injury or death to your child.
Serious injury may include paralysis
and/or permanent brain injury.
T
o
g
e
t
h
e
r
,
w
e
’
r
e
t
h
e
v
i
l
l
a
g
e
.
T
o
g
e
t
h
e
r
,
w
e
’
r
e
t
h
e
v
i
l
l
a
g
e
.
www.coscokids.com
Overview
Welcome to the Cosco family and thank you for choosing
this car seat, also known as a child restraint!
To help you get started using your child’s new car seat,
here are the 4 main tasks you’ll need to complete:
Your child’s safety is worth the time it will take for you to read
and follow these instructions.
Ready? Let’s go!
Pages 1–3 will introduce you to the parts of the car seat.
Page 60 has our contact information. If at any point you would like assistance,
please feel free to reach out to us.
Adjust Car Seat to Fit Your Child
Measure Your Child
Install Car Seat into Your Vehicle
Secure Your Child in Car Seat
Quick Navigation
BOOSTER SEAT
40–100 lb (18.1–45.4 kg) and
43.4–52 in. (110.1–132.1 cm)
In this car seat, your child can use the Booster Seat mode
until they fit the vehicle's lap and shoulder seat belt properly
without a Booster Seat OR outgrow any one of the above.
PAGE 4
Securing
Child
PAGE 29
Forward-Facing
Child Fit
PAGE 7
Booster
Child Fit
PAGE 39
Adjusting
Car Seat
PAGE 8
Vehicle Belt + Tether
PAGE 22
LATCH: Lower Anchor
Belt + Tether
PAGE 25
FORWARD-FACING
40–65 lb (18.1–29.5 kg) and
43.4–49 in. (110.1–125 cm)
In this car seat, your child MUST remain in harnessed
Forward-Facing mode until they outgrow any one of the above.
PAGE 4
Vehicle Belt
PAGE 40
Contents
Getting Started
Parts of Car Seat .............................. 1
Accessory Use ................................. 3
Choosing Car Seat Mode .................. 4
Prepare Car Seat to Fit Your Child ....... 6
Forward-Facing Child Fit ................ 7
Making Adjustments to Car Seat
Changing Shoulder Harness
Strap Position .................................. 8
Choosing LATCH or Vehicle Belt
LATCH: Lower Anchor Use ................10
Vehicle Belts .................................... 13
Tether Use ....................................... 18
Installation in Vehicle
Forward-Facing Mode ................... 20
Forward-Facing Vehicle Belt +
Tether Install .................................... 22
Forward-Facing LATCH
Lower Anchor + Tether Install ...........25
Securing Child in Car Seat ............. 29
Booster Seat Mode .........................33
Removing Harness System ...............35
Storing Harness System ................... 37
Booster Seat Child Fit ...................... 39
Lap/Shoulder Belt Use ....................... 40
Wash & Care of Car Seat Parts
Removing Seat Pad for Cleaning ..... 42
Cleaning Parts of Car Seat and
Installing Seat Pad Set .................... 43
Installing Harness System ................. 44
Safety Information
Child Restraint Use ........................... 48
Vehicle Seating Position ................... 49
Installation in Vehicle ........................ 50
Replacement and Expiration of
Car Seat .......................................... 51
Registration and Safety Notices ......... 53
Aircraft Information .......................... 55
Additional Information
Troubleshooting ............................... 56
Warranty ......................................... 57
Replacement Parts List ..................... 59
Dorel Juvenile Group Information ...... 60
Parts of the Car Seat
1 2
Harness
Strap
Chest Clip
Buckle
1 Moveable
Cup Holder*
Harness
Release Lever
(under flap)
Harness
Adjustment
Strap
LATCH: Lower
Anchor Belt
Bag May Be
Located in
Forward-Facing
Belt Path
Shoulder
Harness
Slots
Forward-Facing
Belt Path
Shell
(car seat)
Lower Anchor Belt
Attachment for
Storage
(under side
of shell)
Tether
Instruction
Manual
Storage
Splitter
Plate
Harness
Adjustment Strap
Tether
Attachment
for Storage
*
See page 3 for Accessory Use.
Arm Rest
(with cup holder
attachment)
Hip Slots
Children vary widely in body size, shape, and
temperament—please consult your doctor
before switching between any modes
within the limits and fit requirements of
the car seat.
Toddlers and Preschoolers
Children can only use a forward-facing car
seat once they outgrow rear-facing weight or
height limits. Once they are forward-facing,
children must use their child restraint in
forward-facing mode with a harness until
they reach the maximum weight or height
limits for forward-facing harness mode.
School-Aged Children
Children can only use a belt-positioning
booster car seat once they outgrow
forward-facing harness weight or height
limits. Children must use the belt-positioning
booster mode until the vehicle’s lap and
shoulder seat belt fit them properly without
the belt-positioning booster.
Accessory Use Choosing Car Seat Mode
3 4
1 Moveable Cup Holder
The cup holder is top-rack
dishwasher safe.
continued on next page
To remove cup holder,
locate the cup holder
tabs on back of the shell.
WARNING
Failure to follow these instructions
may result in serious injury or death to
your child. Serious injury can include
paralysis and/or permanent brain injury.
