4 TON BOTTLE JACK
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
ITEM: 50001
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: 909.628.4900 MON-FRI 9AM TO 3PM PST
1
IMPORTANT SAFETY INFORMATION
GENERAL SAFETY WARNINGS
To maintain the Jack and User Safety, the responsibility of the owner is to read and follow these instructions.
Follow all installation and operation instructions. Inspect the jack for proper operation and function. Read
and follow the safety instructions. Keep Instructions readily available for equipment operators. Make
certain all equipment operators are properly trained, understand how to safely and correctly operate
the unit, and are properly trained. Allow unit operation only with all parts in place and operating safely.
Use only genuine replacement parts. Service and maintain the unit only with authorized or approved
replacement parts negligence will make the jack unsafe for use. Carefully inspect the unit on a regular
basis and perform all maintenance as required. Store these instructions in the handle of your jack. Keep
all decals on the unit clean and visible.
Always use Jack Stands! DO NOT USE wood blocks or any other non-approved load sustaining devices.
The manufacturer only permits loads to be sustained by jack stands that meet current ASME standards.
DO NOT USE wood blocks or any other non-approved lift ing device in addition for a means of lifting with
the jack and or load being raised. Failure to head these warnings may cause injury or death.
Position the Jack. Position the jack to only lift on the areas of the vehicle as specified by the vehicle
manufacturer.
Always Use Support Stands. After lifting the vehicle always support the load with appropriately rated
vehicle supports stands before working on the vehicle.
Do Not Overload Jack. Do not overload this jack beyond its rated capacity. Overloading this jack beyond
its rated capacity can cause damage to or failure of the jack.
Always Use on Hard Level Surfaces. This jack is designed only for use on hard level surfaces capable
of sustaining the load. Use on unstable or other capable of sustaining the load. Use on unstable or other
possible loss of load.
Center Load on Jack Saddle. Center load on jack saddle before lifting vehicle. Off-center loads and
loads lifted when the jack is not level can cause loss of load or damage to the jack.
Do not raise or lower the vehicle unless tools, materials and people are clear. Clean up grease and
oil spills immediately. When the lift is being lowered, make sure everyone is standing at least six feet
away. Be sure there are no tools or equipment, left under the jack before lowering.
Always lower the jack slowly. DO NOT USE THE JACK TO SUPPORT OR STABILIZE A LOAD.
Using the jack to support or stabilize a load may result in unexpected movement and result in serious
injury, being crushed and death. Always securely chock and block (stabilize) the load to be lifted. Never
place any part of the body under a raised load without properly chocking and supporting the load.
Never use the jack on curved or tubular vehicle bumpers. This will result in the vehicle slipping
off the jack and falling, causing serious injury or death. Use a Bumper Lift to lift most vehicles with
curved bumpers or plastic bumpers.
Wear ANSI-approved safety glasses and heavy duty work gloves during use.
Do not adjust the safety valve.
Do not move or dolly vehicle while jack is in use.
Stay alert. Use caution and common sense when operating jack. Do not use a jack when tired,
incoherent, dizzy, under the use or drugs or alcohol.
2
IMPORTANT SAFETY INFORMATION
Spectators: Do not allow bystanders around the jack or under the load supported only by the jack.
Do not allow anyone in the vehicle while the jack is in use. Keep allspectators away from vehicle when in
use.
Inspection: Inspect the jack carefully before each use. Ensure the jack is not damaged, excessively worn,
or missing parts. Do not use the jack unless it is properly lubricated. Using a jack that is not in good clean
working condition or properly lubricated may cause serious injury.
• Do not modify the jack in any way.
Unauthorized modication may impair the function and/or safety and could affect the life of the equipment.
There are specic applications for which the jack was designed.
• Always check for damaged or worn out parts before using the jack. Broken parts will affect the
equipment operation. Replace or repair damaged or worn parts immediately.
• When jack is not in use, store it in a secure place out of the reach of children. Inspect it for good
working condition prior to storage and before re-use.
Chock and Block (Stabilize): Apply parking brake in vehicle before
operating jack.
- A chock is a wedge for steadying an object and holding it motionless, or for preventing the movement of
a wheel. Chock the wheel opposite the end being lifted.
- When you block a load, you secure and support a load that is being lifted. The block(s) or stabilizer(s)
should have a weight capacity that is greater than the weight of the load which is being lifted.
SAVE THESE WARNINGS
3
OPERATION
1. Before operating, estimate the weight of the load. Do not overload the jack beyond its rated load.
5. Lower the ram by turning the release valve. Counter-clockwise with the notched end slacken it slowly
when a load is applied or accidents can occur.
2. Select the point of action according to the gravitational center place the jack on the ground of necessary.
Place a hard plank under the jack so to avoid tottering or falling during operation.
3. Before operating the jacks, rst insert the notched end of the handle into the release valve. Turn the
operating handle clockwise until the release valve is closed. Do not over tighte the valve.
4. Insert the operating handle into the socket and the ram is steadily raised by the up and down movement
of the handle and the load is raised. The ram will stop rising when the required height is reached.
6. When more than one jack is used at the same time it is important to operate the jacks at an equal speed
with equal loads. Otherwise there is a danger of falling.
7. At an ambient temperature from 24F to 113F use machine oil at an abient temperature from 4F to 27F use
sybthetic spindle oil. Synthetic ltered hydrauloc oil should ne maitained in the jacks. Otherwise, the rated
height cannot be reached.
8. Avoid violent shocks during operation.
4
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available individually
as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
DISCLAIMER
PRODUCT MADE IN CHINA
