Operator's Manual
10/16/24
EaziClean™, Premium, and
CanMaster™ Can Openers
Thank you for purchasing this Vollrath® product! Save this manual
for reference and the packaging in case shipping is necessary.
SAFETY PRECAUTIONS
To help ensure safe use, please read and fully understand this
manual and all safety messages before operation!
WARNING
Warning indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
CAUTION
Caution indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE: addresses practices not related to physical injury.
To reduce risk of injury or damage to the unit
• Before each use, inspect the unit to ensure it is clean.
• Ensure blade is fastened and not nicked; replace as necessary.
• Operate in non-public areas, away from children.
• Only operate if opener is functioning properly and undamaged.
FUNCTION AND PURPOSE
These openers are designed to easily pierce and safely open
cans; they are not intended for household or laboratory use.
UNPACKING THE UNIT
1. Remove all packing material and tape, as well as any
protective plastic; dispose of in an environmentally
responsible way when no longer needed.
2. Clean any glue residue left over from the plastic or tape.
Item Model Bar
Length
in. (cm)
Material Replacement Item #
Blades Gear &
Size
in. (cm)
Cartridge
BCO-2000
EaziClean™
16 (40.6)
Medium-
Duty,
Zammac
Alloy
BCO-11
(red knob)
355783-1
(black
knob)
BCO-12
1 (2.5)
BCO-15
(red
knob)
BCO-18
(black
knob)
BCO-3000
25
(63.5)
BCO-5000 16 (40.6)
Heavy-
Duty,
Stainless
Steel
BCO-10
1½ (3.8)
BCO-14
(red
knob)
BCO-19
(black
knob)
BCO-6000
25
(63.5)
BCO-7000
Titan,
Stainless
Steel
BCO-1 Premium
16 (40.6)
Medium-
Duty
Aluminum
Alloy
BCO-12
1 (2.5)
BCO-
0001 (red
knob)
BCO-13
(black
knob)
BCO-4 CanMaster™
BCO-10
1½ (3.8)
BCO-
0002 (red
knob)
BCO-17
(black
knob)
Accessory Description
4425 Manual Food Processor Blade-Cleaning Brush
NOTICE: Maximum can height for 16" (40.6 cm) bar length is
14" (35.6 cm), and 22" (55.9 cm) for a 25" (63.5 cm) bar.
BCO 5000
BCO 6000
BCO-7000
BCO-4
BCO-1
BCO 2000
BCO 3000
Can Openers could have a red or black knob.
2. Using a swift downward movement, punch blade into can lid.
3. Lower handle so it forms a 90® angle with the Bar.
4. Rotate the handle clockwise.
5. Raise handle so it is in line with the bar.
BASE INSTALLATION
Fixed Location
1. Choose a convenient location with a firm work surface.
2. Using a flathead screwdriver, mount the platform base
using the included hardware as shown below.
NOTICE: Using a spacer plate underneath is suggested
if the work surface is thin. This prevents surface flexing,
which could cause the can to spill during opening.
Variable Location (not permanently mounted to a countertop)
1. Install the clamp attachment to the platform base.
2. Tighten clamp to secure the platform base to countertop.
BEFORE FIRST USE
1. Keeping sharp edges away from you, carefully wash all
components in warm, soapy water and rinse thoroughly
WARNING
Sharp Blade Hazard.
To avoid injury, handle with caution.
OPERATION
1. Place the Bar into the Base.
2. Lift handle all the way up. Place can against the bar.
2
EaziClean™, Premium, and CanMaster™ Can Openers
6. Lift up on the handle to release the blade from the can.
7. Carefully move the can away from the opener.
CLEANING
WARNING
Sharp Blade Hazard.
To avoid injury, handle with caution.
NOTICE: Clean unit after every use to extend service life,
maintain appearance, and avoid blade corrosion from food
acids. Hand-wash only; dishwasher detergent and other
alkaline chemicals can damage the unit.
1. Using hot water and a bristle brush, thoroughly rinse or spray
o the can opener.
2. Remove the blade cartridge.
3. Inspect the blade to ensure it is in good condition.
4. If the blade is nicked or damaged, replace it as follows.
REPLACING THE BLADE
WARNING
Sharp Blade Hazard.
To avoid injury, handle with caution.
1. Wash the new blade in hot, soapy water; rinse thoroughly.
2. Remove the blade cartridge; see the Cleaning section.
3. Loosen the cartridge screws and remove the blade.
3
EaziClean™, Premium, and CanMaster™ Can Openers
EaziClean™
Premium and CanMaster™
3. Discard the old blade and Insert the new blade.
4. Tighten the screws and re-insert the blade cartridge.
REPLACING THE GEAR
NOTICE: Your unit could have a red or black knob; both have
the same cleaning, gear replacement, and blade replacement
instructions.
1. Remove the blade cartridge; see the Cleaning section.
2. Use a tool such as a screwdriver to hold the old gear in place
while turning the handle assembly counterclockwise.
3. Once the gear is unscrewed, remove the handle and gear
and also the collar on the EasiClean® opener.
4. Discard the old gear.
5. Install the new gear: EaziClean—insert collar into the body
and align the grooves, then insert the handle.
Premium and CanMaster—insert the handle so the notch is
available to receive the blade cartridge.
6. Slide the gear into position with letters face down.
7. For EaziClean, hold the gear in place with a screwdriver or
other tool (unnecessary for Premium or CanMaster models.)
8. Lower the handle and rotate the opener clockwise until tight.
9. Remove the tool if present and insert the blade cartridge.
Notch
Thumb
Screws
Blade
Screws
Blade
Premium & CanMaster™
EaziClean™
Slide the gear into position with the chamfer facing down.
TROUBLESHOOTING
Problem Potential Cause Course of Action
Can does not rotate Ring gear is worn. Replace the ring gear.
Lids do not cut cleanly. Blade is damaged or worn. Replace the blade.
Blade cartridge does not fit into the body (Premium/CanMaster only).
Black plastic sleeve rotated after
cartridge was removed.
Rotate the sleeve until the cartridge slides into the body.
SERVICE AND REPAIR
Serviceable parts are available on vollrathfoodservice.com.
To avoid serious injury or damage, never attempt to repair the unit or replace a damaged power cord yourself. Do not send units
directly to The Vollrath Company LLC. Please contact Vollrath Technical Services for instructions.
When contacting Vollrath Technical Services, please be ready with item number, model number (if applicable), serial number, and
proof of purchase showing the date the unit was purchased.