Be certain to measure your child’s
weight and height (do not guess) before
choosing this car seat’s mode.
To attach cup holder,
push cup holder onto end of
armrest (until you hear a click).
Push the tab to
the side.
While pushing the tab
to the side, pull out
the cup holder at an
upward angle.
Release Chest Clip
Hold each side of the
chest clip.
Press on the release
button with your
thumb and pull the
chest clip apart.
Prepare Car Seat to Fit Your Child
5 6
Place Child in Car
Seat to Determine
Proper Harness Fit
Your child’s bottom and
back should be flat
against the car seat.
For Forward-Facing child fit, see page 7.
Fully Loosen
Harness Straps
Push down on the
harness release
lever (under the
flap on the front
of the seat pad) while pulling out on
the harness straps as shown.
Unbuckle Harness
Press in towards
the top of the red
button to release
the buckle tongues.
1
3
4
2
FORWARD-FACING MODE
40–65 lb (18.1–29.5 kg) and 43.4–49 in.
(110.1–125 cm)
In this car seat, your child MUST remain
in harnessed Forward-Facing mode until
they outgrow any one of the following:
•
Weight Limit: 65 lb (29.5 kg); OR
•
Height Limit: 49 in. (125 cm); OR
•
Forward-Facing Child Fit requirements,
see page 7
BOOSTER SEAT MODE
40–100 lb (18.1–45.4 kg) and 43.4–52 in.
(110.1–132.1 cm)
In this car seat, your child can use the
Booster Seat mode until they fit the
vehicle’s lap and shoulder seat belt
properly without a Booster Seat OR
outgrow any one of the following:
•
Weight Limit: 100 lb (45.4 kg); OR
•
Height Limit: 52 in.(132.1 cm); OR
•
Booster Child Fit requirements,
see page 39
Forward-Facing Child Fit
7 8
Head Position
The tops of your child’s
ears MUST be below the
top of the car seat.
Buckle Position
The buckle strap should
not be underneath or
behind your child.
Harness Strap Position
The harness strap MUST
be at or slightly above
your child’s shoulders;
never below.
Need to make adjustments?
To change harness strap position,
see pages 8–9.
Fully Loosen
Harness Straps
Push down on
the harness
release lever
(under flap on
front of seat pad) while pulling out
on the harness straps as shown.
From Back
of Car Seat,
Remove Both
Harness Strap
Loops From
Splitter Plate
Pull Harness
Straps Out
of Shoulder
Harness Slots
sewn
end
sewn
end
sewn
end
Rethread Harness
Straps into
Correct Shoulder
Harness Slots For
Your Child
For Forward-Facing child fit,
see page 7.
sewn
end
1
2
3
4
Changing Shoulder Harness Strap Position
continued on next page
9 10
Attach Both Harness
Strap Loops to
Splitter Plate
Sewn ends of
the harness strap
loops MUST face
towards you.
DO NOT twist harness straps or
harness adjustment strap. Make sure
the harness strap loops are fitted
completely on both sides of the
splitter plate.
Check your child’s fit often.
sewn
end
To learn how to check harness
tightness, see pages 29–32.
Check the harness straps often for
any wear or damage.
5
LATCH: Lower Anchor Use
Your vehicle’s features may be considerably different than those pictured here.
The lower anchors of LATCH (Lower Anchors and Tethers for CHildren) is a universal
system for installing car seats without using vehicle seat belts. The LATCH: lower
anchor belt can ONLY be used in vehicles that have the lower anchor bars installed in
designated seating positions. Most vehicles manufactured after September 2002 are
equipped with LATCH: lower anchor bars.
Check your vehicle owner’s manual to see which seating positions may be equipped
with LATCH: lower anchor bars.
Seat Bight
Lower Anchor Bars
For Use in Forward-Facing Mode
WARNING
Make sure the harness height is correct
for your child’s size.
Harness system MUST be installed
correctly. DO NOT use a child restraint
with damaged harness straps.
Failure to follow these warnings can
result in serious injury or death.
Serious injury can include paralysis
and/or permanent brain injury.
WARNING
11 12
Lower Anchor
Hooks
Adjuster
To Remove Lower Anchor Belt from
Storage Location on Car Seat:
Squeeze spring lever on hooks and remove
hooks from storage attachments.
When installing this car seat with vehicle
belts, the lower anchor hooks and belt
MUST be properly stored.
DO NOT use both the lower anchor belt and vehicle belt at the same time.
Storing Lower Anchor Belt:
Thread the lower anchor belt through the Forward-Facing belt
path. Then attach the hooks to storage attachments, as shown.
Gently pull free end of belt to
remove slack.
To Remove Lower Anchor Belt from Vehicle
Lower Anchor Bars:
Remove tension from the belt by pushing down
on side of car seat with the belt adjuster. Then
press the adjuster button to loosen belt.
Unhook from anchor by squeezing spring lever on hook, pushing hook back into the
seat bight, and twisting. Then pull it out of the vehicle seat.
13 14
Your vehicle’s features may be considerably different than those pictured here.
If lower anchors are not an option, you MUST use the vehicle seat belt system to
install the car seat.
