CHECK FOR CONCEALED DAMAGE
FILE CLAIM WITH DELIVERING FREIGHT CARRIER
Replacement Instructions For
SU-P-208
High Limit Switch
Hauppauge, New York 11788
©ADVANCE TABCO JUNE 2022
For Further Assistance
Contact Customer Service at:
800-645-3166
or
Units Prior To 2022
STEP 1:
Unplug or turn off the breaker powering the unit.
Disconnect the wiring from existing High Limit Switch.
STEP 2:
Connect the wiring to the new High Limit Switch. Using the
#10 sheet metal screws, install the mounting to the element
pan as shown.
Units Built January - May 1, 2022
TOOLS REQUIRED: Philips Head Screw Driver
Existing
Limit
Switch
New
Limit Switch
Existing
Limit
Switch
