2 SOLAR LED
POST
CAP LIGHTS
70240
®
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the back
of the manual near the assembly diagram (or month and year of purchase if product has no number). Keep
this manual and the receipt in a safe and dry place for future reference. 24d
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright
©
2023 by Harbor Freight Tools
®
. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 For technical questions, please call 1-888-866-5797. Item 70240
Specifications
Bulb Type SMD LED
Battery Type 500mAh Li-Ion
Fits Square
Post Sizes
3-5/8" x 3-5/8" • 4" x 4"
4-1/2" x 4-1/2" • 5" x 5"
Important Safety Information
1. THIS IS NOT A TOY; FOR
DECORATION ONLY.
2. DO NOT APPLY PRESSURE TO
LENS WHEN INSTALLING.
3. ENSURE SOLAR LIGHT IS
SECURELY ATTACHED TO
THE POST PRIOR TO USE;
FOR OUTDOOR USE ONLY.
4. LENS CAN BREAK, USE CAUTION,
WATCH FOR SHARP PIECES.
5. Assemble only according to these
instructions. Improper assembly
can create hazards.
6. Wear ANSI-approved
safety goggles during setup.
7. Keep assembly area clean and well lit.
8. Keep bystanders out of the
area during assembly.
9. Do not assemble when tired
or when under the influence
of drugs or medication.
10. Position battery in proper polarity.
11. This product is not a toy. Do not allow
children to play with or near this item.
12. Use as intended only.
13. Inspect before every use; do not
use if parts are loose or damaged,
or if sharp edges are exposed.
This is fragile and sharp edges may be
exposed if weathered or damaged.
14. Maintain product labels and nameplates.
These carry important safety
information. If unreadable or missing,
contact Harbor Freight Tools
for a replacement.
15. Contains Li-Ion battery. Battery must
be recycled or disposed of properly.
Do not open, crush or incinerate.
Setup Instructions
1. Decide where you want to place the
Solar Light. Choose a location that
receives full, direct sunlight a minimum
of 8 hours a day. The location should
not be near nighttime light sources such
as porch lights or streetlights as this will
cause the Solar Light to remain off.
2. Remove protective film from
product. Allow Lamp to charge for
at least 24 hours before first use.
3. Set Power Switch to “ON” Position.
4. Attach Lens to Light Cap. Pieces
should snap into place.
Lens
Light Cap
Page 3For technical questions, please call 1-888-866-5797.Item 70240
5. Select Lamp Base that matches post
size. Use Method A or B to attach
Lamp Base to Post using Screws.
Screw
Screw
Lamp Base
Method A
Method B
Screw
6. Place Lamp on secured Lamp Base so
that holes in the bottom of Lens align
with the raised pieces of the Lamp Base.
Lens
Lamp
Base
7. Rotate Lamp counterclockwise
to secure to Lamp Base.
Operating Instructions
Note: During the day, the Solar Light
converts sunlight into electricity, recharging
the battery. The amount of light the
Solar Light receives depends on placement
of the Solar Light, geographic location and
weather. If the weather is cloudy and the light
does not receive a full charge, the Solar Light
may not achieve the full run time. It will
catch up after two to three days of full sun.
1. After a full 8 hours of sunlight charging,
the Solar Light will automatically turn
ON during the night.
2. After initial charge is set, confirm that
Solar Light is on by viewing it at night
or in a dark location. If not lit, check
that Solar Light has had full sunlight for
8 hours.
Maintenance
1. Clean regularly with a damp towel.
Do not clean with solvent.
Do not put too much pressure
on the Solar Light or accessories
while cleaning. Dry thoroughly.
2. BEFORE EACH USE, inspect the
general condition of the light. Check for:
• leaking, swollen, or cracked battery
• loose hardware
• misalignment or binding of parts
• cracked or broken parts
• any other condition that may
affect its safe operation.
3. AFTER USE, wipe external surfaces
of the light with clean cloth.
4. Replace battery every 12 months:
a. Remove the Light Cap from the Lens.
b. Open the battery cover on the
bottom of the Solar Light housing.
c. Remove the old battery.
d. Install new Li-Ion battery into Battery
Compartment. Check that battery is
placed according to correct polarity.
e. Close the Battery Cover
and reinstall Light Cap.
5. Contains Li-Ion battery. Battery must
be recycled or disposed of properly.
Do not open, crush or incinerate.
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence
or accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation
charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection verifies the defect, we will either repair or replace
the product at our election or we may elect to refund the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at our expense,
but if we determine there is no defect, or that the defect resulted from causes not within
the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Replacement parts are not available for this item. Reference UPC 193175493842.
Troubleshooting
Problem Possible Causes Probable Solutions
Light will
not turn on
1. Battery not allowed time for
recharging via Solar Light.
2. Solar Light is set near nighttime
light sources such as porch
lights or street lights.
3. Solar Light is dirty and
covered with dirt or dust.
1. Check that Solar Light has
direct access to sunlight for
enough hours a day.
2. Move Solar Light.
3. Clean Solar Light with a soft cloth.
®