Not all vehicle belts and seating positions will work with child restraints. Please
go through the following steps to understand how to lock a child restraint in
Forward-Facing Mode with a vehicle belt.
Vehicle Belts
continued on next page
Vehicle Belts
You Must Review
Your Vehicle
Owner’s Manual
Your vehicle
owner’s manual will
let you know which
vehicle belts and seating positions
car seats can be installed in.
Check How This Car
Seat Will Be Locked
Into Place
The vehicle belt
MUST not loosen
after tightening. This
means there needs to be a way to lock
the vehicle belt.
The ways this can be done are:
• By using the seat belt’s retractor, see
step 3; OR
• By using the seat belt’s latch plate,
see step 4.
1 2
15 16
continued on next page
Check
Retractor
Retractors pull
seat belts into
stored positions
and lock the belt
to hold passengers in place.
See the following section, for some
common types of vehicle belt
retractors that will work with this
car seat.
Switchable Retractor
(most vehicles have this type)
This retractor can be switched to a
locking mode.
You MUST have the retractor in the
locking mode to use the seat belt with
this car seat.
Switching to locking mode: Slowly pull
the shoulder belt all the way out, then let
it go back in 1–2 in. (2.5–5 cm).
As it goes back in, you will most likely
hear a ratcheting sound.
Gently pull the belt to see if it has locked.
You will not be able to pull any more belt
out if the lock has engaged.
Types of Retractors
3
This retractor always locks.
It will automatically lock after slowly
pulling the seat belt out at least halfway
and letting the belt go back into the
retractor 1–2 in. (2.5–5 cm).
If the retractor does not lock, it is most
likely an Emergency Locking Retractor.
These retractors only lock during a
sudden stop or collision.
Automatic Locking
Retractor
Emergency Locking
Retractor
See Step 4,
Check Latch
Plates.
Locking Latch
Plate
Check Latch Plates
Latch plates are the
part of the seat belt
that goes into
the buckle.
To see if the latch
plate locks:
1. Buckle vehicle belt.
2. Slowly pull up on
the lap portion of
the vehicle belt.
You will need to determine if your seat
belt’s latch plate can lock the belt. See
step 4, Check Latch Plates.
4
17 18
Emergency Locking
Retractor Lap Only Belt
Inflatable Seat Belts
Never Use With This
Car Seat
If the vehicle belt does not slide through
the latch plate, it’s locked.
If the latch plate slides up and down the
vehicle belt, it is a sliding latch plate.
Sliding latch plates
easily slip between
the lap and shoulder
portions of the belt.
Sliding Latch
Plate
If you have an Emergency Locking
Retractor with a Sliding Latch Plate,
you must use a locking clip.
Please contact us for one,
see page 60.
Tether Use
Your vehicle’s features may be
considerably different than those
pictured here.
Tether Anchors
For Forward-Facing
Mode Only
When anchors are available, you must alwaysattach, adjust, and secure the top anchorage (tether)
strap when installing the child restraint in the Forward-Facing Mode with internal harness. Tethers
improve the installation and stability of child restraints and reduce the risk of injury. Attach the tether
hook to the tether anchor designated by your vehicle manufacturer for that seating position. Check your
vehicle owner’s manual for more information. If the seating position does not have a tether anchor, use a
different seating position or see your dealer or a qualified mechanic and have one installed.
WARNING
Using this child restraint without the tether strap anchored as required by the manufacturer would be
a misuse of the child restraint and, in a sudden stop or crash, could result in serious injury or death.
Serious injury can include paralysis and/or permanent brain injury.
DO NOT fasten multiple tether hooks on the same tether anchor in the vehicle.
continued on next page
19 20
Storing Tether Strap
When the car seat is not installed in a vehicle,
attach the tether hook to its storage attachment on
the back of the car seat as shown.
Gently tighten to remove slack.
Adjuster
Strap
Hook
Storage
Attachment
Tether Storage and Parts
Adjusting Tether Strap
To tighten: After the car seat is locked into place
with the lower anchor belt or vehicle belt, push
down on the car seat and gently pull on the free end
of the tether strap.
To loosen: Lift up on the tether adjuster and push it
towards the tether hook.
If your car seat has an adjuster with a button, then
squeeze the adjuster button and pull the strap to
loosen as shown.
Pull free end of
belt to tighten
Lift adjuster
up to
loosen
Forward-Facing Mode
Lower Anchor
Belt with Tether
Do not install by this
method for a child
weighing more than
50 lb (22.7 kg)
40–65 lb (18.1–29.5 kg) and 43.4–49 in. (110.1–125 cm)
Lap/Shoulder
Belt with Tether
Lap Belt
with Tether
continued on next page
For a child up to
65 lb (29.5 kg)
For a child up to
65 lb (29.5 kg)
WARNING
21 22
Forward-Facing Vehicle Belt + Tether Install
Check if Your
Vehicle Belts
Will Work With
This Car Seat
This is very
important because not all vehicle
belts will work with car seats.
Review pages 13–17 and your
vehicle owner’s manual to find out
what kind of vehicle belt you have
and how to lock a car seat in place.
Loosely Attach
Tether Hook
Check your vehicle
owner’s manual
for specific tether
(top anchorage)
anchor locations.
