TWO-WAY EXHAUST FAN
USER MANUAL
CONTENTS
01
01
01
02
03
PRODUCT PARAMETERS
PRODUCT DIMENSION
PACKING LIST
REMOTE CONTROL INSTRUCTIONS
INSTALLATION STEPS
04
INSTALLATION PRECAUTIONS
05
MAINTAINANCE
06
TROUBLESHOOTING
07
GUARANTEE & AFTER-SALE
Power: 40 W
Voltage: 110 V
Frequency: 60 Hz
Airflow: 182 CFM
Speed: 2100 RPM
Noise: 35 dB
Unit: inch
Size φA B C D
6 Inch 5.86 7.87 4.72 5.31
DC
φA
B
6 Inch
Exhaust Fan x1
Remote
Control x1
Metal Mesh
Screen x2
Pack of
Screws x1
1
2 3 4
PACKING LIST
PRODUCT PARAMETERS
PRODUCT DIMENSION
01
REMOTE CONTROL INSTRUCTIONS INSTALLATION STEPS
(1) If you can't control the exhaust fan with the remote control, please check wheth-
er the battery is installed backwards or the power is insufficient.
(3) If you can't control the exhaust fan with the remote control, the remote control
and the exhaust fan may not be correctly matched, please refer to the "Trouble-
shooting" section for the correct matching method.
(2) Please note that when using the function of switching the wind direction, the
fan will first stop rotating and stand for about 8 seconds before it starts working,
please don't worry, this is normal.
(4) The product is not equipped with batteries, please buy two AAA type batteries by
yourself.
OFF
IN
LOW
ON
OUT
HIGH
Turn on the fan.
Switch the wind
direction to air intake.
Switch to low speed.
Turn on the fan.
Switch the wind
direction to air exhaust.
Switch to high speed.
Step 1 Open a hole on the wall or ceiling.
150mm
Step 2 Remove the panel by turning it counterclockwise.
Step 4 Fix the exhaust fan to the wall
with stainless steel screws.
0302
Wall
Step 3 Mark the screws' positions and
nail the plastic screws
completely into the wall.
Wall
(4) Exhaust fans should not be installed in places where water seeps or leaks, or in
places with high temperatures, and the vent pipe connected to the product needs
to avoid entering the flue containing toxic gases.
(5) Use the remote control to control the exhaust fan. Disconnect the power plug
when not in use for a long time.
(6) Take care to avoid backflow of gases from all types of open flame equipment
into the room.
(7) If the power cord is damaged, it must be replaced with a correct cord purchased
from the professional manufacturers. To avoid danger, the repair and replacement
must be performed by the manufacturer or a person with specialized knowledge.
(8) This product is not intended for use by persons lacking experience or common
sense (including children), except under the care or guidance of a guardian (it
should be ensured that children do not use this product as a toy).
(1) The exhaust fan will start working automatically when the plug is inserted.
Please stay away from the fan blades to avoid injury.
(2) Please note that running the fan after installing the filter may slightly increase
the noise and slightly affect the air flow.
(3) If the power cord needs to be set in the hole, please reserve the space for it
when making a hole for the exhaust fan installation.
MAINTAINANCE
INSTALLATION PRECAUTIONS
(1) Please make sure to cut off the power before maintenance.
(2) Remove panels and parts to be cleaned. Rinse with a brush and water. The dirt
that is difficult to remove can be soaked with a neutral cleaner. The motor and
electrical components must not come into contact with water.
(3) Dry the clean parts in the sun or with a cloth before installing the exhaust fan.
If the power cord is found to be broken during maintenance, it should be replaced
by professional maintenance personnel.
(4) Do not use gasoline or corrosive chemicals to clean the exhaust fan. Plastic
parts cannot be soaked in hot water above 60 degrees Celsius.
Step 6 Install the panel by turning it clockwise.
Step 5 Place the screen between the fan body and the panel. (Optional)
Step 7 Plug in the power, use the remote control to run the fan.
0504
GUARANTEE & AFTER-SALE
HG POWER has always abided by the quality policy of "first-class products,
satisfactory service, innovation for development, and integrity forging brand",
strictly in accordance with the management standards of the international quality
system and strict supervision to ensure that the quality of the products provided
fully meet the relevant standards and commitment.
(1) Technical Quality Assurance
Our company has advanced production and testing equipment and efficient
technical personnel of various professions, in the installation process, if you have
quality problems, we will promptly provide professional technical guidance and
warm sales service.
(2) Quality and Reputation Guarantee
Our company insists on serving users and being responsible for them to ensure
that the products supplied are perfect in-process and complete in testing means,
and that the technical properties of the products delivered are in line with the
relevant national standards to ensure that the production process level reaches
the most advanced manufacturing and assembly practices in China, and that the
products provided are brand-new and independent products.
(3) Sales Service Guarantee
We provide users with excellent after-sales consultation, set up a feedback
mailbox, and provide 24-hour service, such as: providing relevant technical
information, strengthening pre-sales, sales of various negotiation activities, as
well as after-sales service, the whole process of service to carry out in the entire
process of product manufacturing, installation, commissioning, maintenance.
(4) Quality Assurance of Required Raw Materials
For the raw materials required for the products, we will select those with good
quality and good reputation, and conduct necessary 'testing' on all raw materials
strictly according to the requirements of quality management system to ensure
that unqualified raw materials are not put into production.
After-sale Email Address: [email protected]
0706
Abnormal Phenomena
The remote
control cannot control
the exhaust fan.
The fan makes unusual
noises.
Causes of Malfunction
Battery installed
incorrectly.
Ensure the battery is
correctly installed.
Misplaced filter mesh.
Check if the filter mesh is
properly installed and
embedded in the exhaust
fan.
Foreign objects on the
outer surface of the fan
blades.
Inspect the internal part of
the exhaust fan for any
foreign objects or large
dust particles. Regularly
clean and maintain the fan
to prevent this.
Matching issue.
Reset the matching
process by following these
steps:
Disconnect the power, wait
for about 60 seconds, then
reconnect the power.
Immediately press and
hold the "OFF" button on
the remote control for 10
seconds to successfully
reset the matching. You
should now be able to
control the exhaust fan
with the remote.
Solutions
The fan does not work.
Poor power cord
connection.
Check the connection
between the plug and
socket to ensure it is
secure.
Voltage mismatch.
Check if the power supply
voltage matches the
requirements.
Foreign object inside the
fan blades.
Turn off the power,
manually rotate the fan
blades to check for any
jamming or excessive
friction. If there is an issue,
use tools to remove the fan
blades and check for any
foreign objects inside.
TROUBLESHOOTING