Place Car Seat
Forward-Facing in
Back Seat
The vehicle seat back
MUST be in the upright
position, but you can
adjust the angle slightly to better match
the angle of the car seat.
2
1
3
continued on next page
• DO NOT use the lower anchors of the child restraint anchorage system (LATCH system) to
attach this child restraint when restraining a child weighing more than 50 lb (22.7 kg).
• The vehicle belt MUST be used for installation if your child weighs more than 50 lb (22.7 kg).
• When anchors are available, you MUST ALWAYS attach, adjust, and secure the tether (top
anchorage) strap when installing the car seat in the Forward-Facing Mode with
internal harness.
• DO NOT use the lower anchor belt along with the vehicle lap or lap/shoulder belt.
• Check the vehicle belt or the lower anchor belt before each use.
• Use ONLY if the belt can be tightened properly and locked securely in place.
• DO NOT fasten multiple lower anchor hooks on the same lower anchor bar in the vehicle.
• Even when unoccupied, this child restraint MUST be firmly secured to the vehicle with the
lower anchor belt or with the vehicle seat belt.
Before you begin installing the seat
into your vehicle, did you check:
Your child’s weight and height?
See page 20.
Your child’s fit? See page 7.
Do you need to make adjustments to the
harness strap position?
Tighten Tether
Push firmly on the back of
the car seat and pull the
free end of the tether strap
to remove all of the slack.
Check Belt Tightness
Hold the car seat at
the Forward-Facing
Belt Path with your
non-dominant hand.
Push and pull the car
seat from side to side. It should not
move more than 1 in. (2.5 cm).
23 24
Buckle
Vehicle Belt
Locate Forward-
Facing Belt Path
Thread the vehicle
belt through Forward-
Facing Belt Path
opening as shown.
The belt goes:
• Across the car seat; AND
• Under the car seat pad; AND
• Out the other Forward-Facing Belt
Path opening. DO NOT twist belt.
Tighten Belt
Place your hand in the
car seat.
Firmly push the car
seat down and back
towards the vehicle
seat back while pulling the shoulder
belt or the free end of lap belt parallel
with the Forward-Facing Belt Path.
4 6
5
7
Securing Child in
Car Seat
To properly secure
your child in the
car seat, see
pages 29–32.
Check your child’s fit often and
make any needed adjustments to
the car seat as they grow.
Finished!
Check the
tightness of the
install often to
make sure it has
not loosened.
8
If it moves more than 1 in. (2.5 cm),
you can try:
• Pulling the belt tighter; OR
• Reinstalling the car seat; OR
• Changing to a different seating location; OR
• Switching to lower anchor belt installation if
lower anchor are available in your vehicle
25 26
Forward-Facing LATCH: Lower Anchor + Tether Install
continued on next page
Remove Lower
Anchor Belt from
Storage Location
Or pull lower anchor
belt packaging out
of Forward-Facing
belt path. Remove lower anchor from
packaging. Discard the packaging.
Locate Forward-
Facing Belt Path
Thread the hook
through the
Forward-Facing
Belt Path opening
as shown.
The adjuster can be on either side of
the car seat.
The belt goes:
• Across the car seat; AND
• Under the car seat pad; AND
• Out the other Forward-Facing
Belt Path opening.
DO NOT twist belt.
2
1
Loosely Attach
Tether Hook
Check your vehicle
owner’s manual
for specific tether
(top anchorage)
anchor locations.
Attach Lower Anchor
Hooks to Vehicle’s
Lower Anchor
Review your vehicle
owner’s manual for
lower anchor locations
and lower anchor belt use. Fasten one
hook to one vehicle lower anchor bar.
Then repeat for the second hook on the
other side of the car seat.
Place Car Seat
Forward-Facing
in Back Seat
The vehicle seat
back MUST be
in the upright
position, but you can adjust the
angle slightly to better match the
angle of the car seat.
4
6
5
Finished Lower
Anchor Belt
Routing
3
Before you begin installing the seat
into your vehicle, did you check:
Your child’s weight and height?
See page 20.
Do not install by this method for a child
weighing more than 50 lb (22.7 kg).
Your child’s fit? See page 7.
Do you need to make adjustments to the
harness strap position?
27 28
Tighten Belt
Place your hand in
the car seat.
Firmly push the
car seat down and
back towards the
vehicle seat backwhile pulling the
free end of the belt parallel with the
Forward-Facing Belt Path.
7
Tighten Tether
Push firmly on the
back of the car seat
and pull the free end
of the tether strap to
remove all of the slack.
Securing Child
in Car Seat
To properly secure your child in the
car seat, see pages 29–32.
Check your child’s fit often and make
any needed adjustments to the car
seat as they grow.
Check Belt
Tightness
Hold the car seat at
the Forward-Facing
Belt Path with your
non-dominant hand.
Push and pull the car seat from side to
side. It should not move more than
1 in. (2.5 cm) at the belt path.
If it moves more than 1 in. (2.5 cm),
you can try:
• Pulling the belt tighter; OR
• Reinstalling the car seat; OR
• Changing to a different seating
location; OR
• Switching to vehicle belt installation
8
9
Finished!
Check the tightness
of the install often
to make sure it has
not loosened.
29 30
Securing Child in Car Seat
Place Child in
Car Seat
Your child’s bottom
and back should
be flat against the
car seat.
Position the harness straps over your
child’s shoulders and upper thighs.
Buckle Harness
Push the buckle
tongues into the
buckle until you hear
them “click”.
Pull up on the harness straps to make
sure the buckle is locked.
Fasten Chest Clip
Insert right half of
the chest clip into
the left half and
snap together.
Tighten Harness
Pull the harness
adjustment strap
straight out to
snugly tighten the
harness system.
continued on next page
1 3
42
Position
Chest Clip
Slide the chest clip
up the harness
straps and position
it at mid-chest
(even with armpits)
and away from
your child’s neck.
Check Harness
Tightness
Try to pinch the harness
strap at the shoulder
vertically between your
index finger and thumb
as shown.
If your fingers slip off, the harness
system is tight enough. If you can pinch
the harness strap, tighten more.
A snug strap should not allow any
slack. It lies in a relatively straight line
without sagging. It does not press on
the child’s flesh or push the child’s
body into an unnatural position.
If one side of the harness is tighter than
the other, lengthen the tighter side by
pulling up the harness near the hip slot.
5 6
WARNING
Failure to fasten and tighten the
harness system correctly may allow
the child to be ejected from the
child restraint in a crash or sudden
stop causing serious injury or death.
Serious injury can include paralysis
and/or permanent brain injury.
DO NOT mistake comfort for
safety. Harness system must be
snugly adjusted.
DO NOT put
snowsuits or bulky
garments on your
child when placing
them in the
child restraint.
Bulky clothing can prevent the
harness straps from being
tightened properly.
31 32
To Remove Child from Car Seat:
Finished!
Your child is now secured in the car seat.
Check your child’s fit often and make any needed
adjustments to the car seat as they grow.
1. Loosen harness strap.
2. Unbuckle harness.
3. Release chest clip.
4. Remove child.
WARNING
33 34
Booster Seat Mode
40−100 lb (18.1–45.4 kg) and 43.4–52 in. (110.1–132.1 cm)
Lap/Shoulder Belt
Keep the booster
seat securely belted
even when
unoccupied.
DO NOT use the harness system when using
as a booster seat.
DO NOT use LATCH when using as a booster
seat. Secure the lower anchor belt and the
tether strap to their storage attachments.
Warning! Use only the vehicle’s lap and
shoulder belt system when restraining the
child in this booster seat.
DO NOT use only the lap
belt when using this seat as
a booster seat. The shoulder
belt MUST always be
adjusted snugly across the
child’s chest.
NEVER place shoulder belt under the
child’s arms or behind their back.
DO NOT use this booster seat if the
tops of your child’s ears are above the
top of the booster seat’s headrest.
35 36
Removing Harness System
From Back of
Seat, Remove
Harness Strap
Loops From
Splitter Plate
Unthread
Chest Clip
Pull Harness
Strap Out
of Shoulder
Harness Slots
Fully Loosen
Harness Straps
Only remove the harness system to clean the seat pad or to convert to
Booster Seat Mode.
1
sewn
end
3
sewn
end
4
sewn
end
2
Pull Harness Strap
Out of Car Seat
sewn
end
sewn
end
Turn Car Seat Over
Locate the buckle’s
metal retainer on the
bottom of the shell.
Unthread Buckle
DO NOT unbuckle.
sewn
end
5
7
6
sewn
end
Rotate Metal
Retainer and
Push It Up
Through Shell
and Pad
8
sewn
end
From Top of Car
Seat, Pull Buckle
Out of Shell
9
37 38
To store the harness system for Booster Seat Mode, you must remove the
harness system. See pages 35−36.
Storing Harness System
Lift up Front
Bottom of Pad
As Shown
From Top of
Seat, Lay Metal
Retainer Flat
Against Shell
As Shown
Insert Buckle’s
Metal Retainer Up
Through Buckle
Slot As Shown
Buckle will hang
down underneath
shell when stored.
Turn Seat Over
and Locate
Buckle Slot on
Bottom of Shell
1
2
3
4
Wrap Harness
Strap Around
Itself As Shown
Place Wrapped
Harness Strap
into Slot
for Storage
Replace Pad
Place Chest
Clip into Slot
for Storage
Secure Splitter
Plate
Pull the harness
adjustment strap
toward you so the
splitter plate is flush
against the shell,
as shown.
5
6
7
8
9
Check Car Position
DO NOT use the booster
seat if your child’s head is
less than 5 in (12.7 cm)
below the roof of the car.
Consult your vehicle manual for proper
seatbelt usage.
Check Lap
Belt Position
The lap belt should
lay snugly across the
child’s hips and not on
their stomach.
Check Shoulder
Belt Position
The shoulder belt should
lay across your child’s
chest, centered on the
edge of their shoulder, and away from
their face and neck.
Check Head Position
The top of the child’s ears
should never be above the
top of the booster seat.
39 40
Booster Seat Child Fit Lap/Shoulder Belt Use
Position Lap
Belt on Child
The lap belt should
lay snugly across
the child’s upper
thighs and not on
the stomach.
The lap belt MUST go under both
armrests. The shoulder belt MUST only
go under the armrest on the buckle
side as shown.
Place Booster Seat
Forward-Facing
Flush Against
Vehicle Seat Back
The vehicle seat
back MUST be in
the upright position,
but you can adjust the angle slightly to
better match the angle of the car seat.
Buckle
Vehicle Belt
2
3
1
continued on next page
5 in. (12.7 cm)
5 in. (12.7 cm)
5 in. (12.7 cm)
NOTE: DO NOT
thread the shoulder
belt through the slots
in the side of the
car seat if they are
present on your model.
41 42
continued on next page
Removing Seat Pad for Cleaning
Remove Pad
Pull the pad off
the bottom of
the car seat and
remove the pad.
You must remove the harness system to remove the pad from the shell.
See pages 35−36.
Release Elastic
Straps From Tabs
on Back of Shell
Position Shoulder
Belt on Child
Pull up on shoulder
belt to tighten.
The shoulder belt
should lay across
your child’s chest,
centered on the edge of their shoulder
away from their face and neck, and
around the side of the car seat.
Check periodically to ensure your child
has not moved out of position and
loosened the shoulder belt.
4
43
44
Insert Buckle’s
Metal Retainer
into Slot
The buckle MUST
face out.
Check Buckle
Pull up on the
buckle to make sure
it is secured.
The buckle MUST not
pull out.
Pull Metal Retainer
Completely
Through Pad
and Shell
sewn
end
sewn
end
sewn
end
Rethread
Harness Strap
With the sewn end
of the harness
strap loop facing
the buckle, thread
the harness strap down through the
hip harness slot.
sewn
end
1 3
2
4
continued on next page
Installing Harness System
Cleaning Pad and Accessories
Machine wash separately with cold water
on a gentle cycle. DO NOT use bleach.
Tumble dry separately for 10−12 minutes
on low heat. Remove immediately.
Cleaning Harness Strap
Check the harness straps often for any
wear or damage.
Spot clean using warm sudsy water and
damp cloth.
Spilled food and liquids on the car seat
may result in mold or bacterial growth
over time. These spills could also attract
insects or rodents.
Cleaning Buckle & Car Seat Shell
Spot clean using warm sudsy water and
damp cloth. DO NOT submerge into water.
Replace Pad
Starting from bottom of car seat, slip pad
on shell. Pull harness adjustment strap
through pad. Wrap pad around the top of
shell. Attach all of the elastic straps.
Install harness system, see pages 44−47.
Cleaning Parts of Car Seat and Installing
Seat Pad Set
WARNING
DO NOT use the child restraint without the
seat pad or with damaged harness straps.
45 46
Thread Harness
Straps Into Correct
Shoulder Harness
Slots For Your Child
For Forward-Facing child fit,
see page 7.
sewn
end
Make Harness
Strap Even
The sewn ends
of harness strap
loops MUST face
each other.
Pull Harness
Strap Across
Bottom of Shell
The harness strap
MUST lie in front
of the harness
adjustment strap as shown. Push the
harness strap up through other the hip
harness slot.
sewn
end
sewn
end
Thread Buckle
and Chest Clip
The harness strap
ends go through the
back of the buckle
tongues and through
the chest clip front to
back as shown.
sewn
end
7
5
6
8
Attach Harness
Strap Loops to
Splitter Plate
As Shown
The sewn ends of
the harness strap
loops MUST face
towards you.
DO NOT twist the
harness strap or
the harness
adjustment strap.
Make sure the harness strap loops are
fitted completely on both sides of the
splitter plate.
sewn
end
sewn
end
9
Check your child’s fit often.
To learn how to check harness
tightness, see pages 29−32.
Check the harness straps often for
any wear or damage.
continued on next page
XXXXXXXXX
1
WARNING
47
Failure to place harness adjustment strap behind the
harness strap as shown can result in serious injury or death.
Serious injury can include paralysis and/or permanent
brain injury.
DO NOT use a child restraint with damaged harness straps.
sewn
end
WARNING
Child Restraint Use
NEVER take your child out of the child
restraint while the vehicle is moving.
NEVER leave child unattended.
Placing your child in a hot child
restraint may result in burns.
DO NOT use a child restraint with
damaged or missing parts.
DO NOT use a child restraint with cut,
frayed or damaged harnesses.
DO NOT substitute parts or try to
modify the child restraint in any way.
DO NOT lubricate buckles
and fasteners.
DO NOT use any child restraint
accessory except those approved by
Dorel Juvenile Group.
NEVER allow any child to play with this
child restraint; it is not a toy.
DO NOT remove or cover up any of the
warning labels or other labels on the
child restraint.
This child restraint has been certified for
use in passenger vehicles. DO NOT use in
a boat, on a motorcycle, or in a cargo van
or bus where there are no seat belts or
tether anchors.
Read all instructions for additional warnings.
48
XXXXXXX XXXXXXXXX
1 1
WARNING
NEVER place a child rear-
facing in a seating position
with an active frontal air bag.
Check the vehicle owner’s
manual for more information about air
bag/child restraint use.
Use the child restraint
only on vehicle seats
that face forward.
DO NOT use on seats
that face the sides or
rear of the vehicle.
For vehicles without a back seat, refer to
your vehicle owner’s manual.
Vehicle Seating Position
According to accident
statistics, children are
safer when properly
restrained in the rear seating positions
than in the front seating positions.
Rear seating positions are statistically
safer, whether you have air bags,
advanced air bags, or no air bags at all.
If you are not sure where to place
the child restraint in your vehicle:
consult your vehicle owner’s manual;
contact Dorel Juvenile Group Consumer
Care Department; or Visit your local
Child Passenger Inspection Station. Go
to https://www.nhtsa.gov/vehicle-safety/
car-seats-and-booster-seats to find your
closest station.
WARNING
To avoid your child being seriously
burned, take the following precautions:
• Park in the shade or where sun does
not directly hit the child restraint.
• Cover the child restraint with a sheet or
blanket when not in use.
• Check for hot seat and buckles before
placing child in child restraint.
To help protect your vehicle seat’s
upholstery from damage, you may use
an accessory approved by Dorel Juvenile
Group or a single layer towel underneath
and behind car seat.
Check the vehicle belt or LATCH belt
before each use. Use only if the belt
is tightened properly and locked
securely in place.
Even when unoccupied, this child
restraint MUST be firmly secured to the
vehicle with a lower anchor belt or with
the vehicle seat belt.
Even when unoccupied, this booster
seat MUST be firmly secured to the
vehicle with the vehicle seat belt.
In a crash or sudden stop, an
unsecured child restraint or booster
seat could injure occupants.
Installation in Vehicle
49 50
Replacement and Expiration of Car Seat
DO NOT risk your child’s safety.
To keep your child as safe as possible, Dorel Juvenile Group strongly recommends
replacing the car seat even after a minor crash; even if it was not occupied at the time.
Replacement After a Minor Crash
The National Highway Traffic Safety Administration states that for a crash to be
considered minor ALL of the following MUST be true:
• Vehicle able to drive away from the crash site; AND
• Vehicle door nearest the car seat was not damaged; AND
• No passengers were injured; AND
• Airbags did not deploy; AND
• There is no visible damage to the car seat.
52
If the crash your car seat was involved in meets ALL the criteria, you may not need to
replace the car seat. If one or more of these criteria are not true or if you are uncertain
of any of your answers, replace the car seat immediately.
Replacement After a Moderate to Severe Crash
You MUST replace this car seat if it has been in a moderate to severe car crash. This
car seat is intended to protect a child in a single crash. During a crash, the car seat
and all of its parts absorb crash energy which can deform or weaken it. Damage is not
always visible. A damaged car seat must be replaced immediately.
Expiration
On the side of the child restraint there is a date of manufacture
label as shown. DO NOT use this child restraint more than 10
years after the date of manufacture.
COSCO FINALE 2-in-1
51
XXXXXXX XXXXXXXXX
1 1
Registration and Safety Notices
Please complete the postage-paid registration card that came with your child restraint,
and send it to us. Child restraints could be recalled for safety reasons. You must register
this restraint to be reached in a recall. Send your name, address, e-mail address if
available and the restraint’s model number and manufacturing date to:
Dorel Juvenile Group
P.O. Box 2609
Columbus, IN 47202
or call 1-800-544-1108 or register online at
https://www.coscokids.com/registration/.
For recall information, call the U.S. Government’s Vehicle
Safety Hotline at 1-888-327-4236 (TTY: 1-800-424-9153),
or go to www.NHTSA.gov.
If you don’t have the card or if your
address changes, you will find the
model number, manufacture date,
and line code on the label located
on side of shell.
COSCO FINALE 2-in-1
Example of model number, line
code and manufacture date.
BRAND CAR SEAT
2025/03/01
Manufacture
Date
Line
Code
Model
Number
53 54
XXXXXXX
1 56
Troubleshooting
1. If the child restraint buckle or harness release lever sticks or you cannot get
the straps tight enough around child:
DO NOT LUBRICATE. Check around lever and retractor for dropped food, sticky spilled
drinks, dirt, leaves, etc. Clean with warm water and/or remove object with tweezers. If
you cannot get the harness to adjust and remain tight with the buckle securely locked,
do not use the child restraint.
2. If your harness twists:
Straighten the harness each time you put your child in the child restraint to help
prevent twisting. Lock the buckle and tighten harness and it will be ready for next use.
©2025 Dorel Juvenile Group, Inc. (800) 544-1108 www.coscokids.com. Styles and colors may vary. Los estilos y loscolores
pueden variar. Made in USA from American and imported parts (including seat pad). Hecho en EE.UU. a partir de piezas americanas
e importadas (incluyendo la almohadilla del asiento). Distributed by (distribuido por) Dorel Juvenile Group, Inc., 2525 State St.,
Columbus, IN 47201-7494. Dorel Juvenile Canada, 2233 Argentia Road, Suite 110, Mississauga, ON L5N 2X7. Representante
exclusivo en Chile: DOREL JUVENILE CHILE S.A. Av. del Parque 4161, oficina 602 A, Huechuraba, Santiago, Chile - Fono:
56 2 24971500 - www.infanti.cl - www.dorel.cl. Importado y distribuido en Perú por: COMEXA COMERCIALIZADORA EXTRANJERA
S.A. SUCURSAL DEL PERÚ - Los Libertadores 455, San Isidro, Lima 27, Lima, Perú RUC 20431062870 – Fono: 4413029 –
www.infanti.com.pe. En Centro América, Caribe y Ecuador por: Best Brands Group S.A. – Av. Balboa, Bay Mall
Plaza, Planta Baja, local 9, Panamá. - Fono: (507) 300 2884. En Colombia por: Baby Universe S.A.S. - Vía 40 No.
77-29, Barranquilla, Colombia - Fono: (575) 353 1110 Importador: DJGM, S.A. DE C.V. Gabriel Mancera No. 1041
Col. Del Valle, Benito Juárez C.P. 03100 México, Ciudad de México R.F.C. DJG140305GN9 Tel. (55) 67199202
Aircraft Information
55
This restraint is certified for aircraft use
when used with the internal harness.
You MUST store the lower anchor belt
and tether strap when installing with
aircraft belts.
WARNING
Forward Facing
Aircraft Installation
Follow the steps on
pages 22–24, skipping
the tether strap steps.
Booster Seat
This restraint is not certified
for aircraft use when used
as a booster seat because
aircraft seats do not have shoulder belts.
Install the child restraint in a window
seat to avoid blocking the aisle. If the
aircraft lap belt is too short, ask the
There is an airplane
certification label located
on the side of this child
restraint as shown.
flight attendant for a belt extender.
Use only on forward facing aircraft seats.
Contact the airline for their specific policies.
Some airlines may ask to see a label stating
that this child restraint is certified for
aircraft use.
57 58
Warranty
Dorel Juvenile Group, Inc. (DJG) warrants this product to the original retail purchaser
as follows:
This product is warranted against defective materials or workmanship for one year
from the date of original purchase.
An original receipt is required to validate your
warranty.
DJG will, at its option, provide replacement parts or replace this product. DJG
reserves the right to substitute if the part or model has been discontinued.
To make a claim under this warranty, please contact our Consumer Care Department by
phone:
1-800-544-1108; text: 1-812-652-2525; or chat with us: www.coscokids.com.
Our hours of operation are from 8:00 a.m. to 6:00 p.m. EST Monday through Thursday
and from 8:00 a.m. to 4:30 p.m. on Friday.
Proof of purchase is required and shipping charges are the responsibility of
the consumer.
Warranty Limitations:
This warranty does not include damages which arise from
misuse or abuse of this product.
Limitation of Damages:
The warranty and remedies as set forth are exclusive and
in lieu of all others, oral or written, expressed or implied. In no event will DJG or the
dealer selling this product be liable to you for any damages, including incidental or
consequential damages, arising out of the use or inability to use this product.
This warranty gives you specific legal rights, and you may have other rights, which vary
from state to state. Neither DJG nor the dealer selling this product authorized any person
to create for it any other warranty, obligation, or liability in connection with this product.
Limitation of warranties and other warranty terms and state law rights:
Any
implied warranties, including implied warranties of the merchantability and fitness
for a particular purpose, shall be limited to the duration and terms of the express
written warranty.
Some states do not allow limitations as to how long an implied warranty lasts or the
exclusion or limitation of incidental or consequential damages, so the above limitations
may not apply to you. This warranty gives you specific legal rights, and you may have
other rights, which vary from state to state. Neither DJG nor the dealer selling this
product authorized any person to create for it any other warranty, obligation, or liability
in connection with this product.
59 60
Replacement Parts List Dorel Juvenile Group Information
Chest Clip
Buckle Assembly
Seat Pad Set
1 Moveable Cup Holder
Tether
Lower Anchor Belt
Harness Strap
Instructions
Locking Clip
If requested color is not available,
similar color will be substituted.
Applicable tax and shipping &
handling will also be added.
For parts availability and questions,
Call: 1-800-544-1108
Text:
1-812-652-2525
Chat: www.coscokids.com
Email: [email protected]
If you already know which parts you
need, you may complete your order with a
credit card by calling us at 1-800-544-1108.
We accept Visa or MasterCard.
Hours of Operation:
M−TH: 8:00 AM−6:00 PM EST
FRI: 8:00 AM−4:30 PM EST
Thank you for choosing this child
restraint. The DJG family is committed
to creating child restraints with
the most comfort and convenience
available today.
Remember, parents are a child’s first
teachers and examples. If you always
buckle your seat belt, your child will
think it is the natural thing to do. Make
it a firm rule that the vehicle does not
go until everyone is buckled up. Make
no exceptions.
Call: 1-800-544-1108
Text: 1-812-652-2525
Chat: www.coscokids.com
Email: [email protected]
Hours of Operation:
M−TH from 8:00 AM to 6:00 PM EST
FRI from 8:00 AM to 4:30 PM EST
No one can predict if use of a child
restraint will prevent injury or death
in a particular crash. However, when
combined with careful driving, proper use
of a child restraint can lower a child’s risk
of injury or death in most crashes.
Your child’s safety is worth the time it will
take to read and follow these instructions.
After reading, if you still have questions
or have any concerns with this child
restraint, please contact our Consumer
Care Department:
